AMWON2055Two Ways Radio of GMRS and FRS

GMR2035-2 GMR2050-2C • 15 GMRS/7 FRS Channels • Battery Strength Meter • Long Battery Life• Call Button • Up to 20-mile Range*• DC IN 5V • Channel Scan• Channel Monitor * Range may vary depending on environmental and/or topographical conditions. 1 2 3 4 5 6 7 8 9 10 1Antenna6Microphone 2 USB Charge Jack7Speaker 3Push to Talk8Channel/Power 4Channel/Volume Up 9Call/Monitor Key 5Channel/Volume Down 10Display Congratulations on your purchase of the Uniden GMR2035-2 or GMR2050-2C (General Mobile Radio) radio. This lightweight, palm-sized radio is a state-of- the-art device, equipped with many valuable features. Use it at sporting events, to stay in contact with family and friends, hiking, skiing, outdoors, or in a neighborhood watch for vital communication. Your package contains the 2 radios, 6 AAA rechargeable NiMH batteries (GMR2050-2C) or 6 AAA alkaline batteries (GMR2035-2), one USB charge cable (GMR2050-2C), this reference guide, and 2 belt clips. To order the following optional accessories, visit our web site at www.uniden.com. • VOX Headset - #ZA-133 Use only Uniden accessories. The radio operates on the General Mobile Radio Service (GMRS) frequencies which require a Federal Communications Commission license to operate. For licensing information and application forms, visit the FCC on-line at: www.fcc. gov/wtb/uls or call the FCC hotline at 1-800-418-3676. If you have any questions you can contact the FCC direct at 1-888-225-5322. Each radio uses 3 AAA batteries for power. GMR2035-2 uses non- rechargeable alkaline batteries and GMR2050-2C uses rechargeable NiMH batteries. These batteries are supplied with your radio. To install the batteries: 1. Make sure your radio is OFF. 2. Remove the battery compartment door by pressing on and sliding the compartment door, and remove the cover. 3. Installthe supplied 3 AAA batteries into the battery compartment. Be certain to follow the + and – symbols in the compartment. Installing the batteries incorrectly will prevent the unit from operating. PACKAGE CONTENTS FCC GMRS LICENSE INSTALL THE BATTERIES 4. Replace the battery compartment door by sliding the door into place. 5. Repeat for each radio. Note: Do not mix rechargeable and Alkaline batteries CHARGING THE RADIO GMR2050-2C only 1. Plug one branch of the microSD Y-Cable into each radio's microSD charge port. 2. Insert the other end (USB) into a USB power source (computer, phone charger, etc - not included). Notes: • Install the batteries before charging. Charge time may vary depending on the battery life remaining. For fastest charging, turn off the radio before charging. (GMR2050-2C only). • Do not attempt to recharge alkaline batteries. Doing so can create a safety hazard or damage the radio. • If battery power is low, you cannot operate the radio even using external power. If you try to transmit while power is low, the radio will automatically turn off. Recharge the batteries. USING THE RADIO In order to get the most out of your new radio, read this reference guide completely before attempting to operate the radio. Turning the Radio On and Adjusting the Volume 1. Press and hold the CH/ key to turn the radio ON. 2. To change the volume level, press the ▲ or ▼ key to increase or decrease the volume level. 3. Press and hold the CH/ key to turn the radio OFF. Choosing a Channel Your radio has 22 channels you can use to talk to others. In order to speak to someone, each of you must be set to the same channel. To choose a channel: Tap the CH/ key to turn the radio on, then use the ▲ or ▼ key to select a channel. Channel Scan Feature Your radio has a channel scan feature that allows you to easily scan all 22 channels. When an active channel is detected, the unit pauses on that channel until the channel is clear. Then, after a 2 second delay, the radio continues scanning. When the unit stops on an active channel, you can press the PTT button on the microphone to transmit on that channel. To turn ON channel scan Tap CH/ then hold ▼ for 3 seconds. The channels will cycle down through all 22 chanels. To reverse scan direction, tap ▲. To stop scanning, press CH/. Talking on Your Radio To talk to others using the radio: 1. Press and hold the PTT button and speak in a clear, normal voice about 2-3 inches away from the microphone. (While you are transmitting, the tx icon displays. To avoid cutting off the first part of your transmission, pause slightly after pressing the PTT button before you start talking.) 2. When you are finished speaking, release the PTT button. You can now receive incoming calls. While receiving, the rx icon displays. Transmitting a Call Alert Tone Your radio is equipped with a call tone that will be transmitted when the CALL/MON key is pressed. To transmit the call tone, tap the CALL/MON key. The tone will be transmitted. Auto Squelch Feature The radio is equipped with an automatic squelch system which shuts off weak transmissions and unwanted noise due to terrain conditions or range limitations. Monitor Mode Feature Your radio allows you to listen for weak signals on the current channel at the press of a key. To turn ON monitor mode: Press and hold the CALL/MON key for 2 seconds. On a channel that does not ____ have activity, you will hear only an open-squelch hissing noise To turn OFF monitor mode: Press the CALL/MON key for 2 seconds again. . Channels15 GMRS/7 FRS Operating Frequency UHF 462.5500 - 467.7125 MHz Power Source 3 AAA NiMH Batteries per radio (GMR2050-2C) 3 AAA Alkaline Batteries per radio (GMR2035-2) Battery Life8 Hours typical Frequency Chart CHFreq.[MHz] - Cross Ref. CHFreq.[MHz] - Cross Ref. 1462.5625 - FRS & GMRS 1 12 467.6625 - FRS 12 2 462.5875 - FRS & GMRS 2 13467.6875 - FRS 13 3462.6125 - FRS & GMRS 3 14467.7125 - FRS 14 4462.6375 - FRS & GMRS 4 15462.5500 - GMRS 11 5462.6625 - FRS & GMRS 5 16462.5750 - GMRS 8 6462.6875- FRS & GMRS 6 17 462.6000 - GMRS 12 7 462.7125 - FRS & GMRS 7 18462.6250 - GMRS 9 8467.5625 - FRS 819462.6500 - GMRS 13 9467.5875 - FRS 920 46…

