Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
BC125AT Owners Manual C 2011 Uniden America Corporation Printed in Vietnam Fort Worth, Texas U01UB370ZZZ(0) Precautions Before you use this scanner, please read and observe the following. EARPHONE WARNING! Be sure to use only a monaural earphone with this scanner. You can also use an optional mono headset. Use of an incorrect earphone or mono headset might be potentially hazardous to your hearing. The output of the phone jack is monaural, but you will hear it in both headphones of a stereo headset. Set the volume to a comfortable audio level coming from the speaker before plugging in the monaural earphone or headset. Otherwise, you might experience some discomfort or possible hearing damage if the volume suddenly becomes too loud because of the volume control or squelch control setting. This might be particularly true of the type of earphone that is placed in the ear canal. WARNING! Uniden does not represent this unit to be waterproof. To reduce the risk of fire or electrical shock, do not expose this unit to rain or moisture. Uniden® is a registered trademark of Uniden America Corporation. Close Call™ is a trademark of Uniden America Corporation. contents the Fcc Wants You to KnoW . . . . . . . . . . . . . . . . . . . . . . . . .7 scanning LegaLLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Feature highLights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 FrequencY range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 incLuded With Y our scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 oPtionaL accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 scanning Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 What is scanning? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 What is searching? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17 understanding scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 What is CTCSS/DCS? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 Conventional Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19 Simplex Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Repeater Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 understanding BanKs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Channel Storage Banks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 Service Search Banks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Custom Search Banks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 Where to Learn More . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21 setting uP Your scanner . . . . . . . . . . . . . . . . . . . . . . . . . . .23 connecting the antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Connecting an Optional Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 connecting an earPhone/headPhone . . . . . . . . . . . . . . . . . . . . . . . .24 connecting an extension sPeaKer . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 adjusting the BeLt cLiP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 connecting to a coMPuter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 PoWering the scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25 Installing Non-Rechargeable Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . .26 Installing Rechargeable Ni-MH Batteries . . . . . . . . . . . . . . . . . . . . . . . . . .26 Charging the Ni-MH Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27 aBout Y our scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 getting to KnoW the scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29 turning on the scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 setting uP Your scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32 Using the SCROll CONTROl Knob . . . . . . . . . . . . . . . . . . . . . . . . . . .33 Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33 Adjusting the Squelch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34 Setting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34 Adjusting the Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35 Setting the Charging Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36 Using the Keypad lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Setting the Beep Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 Resetting the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 controLs, KeYs, and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 a LooK at the disPLaY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 PrograMMing channeLs . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 PrograMMin…
Text truncated - open the document above for the full version.
Uniden America Corporation 4700 Amon Carter Blvd. Fort Worth, TX 76155 817-858-3300 Fax: 817-858-3328 FCC Declaration Letter November 22, 2011 To: Federal Communications Commission Equipment Authorization Branch, Lab Div., OET 7435 Oakland Mills Road Columbia, Maryland 21046 Subject: Compliance to Cellular Band Exclusion Applicant: Uniden America Corporation 4700 Amon Carter Blvd. Fort Worth, Texas 76155 Jon Suehiro, Manager, Engineering and Regulatory Affairs FCC Identifier: AMWUB370 Pursuant to the requirements contained in Part 15.121 of the Commission's Rules, this scanning receiver does not have the capability of tuning the frequencies assigned to the Domestic Public Cellular Radio Telecommunications Service. In this circuitry, this device is not readily alterable to restore the cellular band coverage because the inventory of frequencies contained within this band is not available in the microprocessor. Also, the microprocessor is fixed soldered and not easily removable. In addition, the critical circuitry is "hardened" with a black epoxy that covers the area of the circuitry that might be modified to circumvent the design efforts referenced above. Therefore, since the clipping of leads; or the installation of a simple component such as a diode, resistor, or a jumper wire; or the reprogramming of any semiconductor device contained within this unit cannot be accomplished using a special access code or a personal computer; This is to certify that the conditions mandated in part 15.121 have been met. Please contact the undersigned if you have any questions or need any further information. Regards, Jon Suehiro Manager, Engineering and Regulatory Affairs
Uniden America Corporation 4700 Amon Carter Blvd. Fort W orth, TX 76155 817-858-3300 Fax: 817-858-3328 REQUEST FOR CONFIDENTIALITY October 28, 2011 To: Federal Communications Commission Equipment Authorization Branch Laboratory Division Office of Engineering and Technology 7435 Oakland Mills Road Columbia, Maryland 21046 Subject: Data for FCC Certification Applicant: Uniden America Corporation 4700 Amon Carter Boulevard Fort Worth, Texas 76155 Jon Suehiro - Manager, Engineering and Regulatory Affairs TYPE OF EQUIPMENT: Portable Scanning Receiver FCC IDENTIFIER: AMWUB370 Dear Sir or Madam: Some of the material included in this application contains trade secrets and proprietary information not customarily released to the public. Because public disclosure of the material might be harmful to the applicant and provide unjustified benefits to its competitors, it is requested that the following be withheld from public disclosure: Circuit Description Schematic Diagrams Block Diagrams Trade secrets and proprietary information can be held confidential. Therefore, we wish to invoke the act under the provisions of 47CFR, Sections 0.457(d) and 0.459. Please contact the undersigned if you have any questions or need any further information. Regards, Jon Suehiro Manager, Engineering and Regulatory Affairs
ID Label/Location Info Equipment Identification Label The FCC Label complies with the section 2.925(d) of the FCC Rules and will be permanently affixed to the equipment.
