AJDK131WIRELESS CHARGING CRADLE

T-MF-CAD-908A 185mm 105mm SDA-SC600 WIRELESS CHARGING CRADLE SUPPORT DE RECHARGE SANS FIL SOPORTE DE CARGAR INALÁMBRICO Owner's Manual Manuel d'utilisation Manual del propietario English Specifications Model : SDA-SC600 Charging : Wireless Charging / Qi2 Compatible Cooling Fan : Supported Indicator light : Multicolor Input : 5 V / 2 A , 9 V / 2.2 A , 12 V / 2 A Output : 5 W / 7.5 W / 10 W / 15 W Dimensions : 3.58 inches x 2.64 inches x 1.38 inches ( 91 mm x 67 mm x 35 mm ) Weight : 2.57 ± 2 ounce ( 73 g ± 2 g ) Operating Temperature : 14 °F to 113 °F ( -10 °C to 45 °C ) Product storage temperature : -4 °F to 185 °F ( -20 °C to 80 °C) Charging Frequency : 115 kHz - 205 kHz : -2.3 dBμA/m ( @ 10 m ) 355 kHz - 365 kHz : -8.3 dBμA/m ( @ 10 m ) Induction Distance : 0.16 inches or less ( 4 mm or less ) Magnetic Force : 3.5 lbs ( 1.6 kg ) Product Layout Ⓐ Wireless Charging Area Ⓑ Indicator light Ⓒ USB port ( USB Type-C® ) Ⓓ Touch Key Ⓔ Cooling fan Ⓕ Screw Cap Package Contents • Wireless charging cradle x 1 • Air vent mount x １ • USB cable x 1 • Metal Ring Phone Sticker ( Steel ) x 1 • Installation paper x 1 • Cleaning wipe x 1 • Owner's Manual x 1 How to Use ① Loosen the screw ② Attach the part ③ Tighten the screw ④ Adjust the angle of the part / Securely fasten the part ⑤ Attach Adjust the position of the cradle and mounting components to align with the air vent blades. Also, connect the included USB cable to the device's USB port and to the car's USB port or an optional car charger. Compatible with most vehicle air vents, allowing secure one-touch attachment to the blades. Silicone contact points provide a firm fit and protect the surface from scratches. Please note that some air vent blade designs may not be supported. How to Set Indicator light Colors and Operation • Double-tap the touch key on the back of the device to cycle through color settings in the following order : Rainbow → Green → Blue → Yellow → Purple. • Press and hold the touch key on the back of the device for 2 seconds to turn the indicator light ON / OFF. • While charging, press and hold the touch key on the back of the device for 2 seconds to toggle the fan ON / OFF. Operating Conditions • Startup : The indicator light up, and the fan rotates for about 10 seconds before stopping. • Standby : The indicator light remains lit. • Charging : The indicator light turns off, and the fan operates. • Fully Charged : The fan stops. • Foreign Object Detection : The indicator light flashes red for 5 seconds, then turns off. Warning Be sure to read all warnings in the Owner's manual, handle with care during use, and follow all safety guidelines. • Do not use this appliance in areas of excess moisture or close to water. • Do not expose this appliance to rain or excessive moisture. • This product contains magnets. Keep away from credit cards and other magnetic storage media. Avoid placing the product near sensitive electronic devices or precision instruments to prevent potential interference or damage. • The wireless charging function is available only for compatible devices. • Metal cases or thick cases may prevent charging. • If you are using a protective case on your smartphone, the magnetic force between the magnetic holder and the smartphone may be weakened. For optimal performance, attach the included metal ring. • Ensure that the installation position and method comply with the vehicle's safety standards and do not obstruct the driver's view. Also, refrain from operating the smartphone while driving. • Avoid leaving the product in high temperatures or under direct sunlight for extended periods. • This appliance is not intended for use by individuals ( including children ) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. • Do not disassemble or try to repair this appliance yourself. You might get injured or this appliance may be damaged. • Do not operate this appliance if it has been subjected to shock or damage. Please use a commercially available cord holder to secure cords. It will interfere with driving operation if the cord getting wrapped around the steering wheel, selector lever or brake pedal, that may result in an accident or injury. There is also a risk of it getting wrapped around the neck of an infant. Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the product, and to protect it from overheating. To prevent fire hazard, the openings should never be blocked or covered with items ( such as papers, floor mat, cloths ). The graphical symbol placed on the product means direct current. Trademark USB Type-C® and USB-C® are registered trademarks of USB Implementers Forum. The Qi2 logo is a trademark of the Wireless Power Consortium. French Caractéristiques techniques Modèle : SDA-SC600 Charge : Charge sans fil / Compatible Qi2 Ventilateur de refroidissement : Supporté Voyant indicateur : Multicolore Entrée : 5 V / 2 A , 9 V / 2,2 A , 12 V / 2 A Sortie : 5 W / 7,5 W / 10 W / 15 W Dimensions : 3,58 pouces x 2,64 pouces x 1,38 pouce ( 91 mm x 67 mm x 35 mm ) Poids : 2,57 ± 2 onces ( 73 g ± 2 g ) Température de fonctionnement : 14 °F à 113 °F ( -10 °C à 45 °C ) Température de stockage du produit : -4 °F à 185 °F ( -20 °C à 80 °C ) Fréquence de charge : 115 kHz - 205 kHz : -2,3 dBμA/m ( @ 10 m ) 355 kHz - 365 kHz : -8,3 dBμA/m ( @ 10 m ) Distance d'admission : 0,16 pouce ou moins ( 4 mm ou moins ) Force magnétique : 3,5 lb ( 1,6 kg ) Disposition du produit Ⓐ Zone de recharge sans fil Ⓑ Voyant indicateur Ⓒ Port USB ( USB Type-C® ) Ⓓ Toucher Ⓔ Ventilateur de refroidissement Ⓕ Bouchon à vis Contenu du colis • Support de recharge sans Fil x 1 • Affût d'aérationx1 • Câble USB x1 • Autocollant de téléphone Metal Ring ( Acier ) x 1 • Papier d'installation x 1 • Lingette nettoyante x 1 • Manuel d'utilisation x 1 ① Desserrer la …