Text truncated - open the document above for the full version.

Uniden America Corporation 3001 Gateway Drive, Suite 130 Irving, TX 75063 817-858 -3300 Fax: 817-858-3333 8/11/2015 To whom it may concern, Letter of Agency I, an officer of Uniden America Corporation do hereby authorize Intertek Testing Services (Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Renji Inuzuka Director, Engineering and Quality Uniden America Corporation

Uniden America Corporation 3001 Gateway Drive, Suite 130 Irving, TX 75063 817-858 -3300 Fax: 817-858-3333 REQUEST FOR CONFIDENTIALITY August 24, 2015 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 95 Certification FCC ID: AMWON2055 Request is hereby submitted by Uniden America Corporation to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and § 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and Uniden America Corporation reserves the right to discern which parties can obtain access to these information: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description • Parts List • Tune up Procedures • Operational Description The rationale for request for confidentiality is as followings: This information represents intellectual property of Uniden America Corporation and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Renji Inuzuka Director Engineering and Quality

Uniden America Corporation 3001 Gateway Drive, Suite 130 Irving, TX 75063 817-858 -3300 Fax: 817-858-3333 8/24/15 To whom it may concern, Label Location Justification [FCC ID: AMWON2055] Request is hereby submitted by Uniden America Corporation to request an alternative method of positively identifying the equipment, pursuant to 47 CFR § 2.925(f) of the FCC Rules. The FCC identifier for parent unit will be placed in the battery compartment and the following requirements are confirmed to meet: a) The FCC identifier will visible at the time of purchase, by either of the following approaches:  Marketing the device without the battery installed, or  Providing instruction (stated on the box, user manual, or additional documentation) directing the user as to where to find the FCC label. b) The user accessible area will not require any special tools for access and the FCC label will not be placed on a removable part. The user manual has already included the FCC statements, pursuant to 47 CFR § 15.19(a)(3), 15.21 and 15.105(b). If you have questions or need further information, please contact the undersigned. Regards, Renji Inuzuka Director, Engineering and Quality Uniden America Corporation

INTERTEK TESTING SERVICE Report No.: 15080132HKG-001 FCC ID: AMWON2055 Equipment Photographs Model: GMR2035-2 (External)

UNIDEN AMERICA CORP. MODEL: GMR2050-2C FCC ID: AMWON2055 IC: 513C-ON2055 S/N: 0915000001 Made In China UNIDEN AMERICA CORP. MODEL: GMR2050-2C FCC ID: AMWON2055 IC: 513C-ON2055 S/N: 0915000001 Made In China UNIDEN AMERICA CORP. MODEL: GMR2035-2 FCC ID: AMWON2055 IC: 513C-ON2055 S/N: 0915000001 Made In China UNIDEN AMERICA CORP. MODEL: GMR2035-2 FCC ID: AMWON2055 IC: 513C-ON2055 S/N: 0915000001 Made In China The label would be permanently affixed to the equipment and readily visible to the purchaser at the time of purchase

