AJDK132WIRELESS CHARGING CRADLE

T-MF-CAD-906A 185mm 105mm Español Especificaciones Modelo: SDA-SC400 Carga : Carga inalámbrica / Compatible con Qi2 Luz indicadora : Azul Entrada : 5 V / 3 A , 9 V / 3 A , 12 V / 2.5 A Salida : 5 W / 7.5 W / 10 W / 15 W Dimensiones : 2.52 pulgadas x 2.52 pulgadas x 1.26 pulgadas ( 64 mm x 64 mm x 32 mm ) Peso : 2.05 ± 2 onzas ( 58 g ± 2 g ) Temperatura de funcionamiento : 14 °F a 113 °F ( -10 °C a 45 °C ) Temperatura de almacenamiento del producto : -4 °F a 185 °F ( -20 °C a 80 °C ) Frecuencia de carga : 115 kHz - 205 kHz : -7.32 dBμA/m ( @ 10 m ) 355 kHz - 365 kHz : -13.21 dBμA/m ( @ 10 m ) Distancia de inducción : 0.16 pulgadas o menos ( 4 mm o menos ) Fuerza magnética : 3.5 libras ( 1.6 kg ) Contenido del Paquete • Soporte de cargar inalámbrico x 1 • Soporte para Rejilla de Aire x 1 • Cable USB x 1 • Adhesivo de Anillo Metálico para Teléfono ( Acero ) x 1 • Hoja de Instalación x 1 • Toallita de Limpieza x 1 • Manual del propietario x 1 Diseño del Producto Ⓐ Área de Carga Inalámbrica Ⓑ Luz Indicadora Ⓒ Puerto USB ( USB Type-C® ) Ⓓ Tapa de Tornillo Cómo Usar ① Afloje el tornillo ② Coloque la pieza ③ Apriete el tornillo ④ Ajuste el ángulo de la pieza / Asegure firmemente la pieza ⑤ Coloque Ajuste la posición de la base y los componentes de montaje para alinearlos con las rejillas de ventilación del aire. Además, conecte el cable USB incluido al puerto USB del dispositivo y al puerto USB del automóvil o a un cargador para automóvil opcional. Compatible con la mayoría de las rejillas de ventilación de vehículos, lo que permite una fijación segura con un solo toque a las láminas. Los puntos de contacto de silicona proporcionan un ajuste firme y protegen la superficie contra rayaduras. Tenga en cuenta que algunos diseños de láminas de rejilla de ventilación pueden no ser compatibles. Funcionamiento de la luz indicadora • Inicio / Espera : La luz indicadora permanece encendida. • Cargando : La luz indicadora parpadea lentamente. • Detección de objeto extraño : La luz indicadora parpadea durante 5 segundos y luego se apaga. Advertencia Asegúrese de leer todas las advertencias en el manual del propietario, manipule con cuidado durante el uso y siga todas las pautas de seguridad. • No utilice este aparato en áreas con exceso de humedad o cerca del agua. • No exponga este aparato a la lluvia ni a humedad excesiva. • Este producto contiene imanes. Manténgalo alejado de tarjetas de crédito y otros medios de almacenamiento magnético. Evite colocar el producto cerca de dispositivos electrónicos sensibles o instrumentos de precisión para prevenir posibles interferencias o daños. • La función de carga inalámbrica está disponible solo para dispositivos compatibles. • Las fundas metálicas o gruesas pueden impedir la carga. • Si utiliza una funda protectora en su smartphone, la fuerza magnética entre el soporte magnético y el smartphone puede debilitarse. Para un rendimiento óptimo, coloque el anillo metálico incluido. • Asegúrese de que la posición y el método de instalación cumplan con las normas de seguridad del vehículo y no obstruyan la vista del conductor. Además, evite operar el smartphone mientras conduce. • Evite dejar el producto en temperaturas altas o bajo luz solar directa durante períodos prolongados. • Este aparato no está destinado para uso por personas ( incluidos niños ) con capacidades físicas, sensoriales o mentales reducidas, o falta de experiencia y conocimiento, a menos que estén bajo supervisión o instrucción sobre el uso del aparato por una persona responsable de su seguridad. • No desarme ni intente reparar este aparato usted mismo. Podría lesionarse o dañar el aparato. • No opere este aparato si ha estado sometido a golpes o daños. Utilice un sujetacables disponible comercialmente para asegurar los cables. Puede interferir con la operación del vehículo si el cable se enreda alrededor del volante, la palanca selectora o el pedal de freno, lo que podría provocar un accidente o lesiones. También existe el riesgo de que se enrede alrededor del cuello de un bebé. Marca registrada USB Type-C® y USB-C® son marcas comerciales registradas de USB Implementers Forum. El logotipo Qi2 es una marca registrada del Wireless Power Consortium. English Specifications Model : SDA-SC400 Charging : Wireless Charging / Qi2 Compatible Indicator light : Blue Input : 5 V / 3 A , 9 V / 3 A , 12 V / 2.5 A Output : 5 W / 7.5 W / 10 W / 15 W Dimensions : 2.52 inches x 2.52 inches x 1.26 inches ( 64 mm x 64 mm x 32 mm ) Weight : 2.05 ± 2 ounce ( 58 g ± 2 g ) Operating Temperature : 14 °F to 113 °F ( -10 °C to 45 °C ) Product storage temperature : -4 °F to 185 °F ( -20 °C to 80 °C ) Charging Frequency : 115 kHz - 205 kHz : -7.32 dBμA/m ( @ 10 m ) 355 kHz - 365 kHz : -13.21 dBμA/m ( @ 10 m ) Induction Distance : 0.16 inches or less ( 4 mm or less ) Magnetic Force : 3.5 lbs ( 1.6 kg ) Package Contents • Wireless charging cradle x 1 • Air vent mount x 1 • USB cable x 1 • Metal Ring Phone Sticker(Steel) x 1 • Installation paper x 1 • Cleaning wipe x 1 • Owner's Manual x 1 Product Layout Ⓐ Wireless Charging Area Ⓑ Indicator light Ⓒ USB port ( USB Type-C® ) Ⓓ Screw Cap How to Use ① Loosen the screw ② Attach the part ③ Tighten the screw ④ Adjust the angle of the part / Securely fasten the part ⑤ Attach Adjust the position of the cradle and mounting components to align with the air vent blades. Also, connect the included USB cable to the device's USB port and to the car's USB port or an optional car charger. Compatible with most vehicle air vents, allowing secure one-touch attachment to the blades. Silicone contact points provide a firm fit and protect the surface from scratches. Please note that some air vent blade designs may not be supported. Indicator Light Operation • Startup / Standby : The indicator light remains steadily on. • Charging : The indicator light slowly flashes. • Foreign Object Detection : The indicator light flashes for 5 seconds, then turns off. Warning Be sure to read all warnings in the Owner's…