Text truncated - open the document above for the full version.

Rev 1/26/2023 Pioneer Corporation Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jan. 15, 2026 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: AJDK131 [Pioneer Corporation] certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Pioneer Corporation] certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) (Applicant printed name) Daisuke Sakata Rev 1/26/2023 Pioneer Corporation Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jan. 15, 2026 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: AJDK131 [Pioneer Corporation] certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Daisuke Sakata

1/1 USAgentforServiceofProcessLETTEROFATTESTATION E-mail:daisuke TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USAgentforServiceofProcess: CompanyName:HOPEKCORPORATIONINC Address:16755CoyoteBushDrUnit84,SanDiego,CA92127UnitedStates FRN:0034562900 ContactName:PeterDavis TelephoneNo:561-235-6113 E-mail:[email protected] ThisletteristoconfirmthattheUSAgentforServiceofProcessacceptsresponsibilitytoactas alocalrepresentativeonbehalfofPioneerCorporation TheUSAgentforServiceofProcessisawareofandagreestocomplywiththerequirements outlinedintheFCCEquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause §2.911. Applicant: CompanyName:PioneerCorporation ProductDescription:WIRELESSCHARGINGCRADLE FRN:0030786412 GranteeCode:AJD FCCID:AJDK131 ContactName:DaisukeSakata Address:28-8,Honkomagome2-chome,Bunkyo-ku,Tokyo,113-0021Japan TelephoneNo:81-49-228-7636 [email protected] Applicant’sName: PioneerCorporation USAgentforServiceofProcess’sName: HOPEKCORPORATIONINC Title:ManagerTitle:Manager Signatur The Applicant is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. This Agreement is valid until (Permanently valid). Date: 2026/1/27 eSignature

Pioneer Corporation Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: January 20, 2026 Subject; Request for Confidentiality FCC ID: AJDK131 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Daisuke Sakata Title: Manager

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Pioneer Corporation Date: Jan. 15, 2026 Product Model Number: SDA-SC600 FCC ID: AJDK131 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following:  Testing  Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: 81-49-228-7636 On behalf of: Pioneer Corporation

