Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
BCD325P2 Owner’s Manual ©2015 Uniden America Corporation Prin ted in Vietnam U01UB379ZZZ (0) PRECAUTIONS EARPHONE WARNING! Be sure to use only a monaural earphone with this scanner. You can also use an optional stereo headset. Use of an incorrect earphone or mono headset might be potentially hazardous to your hearing. The output of the phone jack is monaural, but you will hear it in both headphones of a stereo headset. Set the volume to a comfortable audio level coming from the speaker before plugging in the monaural earphone or headset. Otherwise, you might experience some discomfort or possible hearing damage if the volume suddenly becomes too loud because of the volume control or squelch control setting. This might be particularly true of the type of earphone that is placed in the ear canal. WATERPROOF WARNING! Uniden does not represent this unit to be waterproof. To reduce the risk of fire or electrical shock, do not expose this unit to rain or moisture. © 2015 Uniden America Corporation, Irving, Texas. Questions? Problems? Get help on the web at www.uniden.com. Or call our Customer Service line at 800-620-7531. CONTENTS PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 EARPHONE WARNING! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 WATERPROOF WARNING! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 IMPORTANT INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 THE FCC WANTS YOU TO KNOW .............................7 MODIFICATION NOTICE .....................................7 PART 15 INFORMATION .....................................7 SCANNING LEGALLY ........................................7 AVIS D’INDUSTRIE CANADA ..................................8 MAIN FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 UNDERSTANDING DYNAMIC MEMORY . . . . . . . . . . . . . . . . . . . . . . . . .11 CONVENTIONAL SIMPLEX AND REPEATER SYSTEMS . . . . . . . . . . .11 UNDERSTANDING CTCSS/DCS/NAC . . . . . . . . . . . . . . . . . . . . . . . . . .12 UNDERSTANDING TRUNKING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 UNDERSTANDING MULTI-SITE TRUNKING . . . . . . . . . . . . . . . . . . . . .13 INCLUDED WITH YOUR SCANNER . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 OPERATION BASICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 CONNECT THE ANTENNA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 USING BATTERIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 CONNECTING THE USB CABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 TURNING ON THE SCANNER AND SETTING THE SQUELCH . . . . . .15 NAVIGATING THE MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 A LOOK AT THE DISPLAY ....................................21 SETTINGS MENUS .........................................25 Set Backlight ...........................................26 Adjust Key Beep .........................................26 Battery Option ...........................................26 Adjusting the Display Contrast ..............................27 Set C-CH Output ........................................27 Set GPS Format .........................................27 Set GPS Baud Rate ......................................27 Band Defaults ..........................................27 P25 LP Filter ............................................28 P25 Threshold ..........................................28 Disp. Unit ID ...........................................28 See Scanner Info .........................................28 % Memory Used ........................................28 Firmware Version and Serial Number .......................28 Locking/Unlocking the Keyboard ...........................28 Viewing the Battery Level ................................28 Cloning ................................................29 Scanner Reset ..........................................29 PLANNING SYSTEMS, SITES, AND GROUPS . . . . . . . . . . . . . . . . . . . . .29 ENTERING TEXT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 PROGRAMMING SYSTEMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30 PROGRAMMING CONVENTIONAL SYSTEMS ..................31 Set Quick Key ...........................................31 Set Start-up Key .........................................32 Set Number Tag .........................................32 Set Lockout ............................................32 Set Hold Time (in seconds) .................................32 Set Delay Time ..........................................32 Set Audio AGC ..........................................32 P25 Waiting Time ........................................33 PROGRAMMING TRUNKED SYSTEMS . . . . . . . . . . . . . . . . . . . . . . . . . .33 Set Number Tag .........................................34 ID Scan/Search (no EDACS SCAT) ..........................34 Set Delay Time ..........................................35 Edit Fleetmap (Motorola Type I systems only) ..................35 Priority ID Scan (no EDACS SCAT/P25-1Tr) ...................35 Set Status Bit (Motorola only) ...............................35 Set End Code (Motorola only) ...............................35 Emergency Alert (Motorola/EDACS only) ......................36 Set ID Format ...........................................36 Rvw ID:Srch L/O .........................................36 Clr All L/O IDs ...........................................36 Set Audio AGC ..........................................36 P25 NAC Option .........................................37 CREATING SITES .........................................37 Edit Name (no EDACS SCAT) ..............................37 Set Quick Key . . . . . . . . . …
Text truncated - open the document above for the full version.
