AMWUA2001RADAR DETECTOR

LONG RANGE Radar/Laser Detector User’s Manual R9 © 2020 Uniden America Corporation Irving, Texas Issue 1, February 2020 Printed in Korea CUSTOMER CARE At Uniden®, we care about you! If you need assistance, please do NOT return this product to your place of purchase Save your receipt/proof of purchase for warranty. Quickly find answers to your questions by: • Reading this User’s Manual. • Visiting our customer support website at www.uniden.com. Images in this manual may differ slightly from your actual product. DISCLAIMER: Radar detectors are illegal in some states. Some states prohibit mounting any object on your windshield. Check applicable law in your state and any state in which you use the product to verify that using and mounting a radar detector is legal. Uniden radar detectors are not manufactured and/or sold with the intent to be used for illegal purposes. Drive safely and exercise caution while using this product. Do not change settings of the product while driving. Uniden expects consumer’s use of these products to be in compliance with all local, state, and federal law. Uniden expressly disclaims any liability arising out of or related to your use of this product. CONTENTS CUSTOMER CARE ..........................................................................................................2 R9 EXTREME OVERVIEW ............................................................................5 FEATURES ........................................................................................................................5 WHAT’S IN THE BOXES? .............................................................................6 PARTS OF THE R9 EXTREME ......................................................................7 KEY PAD ............................................................................................................................7 DISPLAY UNIT .................................................................................................................9 MENU SYSTEM .........................................................................................11 BASIC OPERATIONS ................................................................................21 FEATURE DETAILS ...................................................................................22 LASER TRANSPONDER SETTING FOR DRAGON EYE ....................................22 AUTO DIM ......................................................................................................................23 Configure Auto Dim from MENU ..................................................................23 ALLOCATING MEMORY ............................................................................................23 USER MARKS (LASER AND RADAR SITES) .........................................................24 RED LIGHT CAMERA POINT DELETE ...................................................................25 HIGHWAY VS CITY MODE ........................................................................................25 POP MODE ....................................................................................................................26 MODE DISPLAY ............................................................................................................26 SCAN DISPLAY .............................................................................................................26 TIME DISPLAY ...............................................................................................................27 ALARM PRIORITIES.....................................................................................................27 THREATS .........................................................................................................................28 AUTO MUTE/AUTO MUTE VOLUME.....................................................................29 USER SPEED LIMIT ......................................................................................................29 QUIET RIDE ....................................................................................................................30 RED LIGHT CAMERA QUIET RIDE .........................................................................30 MAINTENANCE ........................................................................................30 MAINTAINING THE EQUIPMENT ...........................................................................30 UPDATING THE FIRMWARE/DATABASE .............................................................30 TROUBLESHOOTING ...............................................................................30 FCC/IC COMPLIANCE ..............................................................................31 FCC COMPLIANCE ......................................................................................................31 IC COMPLIANCE ..........................................................................................................32 ONE-YEAR LIMITED WARRANTY ...........................................................32 - 5 - UNIDEN LONG RANGE RADAR/LASER DETECTOR USER’S MANUAL R9 EXTREME R9 EXTREME OVERVIEW Uniden’s R9 Extreme is an advanced installed laser rdar detector with actual laser interruption capability. It provides outstanding detection range and usability. FEATURES • GPS on/off • User Mark Alert • Mute on/off and Mute Memory • Store and Update Database (up to 20,000 points should it be 2,000 points? • POI Alert on.off (Speed Camerra Alarm and Red-Light Camera Alarm) • Red-Light Camera Delete • Red-Light Camera Quiet Ride on/off • Front/Read X, K, MRCD, KA, POP, and Laser Detectuion on/off • OLED display (16 x 32 Full Color) • Keyboard (Mute, Dim, Volume +, Volume -, Mark, Menu, Power) • Volume Control (0 - 8) • Dim Mode (Auto, Bright, Dim, Dimmer, Dark, Off) • Operating Modes (Highway, City, Advanced) • Scan, Mode, and Time Displays • Background Color Options • Speed, Speed+Compass, Compass, Voltage, Alti…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (obsolete) 4.0 5.0 Sep-16-2014 Updated company name & logo (current) 5.0 6.0 Jun-27-2018 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 6.0 Uniden America Corporation 3001 Gateway Drive, Suite 130, Irving Texas 75038 United States Tel. 817-858-3624 / Fax. N/A January 20, 2020 To: BVCPS, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, Uniden America Corporation, hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: AMWUA2001 Product Description: RADAR DETECTOR Model: R9 Sincerely, Paul Roby / Manager, Regulatory and Quality Uniden America Corporation