Page1of 5 产品规格书 PRODUCT SPECIFICATION 客 户： CUSTOMER:____________________________________________________________________ 客户料号： CUST P/N:____________________________________________________________________ 德弗力料号： K C P/N:____________________________________________________________________ 产品઻号： 20.5 39 33 0.08mm 80P 11TS D E S E : 日 期： 2024.12.24 D A T E :____________________________________________________________________ 版 本： A.0 VERSION :____________________________________________________________________ ACCEPTANCE STAMP PREPARED BY Zeng xiaoxian Address: No. 107, Xinfeng West Road, Shige Town, Dongguan City Tel：86-076986016320 Http://www.hartai.com Fax：86-076986372427 MERCHANDISER ENGINEER CHECKED BY APPROVED BY Qiu zhihui ZLGD Dongguan city DFL Electronic Technology Co.,LTD ZLGD-Y20.5 39-33-FR ZLGD-0447 Rev. A.0 Before Change -- DESCRIPTION(Content Or Reason ForChanged) Initial Release DateRevisor 2024/12/24 Zeng xiaoxian PREPARED BY ENGINEER CHECKED BY Version Change History Dongguan city DFL Electronic Technology Co.,LTD CUST P/N DFL P/N Page2of 5 ZLGD-Y20.5*39-50-FR ZLGD-0385 Zeng xiaoxian Qiu zhihui 1.OVERALL DIMENSIONS OF PRODUCTS: 2.Unit: mm A 42.5±0.5 J B 39±1.0 K C D 20.5±0.5 LM E N1/N2 F O G P HI PREPARED BY ENGINEER CHECKED BY Dongguan city DFL Electronic Technology Co.,LTD CUST P/N DFL P/N Specification 20±0.5 Page3of 5 33±2.0 3±2 1±0.2 47±1 A B D E F G H C 0.8±0.2 I ZLGD-Y20.5 39-33-FR ZLGD-0447 Zeng xiaoxian Qiu zhihui Turns 11TS Wire Dia. 0.08MM 80P （Silk-Covered Wire） Wdg. Type Spred/Close Close） Wdg.Direction Intersect Yes/Not Yes Coil Positive/Anti Paste 2.电气特性（ELECTRICAL CHARACTERISTICS): 温度 TEMPERATURE:25±10°C,湿度 RELATIVE HUMIDITY:65±10% NO. 1 2 3 ITEM IND DCR TERMINAL S-F S-F Q 值 S-F SPECIFICATION 电感：7.9uH±0.3 阻值： Q 值：8.5以上 TEST FREQUENCY 100kHz/V 100kHz/V 100kHz/V TEST EQUIPMENTS PREPARED BYENGINEER CHECKED BY Specification Dongguan city DFL Electronic Technology Co.,LTD CUST P/N DFL P/N SHDA 1062 SHDA 1062 SHDA 1062 Page4of 5 （Anticlockwise） （Anti/-Paste） ZLGD-Y20.5 39-33-FR ZLGD- Zeng xiaoxian Qiu zhihui 3. BILL OF MATERIAIS: NO. Material name 1wire rod 2 magnetic sheet 3 black film 4 double faced adhesive tape 5 tin bar 6 Gold Finger Adhesive Tape 7glue Description 0.08MM x 80P Hot Air Line Lead-free solder wire Material Code 无铅高温锡条 Vendor code RS ZH / / YX / PREPARED BY ENGINEER CHECKED BY Dongguan city DFL Electronic Technology Co.,LTD CUST P/N DFL P/N Specification / / / / Page5of 5 / / G42.5 - 0.8MM thick perforated non-magnetic sheet + 20 magnetic sheet Adhesive tape 42 with no holes and ear holes (opening length 13mm, width 11mm) inner hole 8MM with ears 5mm wide Universal Glue + 816 Silicone ZLGD-Y20.5 39-33-FR ZLGD-0447 Black film 42 - an unusual shape with no holes and no ears 8 heat shrink tubing 1 28 MMheat shrink tubing Zeng xiaoxian Qiu zhihui

Ext Photos Model: SDA-SC600 Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

Int Photos Model: SDA-SC600 Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 ANT Photo 9 Photo 10

- Page 1 of 11 - Report No.: HB20251231005E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com RF EXPOSURE Test Report Product: WIRELESS CHARGING CRADLE Trade Mark: Pioneer Model Number: SDA-SC600 FCC ID: AJDK131 Prepared for Pioneer Corporation 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo, 113-0021 Japan Prepared by Shenzhen HongBiao Certification& Testing Co., Ltd Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen, China Tel.: +86-755-2998 9321 Fax.: +86-755-2998 5110 Website: http://www.sz-hongbiao.com - Page 2 of 11 - Report No.: HB20251231005E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Table of Contents 1 GENERAL DESCRIPTION ................................................................................................................................... 5 1.1 DESCRIPTION OF EUT ................................................................................................................................................ 5 1.2 TEST MODE .............................................................................................................................................................. 5 1.3 TEST SETUP .............................................................................................................................................................. 5 1.4 ANCILLARY EQUIPMENT .............................................................................................................................................. 5 2 TEST FACILITIES AND ACCREDITATIONS ............................................................................................................ 6 2.1 TEST LABORATORY ..................................................................................................................................................... 6 2.2 ENVIRONMENTAL CONDITIONS ..................................................................................................................................... 6 2.3 MEASUREMENT UNCERTAINTY ..................................................................................................................................... 6 2.4 TEST SOFTWARE ........................................................................................................................................................ 6 3 LIST OF TEST EQUIPMENT ................................................................................................................................ 7 4 RF EXPOSURE .................................................................................................................................................. 8 4.1 MAXIMUM PERMISSIBLE EXPOSURE .............................................................................................................................. 8 4.1.1. Limit ............................................................................................................................................................ 8 4.1.2. Test Procedures ........................................................................................................................................... 8 4.1.3. Test Setup .................................................................................................................................................... 8 4.1.4. Test Result ................................................................................................................................................... 8 5 PHOTOGRAPHS OF THE TEST SETUP............................................................................................................... 11 - Page 3 of 11 - Report No.: HB20251231005E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com TEST RESULT CERTIFICATION Applicant’s Name ................. : Pioneer Corporation Address ................................. : 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo, 113-0021 Japan Manufacturer's Name .......... : Pioneer Corporation Address ................................. : 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo, 113-0021 Japan Product description Product name ........................ : WIRELESS CHARGING CRADLE Model Number ....................... : SDA-SC600 Standards ............................. : FCC CFR 47 PART 1 , 1.1310 Test procedure ....................... : KDB 680106 D01 Wireless Power Transfer v04 This device described above has been tested by Shenzhen HongBiao Certification& Testing Co., Ltd and the test results show that the equipment under test (EUT) is in compliance with the EMC requirements. And it is applicable only to the tested sample identified in the report. Date of Test ............................................ : Date (s) of performance of tests ............. : Dec. 31, 2025~Jan. 14, 2026 Test Result ............................................... : Pass Testing Engineer : (Zoe Su) Technical Manager : (Ming Liu) Authorized Signatory : (L e o S u) - Page 4 of 11 - Report No.: HB20251231005E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Revision History Revised No. Date of Issue Description 01 Jan. 14, 2026 Original - Page 5 of 11 - Report No.: HB20251231005E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street…