Text truncated - open the document above for the full version.

1/1 USAgentforServiceofProcessLETTEROFATTESTATION TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USAgentforServiceofProcess: CompanyName:HOPEKCORPORATIONINC Address:16755CoyoteBushDrUnit84,SanDiego,CA92127UnitedStates FRN:0034562900 ContactName:PeterDavis TelephoneNo:561-235-6113 E-mail:[email protected] ThisletteristoconfirmthattheUSAgentforServiceofProcessacceptsresponsibilitytoactas alocalrepresentativeonbehalfofPioneerCorporation TheUSAgentforServiceofProcessisawareofandagreestocomplywiththerequirements outlinedintheFCCEquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause §2.911. Applicant: CompanyName:PioneerCorporation ProductDescription:WIRELESSCHARGINGCRADLE FRN:0030786412 GranteeCode:AJD FCCID:AJDK132 ContactName:DaisukeSakata Address:28-8,Honkomagome2-chome,Bunkyo-ku,Tokyo,113-0021Japan TelephoneNo:81-49-228-7636 E-mail:[email protected] TheApplicantisawareofandagreestocomplywiththerequirementsoutlinedintheFCC EquipmentAuthorizationProgram,ReportandOrderFCC22-84,andclause§2.911. ThisAgreementisvaliduntil(Permanentlyvalid). Date:2026/1/27 Applicant’sName: PioneerCorporation USAgentforServiceofProcess’sName: HOPEKCORPORATIONINC Title:ManagerTitle:Manager SignatureSignature

Rev 1/26/2023 Pioneer Corporation Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jan. 20, 2026 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: AJDK132 [Pioneer Corporation] certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Pioneer Corporation] certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature) (Applicant printed name) Daisuke Sakata Rev 1/26/2023 Pioneer Corporation Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Jan. 20, 2026 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: AJDK132 [Pioneer Corporation] certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) Daisuke Sakata