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 6.0 Uniden America Corporation 3001 Gateway Drive, Suite 130, Irving Texas 75038 United States Tel. 817-858-3624 / Fax. N/A January 20, 2020 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: AMWUA2001 Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Paul Roby / Manager, Regulatory and Quality Uniden America Corporation SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 6.0 Uniden America Corporation 3001 Gateway Drive, Suite 130, Irving Texas 75038 United States Tel. 817-858-3624 / Fax. N/A January 20, 2020 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: AMWUA2001 To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47, and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days from the Grant Date. See KDB 726920. - e.g. User Manual - e.g. Internal Photos - e.g. Test Setup photos - e.g. External Photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Paul Roby / Manager, Regulatory and Quality Uniden America Corporation

http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval External photos of EUT http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval

<Label format> Bottom of the device

http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval Internal photos of EUT Inside http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval Main Board http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval SUB Board

verify No.483657374048 KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SEF0004-C Page (2) of (16) KCTL-TIT004-006/1 KP19-07362 REPORT REVISION HISTORY Date Revision Page No 2020-01-14 Originally issued - 2020-02-03 Contact name information change and Added comment for Note 1) 4, 13 2020-02-04 Modify product specification 9 2020-02-18 Product specification typo 9, 12 Note. The report No. KR20-SEF0004-B is superseded by the report No. KR20-SEF0004-C This report shall not be reproduced except in full, without the written approval of KCTL Inc. This document may be altered or revised by KCTL Inc. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by KCTL Inc. will constitute fraud and shall nullify the document. KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SEF0004-C Page (3) of (16) This test report shall not be reproduced, except in full, without the written approval. KCTL-TIT004-006/1 KP19-07362 Contents 1. Applicant information ..................................................................................................................... 4 2. Laboratory information ................................................................................................................... 5 3. Test system configuration .............................................................................................................. 6 3.1 Operation environment ....................................................................................................... 6 3.2 Measurement Uncertainty .................................................................................................. 7 4. Description of EUT .......................................................................................................................... 9 4.1 General information ............................................................................................................ 9 4.2 Product description ........................................................................................................... 10 4.3 Auxiliary equipments ........................................................................................................ 10 4.4 Test configuration .............................................................................................................. 11 4.5 Operating conditions ........................................................................................................ 12 5. Summary of test results ............................................................................................................... 13 5.1 Summary of EMI emission test results ............................................................................. 13 6. Test results .................................................................................................................................... 14 6.1 Radiated Emission ........................................................................................................... 14 KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SEF0004-C Page (4) of (16) This test report shall not be reproduced, except in full, without the written approval. KCTL-TIT004-006/1 KP19-07362 1. Applicant information Applicant: Uniden America Corporation Address: 6225 N. State highway 161, Suite 300, Irving Texas 75038 Telephone: +817-858-3624 Fax: +817-858-3219 E-mail: [email protected] Contact name: Paul Roby Manufacturer: ATTOWAVE Co., Ltd. Address: 1005, 10F Leader`s Tower, 60-15 Gasan-dong, Gumchun-gu, Seoul, 153-801, Korea KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SEF0004-C Page (5) of (16) This test report shall not be reproduced, except in full, without the written approval. KCTL-TIT004-006/1 KP19-07362 2. Laboratory information Address KCTL Inc. (Suwon Lab.) 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Telephone Number: 82 31 285 0894 Facsimile Number: 82 505 299 8311 FCC Site Designation No: KR0040 VCCI Registration No. : R-20080, G-20078, C-20059, T-20056 Industry Canada Registration No. : 8035A KOLAS NO.: KT231 SITE MAP KCTL Inc. Suwon city KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SEF0004-C Page (6) of (16) This test report shall not be reproduced, except in full, without the written approval. KCTL-TIT004-006/1 KP19-07362 3. Test system configuration 3.1 Operation environment Temperature Humidity Pressure Chamber 10 m(RE) 21.4 °C 27.8 % R.H. - Test site These testing items were performed following locations; Test item Test site Conducted Emission Shielded Room Radiated Emission 10 m Chamber KCTL Inc. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-31-285-0894 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR20-SEF0004-C Page (7) of (16) This test report shall not be reproduced, except in full, without the written approval. KCTL-TIT004-006/1 KP19-07362 3.2 Measurement Uncertainty All measurements involve certain levels of uncertainties, especially in field of EMC. The factors contributing to uncertainties are test receiver, cable loss, antenna factor calibration, Antenna directivity, antenna factor variation with height, antenna phase center variation, antenna frequency interpolation, measurement distance variation, site imperfection, mismatch, and system repeatability. Based on CISPR 16-4-2, the measurement uncertainty level with a 95 % confidence level was applied. Conducted Emission measurement (Confidence level about 95 %, k = 2) Shi…

Text truncated - open the document above for the full version.

http://www.kctl.co.kr This test report shall not be reproduced, except in full, without the written approval Test setup photos - Radiated Emission 11.7 GHz ~ 12.2 GHz
