AMWON525Two Ways Radio of GMRS, FRS, Weather receiver

GMR3055-2CK GMR3055-2CKHS GMR3055-3VP Congratulations on your purchase of a Uniden GMRS/FRS radio. This lightweight, palm-sized radio is a state-of-the-art device, equipped with many valuable features. Use it at sporting events, to stay in contact with family and friends, hiking, skiing, outdoors, or in a neighborhood watch for vital communication. • 15 GMRS/7 FRS Channels • Battery Charging Cradle (GMR3055-2CK and GMR3055-2CKHS) • 121 Privacy Codes• NOAA Emergency/Weather Channels • Up to 30-Mile Range* • Weather alert • Channel Scan• microUSB charging jack • VOX Headset Jack• 10 Selectable Call Tone Alerts • Roger Beep * Range may vary depending on environmental and/or topographical conditions. GMR3055 HARDWARE 1 2 3 4 5 6 7 8 10 11 9 1Antenna7Speaker 2USB Charge Port/ Headphone Jack 8Channel and Volume 3Push to Talk9WX/LOCK 4Microphone10CH/Backlight 5MENU/Power11Screen 6CALL/MON WHAT'S IN THE BOX All models come with: • 2 radios (3 radios for GMR3055-3VP) • 6 AA rechargeable NiMH batteries (9 NiMH batteries for GMR3055-3VP) • 2 belt clips (3 belt clips for GMR3055-3VP) • This reference guide GMR3055-2CK also has: • 1 battery charging cradle • 1 AC adapter/single microUSB cable GMR3055-2CKHS also has • 1 battery recharging cradle • 1 AC adapter/single microUSB cable • 2 earbud-style headphones (GMR3055- 2CKHS GMR3055-3VP also has: • 1 AC adapter/Y-Split microUSB charge cable (GMR3055-3VP) Visit our web site at www.uniden.com to order accessories. Use only Uniden accessories. The radio operates on the General Mobile Radio Service (GMRS) frequencies which require a Federal Communications Commission license to operate. For licensing information and application forms, visit the FCC on-line at: www. fcc.gov/wtb/uls or call the FCC hotline at 1-800- 418-3676. If you have any questions you can contact the FCC direct at 1-888-225-5322. Each radio uses 3 AA rechargeable NiMH batteries (included). To install the batteries: 1. If installed, remove the belt clip. 2. Remove the battery compartment door by pressing on the latch and releasing the cover. Remove it. 3. Install the supplied 3 NiMH batteries into the battery compartment. Be certain to follow the + and – symbols in the compartment. Installing the batteries incorrectly will prevent the unit from operating. 4. Replace the battery compartment door. 5. Replace the belt clip if necessary. 6. Repeat for each radio. Note: You may also use 3 AA non-rechargeable alkaline batteries in each radio. However, do not mix NiMH and alkaline batteries in the same radio. FCC GMRS LICENSE INSTALL THE BATTERIES CHARGING THE RADIO Review the following tips before charging your radios: CAUTION: Do not attempt to recharge alkaline batteries. Doing so can create a safety hazard or damage the radio. • Install the batteries before connecting the AC adapter to the radio and power source. • The battery icon flashes while the radio charges, whether the radio is turned on or not. The charge stops after 14 hours of continuous charging. If there is a power interruption, the charging timer resets to 14 hours. If the radio is off and charging stops, the battery icon stops flashing. • Charge time may vary depending on the battery life remaining. For fastest charging, turn off the radio before charging. • If battery power is low, you cannot operate the radio even using external power. If you try to transmit while power is low, the radio will automatically turn off. Recharge the batteries. GMR3055-2CK, GMR3055-2CKHS These models use a charging cradle (included) to charge their NiMH batteries. 1. Plug the charging cradle into an AC adapter and then plug the AC adapter into a power source (wall outlet). . 2. Install the NiMH batteries in the radios. 3. Place the radios in the charging cradle. The radios begin charging and the red LEDs turn on. 4. The radio is fully charged when the red POWER LEDs go off. GMR3055-3VP This model charges through a microUSB Y-branch cable (included) with an AC adapter that plugs into an AC power source. 1. Plug one branch of the microUSB Y-Cable into each radio's microUSB charge port. 2. Insert the AC adapter into an AC power source (wall plug). 3. The radios are charged after 14 hours when the battery icon on the screen stops flashing. Note: You will have to charge 2 of the 3 radios and then charge the last one. USING THE RADIO Turning the Radio On and Adjusting the Volume 1. Press and hold the MENU/ key to turn the radio ON. 2. To change the volume level, press the ▲ or ▼ key to increase or decrease the volume level. There are 8 volume levels (L1 - L8) plus volume off (L0) 3. Press and hold the MENU/ key to turn the radio OFF. Using Headphones The GMR3055-2CKHS radio comes with earbud headphones for each radio. You can purchase optional earbuds or headsets for other radios if desired. See www.uniden.com to purchase authentic Uniden products. Using the earbuds lets you have more private communications. To use the earbuds, lift the rubber cover from the headset jack, then plug in the earbuds. The microphone is on the earbud cable. Important: Your radio is not weather resistant when using a headset jack. When you remove the earbuds, be sure to fully press the cover into place to restore its weather resistant capability. Using the Menu Press MENU/ to access the three menu options: • Privacy Code (121 codes). The privacy codes display underneath the channel number on the screen. • Call Tone (10 call tone options plus Off) • VOX (5 levels plus Off) Each menu option is discussed later in the manual with the feature that uses it. Choosing a Channel Your radio has 22 channels you can use to talk to others. In order to speak to someone, each of you must be set to the same channel and privacy code. Each of the channels 1-22 may have any one of the privacy codes, 0 (OFF), or 1-121 selected. Code oF (OFF) indicates no privacy code selected and your radio can receive a signal regardless of the code settings of the transmitting radio. To choose a privacy code: …

