AMWUC7972.4 GHz Cordless Phone

UC774BH ENG (TRU446) 2/26/03 10:53 AM Page ii www.uniden.com UC774BH ENG (TRU446) 2/26/03 10:53 AM Page 1 [ 2 ] Contents WELCOME/FEATURES 3 QUICK REFERENCE GUIDE 5 CONTROLS AND FUNCTIONS 6 GETTING STARTED 8 Read This First 8 Checking the Package Contents 9 Setting up the Phone 10 Terminology 14 Setting Caller ID Options 15 Selecting a Language 17 BASICS 18 Making and Receiving Calls 18 Redialing a Call 19 Ringer Volume Setup 20 Ringer Tone Setting 20 Distinctive Ringer Setup 21 Adjusting the Earpiece Volume 21 Mute Microphone 22 Tone Dialing Switch-over 22 Traveling Out-of-Range 22 Selecting a Different Channel 23 Find Handset 23 Flash and Call Waiting 23 Voice Mail LED 23 PHONEBOOK 24 Storing Phone Numbers, Names, Distinctive Rings, and Speed Dial 24 Steps for Entering Names and Special Characters 25 Viewing the Phonebook 27 Making Calls Using the Phonebook 28 Speed Dialing 28 Editing or Erasing a Stored Name, Phone Number, Distinctive Ring, and Speed Dial 29 RocketDial (One Touch Dialing) 29 Chain Dialing 30 CALLER ID 31 Viewing the Caller ID List 32 Deleting Information from the Caller ID List 33 Using the Caller ID Message List 34 Call Waiting Deluxe Features 35 EXPANDING YOUR PHONE 36 How to Distinguish the Original Handset and the Second Handset 36 Registering the Second Handset 36 Call Transfer Feature 37 Second Handset Operation 38 ADDITIONAL INFORMATION 40 Changing the Digital Security Code 40 Installing the Beltclip 41 Headset Installation 41 Note on Power Sources 42 Maintenance 42 General Information 43 TROUBLESHOOTING 44 PRECAUTIONS & WARRANTY 45 I.C. NOTICE 47 INDEX 48 UC774BH ENG (TRU446) 2/26/03 10:53 AM Page 2 WelcomeFeatures Congratulations on your purchase of the Uniden cordless telephone. This phone is designed andengineered to exacting standards for reliability, long life and outstanding performance. To enjoythe best performance from this phone’s features, please read this manual carefully and save it forfuture reference.Note: Some illustrations in this manual may differ from the actual unit for explanation purposes. As an Energy Star ® Partner, Uniden has determined that this product or product models meets the Energy Star ® guidelines for energy efficiency. Energy Star ® is a U.S. registered mark. • 2.4 GHz Spread Spectrum Technology • Two Handset Expandability • Caller ID and Call Waiting Caller ID • Dynamic Memory Location for Caller ID Messages and Phonebook Locations(up to 100 numbers in total) • Trilingual Language Option • 6 Hour Talk Time • 10 Day Standby Battery Life • 3-Line, 16 Character Backlit Handset Display • One Touch Dialing • Call Transfer • 32 Digit Redial / 3 Last Number Redial Locations • 10 Distinctive Ring Options (6 ringers and 4 melodies) • Flash and Pause • Find Handset • Hearing Aid Compatible • Tone/Pulse Dialing • Handset Earpiece and Ringer Volume Control [ 3 ] INTRODUCTION/FEATURES UC774BH ENG (TRU446) 2/26/03 10:53 AM Page 3 [ 4 ] INTRODUCTION/FEATURES [ 4 ] The TRU446 series features include AutoTalk™ and AutoStandby ™ . AutoTalk allows you to answer a call by just removing the handset from the base so you don ’ t have to waste time pushing buttons. AutoStandby allows you to hang up by simply returning the handset to the base.To protect you against mis-billed calls, which might result from your phone being activated byother equipment, the TRU446 series has Random Code ™ digital security, which automatically selects one of over 65,000 digital security codes for the handset and base. Also, AutoSecure ™ electronically locks your phone when the handset is in the base.RocketDial ™ is a one touch speed dial key that automatically dials your most important or frequently called number. The number dialed, is a preset number stored by the user.Digital Spread Spectrum Technology utilizes a “ wider frequency band ” vs. a “ single narrow band ” used in standard digital transmissions. The result is a more secure conversation with the clarityof digital sound, extended range, and minimal interference from other cordless phones. Be sure to visit our web site: www.uniden.comUniden ® is a registered trademark of Uniden America Corporation. AutoTalk, AutoStandby, Random Code, AutoSecure, and RocketDialare trademarks of Uniden America Corporation. UC774BH ENG (TRU446) 2/26/03 10:53 AM Page 4 Q UICK R EFERENCE G UIDE INSTALL THE HANDSET BATTERY Remove the cover.Connect the batterypack connector withthe correct polarity.Replace the cover. PLUG INTO AC POWER Plug the AC adapter cord into the base unit and then toa 120V AC outlet.Place the handset in the base . CONNECT TO A PHONE LINEWhen the handset battery pack is fully charged, plug thetelephone cord into the base unit and then into a telephone wall jack. Your phone is set for tone dialing. If your local network requirespulse dialing, please see “Setting up the phone, Choose thedialing mode” in your owner’s manual. TO SELECT CALLER ID OPTIONS Press menu/mute . Press + or - to move the pointer to “ Caller ID Setup ” , then press select/ch . Press + or - to move the pointer to an option, then press select/ch . Press + or - to change the option setting. Press select/ch and return the handset to the base. TO CHOOSE THE LANGUAGE Press menu/mute . Press + or - to move the pointer to “ Language ” , then press select/ch . Press + or - to change the option setting. Press select/ch and return the handset to the base. Note: You must charge the battery pack continuousfor 15-20 hours before using the phone. Note : Three Caller ID options are available: Auto Talk, Caller ID on Call Waiting (CIDCW)and Area Code. Step 1 Charging the Battery Step 2 Connecting Step 3 Setting up the Caller ID Options/Language QUICK REFERENCE GUIDE [ 5 ] UC774BH ENG (TRU446) 2/26/03 10:53 AM Page 5 [ 6 ] CONTROLS AND FUNCTIONS [ 6 ] Controls and Functions 1423 6 5789 10 11 12 13 15161718192021 14 1. Handset Antenna2. Headset Jack Cover3. Beltclip Hole4. Handset Battery Compartment5. Voice Mail LED6. Handset Earpiece7. LCD Display8. CID (Calle…

