AMWLRD350RADAR DETECTOR

UNIDEN LONG RANGE RADAR/ LASER DETECTOR LRD350 DISCLAIMER: Radar detectors are illegal in some states. Some states prohibit mounting any object on your windshield. Check applicable law in your state and any state in which you use the product to verify that using and mounting a radar detector is legal. Uniden radar detectors are not manufactured and/or sold with the intent to be used for illegal purposes. Drive safely and exercise caution while using this product. Do not change settings of the product while driving. Uniden expects consumer’s use of these products to be in compliance with all local, state and federal law. Uniden expressly disclaims any liability arising out of or related to your use of this product. FEATURES • X, K, and Ka band alarms • Laser alarms • Highway/City/City 1 modes • Invisible to VG-2 and Spectre I/IV/IV+ radar detectors • Mute alarm audio • Memory feature saves user’s last settings (except MUTE) when the unit is powered down/disconnected from power. WHAT’S IN THE BOX • LRD350 radar detector • Straight 12V DC Power Cord • Windshield Mounting Bracket • Hook and loop fastener tape • Spare fuse for DC Power Cord LRD350 HARDWARE NO.NAMEWHAT IT DOES 1Eagle Eye360° Laser detection 2Power JackPlugs into power source. 3EjectReleases LRD350 from mounting hardware. 4 DIM Dims the display brightness. 5 MUTE Turns off the sound. 6 CITY Sets the unit to CITY, CITY I, or HIGHWAY mode. 7Power/ Volume Dial Turns unit on and adjusts volume. 8Mounting Bracket Slot The mounting bracket fits into this slot. LED DISPLAY When a signal is detected, the display will show the band type, City/Highway setting, and signal strength. If the LRD350 detects a laser, the display shows L. (Laser is used in close proximity and has no signal associated with it.) The Signal Strength Meter bars indicate the following: SS METER BARBAR STATUSMEANING SSM Bar 1SolidSSM Level 1 SSM Bar 3Solid SSM Bar 1 + Blinking Bar 3 SSM Level 2 Solid SSM Bar 1 and Bar 3 SSM Level 3 SS METER BARBAR STATUSMEANING SSM Bar 5Solid SSM Bars 1 and 3 + Blinking Bar 5 SSM Level 4 Solid SSM Bars 1, 3, and 5 SSM Level 5 INSTALLATION AND TURN UP Install the LRD350 on the front windshield or on the dashboard. For best performance, position the detector as low as possible in the center of the front windshield. Be sure the unit’s view of the road, either to the front or the back, is clear. INSTALLATION WINDSHIELD 1. Clean the windshield and the rubber cups of the mounting bracket. Attach the rubber cups to the bracket. 2. Push the bracket firmly onto the windshield. 3. Slide the unit onto the bracket. 4. Gently adjust the bracket angle if needed. Do not use the detector to adjust the bracket angle. 5. Plug the power cord into the detector. 6. Plug the cigarette lighter adapter into the vehicle’s cigarette lighter. You can remove the detector by pressing the Eject button. Dashboard 1. Place the unit on the dashboard so that it has a clear, level view of the road. The unit cannot be readjusted after final installation. 2. Remove the backing from one side of the hook and loop fastener tape. 3. Place that fastener tape on the dashboard where you want the unit. 4. Attach the other piece of the fastener tape to the bottom of the unit and attach the unit to the dashboard fastener tape. You can remove the unit as needed. 5. Plug the power cord into the detector. 6. Plug the cigarette lighter adapter into the vehicle’s cigarette lighter. TURN UP Once the detector is installed and the car is turned on, turn the volume dial away from you until it clicks. The unit is now turned on. The LED cycles through the display in this order: X - K - Ka - Laser, then signal strength except for Laser (L). Once the cycle is complete, the detector turns to standby mode. STANDBY MODE Highway X KKaL C CityX K KaL C STANDBY MODE City 1XK Ka L C DETECTION The LRD350 detects emissions from radar guns and sounds an audio alert for the driver. The detector determines which band range the signal is from and displays that frequency type on the display (X, K, Ka, or L). The signal strength (1 through 5) also displays as applicable. If there is a specific alert code, that is also displayed. False signals can come from other devices such as the automatic doors at a supermarket or even another car’s cruise control; these devices operate in the same frequency ranges as radar guns. BANDS The LRD350 recognizes: • X Band: This band was the first frequency band assigned to police radar. It operated on a lower frequency (10.525GHz) with a higher power output. • K Band: This band is the most common frequency used in radar detectors (24.150). Its relatively small wavelength gives it a clocking distance of about 1/4 mile although, depending on the environment, it can detect up to 2 miles. • Ka Band: Over the years, the Ka band incorporated the Ka-Band, the Ka Wide-Band, and the Ka Super Wide-Band. Most photo radars (also known as stop light cameras) use this band. • Laser: Police use the laser’s narrower light pulses for speed detection as it is more accurate and faster. Laser beams are more detectable after they have bounced off their target and begin to disperse on the return trip. MODES The LRD350 operates in three modes: • Highway. Provides audio and visual alerts any time all bands and laser are detected. Recommended for highway or rural driving. (X, K, Ka Laser) • City. Provides audio and visual alerts any time all bands and laser are detected. Provides a stronger signal for the X band so it can pick up weaker signals. (X, K, Ka, Laser) • City I. Similar to City mode, but no X band is detected. (K, Ka, Laser) HIGHWAY X KKaLC X K KaLC XK Ka LC XKKa L C 1 MUTE CIT Y DIM 34 5 6 2 78 City (C) City 1 (C + SSM Bar 1) Highway (SSM Bar 1) Various Alerts X K Ka L C Band Type Signal Strength Meter Bars (1, 3, 5) Laser (L + SSM Bars 1, 3, and 5) CITYCITY 1 X KKaL C C+ X K KaL C C+ XK Ka L C C+ XKKa L C C+ OPERATION SETUP After installing your radar detector, you can set it to your own…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 March 19, 2015 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Uniden America Corporation hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): RADAR DETECTOR / LRD350 FCC ID: AMWLRD350 Sincerely, Renji Inuzuka / Director Uniden America Corporation 6225 North State Highway 161, Suite 300, Irving Texas 75038 United States