CUSTOMER: DESCRIPTION : DATE:2024-3-13 REV.NO.:A0 department quality project department project purchase quality TEL：15112254520 FAX：+86-0755-28015170 page:1/2 ADD：No. 1, 2nd Floor, 48 Zhuanwan Ring Wanquan Road, Longhua New District, Shenzhen City Note： HRSW ELECTRONICS CO.,LTD Note： Shenzhen Hui'er Wireless Technology Technology Co., Ltd. acknowledges, signs and stamps. Confirm / DateReview / DateApproval / Date (cover the company's official seal) Dong Wanhong 2024-3- 13 Lu Hui 2024-3-13 Wei Hanman 2024-3-13 He Wei-Hua 2024-3-13 Wei Lihong 2024-3-13 Wei Lihong 2024-3-13 SPECIFICATION FOR APPROVAL Shenzhen Hui'er Wireless Technology Technology Co., Ltd. CUSTOMER P/N: SPECIFICATION：G43.5 Slotting + Magnetic Coil + Small Magnet + Glue 35MM Hong Rishengwei Technology acknowledges the signing and stamping process. Confirm / DateReview / DateApproval / Date (cover the company's official seal) 1.MECHANICAL DIMENSION (UNIT:mm) 2.SCHEMATICS: ADC I2H 43.5±0.519±0.5 0.8±0.05 31±22.5Max 3.WINDING： STE P TAPE REMAR K N1 4.ELECTRICAL SPECIFICATION: ITEM SPEC 5.BILF OF MATERIAL： NO.SGS NO. 1 2 3 4 5 page:2/2 He weihuaWei lihongWei lihong TEST COND HRSW ELECTRONICS CO.,LTD PART NO TITLE G43.5 Slotting + Magnetic Coil + Small Magnet + Glue 31MM DRAWN BYCHECKED BY APPROVED BY glueYellow Glue 999 LIANCHENG CO.,LTD high-temperature adhesive tape 8mm wide heat-resistant adhesive tapeCUDAK CO.,LTD Lead-free tin rodLead-free tin rod QIAODO magnetic sheet ⌀43.5*0.8 manganese-zinc hard magnetic sheet with L-shaped slot TAIYI CO.,LTD ITEMMATERIAL SPECIFICATIONMANUFACTURER Hot air line Hot air line: 0.08 * 80 strands NANJINGJINNINGCO,LTD 100KHz,0.25V AT 25°C 7.4uH±10% 58mΩ Max 80°C HI-POT Coil with magnetic sheet S-FNormal state S-F Hot air line⌀ 0.08*80mm 2UEW 11TS (Ref) LDCRtemperature SPECIFICATION FOR APPROVAL START-FINISHWIRE TYPETURNS

Pioneer Corporation Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: January 20, 2026 Subject; Request for Confidentiality FCC ID: AJDK132 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Daisuke Sakata Title: Manager

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 Pioneer Corporation Date: Jan. 20, 2026 Product Model Number: SDA-SC400 FCC ID: AJDK132 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following:  Testing  Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: 81-49-228-7636 On behalf of: Pioneer Corporation

Ext Photos Model: SDA-SC400 Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7

Int Photos Model: SDA-SC400 Photo 1 Photo 2 ANT Photo 3 Photo 4 Photo 5 Photo 6

- Page 1 of 11 - Report No.: HB20251229019E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com RF EXPOSURE Test Report Product: WIRELESS CHARGING CRADLE Trade Mark: Pioneer Model Number: SDA-SC400 FCC ID: AJDK132 Prepared for Pioneer Corporation 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo, 113-0021 Japan Prepared by Shenzhen HongBiao Certification& Testing Co., Ltd Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen, China Tel.: +86-755-2998 9321 Fax.: +86-755-2998 5110 Website: http://www.sz-hongbiao.com - Page 2 of 11 - Report No.: HB20251229019E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Table of Contents 1 GENERAL DESCRIPTION ................................................................................................................................... 5 1.1 DESCRIPTION OF EUT ................................................................................................................................................ 5 1.2 TEST MODE .............................................................................................................................................................. 5 1.3 TEST SETUP .............................................................................................................................................................. 5 1.4 ANCILLARY EQUIPMENT .............................................................................................................................................. 5 2 TEST FACILITIES AND ACCREDITATIONS ............................................................................................................ 6 2.1 TEST LABORATORY ..................................................................................................................................................... 6 2.2 ENVIRONMENTAL CONDITIONS ..................................................................................................................................... 6 2.3 MEASUREMENT UNCERTAINTY ..................................................................................................................................... 6 2.4 TEST SOFTWARE ........................................................................................................................................................ 6 3 LIST OF TEST EQUIPMENT ................................................................................................................................ 7 4 RF EXPOSURE .................................................................................................................................................. 8 4.1 MAXIMUM PERMISSIBLE EXPOSURE .............................................................................................................................. 8 4.1.1. Limit ............................................................................................................................................................ 8 4.1.2. Test Procedures ........................................................................................................................................... 8 4.1.3. Test Setup .................................................................................................................................................... 8 4.1.4. Test Result ................................................................................................................................................... 8 5 PHOTOGRAPHS OF THE TEST SETUP............................................................................................................... 11 - Page 3 of 11 - Report No.: HB20251229019E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com TEST RESULT CERTIFICATION Applicant’s Name ................. : Pioneer Corporation Address ................................. : 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo, 113-0021 Japan Manufacturer's Name .......... : Pioneer Corporation Address ................................. : 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo, 113-0021 Japan Product description Product name ........................ : WIRELESS CHARGING CRADLE Model Number ....................... : SDA-SC400 Standards ............................. : FCC CFR 47 PART 1 , 1.1310 Test procedure ....................... : KDB 680106 D01 Wireless Power Transfer v04 This device described above has been tested by Shenzhen HongBiao Certification& Testing Co., Ltd and the test results show that the equipment under test (EUT) is in compliance with the EMC requirements. And it is applicable only to the tested sample identified in the report. Date of Test ............................................ : Date (s) of performance of tests ............. : Dec. 31, 2025~Jan. 20, 2026 Test Result ............................................... : Pass Testing Engineer : (Zoe Su) Technical Manager : ( G ar y L u) Authorized Signatory : (L e o S u) - Page 4 of 11 - Report No.: HB20251229019E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Revision History Revised No. Date of Issue Description 01 Jan. 20, 2026 Original - Page 5 of 11 - Report No.: HB20251229019E-02 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Str…