Text truncated - open the document above for the full version.

© 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone

PCTEST PT. 15.247 REPORT CERTIFICATION REPORT Reviewed By: Quality Manager Test Report S/N: 15.230116099.AMW Test Dates: Jan. 29-30 & Feb. 26, 2003 EUT Type: Uniden 2.4GHZ DTS Cordless Phone FCC ID: AMWUC797 Page 1 of 2 FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE) PCTEST PT. 15.247 REPORT CERTIFICATION REPORT Reviewed By: Quality Manager Test Report S/N: 15.230116099.AMW Test Dates: Jan. 29-30 & Feb. 26, 2003 EUT Type: Uniden 2.4GHZ DTS Cordless Phone FCC ID: AMWUC797 Page 2 of 2 FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

© 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone

PCTEST ENGINEERING LABORATORY, INC. 6660 – B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR TEST REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.230116025.AMW Test Dates: Jan. 29-30, 2003 EUT Type: UNIDEN 2.4 GHz DTS Cordless Phone FCC ID: AMWUC797 Page 1 of 24 © 2003 PCTEST Engineering Laboratory, Inc. APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: UNIDEN AMERICA CORPORATION Dates of Tests: Jan. 29-30, 2003 Engineering Services Office Test Report S/N: SAR.230116052.AMW 216 John Street Test Site: PCTEST Lab, Columbia, MD USA P.O. Box 580 Lake City, SC 29560-0580 Attn: Mr. Jim Haynes, Vice President - Engineering & Regulatory Affairs FCC ID: AMWUC797 APPLICANT NAME: UNIDEN AMERICA CORPORATION EUT Type: 2.4 GHz Cordless Phone Tx Frequency: 2407.424 – 2477.056 MHz (DTS) Rx Frequency: 2407.424 – 2477.056 MHz (DTS) Max. RF Output Power: 0.0255 W (14.071 dBm) EIRP (Handset) 0.0509 W (17.071 dBm) EIRP (Base Set) Max. SAR Measurement: 0.09 W/kg over 1 gm (Head) 0.28 W/kg over 1 gm (Body – Handset) 0.50 W/kg over 1 gm (Body – Base)(Antenna #1) Trade Name/Model(s): UNIDEN TRU446 FCC Rule Part(s): §15.247, §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: Identical Prototype [S/N: #1] This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-200X (Draft 6.5, January 15, 2002). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Notes: Power output is EIRP (0.0509W Base/ 0.0255W Handset). This device has been tested for SAR compliance for head and body-worn configurations. SAR compliance for body-worn operating configurations is limited to the specific belt-clip tested for this filing. End-users must be informed of the operating requirements for satisfying RF exposure compliance. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. SAR.230116025.AMW PCTEST SAR TEST REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.230116025.AMW Test Dates: Jan. 29-30, 2003 EUT Type: UNIDEN 2.4 GHz DTS Cordless Phone FCC ID: AMWUC797 Page 2 of 24 © 2003 PCTEST Engineering Laboratory, Inc. TABLE OF CONTENTS 1. INTRODUCTION / SAR DEFINITION.................................................................................3 2. SAR MEASUREMENT SETUP..............................................................................................4 3. ALIDX-500 E-FIELD PROBE SYSTEM..................................................................................5 4. PROBE CALIBRATION PROCESS.......................................................................................6 5. PHANTOM & EQUIVALENT TISSUES.................................................................................7 6. TEST SYSTEM SPECIFICATIONS.........................................................................................8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS................................................................9 8. DEFINITION OF REFERENCE POINTS..............................................................................10 9. TEST CONFIGURATION POSITION.................................................................................11 10. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS.................................................................12 11. MEASUREMENT UNCERTAINTIES...................................................................................13 12. SYSTEM VERIFICATION..................................................................................................14 13. SAR TEST DATA SUMMARY............................................................................................15 14. SAR DATA SUMMARY...............................................................................................16-21 15. SAR TEST EQUIPMENT...................................................................................................22 16. CONCLUSION...............................................................................................................23 17. REFERENCES..................................................................................................................24 PCTEST SAR TEST REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR.230116025.AMW Test Dates: Jan. 29-30, 2003 EUT Type: UNIDEN 2.4 GHz DTS Cordless Phone FCC ID: AMWUC797 Page 3 of 24 © 2003 PCTEST Engineering Laboratory, Inc. 1. INTRODUCTION / SAR DEFINITION The FCC has adopted the guidelines for evaluating the environmental effects of radiofrequency radiation in ET Docket 93-62 on Aug. 6, 1996 to protect the public and workers from the potential hazards of RF emissions due to FCC-regulated portable devices.[1] The safety limits used for the environmental evaluation measurements are based on the criteria published by the American National Standards Institute (ANSI) for localized specific absorption rate (SAR) in IEEE/ANSI C95.1-1992 Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. (c) 1992 by the Institute of Electrical and Electronics Engineers, Inc., New York, New York 10017.[2] The measurement procedure described in IEEE/ANSI C95.3-199…

Text truncated - open the document above for the full version.