Text truncated - open the document above for the full version.

Uniden America Corporation 3001 Gateway Drive, Suite 130 Irving, TX 75063 817-858 -3300 Fax: 817-858-3333 8/11/2015 To whom it may concern, Letter of Agency I, an officer of Uniden America Corporation do hereby authorize Intertek Testing Services (Mr. Melvin Nip) to act on our behalf in front of the Federal Communications Commission with respect to all matters relating to certification of equipment of the FCC Rules until further notice. I further certify that no party (as defined in §1.2002(b) of CFR 47, 2004) to this application, including myself, is subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C., 862. Regards, Renji Inuzuka Director, Engineering and Quality Uniden America Corporation

Uniden America Corporation 3001 Gateway Drive, Suite 130 Irving, TX 75063 817-858 -3300 Fax: 817-858-3333 REQUEST FOR CONFIDENTIALITY August 11, 2015 To whom it may concern, Request for Permanent Confidentiality Under FCC Part 95 Certification FCC ID: [AMWON525] Request is hereby submitted by Uniden America Corporation to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR § 0.457(d) and § 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential and Uniden America Corporation reserves the right to discern which parties can obtain access to these information: • Schematics • Detailed Block diagrams • Detailed Operational/Functional Description • Parts List • Tune up Procedures • Operational Description The rationale for request for confidentiality is as followings: This information represents intellectual property of Uniden America Corporation and it is subject to competition. We have invested considerable time and materials in research and development to produce the referenced product. Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. If you have questions or need further information, please contact the undersigned. Regards, Renji Inuzuka Director Engineering and Quality

