AMWUN110BLUETOOTH INSIDE OF A DECT PHONE-BASE UNIT

DECT3181 base with answering system and cordless handset Battery cover Accessory handset and charger (DCX310 displayed) If you purchased model number: You should have: DECT3181None DECT3181-21 Accessory HS DECT3181-32 Accessory HS :: DECT3181-1211 Accessory HS You will also find: Not pictured: Rechargeable battery (BT-1018) AC adapter (PS-0034) Telephone cord - - - If any items are missing or damaged, contact our Customer Care Line immediately. Never use damaged products! Need help? Get answers 24/7 at our website: www.uniden.com. If You...Contact Uniden’s...Phone Number have a question or problemCustomer Care Line* 817-858-2929 or 800-297-1023 need a replacement part or an accessory Parts Department*800-554-3988 need special assistance due to a disability Accessibility Help Line 800-874-9314 (voice or TTY) * During regular business hours, Central Standard Time; see our website for detailed busi- ness hours.   DECT3181 Series User's Guide What's in the box? For each accessory handset (not pictured): Rechargeable battery (BT-1018) Battery cover Charger AC adapter - - - © 2010 Uniden America Corp. Printed in Vietnam Ft. Worth, Texas UNZZ01184EZ(1) 2 Accessory Handset Options MULTIRANGE™ Charger and Accessory Handset If the model number ends in R, at least one of the handsets included with your phone is a DRX312 handset with a MULTIRANGE™ charger. For more information, see page 8 or the separate DRX312 user guide. Waterproof Accessory Handset If the model number ends in WX, at least one of the handsets included with your phone is a DWX317 waterproof handset with a water-resistant charger. For more information, refer to the separate DWX317 user guide. AC Adapter and Battery Specification AC Adapter for -Part NumberInput Voltage Output Voltage DECT3181 BasePS-0034120V AC, 60 Hz7.8V AC @ 450mA DCX310 ChargerPS-0035120V AC, 60 Hz8V AC @ 300mA DRX312 MULTIRANGE Charger PS-0033120V AC, 60 Hz6.5V AC @ 350mA DWX317 Water- Resistant Charger PS-0035120V AC, 60 Hz8V AC @ 300mA Battery packHandsetWaterproof handset Part numberBT-1018BT-1018 Capacity500mAh, 2.4V DC 500mAh, 2.4V DC 3 ImPOrTANT SAfETY INSTrUCTIONS! When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: This unit is NOT waterproof. DO NOT expose this unit to rain or moisture. Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning.    What’s in the manual? Accessory Handset Options .....................................2 AC Adapter and Battery Specification .............................2 Important Safety Instructions! .....3 Getting Started ............................4 Installing Your Phone ..................4 Setting Up the CellLink™ Bluetooth™ Connection ...........5 Setting Up MULTIRANGE TM Chargers ...................................8 Understanding Your Phone ..........9 Parts of the Base .........................9 Parts of the Handset .................11 Using the Menus .......................14 Using Your Phone ......................18 Learning the Basics ...................18 Using Caller ID and Redial Lists .............................19 Using the Directory ...................21 Finding a Lost Handset ..............23 Using Multi-Handset Features .................................23 Using Special Features ..............26 Using the Answering System .....27 Answering System Options (Ans. Setup) ...........................27 Accessing the Answering System ....................................28 Personalizing Your Greeting .....29 Getting Your Messages .............30 Screening Your Calls..................30 Using the System While You’re Away from Home ........31 Important Information ..............32 Solving Problems ......................32 Changing from Tone to Pulse Dialing ....................................36 Resetting and Registering Handsets ................................37 Compliance Information ...........39 Warranty (Limited, 1 Year) .......42 4 Do not use the telephone to report a gas leak in the vicinity of the leak. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special disposal instructions. Do not place the handset in any charging cradle without the battery installed and the battery cover securely in place. SAVE THESE INSTrUCTIONS! CAUTION! risk of explosion if battery is replaced by an incorrect type! Dispose of used batteries according to the instructions. Do not open or mutilate the battery. Disconnect the battery before shipping this product. For more details, see the Important Information section. GETTING STArTED Installing Your Phone Charge the battery Unpack all handsets, batteries, and battery covers. If you need to remove a battery cover, press in on the notch and slide the cover down. Line up the battery connector with the jack inside the handset and push the connector in until it clicks into place. Tug gently on the wires to make sure the battery pack is securely connected. Replace the cover and slide it up into place. Connect the base AC adapter to the ac in 7.8V jack on the base. Run the cord through the indent and out the back. If you have accessory handsets, connect each charger’s applicable AC adapter to the power jack. If you have a DRX312 handset with a MULTIRANGE charger or a DWX317 waterproof handset, be sure to use the correct AC      1. 2. 3. 4. 5.  5 adapter for the charger. See the separate DRX312 or DWX317 user guide that was packaged with your phone. Plug the other end of each adapter into a standard 120V AC power outlet. Place one handset in the base and the other(s) in the charger(s) with the display(s) facing forward.…