Text truncated - open the document above for the full version.

- Page 1 of 32 - Report No.: HB20251229019E-01 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Test Report Product: WIRELESS CHARGING CRADLE Trade Mark: Pioneer Model Number: SDA-SC400 FCC ID: AJDK132 Prepared for Pioneer Corporation 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo, 113-0021 Japan Prepared by Shenzhen HongBiao Certification& Testing Co., Ltd Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen, China Tel.: +86-755-2998 9321 Fax.: +86-755-2998 5110 Website: http://www.sz-hongbiao.com - Page 2 of 32 - Report No.: HB20251229019E-01 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com Table of Contents 1 GENERAL DESCRIPTION ................................................................................................................................... 5 1.1 DESCRIPTION OF EUT ................................................................................................................................................ 5 1.2 TEST MODE .............................................................................................................................................................. 5 1.3 TEST SETUP .............................................................................................................................................................. 6 1.4 POWER SETTING CONFIGURATION PARAMETERS ............................................................................................................... 6 1.5 ANCILLARY EQUIPMENT .............................................................................................................................................. 6 2 SUMMARY OF TEST RESULT ............................................................................................................................. 7 3 TEST FACILITIES AND ACCREDITATIONS ............................................................................................................ 8 3.1 TEST LABORATORY ..................................................................................................................................................... 8 3.2 ENVIRONMENTAL CONDITIONS ..................................................................................................................................... 8 3.3 MEASUREMENT UNCERTAINTY ..................................................................................................................................... 8 3.4 TEST SOFTWARE ........................................................................................................................................................ 8 4 LIST OF TEST EQUIPMENT .............................................................................................................................. 10 5 TEST ITEM AND RESULTS ............................................................................................................................... 12 5.1 ANTENNA REQUIREMENT .......................................................................................................................................... 12 5.2 CONDUCTED EMISSION ............................................................................................................................................. 13 5.3 RADIATED EMISSION ................................................................................................................................................ 17 5.4 OCCUPIED BANDWIDTH ............................................................................................................................................ 22 6 PHOTOGRAPHS OF THE TEST SETUP............................................................................................................... 24 7 PHOTOGRAPHS OF THE EUT .......................................................................................................................... 26 - Page 3 of 32 - Report No.: HB20251229019E-01 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.com TEST RESULT CERTIFICATION Applicant’s Name ................. : Pioneer Corporation Address ................................. : 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo, 113-0021 Japan Manufacturer's Name .......... : Pioneer Corporation Address ................................. : 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo, 113-0021 Japan Product description Product name ........................ : WIRELESS CHARGING CRADLE Model Number ....................... : SDA-SC400 Standards ............................. : FCC Part 15C Test procedure ....................... : IEEE/ANSI C63.10-2020 This device described above has been tested by Shenzhen HongBiao Certification& Testing Co., Ltd and the test results show that the equipment under test (EUT) is in compliance with the EMC requirements. And it is applicable only to the tested sample identified in the report. Date of Test ............................................ : Date (s) of performance of tests ............. : Dec. 31, 2025~Jan. 20, 2026 Test Result ............................................... : Pass Testing Engineer : (Zoe Su) Technical Manager : ( G a r y L u) Authorized Signatory : (L e o S u) - Page 4 of 32 - Report No.: HB20251229019E-01 Add:Room 102, 201, Building 2, Yuanwanggu RFID Industrial Park, Tongguan Road, Tianliao Community, Yutang Street, Guangming District, Shenzhen,China Tel: (86-755) 29989321 Fax: (86-755) 29985110 Web:www.sz-hongbiao.c…

Text truncated - open the document above for the full version.

Photographs of the Test Setup Model: SDA-SC400 Radiated Emission Below 30MHz Radiated Emission Above 30MHz Conducted Emission MPE