SAR Data Report 03013014 Start : 29-Jan-03 11:33:18 am End : 29-Jan-03 11:39:43 am Code Version : 4.08 Robot Version: 4.08 Product Data: Type : UNIDEN Model Number : TRU446 Serial Number : 1 Frequency : 2407.424 MHz Transmit Pwr : 0.026 W Antenna Type : Helical Antenna Posn. : Fixed Measurement Data: Phantom Name : SAM-RIGHT Phantom Type : Right Ear Tissue Type : Brain Tissue Dielectric : 39.100 Tissue Conductivity : 1.880 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT003 Probe Type : E Fld Triangle Frequency : 2440 MHz Tissue Type : Brain Calibrated Dielectric : 39.340 Calibrated Conductivity : 1.770 Calibrated Density : 1.300 Probe Offset : 2.400 mm Conversion Factor : 8.800 Probe Sensitivity : 2.075 2.820 2.456 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 1000 Samples NIDAQ Gain: 5 Comments: DSSS Mode CH-01 Cheek CF=1; Amb. Temp= 22.3 'C; Liq. Temp=21.1 'C Area Scan - Max Peak SAR Value at x=-29.0 y=5.0 = 0.03 W/kg Zoom Scan - Max Peak SAR Value at x=-22.0 y=6.0 z=0.0 = 0.07 W/kg Max 1g SAR at x=-19.0 y=8.0 z=0.0 = 0.03 W/kg Max 10g SAR at x=-24.0 y=8.0 z=0.0 = 0.01 W/kg -0.01 0.00 0.01 0.02 0.03 0.04 0.05 0.06 0.07 SAR (mW/g) 102030 Z Distance (mm) SAR - Z Axis at Hotspot x:-22.0 y:6.0 1g SAR Values 0.0283 0.0259 0.0235 0.0210 0.0186 0.0162 0.0138 0.0114 0.0089 0.0065 0.0041 SAR Data Report 03013010 Start : 29-Jan-03 10:55:46 am End : 29-Jan-03 11:02:11 am Code Version : 4.08 Robot Version: 4.08 Product Data: Type : UNIDEN Model Number : TRU446 Serial Number : 1 Frequency : 2407.424 MHz Transmit Pwr : 0.026 W Antenna Type : Helical Antenna Posn. : Fixed Measurement Data: Phantom Name : SAM-RIGHT Phantom Type : Right Ear Tissue Type : Brain Tissue Dielectric : 39.100 Tissue Conductivity : 1.880 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT003 Probe Type : E Fld Triangle Frequency : 2440 MHz Tissue Type : Brain Calibrated Dielectric : 39.340 Calibrated Conductivity : 1.770 Calibrated Density : 1.300 Probe Offset : 2.400 mm Conversion Factor : 8.800 Probe Sensitivity : 2.075 2.820 2.456 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 1000 Samples NIDAQ Gain: 5 Comments: DSSS Mode CH-01 Tilt CF=1; Amb. Temp= 22.3 'C; Liq. Temp=21.1 'C Area Scan - Max Peak SAR Value at x=-22.0 y=5.0 = 0.05 W/kg Zoom Scan - Max Peak SAR Value at x=-25.0 y=7.0 z=0.0 = 0.12 W/kg Max 1g SAR at x=-23.0 y=10.0 z=0.0 = 0.05 W/kg Max 10g SAR at x=-20.0 y=10.0 z=0.0 = 0.02 W/kg -0.01 0.00 0.01 0.02 0.03 0.04 0.05 0.06 0.07 0.08 0.09 0.10 0.11 0.12 SAR (mW/g) 102030 Z Distance (mm) SAR - Z Axis at Hotspot x:-25.0 y:7.0 1g SAR Values 0.0532 0.0486 0.0439 0.0393 0.0347 0.0301 0.0254 0.0208 0.0162 0.0115 0.0069 SAR Data Report 03013007 Start : 29-Jan-03 10:20:41 am End : 29-Jan-03 10:27:17 am Code Version : 4.08 Robot Version: 4.08 Product Data: Type : UNIDEN Model Number : TRU446 Serial Number : 1 Frequency : 2407.424 MHz Transmit Pwr : 0.026 W Antenna