AMWUC358Cordless Telephone System - Base

EXI2246 EXI2246 12/25/1 9:33 AM Page 1 www.uniden.com EXI2246 12/25/1 9:33 AM Page 2 Contents Welcome/Features 2 Quick Reference Guide 3 Controls and Functions 4 Getting Started Read this First 6 Checking the Package Contents 7 Setting up the Phone 8 Mounting the Base Unit on a Wall 12 Terminology 13 Setting Menu Options 14 Basics Making and Receiving Calls 17 Adjusting the Handset Ringer and Earpiece Volume 18 Redial 19 Tone Dialing Switch-over 19 Traveling Out-of-Range 19 Selecting a Different Channel 20 Page 20 Flash and Call Waiting 20 Memory Dialing Storing Phone Numbers and Names 21 Steps for Entering Names and Special Characters 23Making Calls with Memory Dialing 25 Chain Dialing 26 Editing a Stored Name and/or Phone Number 27 Erasing a Stored Name and Phone Number 29 RocketDial RocketDial 30 Storing and Editing the RocketDial 30 Making Calls with the RocketDial 30 Deleting the RocketDial 31 Caller ID Features Caller ID 32 When the Telephone Rings 32 Viewing the Caller ID Message List 33 Deleting Information from the Caller ID List 34 Using the Caller ID List 36 Additional Information Changing the Digital Security Code 38 Installing the Beltclip 38 Headset Installation 38 Note on Power Sources 39 Maintenance 39 Troubleshooting 40 General Information 42 Precautions & Warranty 43 I.C. Notice 45 Index 46 EXI2246 12/25/1 9:33 AM Page 1 [ 2 ] Welcome Congratulations on your purchase of the Uniden EXI2246 cordless telephone. This phoneis designed and engineered to exacting standards for reliability, long life, and outstand-ing performance.Note: Some illustrations in this manual may differ from the actual unit for explanation purpose. The EXI2246 features include AutoTalk TM and AutoStandby TM . AutoTalk allows you to answer a call by just removing the handset from the base so you don't have to waste time pushing buttons or flipping switches. AutoStandby allows you to hang up by simplyreturning the handset to the base.The UltraClear Plus TM true compander circuitry virtually eliminates background noise. This innovative technology, together with 20 different channels, provides you with the bestpossible reception during all your conversations.To protect you against misbilled calls which might result from your phone being activatedby other equipment, the EXI2246 has Random Code TM digital security which automatically selects one of approx. 260,000 digital security codes for the handset and base. Also, theAutoSecure TM feature electronically locks your phone when the handset is in the base. RocketDial TM is a one touch speed dial key that automatically dials your most important or frequently called number. The number dialed, is a preset number stored by the user.Be sure to visit our web site: www.uniden.com Features • 2.4 GHz Extended Range Technology• 3 Line Backlit Display• Caller ID and Call Waiting Caller ID• RocketDial• 10 Number Memory Dialing• The Keypad Facing Up/Down Charging• 32 Digit Redial• Flash and Pause • English or French Display Option• Tone/Pulse Dialing• Page/Find handset• 7 Hour Talk Time/14 Day Standby Time• Handset Earpiece and Ringer Volume Control • Hearing Aid Compatible• 20 Channel Autoscan Uniden ® is a registered trademark of Uniden America Corporation. AutoTalk, AutoStandby, UltraClear Plus, Random Code, AutoSecure, and RocketDial are trademarks ofUniden America Corporation. As E NERGY S TAR ® Partner, Uniden has determined that this product or product models meets the E NERGY S TAR ® guide lines for energy efficiency. E NERGY S TAR ® is a U.S. registered mark. EXI2246 12/25/1 9:33 AM Page 2 QUICK REFERENCE GUIDE [ 3 ] Step 1 Charging the Battery TO INSTALL THE HANDSET BATTERY CONNECT TO A PHONE LINE When the handset battery pack is fully charged,after 15-20 hours of charging, plug the telephonecord into the base unit and then into a telephonewall jack. Your phone is set for tone dialing. If your localnetwork requires pulse dialing, please see “Choosethe dialing mode” on page 15. 1 Remove the cover. TO CHANGE CALLER ID OPTIONS 1 Press and hold cid/menu . 2 Press or to move the pointer to an option. 3 Press select to change the option setting. 4 Press end and return the handset to the base. TO CHOOSE THE LANGUAGE 1 Press and hold cid/menu . 2 Press or to move the pointer to Language . 3 Press select to select Eng (English) or Fr. (French). 4 Press end and return the handset to the base. 1 Plug AC adapter cord into the base unitand then into a 120V AC outlet. 2 Place the handset on the base. 2 Connect the battery packconnector with the correct polarity. 3 Replace the cover. TO PLUG INTO AC POWER Note: You must charge the battery continuously for15 - 20 hours before using the phone. Note: Three Caller ID options are available: AutoTalk, Caller ID on Call Waiting (CIDCW), and Area Code. QUICK REFERENCE GUIDE Step 2 Connecting Step 3 Setting Up the Caller ID/Language EXI2246 12/25/1 9:33 AM Page 3 CONTROLS AND FUNCTIONS [ 4 ] 23 4 1 57689 11 2016151413 1012 191817 1. Handset antenna 2. Beltclip holes 3. Optional headset jack 4. Handset battery compartment 5. Handset earpiece 6. LCD display 7. Caller ID/menu key 8. Talk flash key 9. * /tone/left cursor ( ) key 10. Redial/pause (p) key11. Select key12. Handset microphone and ringer speaker 13. Volume up ( ) key14. RocketDial key15. End key16. Volume down ( ) key17. #/right cursor ( ) key18. Memory key19. Delete/channel (ch) key20. Handset charging contacts Controls and Functions EXI2246 12/25/1 9:33 AM Page 4 2122 24 25 23 21. Status LED22. Find handset key23. Base charging contacts24. DC IN 9V jack25. Telephone line jack CONTROLS AND FUNCTIONS [ 5 ] EXI2246 12/25/1 9:33 AM Page 5 GETTING STARTED [ 6 ] Read this First This cordless telephone must be set up before use. Follow these steps: About the digital security code This cordless telephone uses adigital security code to preventunauthorized access to your baseunit. This security code preventsother cordless handset from making calls through your baseunit.A random secur…

Text truncated - open the document above for the full version.

C:\windows\TEMP\probonholdemail.doc TIMCO TIMCOTIMCO TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: tei@t imcoengr.com 31 January 2002 FCC SUBJECT: UNIDEN AMERICA CORPORATION FCC ID: AMWUC358 MODEL: To Whom It May Concern: Originally this application was prepared for submittal with the test report combined for both the handset & the base unit, before they knew that EUT’s on separate bands had to be separate FCC Identifiers. Sincerely, Sid Sanders

find handset status 2.4GHz exi2246 CONFIDENTIAL 10.31.01 redial/pselect flash delete/chmemory vol call id/menu 7 pqrs 4 ghi 1 8 tuv 5 jkl 2 opertone 0 abc 9 wxyz 6 mno def 3 # talk end RocketDial