Uniden America Corporation 3001 Gateway Drive, Suite 130 Irving, TX 75063 817-858-3300 Fax: 817-858-3333 February 20, 2015 To:Federal Communications Commission Equipment Authorization Branch Laboratory Division Office of Engineering and Technology 7435 Oakland Mills Road Columbia, Maryland 21046 Subject:Attestation statement regarding the cell phone channels Applicant:Uniden America Corporation 3001 Gateway Drive, Suite 130, Irving, TX 75063 Renji Inuzuka, Director Engineering and Quality TYPE OF EQUIPMENT:Digital Scanning Receiver FCC IDENTIFIER:AMWUB379 Dear Sir or Madam: I attest that the receiver is incapable of tuning, or readily being altered, by the user to operate within the frequency bands allocated to the Domestic public Cellular Telecommunications Service in Part 22. Please contact the undersigned if you have any questions or need any further information. Regards, Renji Inuzuka Director Engineering and Quality
Uniden America Corporation 3001 Gateway Drive, Suite 130 Irving, TX 75063 817-858-3300 Fax: 817-858-3333 REQUEST FOR CONFIDENTIALITY February 20, 2015 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: AMWUB376. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Circuit Description (AMWUB379_CIRCUIT_DESCRIPTION.pdf) Schematic Diagrams (AMWUB379_SCHEMATIC_DIAGRAM.pdf) Block Diagrams (AMWUB379_BLOCK_DIAGRAM.pdf) Internal Photos (BCD325P2_IntPho.pdf) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name External Photos (BCD325P2_ExtPho.pdf) Test Setup Photos (Test Set Up Photos.pdf) User Manual (BCD325P2 User Manual.pdf) Sincerely, Renji Inuzuka Director Engineering and Quality
External Photos (513C-UB379) Front View Rear View External Photos (513C-UB379) Front View (in operation)
Equipment Identification label (BCD325P2) 1) The following markings are permanently shown to the rear case: 46 mm (W) X 38 mm (H)
Equipment Identification label (BCD325P2) 1) The following markings are permanently shown to the rear case: 41.5 mm (W) X 28.7 mm (H)
FCC PART 15 SCANNING RECEIVER Applicant UNIDEN AMERICA CORPORATION Address 3001 GATEWAY DRIVE SUITE 130 IRVING TEXAS 75063 USA FCC ID: AMWUB379 Model Number BCD32SPD Product Description DIGITAL SCANNING RECEIVER Date Sample Received 1/27/2015 Date Tested 3/2/2015 Tested By Christian Pawlak Approved By Sid Sanders Test Results PASS FAIL Report Number Version Number Description Issue Date 212AUT15TestReport.doc Rev.1 Initial Issue 3/2/2015 THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW State Road 45 Newberry, Fl 32669 USA Phone: 888.472.2424 or 352.472.5500 Fax: 352.472.2030 Email: [email protected] Website: www.timcoengr.com APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB379 REPORT #: V:\U\UNIDEN AMW\212AUT15\212AUT15TESTREPORT_REV1.DOCX Page 2 of 18 TABLE OF CONTENTS GENERAL REMARKS .................................................................................................... 3 REPORT SUMMARY PAGE ............................................................................................. 4 GENERAL INFORMATION ............................................................................................. 5 TEST PROCEDURE ...................................................................................................... 6 RADIATED SPURIOUS EMISSIONS ................................................................................ 7 Test Data: Plots Low End of Band 25.0 MHz.......................................................... 8 30–200 MHz PLOT ............................................................................................... 8 Test Data: Plots Low End of Band 25.0 MHz.......................................................... 9 200-1000 MHz PLOT ............................................................................................ 9 Test Data: Plots Low End of Band 25.0 MHz........................................................ 10 1000-5000 MHz PLOT ........................................................................................ 10 Test Data: Plots Middle of Band 489.5 MHz ........................................................ 11 30-200 MHz PLOT .............................................................................................. 11 Test Data: Plots Middle of Band 489.5 MHz ........................................................ 12 200–1000 MHz PLOT .......................................................................................... 12 Test Data: Plots Middle of Band 489.5 MHz ........................................................ 13 1000-5000 MHz PLOT ........................................................................................ 13 Test Data: Plots High End of Band 850.0 MHz ..................................................... 14 30-200 MHz Plot ................................................................................................ 14 Test Data: Plots High End of Band 850.0 MHz ..................................................... 15 200-1000 MHz Plot ............................................................................................ 15 Test Data: Plots High End of Band 850.0 MHz ..................................................... 16 1000-5000 MHZ PLOT ........................................................................................ 16 38 dB REJECTION RATIO ........................................................................................... 17 TEST EQUIPMENT LIST ............................................................................................. 18 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB379 REPORT #: V:\U\UNIDEN AMW\212AUT15\212AUT15TESTREPORT_REV1.DOCX Page 3 of 18 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025: 2005 requirements. I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Christian Pawlak Compliance Engineer Date: 3/5/2015 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB379 REPORT #: V:\U\UNIDEN AMW\212AUT15\212AUT15TESTREPORT_REV1.DOCX Page 4 of 18 REPORT SUMMARY PAGE REPORT Disclaimer The test results only relate to the item tested. Standards Applied Rule(s) CFR 47 FCC Pt 15.109, Pt 15.107, ANSI C63.4: 2003 Related Report NA ENVIRONMENT Test Facility Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 USA. Test Condition in the laboratory Temperature: 24-26ºC Relative humidity: 50-65% Barometric Pressure: SETUP Test Setup Diagram/ Description The EUT was placed on the turntable per setup per ANSI C63.4: 2003. A test set up photo is provided for clarification. Deviation from the standard/procedure No deviation Revision History of EUT No modification RESULTS 15.109 Radiated Emissions PASS 15.107 Powerline Conducted Emissions NOT APPLICABLE 15.121(b) 38 dB Rejection Ratio PASS TABLE OF CONTENTS APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUB379 REPORT #: V:\U\UNIDEN AMW\212AUT15\212AUT15TESTREPORT_REV1.DOCX Page 5 of 18 GENERAL INFORMATION The test results relate only to the items tested. DUT Description DIGITAL SCANNING RECEIVER FCC ID AMWUB379 Model Number BCD32SPD DUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Modifications to DUT None Test S…
Text truncated - open the document above for the full version.
APPLICANT: UNIDEN AMERICA CORP. FCC ID: AMWUB379 IC: 513C-UB379 TEST SET UP PHOTOS
849 NW State Road 45 · Newberry, Florida · United States
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 5 | 15B | 849.0125 MHz - 849.0125 MHz | - |