Uniden America Corporation 3001 Gateway Drive, Suite 130 Irving, TX 75063 817-858 -3300 Fax: 817-858-3333 Appendix C5 FCC Labeling Requirements (Updated on Jan 17, 2007) The FCC identifier shall be permanently affixed to the exterior of the device and shall be readily visible to the purchaser at the time of purchase. As an option to placing the FCC label on the exterior of the device, the FCC label can be placed in a user accessible area (e.g. battery compartment) if ALL of the following conditions are met. 1. The device is handheld (e.g. handset). 2. The FCC identifier is visible at the time of purchase. Marketing the device without the battery installed when the label is in the battery compartment is acceptable. Providing instruction (stated on the box, user manual, or additional documentation) directing the user as to where to find the FCC label also satisfies this requirement. 3. The user accessible area must not require any special tools for access and the FCC label must not be placed on a removable part. 4. The FCC identifier, model no. or FCC logo must be on the label and must meet all general labeling requirements or policies that apply for Certification, Verification or DOC; e.g. for Certification, for handheld devices, the identifier must go on the label but the two part warning statement in Section 15.19(a)3 can go in the manual. Uniden America Corporation 3001 Gateway Drive, Suite 130 Irving, TX 75063 817-858-3300 Fax: 817-858-3333 8/11/2015 To whom it may concern, Label Location Justification [FCC ID: AMWON525] Request is hereby submitted by Uniden America Corporation to request an alternative method of positively identifying the equipment, pursuant to 47 CFR § 2.925(f) of the FCC Rules. The FCC identifier for radio unit will be placed in the battery compartment and the following requirements are confirmed to meet: a) The FCC identifier will visible at the time of purchase, by either of the following approaches:  Marketing the device without the battery installed, or  Providing instruction (stated on the box, user manual, or additional documentation) directing the user as to where to find the FCC label. b) The user accessible area will not require any special tools for access and the FCC label will not be placed on a removable part. The user manual has already included the FCC statements, pursuant to 47 CFR § 15.19(a)(3), 15.21 and 15.105(b). If you have questions or need further information, please contact the undersigned. Regards, Renji Inuzuka Director, Engineering and Quality Uniden America Corporation

INTERTEK TESTING SERVICE Report No.: 15071281HKG-001 FCC ID: AMWON525 Equipment Photographs Model: GMR3055-2CK (External)

UNIDEN AMERICA CORP. MODEL: GMR3050-3VP FCC ID: AMWON525 IC: 513C-ON525 S/N: 0915000001 Made In China UNIDEN AMERICA CORP. MODEL: GMR3050-3VP FCC ID: AMWON525 IC: 513C-ON525 S/N: 0915000001 Made In China 机贴纸 尺寸：27*12MM The label would be permanently affixed to the equipment and readily visible to the purchaser at the time of purchase UNIDEN AMERICA CORP. MODEL: GMR3050-2CK FCC ID: AMWON525 IC: 513C-ON525 S/N: 0915000001 Made In China UNIDEN AMERICA CORP. MODEL: GMR3050-2CK FCC ID: AMWON525 IC: 513C-ON525 S/N: 0915000001 Made In China 机贴纸 尺寸：27*12MM The label would be permanently affixed to the equipment and readily visible to the purchaser at the time of purchase UNIDEN AMERICA CORP. MODEL: GMR3050-2C FCC ID: AMWON525 IC: 513C-ON525 S/N: 0915000001 Made In China UNIDEN AMERICA CORP. MODEL: GMR3050-2C FCC ID: AMWON525 IC: 513C-ON525 S/N: 0915000001 Made In China 机贴纸 尺寸：27*12MM The label would be permanently affixed to the equipment and readily visible to the purchaser at the time of purchase UNIDEN AMERICA CORP. MODEL: GMR3055-2CKHS FCC ID: AMWON525 IC: 513C-ON525 S/N: 0915000001 UNIDEN AMERICA CORP. GMRS Charger Model: RC656R Input: DC 5.0V, 550mA Made in China Made In China UNIDEN AMERICA CORP. MODEL: GMR3055-2CKHS FCC ID: AMWON525 IC: 513C-ON525 S/N: 0915000001 Made In China 机贴纸 尺寸：27*12MM The label would be permanently affixed to the equipment and readily visible to the purchaser at the time of purchase UNIDEN AMERICA CORP. GMRS Charger Model: RC656R Input: DC 5.0V, 550mA Made in China