Type : Helical Antenna Posn. : Fixed Measurement Data: Phantom Name : SAM-LEFT Phantom Type : Left Ear Tissue Type : Brain Tissue Dielectric : 39.100 Tissue Conductivity : 1.880 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT003 Probe Type : E Fld Triangle Frequency : 2440 MHz Tissue Type : Brain Calibrated Dielectric : 39.340 Calibrated Conductivity : 1.770 Calibrated Density : 1.300 Probe Offset : 2.400 mm Conversion Factor : 8.800 Probe Sensitivity : 2.075 2.820 2.456 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 1000 Samples NIDAQ Gain: 5 Comments: DSSS Mode CH-01 Cheek CF=1; Amb. Temp= 22.3 'C; Liq. Temp=21.1 'C Area Scan - Max Peak SAR Value at x=-18.0 y=16.0 = 0.03 W/kg Zoom Scan - Max Peak SAR Value at x=-19.0 y=24.0 z=0.0 = 0.19 W/kg Max 1g SAR at x=-19.0 y=24.0 z=0.0 = 0.06 W/kg Max 10g SAR at x=-19.0 y=19.0 z=0.0 = 0.02 W/kg 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0.16 0.18 0.20 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:-19.0 y:24.0 1g SAR Values 0.0553 0.0521 0.0488 0.0456 0.0424 0.0391 0.0359 0.0326 0.0294 0.0261 0.0229 SAR Data Report 03013005 Start : 29-Jan-03 10:03:15 am End : 29-Jan-03 10:09:52 am Code Version : 4.08 Robot Version: 4.08 Product Data: Type : UNIDEN Model Number : TRU446 Serial Number : 1 Frequency : 2407.424 MHz Transmit Pwr : 0.026 W Antenna Type : Helical Antenna Posn. : Fixed Measurement Data: Phantom Name : SAM-LEFT Phantom Type : Left Ear Tissue Type : Brain Tissue Dielectric : 39.100 Tissue Conductivity : 1.880 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT003 Probe Type : E Fld Triangle Frequency : 2440 MHz Tissue Type : Brain Calibrated Dielectric : 39.340 Calibrated Conductivity : 1.770 Calibrated Density : 1.300 Probe Offset : 2.400 mm Conversion Factor : 8.800 Probe Sensitivity : 2.075 2.820 2.456 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 1000 Samples NIDAQ Gain: 5 Comments: DSSS Mode CH-01 Tilt CF=1; Amb. Temp= 22.3 'C; Liq. Temp=21.1 'C Area Scan - Max Peak SAR Value at x=-22.0 y=15.0 = 0.08 W/kg Zoom Scan - Max Peak SAR Value at x=-21.0 y=13.0 z=0.0 = 0.18 W/kg Max 1g SAR at x=-21.0 y=16.0 z=0.0 = 0.09 W/kg Max 10g SAR at x=-21.0 y=16.0 z=0.0 = 0.05 W/kg 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0.16 0.18 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:-21.0 y:13.0 1g SAR Values 0.0908 0.0853 0.0798 0.0743 0.0688 0.0633 0.0578 0.0523 0.0467 0.0412 0.0357 SAR Data Report 03012912 Start : 29-Jan-03 04:56:42 pm End : 29-Jan-03 05:04:06 pm Code Version : 4.08 Robot Version: 4.08 Product Data: Type : UNIDEN Model Number : TRU446 Serial Number : 1 Frequency : 2407.424 MHz Transmit Pwr : 0.026 W Antenna Type : Helical Antenna Posn. : Fixed Measurement Data: Phantom Name : SAM FLAT Phantom Type : Uniphantom Tissue Type : Muscle Tissue Dielectric : 53.700 Tissue Conductivity : 1.880 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT00…