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 March 19, 2015 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: AMWLRD350 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Circuit Diagram - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Renji Inuzuka / Director Uniden America Corporation 6225 North State Highway 161, Suite 300, Irving Texas 75038 United States

Appendix C. External Photographs Report no. ETLE150224.0258, Page C1 of C5 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC ID:AMWLRD350 View of total construct Appendix C. External Photographs Report no. ETLE150224.0258, Page C2 of C5 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC ID:AMWLRD350 Front view of EUT Rear view of EUT Appendix C. External Photographs Report no. ETLE150224.0258, Page C3 of C5 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC ID:AMWLRD350 Left side view of EUT Right side view of EUT Appendix C. External Photographs Report no. ETLE150224.0258, Page C4 of C5 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC ID:AMWLRD350 Top side view of EUT Bottom side view of EUT Appendix C. External Photographs Report no. ETLE150224.0258, Page C5 of C5 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC ID:AMWLRD350 View of Cigar jack (power line)

Appendix A. FCC ID Label and Location Report no. ETLE150224.0258, Page A1 of A1 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC ID:AMWLRD350 Product Label Sample with FCC Label information Following is a sample copy of the label that will be placed on the rear cabinet of the product. The FCC ID Label and compliance statement are marked in the product label. The warning statement and Information to the User are described in the user manual. Label Location The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase.(Labeling requirements per 2.925) Label here

Appendix D. Internal Photographs Report no. ETLE150224.0258, Page D1 of D5 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC ID:AMWLRD350 Inside view of EUT Appendix D. Internal Photographs Report no. ETLE150224.0258, Page D2 of D5 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC ID:AMWLRD350 Inside view of EUT Appendix D. Internal Photographs Report no. ETLE150224.0258, Page D3 of D5 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC ID:AMWLRD350 Top side view of main board #1 Appendix D. Internal Photographs Report no. ETLE150224.0258, Page D4 of D5 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC ID:AMWLRD350 Top side view of main board #1-1 (without case) Appendix D. Internal Photographs Report no. ETLE150224.0258, Page D5 of D5 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC ID:AMWLRD350 Bottom side view of main board

