AMWUB375DIGITAL SCANNER RECEIVER

Front Cover This product uses one or more of the following patents: Other patents pending. The AMBE+2™ voice coding Technology embodied in this product is protected by intellectual property rights including patent rights, copyrights and trade secrets of Digital Voice Systems, Inc. This voice coding Technology is licensed solely for use within this Communications Equipment. The user of this Technology is explicitly prohibited from attempting to extract, remove, decompile, reverse engineer, or disassemble the object code, or in any other way convert the Object Code into a human-readable form. US Patent Nos. #7,970,606, #6,912,495 B2, #6,199,037 B1, #5,870,405, #5,826,222, #5,754,974, #5,701,390, #5,715,365, #5,649,050, #5,630,011, and #5,517,511. © 2013 Uniden America Corporation, Ft. Worth, Texas. HomePatrol is a registered trademark of Uniden America Corporation, Ft. Worth, Texas. Questions? Problems? Get help on the web at www.uniden.com. Or call our Customer Service line at 800‐292‐2294. Contents Important Information .......................................................................................... 1 Introduction ........................................................................................................... 5 Main Features ...................................................................................................... 7 Included With Your Scanner ............................................................................ 11 Setting up Your Scanner .................................................................................. 12 Base Station .................................................................................................... 13 Vehicle Installation .......................................................................................... 14 Using Internal Batteries (BCD436HP Only) .................................................... 18 Understanding the Memory ............................................................................. 19 Favorites Lists ................................................................................................. 19 Profiles ............................................................................................................ 19 Sentinel Software .............................................................................................. 21 Turning on the Scanner .................................................................................... 23 Data Naming ...................................................................................................... 24 Set Your Location and Range ......................................................................... 24 Set Up GPS ..................................................................................................... 24 Understanding Range ..................................................................................... 25 Selecting Service Types ................................................................................... 26 Keypad and Knob Controls .............................................................................. 26 Key Operations ............................................................................................... 26 Navigating the Menus ....................................................................................... 31 Display Options .................................................................................................. 32 Set the Backlight/Dimmer ............................................................................... 32 Adjust Contrast ................................................................................................ 32 Display Unit ID ................................................................................................ 32 Set ID Format .................................................................................................. 33 Set Upside-Down ............................................................................................ 33 A Look at the Display ........................................................................................ 33 Settings Menu .................................................................................................... 37 Adjust Key Beep .............................................................................................. 37 Battery Option ................................................................................................. 37 Band Defaults .................................................................................................. 37 Auto Shutoff .................................................................................................... 37 Set Clock ......................................................................................................... 37 Replay Options ................................................................................................ 38 Restore Options .............................................................................................. 38 See Scanner Info ............................................................................................ 38 Contents View Battery Level ........................................................................................... 38 Wi-Fi Setup (BCD536HP Only) ....................................................................... 39 Planning Profiles ............................................................................................... 40 Quick Keys ...................................................................................................... 40 Favorites List Quick Keys ................................................................................ 40 System Quick Keys ......................................................................................... 40 Search Quick Keys ...............................................................................…

Text truncated - open the document above for the full version.

External Photos Front View Rear View External Photos Front Left Right External Photos Top