Text truncated - open the document above for the full version.

SAR Data Report 03012908 Start : 29-Jan-03 12:17:26 pm End : 29-Jan-03 12:22:41 pm Code Version : 4.08 Robot Version: 4.08 Product Data: Type : Validation Frequency : 2440 MHz Transmit Pwr : 0.050 W Antenna Type : Dipole Measurement Data: Phantom Name : SAM-FLAT-B Phantom Type : Uniphantom Tissue Type : Brain Tissue Dielectric : 39.100 Tissue Conductivity : 1.880 Tissue Density : 1.000 Robot Name : CRS Probe Data: Probe Name : PCT003 Probe Type : E Fld Triangle Frequency : 2440 MHz Tissue Type : Brain Calibrated Dielectric : 39.340 Calibrated Conductivity : 1.770 Calibrated Density : 1.300 Probe Offset : 2.400 mm Conversion Factor : 8.800 Probe Sensitivity : 3.026 3.290 3.570 mV/(mW/cm^2) Amplifier Gains : 20.00 20.00 20.00 Sample: Rate: 6000 Samples/Sec Count: 1000 Samples NIDAQ Gain: 5 Comments: 2440 MHz Validation CF=1; Amb. Temp= 23.3 'C; Liq. Temp=22.1 'C Area Scan - Max Peak SAR Value at x=-4.0 y=0.0 = 2.36 W/kg Zoom Scan - Max Peak SAR Value at x=-3.0 y=0.0 z=0.0 = 6.07 W/kg Max 1g SAR at x=-3.0 y=1.0 z=0.0 = 2.75 W/kg Max 10g SAR at x=-3.0 y=1.0 z=0.0 = 1.14 W/kg Validation Results at 0.05 W: 1g Nominal = 2.6, Error: 4.92 % 0 1 2 3 4 5 6 7 SAR (mW/g) 0102030 Z Distance (mm) SAR - Z Axis at Hotspot x:-3.0 y:0.0 1g SAR Values 2.75 2.55 2.36 2.16 1.97 1.77 1.57 1.38 1.18 0.99 0.79