INTERTEK TESTING SERVICE Report No.: 15080132HKG-001 FCC ID: AMWON2055 Equipment Photographs Model: GMR2035-2 (Internal) INTERTEK TESTING SERVICE Report No.: 15080132HKG-001 FCC ID: AMWON2055 Equipment Photographs Model: GMR2035-2 (Internal) INTERTEK TESTING SERVICE Report No.: 15080132HKG-001 FCC ID: AMWON2055 Equipment Photographs Model: GMR2035-2 (Internal) INTERTEK TESTING SERVICE Report No.: 15080132HKG-001 FCC ID: AMWON2055 Equipment Photographs Model: GMR2035-2 (Internal) INTERTEK TESTING SERVICE Report No.: 15080132HKG-001 FCC ID: AMWON2055 Equipment Photographs Model: GMR2035-2 (Internal) INTERTEK TESTING SERVICE Report No.: 15080132HKG-001 FCC ID: AMWON2055 Equipment Photographs Model: GMR2035-2 (Internal)

A Test Lab Techno Corp. Changan Lab：No. 140 -1, Changan Street, Bade City, Taoyuan County, Taiwan R.O.C. Te l：886-3-271-0188 / Fax：886-3-271-0190 SAR EVALUATION REPORT Test Report No. ： 1510FS22 Applicant ： UNIDEN AMERICA CORPORATION Product Type ： Walkie Talkie Trade Name ： Uniden Model Number ： GMR2035-2, GMR2050-2C Date of Received ： Aug. 18, 2015 Test Period ： Aug. 19 ~ Oct. 26, 2015 Date of Issued ： Nov. 10, 2015 Test Environment ： Ambient Temperature： 22 ± 2 ° C Relative Humidity：40 - 70 % Standard ： ANSI/IEEE C95.1-1999 IEEE Std. 1528-2013 47 CFR Part §2.1093 KDB 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04 KDB 865664 D02 RF Exposure Reporting v01r02 KDB 447498 D01 General RF Exposure Guidance v06 Test Lab Location ： Chang-an Lab 1. The test operations have to be performed with cautious behavior, the test results are as attached. 2. The test results are under chamber environment of A Test Lab Techno Corp. A Test Lab Techno Corp. does not assume responsibility for any conclusions and generalizations drawn from the test results with regard to other specimens or samples. 3. The measurement report has to be written approval of A Test Lab Techno Corp. It may only be reproduced or published in full. This report shall not be reproduced except in full, without the written approval of A Test Lab Techno Corp. The test results in the report only apply to the tested sample. Approved By ： Tested By ： (Bill Hu) (Sky Chou) Report Number: 1510FS22Page 1 of 73 ©2015 A Test Lab Techno Corp. Contents 1. Summary of Maximum Reported SAR Value ................................................................................................. 3 2. Description of Equipment under Test (EUT) .................................................................................................. 4 3. Introduction..................................................................................................................................................... 5 3.1 SAR Definition ..................................................................................................................................... 5 4. SAR Measurement Setup .............................................................................................................................. 6 4.1 DASY E-Field Probe System............................................................................................................... 7 4.1.1 E-Field Probe Specification ................................................................................................................. 8 4.1.2 E-Field Probe Calibration process ...................................................................................................... 9 4.2 Data Acquisition Electronic (DAE) System ........................................................................................ 10 4.3 Measurement Server......................................................................................................................... 10 4.4 Device Holder .................................................................................................................................... 11 4.5 Oval Flat Phantom - ELI 5.0 .............................................................................................................. 11 4.6 Data Storage and Evaluation............................................................................................................. 12 4.6.1 Data Storage ..................................................................................................................................... 12 4.6.2 Data Evaluation ................................................................................................................................. 13 5. Tissue Simulating Liquids............................................................................................................................. 15 5.1 Ingredients......................................................................................................................................... 16 5.2 Recipes.............................................................................................................................................. 16 5.3 Liquid Depth ...................................................................................................................................... 17 6. SAR Testing with RF Transmitters ............................................................................................................... 18 6.1 Conducted Power .............................................................................................................................. 18 6.2 Antenna Location .............................................................................................................................. 19 6.3 Stand-alone SAR Evaluate................................................................................................................ 20 6.4 SAR test reduction according to KDB ............................................................................................... 20 7. System Verification and Validation ............................................................................................................... 21 7.1 Symmetric Dipoles for System Verification ....................................................................................... 21 7.2 Liquid Parameters ............................................................................................................................. 22 7.3 Verification Summary ........................................................................................................................ 23 7.4 Validation Summary .......................................................................................................................... 24 8. Test Equipment List ......................................................................................................................…

Text truncated - open the document above for the full version.