Text truncated - open the document above for the full version.

Uniden America Corporation 4700 Amon Carter Blvd. Fort Worth, TX 76155 817-858-3300 Fax: 817-858-3328 REQUEST FOR CONFIDENTIALITY August 23, 2010 To: Federal Communications Commission Equipment Authorization Branch, Lab Div., OET 7435 Oakland Mills Road Columbia, Maryland 21046 Subject: Data for FCC Certification Applicant: Uniden America Corporation 4700 Amon Carter Blvd. Fort Worth, Texas 76155 Jon Suehiro, Manager, Engineering and Regulatory Affairs TYPE OF EQUIPMENT: BLUETOOH inside 1.9 GHz UPCS Cordless Telephone – Base Unit FCC IDENTIFIERS: AMWUN110 Dear Sir or Madam: Some of the material included in this application contains trade secrets and proprietary information not customarily released to the public. Because public disclosure of the material might be harmful to the applicant and provide unjustified benefits to its competitors, it is requested that the following be withheld from public disclosure: Circuit Description – file: Bluetooth test mode description.rtf Schematic Diagram – file: BASE MAIN_SCHEMATIC DIAGRAM2.pdf Block Diagram - file: BASE_BLOCK_DIAGRAM.pdf Trade secrets and proprietary information can be held confidential. Therefore, we wish to invoke the act under the provisions of 47CFR, Sections 0.457(d) and 0.459. Please contact the undersigned if you have any questions or need any further information. Regards, Jon Suehiro Manager, Engineering and Regulatory Affairs

DECT3181 base Equipment Labels: The following Labels are permanently affixed to the equipment. 1) FCC LABEL: 2) FCC STATEMENT: DECT3181 handset Equipment Labels: The following Labels are permanently affixed to the equipment. 3) HANDSET: 46.1 mm (W) X 17.1 mm (H)

