AMWUC357Cordless Telephone System - Base

EXP2240 Series EXP2240 12/19/1 10:28 AM Page 11 1 Introduction The Uniden EXP2240 Series (EXP2240/EXP2241/EXP2243) 2.4 GHz cordless phones are designed and engineered to exacting standards for reliability, long life, and outstanding performance. Features • 2.4 GHz Extended Range Technology• 10-Number Memory Dialing• 20 Channel Autoscan • Pulse/Tone Dialing• Handset Volume Control• 24 Digit Redial • One Touch RocketDial™ Number• AutoTalk™• AutoStandby™ • 7 Hours Talk Time• 14 days Standby Time• Hearing Aid Compatible The EXP2240 Series features include AutoTalkand AutoStandby. AutoTalkallows you to answer a call by just removing the handset from the base so you don’t have to waste time pushing buttons or flipping switches. AutoStandbyallows you to hang up by simply returning the handset to the base. The UltraClear Plus™true compander circuitry virtually eliminates background noise. This innovative technology provides you with the best possible reception during all your conversations. To protect you against misbilled calls which might result from your phone being activated by other equipment, the EXP2240 Series has Random Code™digital security which automatically selects one of approx. 260,000 digital security codes for the handset and base. Also, the AutoSecure™feature electronically locks your phone when the handset is in the base. RocketDial™is a one-touch speed dial key that automatically dials your most important or frequently called number. The number dialed, is a preset number stored by the user. Be sure to visit our web site: www.uniden.com Uniden ® is a registered trademark of Uniden America Corporation. AutoTalk, AutoStandby, UltraClear Plus, Random Code, AutoSecure, and RocketDial are trademarks of Uniden America Corporation. As E NERGYSTAR ® Partner, Uniden has determined that this product or product models meets the E NERGYSTAR ® guide lines for energy efficiency. E NERGYSTAR ® is a U.S. registered mark. Controls and Functions 14 15 1 3 2 4 5 6 7 12 13 11 10 9 8 1. Handset earpiece 2.talk/batt lowLED - indicates when phone is in use or the battery is low 3.flash- accesses call waiting (if available) 4.talk- answers or places calls 5. * /tone - switches to tone dialing in pulse dial mode 6.redial/p- redials the last number / adds a timed pause in a memory dialing sequence. 7. Handset Microphone 8.m- enters or recalls numbers in memory 9.RocketDial - one touch priority key 10.end- hangs up a phone call / mutes the ringing tone temporarily 11.vol (v) - sets the ringer tone and earpiece volumes 12.channel- selects another channel for clearer reception 13. Battery Charging Contacts 14. Status LED 15.find handset- locates the handset EXP2240 12/19/1 10:28 AM Page 1 2 Do the following steps: A. Choose the best locationC. Connect the base unit B. Install the battery packD. Choose the dialing mode A. Choose the best location Before choosing a location for your new phone, read the INSTALLATION CONSIDERATIONS included in the PRECAUTIONS AND IMPORTANT SAFETY INSTRUCTIONS. Here are some important guidelines you should consider: • Be sure there is sufficient space to raise the base antenna to a vertical position. • The location should be close to both a phone jack and a continuous power outlet which is not switchable. • Keep the base and handset away from sources of electrical noise such as motors and fluorescent lighting. • The base can be placed on a desk, tabletop, or mounted on a standard wall plate. B. Install the battery pack Charge the battery pack for at least 15-20 hours before plugging the phone line into your phone. 1) Press in on the battery cover release and slide the cover down until it comes off. 2) Connect the battery pack connector observing correct polarity (black and red wires) to the jack inside the battery compartment. Do not exert any force on this connection. It could cause damage to the battery or handset. The plastic connector will fit together only one way. Once you are certain that you have made a good connection, then insert the battery pack into the battery compartment. Do not pinch the wires. 3) Securely close the battery compartment cover by sliding it up until it snaps into place. Avoid heat sources, such as radiators, air ducts, and sunlight Avoid television sets and other electronic equipment Choose a central location Avoid noise sources such as a window by a street with heavy traffic Avoid microwave ovens Avoid excessive moisture, extremely low temperatures, dust, mechanical vibration, or shock Avoid personal computers Avoid other cordless telephones • Base• AC Adapter• Rechargeable Battery • Handset• Telephone Cord Included with Your Phone Setting up the Phone EXP2240 12/19/1 10:28 AM Page 2 3 4) Place the handset on the base. Be sure there is sufficient space to raise the base antenna to a vertical position. NOTE: Use only the Uniden Battery (BT-905) supplied with your phone.Replacement batteries are also available through the Uniden Parts Department. Battery use time (per charge) From fully charged • Seven hours continuous use • Fourteen days when the handset is in the standby mode Low Battery Alert When the battery pack is very low and needs to be charged, the phone is programmed to eliminate functions in order to save power. If the phone is not in use, the talk/batt lowLED flashes when the battery pack is low. If the phone is in use, the talk/batt lowLED flashes and the handset beeps. Complete your conversation as quickly as possible and return the handset to the base for charging. Cleaning the Battery Charging Contacts To maintain a good charge, it is important to clean the battery contacts on the handset and base unit with a dry cloth or a pencil eraser about once a month. Do not use any liquids or solvents. NOTE:Even when the battery pack is not being used, it will gradually discharge over a long period of time. For optimum performance, be sure to return the handset to the base unit after each telephone call. C. Connect the base unit 1) Connect th…

Text truncated - open the document above for the full version.

C:\windows\TEMP\probonholdemail.doc TIMCO TIMCOTIMCO TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: tei@t imcoengr.com 1 February 2002 FCC SUBJECT: UNIDEN AMERICA CORPORATION FCC ID: AMWUC357 MODEL: To Whom It May Concern: Originally this application was prepared for submittal with the test report combined for both the handset & the base unit, before they knew that EUT’s on separate bands had to be separate FCC Identifiers. Sincerely, Sid Sanders

exp2240 CONFIDENTIAL 10.31.01 redial/p vol channel find handset status flash 7 pqrs 4 ghi 1 8 tuv 5 jkl 2 opertone 0 abc 9 wxyz 6 mno def 3 # talk end m v 2.4 GHz batt lowtalk / 2.4GHz RocketDial