SAR Test Setup Photographs EUT Side Definition Item Side 1 Front side 2 Back side 1 2 Report Number: 1510FS22 1 of 4 A Test Lab Techno Corp. Phantom Position： FRS/GMRS EUT side：Front_Brain Spacing to phantom： 25 mm Accessory：N/A Report Number: 1510FS22 2 of 4 A Test Lab Techno Corp. Phantom Position： FRS/GMRS EUT side：Back_Muscle Spacing to phantom： 10 mm Accessory：N/A Report Number: 1510FS22 3 of 4 A Test Lab Techno Corp. Phantom Position： FRS/GMRS EUT side：Back_Muscle Spacing to phantom： 0 mm Accessory：Belt clip Report Number: 1510FS22 4 of 4 A Test Lab Techno Corp.

- Intertek’s standard Terms and Conditions can be obtained at our website: http://www.intertek.com/terms/. - The test report only allows to be revised the retention period issued date unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Uniden America Corporation Application For FCC Part 95 - Certification Two Ways Radio of GMRS and FRS (FCC ID: AMWON2055) 15080132HKG-001 MN/ cl August 27, 2015 INTERTEK TESTING SERVICES Test Report Number: 15080132HKG-001 MEASUREMENT/TECHNICAL REPORT Ap plicant : Uniden America Corporation Trade Name/Model No : Uniden / GMR2035-2 GMR2050-2C Date : August 27, 2015 This report concerns (check one:)Original Grant X FCC ID: AMWON2055 Page 1 of 53 Class II Change Equipment Type: FRF – Part 95 Family Radio Face Held Transmitter Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Report prepared by: Nip Ming Fung, Melvin Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Phone: 852-2173-8535 Fax: 852-2741-1693 INTERTEK TESTING SERVICES Test Report Number: 15080132HKG-001 FCC ID: AMWON2055 Page 2 of 53 Table of Contents 1.0 General Description................................................................................................. 4 1.1 Product Description ................................................................................................. 4 1.2 Related Submittal(s) Grants .................................................................................... 5 1.3 Test Methodology.................................................................................................... 5 1.4 Test Facility............................................................................................................. 5 2.0 System Test Configuration...................................................................................... 7 2.1 Justification ............................................................................................................. 7 2.2 EUT Exercising Software......................................................................................... 8 2.3 Special Accessories ................................................................................................ 8 2.4 Measurement Uncertainty ....................................................................................... 8 2.5 Equipment Modification ........................................................................................... 8 2.6 Support Equipment.................................................................................................. 8 3.0 RF Power Output (Section 2.1046(a), 95.639(d))................................................. 10 4.0 Modulation Characteristics (Section 2.1047(a)(b), 95.637(a))............................... 14 4.1 Modulation Frequency Response......................................................................... 15 4.2 Modulation Limiting Characteristics...................................................................... 18 4.3 Audio Low Pass Filter Response.......................................................................... 21 5.0 Occupied Bandwidth (Section 95.633(c))............................................................ 25 6.0 Spurious Emission................................................................................................ 29 6.1 Power of Spurious Radiation (Section 2.1053, 95.635(b)) ................................... 30 6.2 Field Strength of Radiation Emission (Section 15.109)..................................... 37 7.0 Frequency Stability (Section 2.1055(a)(b)(d), 95.621(b), 95.626(b))..................... 46 7.1 Frequency Tolerance ........................................................................................... 47 7.2 Temperature Extreme Condition .......................................................................... 49 7.3 Voltage Extreme Condition................................................................................... 51 8.0 Equipment List...................................................................................................... 53 INTERTEK TESTING SERVICES Test Report Number: 15080132HKG-001 FCC ID: AMWON2055 Page 3 of 53 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES Test Report Number: 15080132HKG-001 1.0 General Description 1.1 Product Description The Equipment Under Test (EUT) is a Two Ways Radio with GMRS and FRS, ,Weather Band. GMRS and FRS operate between 462.5500MHz and 467.7125MHz. The Channel 1 - 7 are shared channels for GMRS and FRS. Channel 4 is the representable channel to the test. The EUT is powered by 3.6V (3 x 1.2V “Ni-MH” type rechargeable battery) or 4.5V (3 x “AA” size 1.5V alkaline batteri…

Text truncated - open the document above for the full version.

Configuration Photographs Worst-Case Line-Conducted Emissions (Front View) Model : GMR2035-2 Configuration Photographs Worst-Case Line-Conducted Emissions (Back View) Model : GMR2035-2 Configuration Photographs Worst-Case Line-Conducted Emissions (Side View) Model : GMR2035-2 INTERTEK TESTING SERVICE Report No: 15080132HKG-001 FCC ID: AMWON2055 Configuration Photographs Worst-Case Radiated Emissions (Front View) Model: GMR2035-2 INTERTEK TESTING SERVICE Report No: 15080132HKG-001 FCC ID: AMWON2055 Configuration Photographs Worst-Case Radiated Emissions (Rear View) Model: GMR2035-2