Text truncated - open the document above for the full version.

- Page 1 of 33 - Report No.: HB20251231005E-01 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Test Report Product: WIRELESS CHARGING CRADLE Trade Mark: Pioneer Model Number: SDA-SC600 FCC ID: AJDK131 Prepared for Pioneer Corporation 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo, 113-0021 Japan Prepared by Shenzhen HongBiao Certification& Testing Co., Ltd Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen, China Tel.: +86-755-2998 9321 Fax.: +86-755-2998 5110 Website: http://www.sz-hongbiao.com - Page 2 of 33 - Report No.: HB20251231005E-01 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Table of Contents 1 GENERAL DESCRIPTION ................................................................................................................................... 5 1.1 DESCRIPTION OF EUT ................................................................................................................................................ 5 1.2 TEST MODE .............................................................................................................................................................. 5 1.3 TEST SETUP .............................................................................................................................................................. 5 1.4 POWER SETTING CONFIGURATION PARAMETERS ............................................................................................................... 6 1.5 ANCILLARY EQUIPMENT .............................................................................................................................................. 6 2 SUMMARY OF TEST RESULT ............................................................................................................................. 7 3 TEST FACILITIES AND ACCREDITATIONS ............................................................................................................ 8 3.1 TEST LABORATORY ..................................................................................................................................................... 8 3.2 ENVIRONMENTAL CONDITIONS ..................................................................................................................................... 8 3.3 MEASUREMENT UNCERTAINTY ..................................................................................................................................... 8 3.4 TEST SOFTWARE ........................................................................................................................................................ 8 4 LIST OF TEST EQUIPMENT .............................................................................................................................. 10 5 TEST ITEM AND RESULTS ............................................................................................................................... 12 5.1 ANTENNA REQUIREMENT .......................................................................................................................................... 12 5.2 CONDUCTED EMISSION ............................................................................................................................................. 13 5.3 RADIATED EMISSION ................................................................................................................................................ 17 5.4 OCCUPIED BANDWIDTH ............................................................................................................................................ 22 6 PHOTOGRAPHS OF THE TEST SETUP............................................................................................................... 24 7 PHOTOGRAPHS OF THE EUT .......................................................................................................................... 26 - Page 3 of 33 - Report No.: HB20251231005E-01 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com TEST RESULT CERTIFICATION Applicant’s Name ................. : Pioneer Corporation Address ................................. : 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo, 113-0021 Japan Manufacturer's Name .......... : Pioneer Corporation Address ................................. : 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo, 113-0021 Japan Product description Product name ........................ : WIRELESS CHARGING CRADLE Model Number ....................... : SDA-SC600 Standards ............................. : FCC Part 15C Test procedure ....................... : IEEE/ANSI C63.10-2020 This device described above has been tested by Shenzhen HongBiao Certification& Testing Co., Ltd and the test results show that the equipment under test (EUT) is in compliance with the EMC requirements. And it is applicable only to the tested sample identified in the report. Date of Test ............................................ : Date (s) of performance of tests ............. : Dec. 31, 2025~Jan. 14, 2026 Test Result ............................................... : Pass Testing Engineer : (Zoe Su) Technical Manager : (M i n g Liu) Authorized Signatory : (L e o S u) - Page 4 of 33 - Report No.: HB20251231005E-01 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.co…

Text truncated - open the document above for the full version.

Photographs of the Test Setup Model: SDA-SC600 Radiated Emission Below 30MHz Radiated Emission Above 30MHz Conducted emission MPE
