AMWUB328PORTABLE TYPE SCANNER

BCD396T OWNER’S MANUAL OWNER’S MANUAL (INDICATES INFORMATION SUBJECT TO * * AND/OR DELETION)CHANGE Revision 1; 031005 2 Precautions Precautions Before you use this scanner, please read and observe the following. IMPORTANT! This scanning radio has been manufactured so that it will not tune to the radio frequencies assigned by the FCC for cellular telephone usage. The Electronic Communications Privacy Act of 1986, as amended, makes it a federal crime to intentionally intercept cellular or cordless telephone transmissions or to market this radio when altered to receive them. The installation, possession, or use of this scanning radio in a motor vehicle may be prohibited, regulated, or require a permit in certain states, cities, and/or local jurisdictions. Your local law enforcement officials should be able to provide you with information regarding the laws in your community. Changes or modifications to this product not expressly approved by Uniden, or operation of this product in any way other than as detailed by this Operating Guide, could void your authority to operate this product. EARPHONE WARNING! Be sure to use only a monaural earphone with this scanner. You can also use an optional 32 Ω stereo headset. Use of an incorrect earphone or stereo headset might be potentially hazardous to your hearing. The output of the phone jack is monaural, but you will hear it in both headphones of a stereo headset. Set the volume to a comfortable audio level coming from the speaker before plugging in the monaural earphone or a stereo headset of the proper impedance (32 Ω). Otherwise, you might experience some discomfort or possible hearing damage if the volume suddenly becomes too loud because of the volume control or squelch control setting. This might be particularly true of the type of earphone that is placed in the ear canal. Precautions 3 Precautions WARNING! Uniden does not represent this unit to be waterproof. To reduce the risk of fire or electrical shock, do not expose this unit to rain or moisture. Astro ® , DPL ® , Digital Private Line ® , Motorola ® , PL ® , PRIVACY PLUS ® , Private Line ® , SMARTNET ® ,and SMARTZONE ® are registered trademarks of Motorola, Inc. LTR ® is a registered trademark of E.F. Johnson Co. EDACS ® is a registered trademark of M/A-COM Private Radio Systems Inc. Uniden ® and Bearcat ® are registered trademarks of Uniden America Corporation. TrunkTracker ™ , Trunk Tracking ™ , and Close Call ™ are proprietary trademarks of Uniden America Corporation. Other trademarks used throughout this manual are the property of their respective holders. 4 Contents Contents Precautions 2 Contents 4 The FCC Wants You to Know 8 Scanning Legally 8 Introduction 10 Feature Highlights 11 About This Manual 16 Using the Multifunction Scroll Control 16 Entering Text 16 How the Scanner’s Controls Are Represented in This Manual 17 Understanding Scanning 19 Understanding the Scanner’s Memory 19 What is Scanning? 19 What is Searching? 20 What is CTCSS/DCS? 20 Conventional Scanning 22 Simplex Operation 23 Repeater Operation 23 What is Trunk Tracking? 23 Trunked Scanning 24 Types of Trunking Systems 25 Motorola Trunking 25 EDACS Trunking 27 LTR Trunking 28 I-Call (Motorola/EDACS) 29 Where To Get More Information 29 Information On The Internet 29 Included With Your Scanner 31 Setting Up Your Scanner 32 Using Internal Batteries 32 Using Rechargeable Batteries 34 Removing the Display Sticker 35 Using AC Power 35 Connecting the Antenna 35 Connecting an Optional Antenna 35 Connecting an Earphone/Headphone 36 Connecting an Extension Speaker 36 Attaching the Belt Clip 36 Attaching the Wrist Strap 36 A Look At The Keypad 37 A Look At The Display 41 Using Menu 42 Using Func 42 Basic Operation 43 Turning On the Scanner and Setting the Squelch 43 Scanning Systems 43 Preprogrammed System Tips 44 Selecting Systems to Scan 45 Selecting System Channel Groups 45 Locking/Unlocking Systems 46 Locking/Unlocking Channels 46 ID Scan/ID Search Mode 46 Temporarily Holding On a System 47 Holding On a Channel 47 Quickly Storing an ID During ID Search 47 Quick-Storing Channels or Talk Group ID’s 47 Quickly Recalling Channels 48 Monitoring Trunking Activity 48 Using the Menu 49 Programming Systems Menu 51 Other Settings 53 Displaying System Information 53 Contents 5 Contents Viewing Memory Used 53 Viewing the Firmware Version 53 Adjusting the Key Beep 53 Locking/Unlocking the Keypad 53 Turning Power Save On or Off 54 Priority Scan 54 Other Settings 54 Using the Backlight 54 Setting the Audio AGC 55 Adjusting the Display Contrast 55 Initializing the Scanner’s Memory 55 Connecting Your Scanner to a Personal Computer 56 Using the Cloning Options 56 Wired Cloning 57 On-Air Cloning 58 Programming Radio Systems 59 Programming Conventional Systems 60 Entering/Editing Conventional Channel Groups 60 Entering/Editing Conventional Channels 61 Programming Motorola Systems 62 Setting System Frequencies 63 Setting Modulation 64 Setting Attenuation 64 Entering/Editing Motorola Channel Groups 65 Entering/Editing Motorola Channels 66 Programming EDACS Systems 66 Setting System Frequencies 68 Entering/Editing EDACS Channel Groups 68 Entering/Editing EDACS Channels 69 Programming LTR Systems 69 Setting System Frequencies 70 Entering/Editing LTR Channel Groups 70 Entering/Editing LTR Channels/Talkgroups 71 Programming/Editing Optional Settings 72 System-Level Settings 72 Editing the System Name 72 Editing the System Quick Key 73 Setting System Lockout 73 Setting the System Hold Time 74 Setting the Channel Delay Time 74 Setting ID Scan/Search (Trunked Systems Only) 75 Editing the Fleet Map (Motorola Systems Only) 75 Setting the Motorola Status Bit (Motorola Systems Only) 76 Setting the End Code Operation (Motorola Systems Only) 77 Setting I-Call (Motorola Analog and EDACS Systems Only) 77 Setting Emergency Alert (Motorola and EDACS Systems Only) 78 Setting Control-Channel Only (Motorola Systems Only) 78 Reviewing Locked Out Frequencies 79 Clearin…