Calibration Laboratory 6660-B Dobbin Road Columbia, Maryland 21045 USA © 2003 PCTEST Calibration Summary Model: E-010 S/N: PCT003 Boundary Effect < 2%, 2.6 mm from probe tip to phantom Diode Compression Point: 76 mV Environmental Conditons: Temperature: 23.34 o C Relative Humidity: 34% Barometer: 100.1 kPa --------------------- This probe was calibrated under the IEEE Std 1309-1966, IEEE Standard for Calibration of Electromagnetic Field Sensors and Probes, Exluding Antennas, from 9 kHz to 40 GHz. OFFSET ANGLE (cm) (deg) 0.24 54.73 Tissue Type Frequency (MHz) Dielectric Constant r ε Conductivity (S/m) σ Conversion Factor zyx γγγ,, Brain 835 40.00 0.91 7.20 Brain 1880 40.20 1.41 4.05 Brain 2440 39.34 1.77 8.80 Brain 5300 37.10 4.84 3.20 Brain 5800 36.00 5.28 2.30 Muscle 835 55.70 0.98 7.70 Muscle 1900 53.90 1.48 4.40 Muscle 2440 52.30 1.99 9.90 Muscle 5300 48.80 5.43 3.45 Muscle 5800 48.50 6.05 2.50 Isotropy Frequency (MHz) % dB 835 3.49 0.15 1880 5.35 0.23 2440 4.02 0.17 5300 4.85 0.21 5800 4.93 0.21 Calibration Laboratory 6660-B Dobbin Road Columbia, Maryland 21045 USA © 2003 PCTEST 835 MHz Calibration (PCT003) 0 0.2 0.4 0.6 0.8 1 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 Ch1 Ch2 Ch3 Sum 1880 MHz Calibration (PCT003) 0 0.25 0.5 0.75 1 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 Ch1 Ch2 Ch3 Sum Calibration Laboratory 6660-B Dobbin Road Columbia, Maryland 21045 USA © 2003 PCTEST 2440 MHz Calibration (PCT003) 0 0.25 0.5 0.75 1 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 Ch1 Ch2 Ch3 Sum 5300 MHz Calibration (PCT003) 0 0.25 0.5 0.75 1 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 Ch1 Ch2 Ch3 Sum Calibration Laboratory 6660-B Dobbin Road Columbia, Maryland 21045 USA © 2003 PCTEST 5800 MHz Calibration (PCT003) 0 0.25 0.5 0.75 1 0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170 180 190 200 210 220 230 240 250 260 270 280 290 300 310 320 330 340 350 Ch1 Ch2 Ch3 Sum 0 30 60 90 120 150 180 210 240 270 300 330 0 60 120 180 240 300 360 -1 -0.5 0 0.5 1 dB Polarization Rotation (theta) Probe Rotation (phi) Verification of Isotropy for PCT003 Calibration Laboratory 6660-B Dobbin Road Columbia, Maryland 21045 USA © 2003 PCTEST Linearity Calibration Plot for PCT003 0 100 200 300 400 500 600 700 800 900 1000 00.511.522.5 Power (Watts) Power Density (mW/cm^2) Uncompensated Compensated Probe Physical Characteristics Serial Number: PCT003 Sensor Offset: 2.4 mm Sensor Length: 2.5 mm Tip Enclosure: Glass Tip Diameter: 7 mm Tip Length: 40 mm Total Length: 290 mm Calibration Laboratory 6660-B Dobbin Road Columbia, Maryland 21045 USA © 2003 PCTEST Test Equipment The test equipment used during the probe calibration are listed as follows: EQUIPMENT SPECIFICATIONS Type Calibration Date Asset Number/ Serial Number CRS Robot F3 February 2002 RAF0134133 CRS C500C Motion Controller February 2002 RCB0003303 CRS Teach Pendant (Joystick) February 2002 STP0132231 DELL Computer, Pentium 4 1.6 GHz, Windows 2000 TM February 2002 4PJZ111 E-Field Probe E-010 January 2003 PCT003 Flat SAM Phantom (P-SAM-FLAT) February 2002 94X-097 IDX Robot End Effector (EE-103-C) February 2002 07111223 IDX Probe Amplifier February 2002 07111113 Validation Dipole D-835S October 2002 PCT441 Validation Dipole D-1900S October 2002 PCT541 Validation Dipole D-2450S October 2002 PCT641 Validation Dipole D-5000S November 2002 PCT741 HP-778D Dual-Directional Coupler (0.1 ~ 2.0 GHz) November 2002 PCT664 MicroCircuits Directional Coupler (4.0 ~ 8.0 GHz) November 2002 PE2204-6 Amplifier Research 5S1G4 Power Amp January 2003 PCT540 IFI T184-10 Power Amplifier (4.0 ~ 18.0 GHz) December 2002 5957 Agilent E8241A (250kHz ~ 20GHz) Signal Generator November 2002 US42110432 HP-8648D (9kHz ~ 4 GHz) Signal Generator January 2003 PCT526 HP-8753E (30kHz ~ 6GHz) Network Analyzer January 2003 PCT552 HP85070B Dielectric Probe Kit January 2003 PCT501 IFI CC110EXX TEM Cell (DC to 2000 MHz) January 2003 PCT498 EMCO 3115 Horn Antenna (2.0 ~ 18.0 GHz) August 2002 PCT496 Guidline 5150 Precision Dual-Thermometer November 2002 66145 Calibration Laboratory 6660-B Dobbin Road Columbia, Maryland 21045 USA © 2003 PCTEST Calibration Laboratory 6660-B Dobbin Road Columbia, Maryland 21045 USA © 2003 PCTEST Calibration Laboratory 6660-B Dobbin Road Columbia, Maryland 21045 USA © 2003 PCTEST