FCC PART 15 SCANNING RECEIVER Applicant UNIDEN AMERICA CORPORATION Address 4700 AMON CARTER BLVD. FORT WORTH TEXAS 76155 USA FCC ID: AMWUB370 Model Number BC125AT Product Description SCANNING RECEIVER Date Sample Received 10/26/2011 Date Tested Nam Nguyen Tested By 11/14/2011 Approved By Mario de Aranzeta Report Number 2499AT11TestReport.doc Test Results PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW State Road 45 Newberry, Fl 32669 USA Phone: 888.472.2424 or 352.472.5500 Fax: 352.472.2030 Email: [email protected] Website: www.timcoengr.com Certificate # 0955-01 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB370 REPORT #: U\UNIDEN AMW\2499AT11\2499AT11TestReport.doc Page 2 of 12 TABLE OF CONTENTS GENERAL REMARKS ............................................................................................................... 3 GENERAL INFORMATION ........................................................................................................ 4 TEST EQUIPMENT LIST ........................................................................................................... 5 TEST PROCEDURE .................................................................................................................. 6 RADIATED SPURIOUS EMISSIONS .......................................................................................... 7 POWER LINE CONDUCTED INTERFERENCE........................................................................... 9 38 Db REJECTION RADIO ..................................................................................................... 12 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB370 REPORT #: U\UNIDEN AMW\2499AT11\2499AT11TestReport.doc Page 3 of 12 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: 11/15/2011 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB370 REPORT #: U\UNIDEN AMW\2499AT11\2499AT11TestReport.doc Page 4 of 12 GENERAL INFORMATION The test results relate only to the items tested. DUT Description SCANNING RECEIVER FCC ID AMWUB370 Model Number BC125AT DUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Modifications to DUT None Test Standards FCC Part 15, Subpart B, ANSI C63.4-2003 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB370 REPORT #: U\UNIDEN AMW\2499AT11\2499AT11TestReport.doc Page 5 of 12 TEST EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter Semi- Anechoic Chamber Panashield N/A N/A Listed 5/10/10 5/10/12 AC Voltmeter HP 400FL 2213A14499 CAL 6/12/11 6/12/13 Antenna: Active Loop ETS-Lindgren 6502 00062529 CAL 9/23/10 9/23/12 Antenna: Passive Loop EMC Test Systems EMCO 6512 9706-1211 CAL. 12/1/09 12/2/11 Frequency Counter HP 5385A 2730A03025 CAL 8/17/11 8/17/13 Hygro- Thermometer Extech 445703 0602 CAL 6/15/11 6/15/13 Modulation Analyzer HP 8901A 3435A06868 CAL 7/18/11 7/18/13 Digital Multimeter Fluke FLUKE-77 35053830 CAL 9/9/11 9/9/13 Analyzer Tan Tower Preamplifier HP 8449B-H02 3008A00372 CAL 11/21/09 11/21/11 Analyzer Tan Tower Quasi- Peak Adapter HP 85650A 3303A01690 CAL 11/22/09 11/22/11 Analyzer Tan Tower RF Preselector HP 85685A 3221A01400 CAL 11/21/09 11/21/11 Analyzer Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 11/24/09 11/24/11 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 4/25/10 4/25/12 Antenna ETS 3117 41534 9/22/2010 9/22/2012 Antenna Electro metrics LPA-25 1122 5/04/2011 5/04/2013 Antenna Electro metrics BIA-25 1171 1/15/2010 1/15/2012 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB370 REPORT #: U\UNIDEN AMW\2499AT11\2499AT11TestReport.doc Page 6 of 12 TEST PROCEDURE General: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. Radiation Interference: The test procedure used was ANSI Standard C63.4-2003 using a spectrum analyzer with a pre-selector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The video bandwidth was always greater than or equal to the RBW. Formula Of Conversion Factors: The Field Strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBμV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the Preselector was accounted for in the Spectrum Analyzer Meter Reading. Example: Freq (MHz) Meter Reading + ACF +CL = FS 33 20 dBμV + 10.36 dB/m +0.40 dB =30.76 dBμV/m @ 3m ANSI C63.4-2003 Section 10.1.7 Measurement Procedures: The unit under test was placed on a table 80 cm high and with dimensions of 1mby 1.5m. The table used for radiated measurements is capable of continuous rotation. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from …
Text truncated - open the document above for the full version.
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 4 | 15B | 400 MHz - 512 MHz | - |