FCC PART 15.249 TEST REPORT Applicant UNIDEN AMERICA CORPORATION Address 4700 AMON CARTER BLVD. FORT WORTH TEXAS 76155 USA FCC ID AMWUN110 Model Number DECT3181 Product Description BLUETOOTH INSIDE OF A DECT PHONE Date Sample Received 11/24/2009 Date Tested 12/15/2009 Tested By Nam Nguyen Approved By Mario de Aranzeta Report Number 2869UT9TestReport_Rev.doc Test Results PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW State Road 45 Newberry, FL 32669 USA Ph: 888.472.2424 or 352.472.5500 Fax: 352.472.2030 Email: [email protected] Website: www.timcoengr.com Testing Certificate # 0955-01 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUN110 REPORT: Y:\U\Uniden AMW\2869UT9\2869UT9TestReport_Rev.doc Page 2 of 21 TABLE OF CONTENT GENERAL REMARKS ........................................................................................................................... 3 GENERAL INFORMATION .................................................................................................................... 4 EMC EQUIPMENT LIST ....................................................................................................................... 5 TEST PROCEDURES ........................................................................................................................... 6 RADIATION INTERFERENCE ............................................................................................................... 7 POWER LINE CONDUCTED INTERFERENCE ..................................................................................... 10 20dB OCCUPIED BANDWIDTH .......................................................................................................... 13 CARRIER FREQUENCY SEPARATION: ............................................................................................... 14 NUMBER OF HOPPING FREQUENCIES: ............................................................................................ 14 TIME OF OCCUPANCY (DWELL TIME): .............................................................................................. 16 SPURIOUS EMISSIONS AT ANTENNA TERMINALS ............................................................................. 17 RADIATED SPURIOUS EMISSIONS INTO ADJACENT RESTRICTED BAND ......................................... 18 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUN110 REPORT: Y:\U\Uniden AMW\2869UT9\2869UT9TestReport_Rev.doc Page 3 of 21 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. The test results relate only to the items tested. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Testing Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: 12/15/2009 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUN110 REPORT: Y:\U\Uniden AMW\2869UT9\2869UT9TestReport_Rev.doc Page 4 of 21 GENERAL INFORMATION DUT Specification Applicable Standard Part 15.249 DUT Description BLUETOOTH INSIDE OF A DECT PHONE FCC ID AMWUN110 Operating Frequency TX: (2402.00 – 2480.00) MHz Number of channels 79 DUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable Antenna Connector N/A Antenna N/A Test Facility Timco Engineering Inc. located at 849 NW State Road 45 Newberry, FL 32669 USA. Test Conditions Temperature: 26ºC Relative humidity: 50% Test Exercise The DUT was placed in continuous transmit mode of operation. Test Supporting Equipment Supporting Device Manufacturer Model / FCC ID Serial Number N/A APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUN110 REPORT: Y:\U\Uniden AMW\2869UT9\2869UT9TestReport_Rev.doc Page 5 of 21 EMC EQUIPMENT LIST Device Manufacturer Model Serial Number Cal/Char Date Due Date 3-Meter Semi- Anechoic Chamber Panashield N/A N/A Listed 5/11/07 5/11/10 AC Voltmeter HP 400FL 2213A14499 CAL 3/23/09 3/23/10 Analyzer Tan Tower Quasi- Peak Adapter HP 85650A 3303A01690 CAL 11/22/09 11/22/11 Analyzer Tan Tower RF Preselector HP 85685A 3221A01400 CAL 11/21/09 11/21/11 Analyzer Tan Tower Spectrum Analyzer HP 8566B Opt 462 3138A07786 3144A20661 CAL 11/24/09 11/24/11 Analyzer Tan Tower Preamplifier HP 8449B- H02 3008A00372 CAL 11/21/09 11/21/11 Coaxial Cable #64 Semflex Inc. 60637 Timco #64 CHAR 3/30/09 3/30/11 Antenna: Dipole Kit Electro- Metrics TDA- 30/1-4 152 CAL 3/3/09 3/3/12 Antenna: Dipole Kit Electro- Metrics TDA- 30/1-4 153 CHAR 4/5/09 4/5/12 Hygro- Thermometer Extech 445703 0602 CAL 1/30/09 1/30/11 Modulation Analyzer HP 8901A 3435A06868 CAL 5/9/09 5/9/11 Digital Multimeter Fluke FLUKE- 77-3 79510405 CAL 5/14/09 5/14/11 System One Audio Precision System One SYS1-45868 CHAR 2/27/08 2/27/10 Temperature Chamber Tenney Engineering TTRC 11717-7 CHAR 4/25/08 4/25/10 APPLICANT: UNIDEN AMERICA CORPORATION FCC ID: AMWUN110 REPORT: Y:\U\Uniden AMW\2869UT9\2869UT9TestReport_Rev.doc Page 6 of 21 TEST PROCEDURES Radiation Interference: ANSI C63.4-2003 using a spectrum analyzer, a preselector, a quasi-peak adapter, and an appropriate antenna. The analyzer was calibrated in dB above a microvolt at the output of the antenna. The resolution bandwidth was 1…