Text truncated - open the document above for the full version.

GENERAL INFORMATION General Information in accordance with the Federal Communications Commission Rules and Regulations, Volume II, Part 2. (1) Applicant: Uniden America Corporation 181 N. Country Club Road, P.O. Box 580 Lake City, South Carolina 29560 Mr. James R. Haynes, Vice President (2) FCC Identifier: FCC ID: AMWUB3328 MODEL NO.: (3) Instruction Manual: Refer to User Manual (4) Circuit Description: Refer to Operational Description (5) Circuit & Block Diagrams: Refer to Schematics Block diagrams (6) Measurement Data: Refer to Test Report Standard Test Conditions: The following conditions and procedures were followed during testing of the equipment. Room Temperature: 23 - 27 Degrees Celsius Room Humidity: 40 - 60 % Note 1: This equipment is intended to use with; 3 AA battery Note 2: Prior to testing, the unit is tuned-up according to the manufacturer's alignment procedure. All presented data will represent the "worst case" parameter being measured. (7) Photographs & Equipment Identification: Refer to ID Label/Location Info & External Photos (8) Peripheral or Accessory Device: Not used (9) Transition provisions in section 15.37 Rules: This equipment complies with the new Part 15 of FCC rules and is not affected by section 15.37. (10) Decoding the Emergency Broadcast System Attention Signal: Not Applicable (11) Direct Sequence Spread Spectrum Transmitter: Not Applicable (12) Compliance to Cellular Band Exclusion: Pursuant to the requirements contained in Part 15.121 of the Commission's Rules, this scanning receiver does not have the capability of tuning the frequencies assigned to the Domestic Public Cellular Radio Telecommunications Service. In this circuitry, this device is not readily alterable to restore the cellular band coverage because the inventory of frequencies contained within this band is not available in the microprocessor. Also, the microprocessor is fixed soldered and not easily removable. In addition, the critical circuitry is "hardened" with a black epoxy that covers the area of the circuitry that might be modified to circumvent the design efforts referenced above. Therefore, since the clipping of leads; or the installation of a simple component such as a diode, resistor, or a jumper wire; or the reprogramming of any semiconductor device contained within this unit cannot be accomplished using a special access code or a personal computer; This is to certify that the conditions mandated in part 15.121 have been met.

UNIDEN AMERICA CORPORATION. FCC ID: AMWB328 EXTERNAL PHOTOGRAPHS

ID Label/Location Info Equipment Identification Label The FCC Label complies with the section 2.925(d) of the FCC Rules and will be permanently affixed to the equipment. 1) FCC STETEMENT: Size: 42 mm (W) by 18 mm (H) 2) FCC LABEL: Size: 36 mm (W) by 22 mm (H)

TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB328 REPORT #: U/Uniden AMW/470AUT5/470AUT5TestReport.doc TABLE OF CONTENTS LIST TABLE OF CONTENTS LIST APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB328 TEST REPORT CONTAINING: PAGE 1......TEST EQUIPMENT LIST PAGE 2......TEST PROCEDURE PAGE 3-5....RADIATION INTERFERENCE TEST DATA PAGE 6......38dB REJECTION RATIO EXHIBITS CONTAINING: BLOCK DIAGRAM SCHEMATICS INSTRUCTION MANUAL SAMPLE OF FCC ID LABEL AND SKETCH OF LOCATION RADIATED TEST SETUP PHOTOGRAPH EXTERNAL PHOTOS INTERNAL PHOTOS CIRCUIT DESCRIPTION TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB328 REPORT #: U/Uniden AMW/470AUT5/470AUT5TestReport.doc Page 1 of 6 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB328 EMC Equipment List Device Manufacturer Model Serial Number Cal/Char Date Due Date 3/10-Meter OATS TEI N/A N/A Listed 3/27/04 3/26/07 3-Meter OATS TEI N/A N/A Listed 1/13/03 1/12/06 Biconnical Antenna Eaton 94455-1 1057 CAL 3/18/03 3/18/05 Biconnical Antenna Eaton 94455-1 1096 CAL 8/17/04 8/17/06 Biconnical Antenna Electro- Metrics BIA-25 1171 CAL 4/26/01 4/26/03 Blue Tower Quasi-Peak Adapter HP 85650A 2811A01279 CAL 4/15/03 4/15/05 Blue Tower RF Preselector HP 85685A 2620A00294 CAL 4/27/04 4/27/06 Blue Tower Spectrum Analyzer HP 8568B 2928A04729 2848A18049 CAL 4/15/03 4/15/05 LISN Electro- Metrics ANS-25/2 2604 CAL 8/27/04 8/27/06 LISN Electro- Metrics EM-7820 2682 CAL 3/12/03 3/12/05 Log- Periodic Antenna Eaton 96005 1243 CAL 5/8/03 5/8/05 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB328 REPORT #: U/Uniden AMW/470AUT5/470AUT5TestReport.doc Page 2 of 6 TEST PROCEDURE GENERAL: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. RADIATION INTERFERENCE: The test procedure used was ANSI STANDARD C63.4-2003 using a HEWLETT PACKARD spectrum analyzer with a preselector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 100KHz and the video bandwidth was 300KHz. The ambient temperature of the UUT was 80oC with a humidity of 76%. FORMULA OF CONVERSION FACTORS: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBuV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) METER READING + ACF = FS 33 20 dBuV + 10.36 dB = 30.36 dBuV/m @ 3m ANSI STANDARD C63.4-2003 10.1.7 MEASUREMENT PROCEDURES: The unit under test was placed on a table 80 cm high and with dimensions of 1m by 1.5m. The table used for radiated measurements is capable of continuous rotation. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and vertical planes. TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB328 REPORT #: U/Uniden AMW/470AUT5/470AUT5TestReport.doc Page 3 of 6 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB328 NAME OF TEST: RADIATION INTERFERENCE RULES PART NUMBER: 15.109 REQUIREMENTS: 30 to 80 MHz: 40.0 dBuV/M @ 3 METERS 88 to 216 MHz: 43.5 dBuV/M 216 to 960 MHz: 46.0 dBuV/M ABOVE 960 MHz: 54.0 dBuV/M TEST RESULTS: A search was made of the spectrum from 30 to 1000 MHz and the measurements indicate that the unit DOES meet the FCC requirements. TEST DATA: Tuned Frequency MHz Emission Frequency MHz Meter Reading dBuV Ant. Polarity Coax Loss dB Correction Factor dB Field Strength dBuV/m Margin dB 25.0 405.73 10.1 H 1.21 16.27 27.58 12.42 25.0 405.73 11.3 V 1.21 16.11 28.62 11.38 40.8 421.53 9.2 V 1.22 16.28 26.70 13.3 40.8 421.53 9.9 H 1.22 16.70 27.82 12.18 54.0 434.63 9.7 H 1.23 16.70 27.63 12.37 54.0 434.63 10.0 V 1.23 16.29 27.52 12.48 54.1 434.72 9.0 H 1.23 16.70 26.93 13.07 54.1 434.72 10.1 V 1.23 16.29 27.62 12.38 72.0 452.71 8.8 V 1.25 16.83 26.88 13.12 72.0 452.71 10.2 H 1.25 17.18 28.63 11.37 107.9 488.59 9.8 H 1.29 18.34 29.43 14.07 107.9 488.59 10.1 V 1.29 17.62 29.01 14.49 118.8 499.50 9.6 H 1.30 18.78 29.68 13.82 118.8 499.50 10.5 V 1.30 17.89 29.69 13.81 127.2 507.81 9.9 V 1.32 17.98 29.20 14.3 127.2 507.81 10.4 H 1.32 19.03 30.75 12.75 135.5 516.24 9.5 H 1.35 19.16 30.01 13.49 135.5 516.24 10.5 V 1.35 18.25 30.10 13.4 138.2 518.84 9.8 H 1.36 19.19 30.35 13.15 138.2 518.84 9.8 V 1.36 18.35 29.51 13.99 162.0 542.61 9.8 V 1.43 18.23 29.46 14.04 162.0 542.61 10.0 H 1.43 18.73 30.16 13.34 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB328 REPORT #: U/Uniden AMW/470AUT5/470AUT5TestReport.doc Page 4 of 6 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB328 NAME OF TEST: RADIATION INTERFERENCE RULES PART NUMBER: 15.109 REQUIREMENTS: 30 to 80 MHz: 40.0 dBuV/M @ 3 METERS 88 to 216 MHz: 43.5 dBuV/M 216 to 960 MHz: 46.0 dBuV/M ABOVE 960 MHz: 54.0 dBuV/M TEST DATA CONTD. Tuned Frequency MHz Emission Frequency MHz Meter Reading dBuV Ant. Polarity Coax Loss dB Correction Factor dB Field Strength dBuV/m Margin dB 173.2 553.90 9.9 H 1.46 18.92 30.28 13.22 173.2 553.90 1…