FCC PART 15 SCANNING RECEIVER Applicant UNIDEN AMERICA CORPORATION Address 6225 N. State Highway 161, Suite 300 IRVING TEXAS 75038 USA FCC ID: AMWUB375 Model Number BCD536HP Product Description SCANNING RECEIVER Date Sample Received 8/26/2013 Date Tested 8/29/2013 Tested By NAM NGUYEN Approved By NAM NGUYEN Report Number 1468AUT13TestReport.docx Test Results PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW State Road 45 Newberry, Fl 32669 USA Phone: 888.472.2424 or 352.472.5500 Fax: 352.472.2030 Email: [email protected] Website: www.timcoengr.com Certificate # 0955-01 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB375 REPORT #: U\UNIDEN AMW\1468AUT13\1468AUT13TestReport.docx Page 2 of 12 TABLE OF CONTENTS GENERAL REMARKS ................................................................................................................. 3 GENERAL INFORMATION .......................................................................................................... 4 TEST EQUIPMENT LIST ............................................................................................................. 5 TEST PROCEDURE .................................................................................................................... 6 RADIATED SPURIOUS EMISSIONS ........................................................................................... 7 POWER LINE CONDUCTED INTERFERENCE ............................................................................ 9 38 dB REJECTION RATIO ........................................................................................................ 12 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB375 REPORT #: U\UNIDEN AMW\1468AUT13\1468AUT13TestReport.docx Page 3 of 12 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025: 2005 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Nam Nguyen Project Manager/Testing Technician Date: Aug 30, 2013 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB375 REPORT #: U\UNIDEN AMW\1468AUT13\1468AUT13TestReport.docx Page 4 of 12 GENERAL INFORMATION The test results relate only to the items tested. DUT Description SCANNING RECEIVER FCC ID AMWUB375 Model Number BCD536HP DUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Modifications to DUT None Test Standards FCC Part 15, Subpart B, ANSI C63.4-2003 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB375 REPORT #: U\UNIDEN AMW\1468AUT13\1468AUT13TestReport.docx Page 5 of 12 TEST EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter Semi- Anechoic Chamber Panashield N/A N/A 12/31/11 12/31/13 Analyzer Tan Tower Preamplifier HP 8449B-H02 3008A00372 10/28/11 10/28/13 Analyzer Tan Tower Quasi- Peak Adapter HP 85650A 3303A01690 10/28/11 10/28/13 Analyzer Tan Tower RF Preselector HP 85685A 3221A01400 10/28/11 10/28/13 Analyzer Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 10/28/11 10/28/13 EMI Receiver Rohde & Schwarz ESIB40 100274 3/16/12 3/16/14 Antenna: Biconnical Eaton 94455-1 1096 05/10/13 05/10/15 Antenna: Log- Periodic Electro-Metrics LPA-25 1122 05/09/13 05/09/15 LISN Electro-Metrics ANS-25/2 2604 10/28/11 10/28/13 LISN Electro-Metrics EM-7820 2682 02/26/13 02/26/15 Signal Generator HP 8640B 2308A21464 02/23/12 02/23/14 Antenna: Double-Ridged Horn/ETS Horn 1 ETS-Lindgren 3117 00035923 12/07/11 12/07/13 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB375 REPORT #: U\UNIDEN AMW\1468AUT13\1468AUT13TestReport.docx Page 6 of 12 TEST PROCEDURE General: This report shall NOT be reproduced except in full without the written approval of TIMCO ENGINEERING, INC. Radiation Interference: The test procedure used was ANSI C63.4-2003 using a spectrum analyzer with a pre-selector. The bandwidth of the spectrum analyzer was 100 kHz with an appropriate sweep speed. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The video bandwidth was always greater than or equal to the RBW. Formula Of Conversion Factors: The field strength at 3m was established by adding the meter reading of the spectrum analyzer (which is set to read in units of dBμV) to the antenna correction factor supplied by the antenna manufacturer. The antenna correction factors are stated in terms of dB. The gain of the preselector was accounted for in the spectrum analyzer Meter Reading. Example: Freq (MHz) Meter Reading + ACF +CL = FS 33 20 dBμV + 10.36 dB/m +0.40 dB =30.76 dBμV/m @ 3m ANSI C63.4-2003 Section 10.1.7 Measurement Procedures: The unit under test was placed on a table 80 cm high and with dimensions of 1mby 1.5m. The table used for radiated measurements is capable of continuous rotation. When an emission was found, the table was rotated to produce the maximum signal strength. At this point, the antenna was raised and lowered from 1m to 4m. The antenna was placed in both the horizontal and verticals planes. If power line conducted testing was required for this device, the situation was similar for the conducted measurement except that the table did not rotate. The EUT…