Report no. ETLE150224.0258, Page 2 of 13 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC TEST REPORT FCC ID:AMWLRD350 Table of Contents FCC Measurement Report 1. Introduction 2. Product Information 3. Description of Tests 4. Test Condition 5. Test Results 5.1 Summary of Test Results 5.2 Radiated Emissions Measurement 6. Sample Calculation 7. List of test Equipment used for Measurement Appendix A. FCC ID Label and Location Appendix B. Test Setup Photographs Appendix C. External Photographs Appendix D. Internal Photographs Appendix E. Block Diagram Appendix F. Operating Description Appendix G. User Manual Appendix H. Circuit Diagram Report no. ETLE150224.0258, Page 3 of 13 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC TEST REPORT FCC ID:AMWLRD350 FCC MEASUREMENT REPORT Scope – Measurement and determination of electromagnetic emission(EME) of radio frequency devices including intentional radiators and/or unintentional radiators for compliance with the technical rules and regulations of the U.S Federal Communications Commission(FCC) General Information  EUT Type : RADAR DETECTOR  Model Number : LRD350  FCC ID : AMWLRD350  S/N : Proto-type  Rule Part(s) : FCC Part 15 Subpart B  Test Procedure : ANSI C63.4-2001 and FCC 02-211  FCC Classification : Unintentional Radiators CRD - Part 15 Radar Detector  Dates of Tests : March 04, 2015 Temperature: (3.5 ± 0.6) °C Humidity: (43 ± 1) % R.H.  Environmental of Tests: Atmospheric Pressure: (102.0 ± 0.0) kPa  Place of Tests : ETL Inc. Testing Lab. (FCC Designation Number : KR0022) Radiated Emission test 1; #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea Radiated Emission test 2 and Conducted Emission test; #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea  Test Report No. : ETLE150224.0258 Applicant Name : Uniden America Corporation Address : 6225 North State Highway 161, Suite 300, Irving Texas 75038 United States Attention : Renji Inuzuka / Director Report no. ETLE150224.0258, Page 4 of 13 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC TEST REPORT FCC ID:AMWLRD350 1. INTRODUCTION The measurement tests for radiated and conducted emission test were conducted at the ETL Inc. The site is constructed in conformance with the requirements of the ANSI C63.4-2001 and CISPR Publication 16. The ETL has site descriptions on file with the FCC for 3 m and 10 m site configurations. Detailed description of test facility was found to be in compliance with FCC Rules according to the ANSI C63.4-2001 and registered to the Federal Communications Commission (FCC Designation Number : KR0022). The measurement procedure described in American National Standard for Method of Measurement of Radio- Noise Emission from Low-Voltage Electrical and Electronic Equipment in the Range of 9 kHz to 40 GHz (ANSI C63.4-2001) was used in determining radiated and conducted emissions from the Uniden America Corporation, Model: LRD350. Report no. ETLE150224.0258, Page 5 of 13 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC TEST REPORT FCC ID:AMWLRD350 2. PRODUCT INFORMATION 2.1 Equipment Description The Equipment Under Test (EUT) is the RADAR DETECTOR (model: LRD350). The model LRD350 is basic model that was tested. 2.2 General Specification Receiver Type Radar Double Conversion Super-heterodyne Self-Contained Antenna Laser Pulse Laser Signal Receiver Frequency X Band (10.525 ± 0.050) GHz K Band (24.150 ± 0.100) GHz Ka Band (Super-wide) (34.700 ± 1.300) GHz Laser (950 ± 150) nm Detector Type Radar Scanning Frequency Discriminator Laser Pulse Width Discriminator Alarm Type Beep (Detected Band and Signal strength) Antenna Type Radar Linear Polarized E-vector Vertical Laser Front Convex Condenser Lens Laser Back Concave Condenser Lens General Dimensions 110.0 mm (D) x 69.0 mm (W) x 29.5 mm (H) Weight 3.4 oz (95 g) Operating Temperature (90.5 ± 94.5) °F (Radar/Laser) (32.5 ± 52.5) °C (Radar/Laser) Storage Temperature (90.5 ± 112.5) °F (Radar/Laser) (32.5 ± 62.5) °C (Radar/Laser) Operating Power Source (13.5 ± 2.5) V DC High Internal Frequency MCU Clock  22 MHz Report no. ETLE150224.0258, Page 6 of 13 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC TEST REPORT FCC ID:AMWLRD350 3. DESCRIPTION OF TESTS The tests documented in this report were performed in accordance with ANSI C63.4-2001, FCC 02-211 and FCC CFR 47 15.109. 3.1 Radiated Emission Measurement Radiated emission measurements were made in accordance with section 12, “Measurement of unintentional radiators other than ITE" of ANSI C63.4-2001 and FCC 02-211. The measurements were performed over the frequency range of 11.7 GHz to 12.2 GHz using antenna as the input transducer to a spectrum analyzer. The measurements were made with the detector set for "Peak" within a bandwidth of 1 MHz. Preliminary measurements were made at 3 m using broadband antennas, and spectrum analyzer to determined the frequency producing the maximum emission in shielded room. Appropriate precaution was taken to ensure that all emission from the EUT were maximized and investigated. The system configuration, mode of operation, turntable azimuth and height with respect to the antenna were noted for each frequency found.…

Text truncated - open the document above for the full version.

Appendix B. Test Setup Photographs Report no. ETLE150224.0258, Page B1 of B1 Head Office: #371-51, Gasan-dong, Geumcheon-gu, Seoul, 153-803, Korea Tel : 82-2-858-0786 Fax : 82-2-858-0788 Open site: #499-1, Sagot-ri, Seosin-myeon, Hwaseong-si, Gyeonggi-do, 445-882, Korea ETLQP-21-F22-0 FCC ID:AMWLRD350 Radiated Emission Test Setup