INTERTEK TESTING SERVICE Report No.: 15071281HKG-001 FCC ID: AMWON525 Equipment Photographs Model: GMR3055-2CK (Internal) INTERTEK TESTING SERVICE Report No.: 15071281HKG-001 FCC ID: AMWON525 Equipment Photographs Model: GMR3055-2CK (Internal) INTERTEK TESTING SERVICE Report No.: 15071281HKG-001 FCC ID: AMWON525 Equipment Photographs Model: GMR3055-2CK (Internal) INTERTEK TESTING SERVICE Report No.: 15071281HKG-001 FCC ID: AMWON525 Equipment Photographs Model: GMR3055-2CK (Internal) INTERTEK TESTING SERVICE Report No.: 15071281HKG-001 FCC ID: AMWON525 Equipment Photographs Model: GMR3055-2CK (Internal) INTERTEK TESTING SERVICE Report No.: 15071281HKG-001 FCC ID: AMWON525 Equipment Photographs Model: GMR3055-2CK (Internal)

- Intertek’s standard Terms and Conditions can be obtained at our website: http://www.intertek.com/terms/. - The test report only allows to be revised the retention period issued date unless further standard or the requirement was noticed. - This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Website: www.hk.intertek-etlsemko.com Uniden America Corporation Application For FCC Part 95 - Certification Two Ways Radio of GMRS, FRS, Weather Band receiver (FCC ID: AMWON525) 15071281HKG-001 MN/ cl August 26, 2015 INTERTEK TESTING SERVICES Test Report Number: 15071281HKG-001 FCC ID: AMWON525 Page 1 of 63 MEASUREMENT/TECHNICAL REPORT Applicant : Uniden America Corporation Trade Name/Model No : Uniden / GMR3055-2CK GMR3050-2C, GMR3050-3VP, GMR3055-2CKHS Date : August 26, 2015 This report concerns (check one:)Original Grant X Class II Change Equipment Type: FRF – Part 95 Family Radio Face Held Transmitter CXX - Communications Rcvr for use w/ licensed Tx and CBs Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Report prepared by: Nip Ming Fung, Melvin Intertek Testing Services Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Phone: 852-2173-8535 Fax: 852-2741-1693 INTERTEK TESTING SERVICES Test Report Number: 15071281HKG-001 FCC ID: AMWON525 Page 2 of 63 Table of Contents 1.0 General Description..............................................................................................................4 1.1 Product Description..............................................................................................................4 1.2 Related Submittal(s) Grants................................................................................................5 1.3 Test Methodology.................................................................................................................5 1.4 Test Facility...........................................................................................................................5 2.0 System Test Configuration.................................................................................................7 2.1 Justification...........................................................................................................................7 2.2 EUT Exercising Software....................................................................................................8 2.3 Special Accessories.............................................................................................................8 2.4 Measurement Uncertainty...................................................................................................8 2.5 Equipment Modification.......................................................................................................8 2.6 Support Equipment..............................................................................................................8 3.0 RF Power Output (Section 2.1046(a), 95.639(d))........................................................10 4.0 Modulation Characteristics (Section 2.1047(a)(b), 95.637(a))....................................14 4.1 Modulation Frequency Response...................................................................................15 4.2 Modulation Limiting Characteristics...............................................................................18 4.3 Audio Low Pass Filter Response....................................................................................21 5.0 Occupied Bandwidth (Section 95.633(c)).....................................................................25 6.0 Spurious Emission.............................................................................................................29 6.1 Power of Spurious Radiation (Section 2.1053, 95.635(b)).........................................30 6.2 Field Strength of Radiation Emission (Section 15.109).................................................38 7.0 Frequency Stability (Section 2.1055(a)(b)(d), 95.621(b), 95.626(b)).........................56 7.1 Frequency Tolerance........................................................................................................57 7.2 Temperature Extreme Condition.....................................................................................59 7.3 Voltage Extreme Condition..............................................................................................61 8.0 Equipment List....................................................................................................................63 INTERTEK TESTING SERVICES Test Report Number: 15071281HKG-001 FCC ID: AMWON525 Page 3 of 63 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES Test Report Number: 15071281HKG-001 FCC ID: AMWON525 Page 4 of 63 1.0 General Description 1.1 Produc…