© 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone © 2003 PCTEST Lab UNIDEN FCC ID: AMWUC797 2.4 GHz DSS Cordless Phone

PCTEST PT. 15.247 REPORT CERTIFICATION REPORT Reviewed By: Quality Manager Test Report S/N: 15.230116099.AMW Test Dates: Jan. 29-30 & Feb. 26, 2003 EUT Type: Uniden 2.4GHZ DTS Cordless Phone FCC ID: AMWUC797 Page 1 of 31 PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road • Columbia, MD 21045 • U.S.A. TEL (410) 290-6652 • FAX (410) 290-6654 http://www.pctestlab.com CERTIFICATE OF COMPLIANCE UNIDEN AMERICA CORPORATION Dates of Tests: Jan. 29-30 & Feb. 26, 2003 Engineering Services Office Test Report S/N: 15.230116099.AMW 216 John Street Test Site: PCTEST Lab, Columbia MD P.O. Box 580 Lake City, SC 29560-0580 Attn: Mr. Jim Haynes, Vice President ~ Engineering & Regulatory Affairs FCC ID AMWUC797 APPLICANT UNIDEN AMERICA CORP. FCC Rule Part(s): § 15.247; ANSI C-63.4 (1992) Classification: Digital Transmission System (DTS) Max Output Power: 0.0255 W (14.071 dBm) EIRP (Handset) 0.0509 W (17.071 dBm) EIRP (Base Set) Method/System: Direct Sequence Spread Spectrum Modulation Equipment Type: 2.4 GHz Cordless Phone Frequency Range: 2407.424 – 2477.056 MHz (DTS) Model No(s).: UNIDEN TRU446 This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in ANSI C-63-4. I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Grant Notes: Power output is EIRP (0.0509W Base/ 0.0255W Handset). This device has been tested for SAR compliance for head and body-worn configurations. SAR compliance for body-worn operating configurations is limited to the specific belt-clip tested for this filing. End-users must be informed of the operating requirements for satisfying RF exposure compliance. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220401140.A3L PCTEST PT. 15.247 REPORT …

Text truncated - open the document above for the full version.
