UP094BH.indd AUP094BH.indd A9/28/2006 10:46:26 AM9/28/2006 10:46:26 AM 1 Introduction Uniden 2.4GHz cordless phones are designed and engineered to exacting standards for reliability, long life, and outstanding performance. NOTE: Illustrations in this manual are used for explanation purposes. Some illustrations in this manual may differ from the actual unit. The color of your cordless phone may vary. Features • 2.4 GHz Extended Range Technology • AutoTalk™ • Pulse/Tone Dialing • 20 Channel Autoscan • Last Number Redial • 10-Number Memory Dialing • AutoStandby™ • Earpiece Volume Control • Hearing Aid Compatible • Find Handset Locator The cordless phone features AutoTalk™ and AutoStandby™.AutoTalk™ allows you to answer a call by just removing the handset from the base so you don't have to waste time pushing buttons. AutoStandby™ allows you to hang up by simply returning the handset to the base. TheUltraClear Plus™ true compander circuitry virtually eliminates background noise. This innovative technology, together with 20 different channels, provides you with the best possible reception during all your conversations. To protect you against misbilled calls which could result from your phone being activated by other equipment, the cordless phone has Random Code™ digital security which automatically selects one of approx. 262,000 digital security codes for the handset and base. Also, the AutoSecure™ feature electronically locks your phone when the handset is charging in the base. If you have any trouble with your phone, call our Customer Hotline at 1- 800-297- 1023, Mon-Fri 7 am to 7 pm, Sat/Sun 9 am to 5 pm, CST. (Phone support is closed on holidays.) For more information on Uniden products and accessories, be sure to visit our web site: www.uniden.com Uniden ® is a registered trademark of Uniden America Corporation. AutoTalk,AutoStandby,UltraClear Plus,Random Code and AutoSecure are trademarks of Uniden America Corporation. Controls and Functions 1 2 3 9 13 5 14 10 11 12 6 7 8 4 15 16 1. Handset antenna 2. Handset earpiece 3.talk/batt low LED - indicates when phone is in use or the battery is low 4.[volume/ ] - sets the ringer tone and earpiece volume 5.[fl ash] - accesses call waiting (if available) 6.[ /tone] – temporarily switches to tone dialing when in pulse dial mode 7.[redial/pause] - redials the last number / adds a 2-second pause in a memory dialing sequence. 8.[memory] - enters or recalls numbers in stored in memory 9. Handset microphone and ringer speaker 10.[talk] - answers or places calls 11. [end] - hangs up a phone call / mutes the ringing tone temporarily 12.[channel] - selects another channel for clearer reception 13. Handset charging contacts 14. Base charging contacts 15.in use/ LED 16.[fi nd] - locates the handset UP094BH.indd 1UP094BH.indd 19/28/2006 10:46:26 AM9/28/2006 10:46:26 AM 2 Included with Your Phone • Base Unit • Handset • AC Adapter • Rechargeable Battery •Telephone Cord • This owner’s manual Replacement adapters, batteries and other parts may be purchased by calling the Customer Hotline at 1-800-297-1023, Mon-Fri 7 am to 7 pm, Sat/Sun 9 am to 5 pm, CST. (Phone support is closed on holidays.) Terminology Throughout this manual, terms such as Standby and Talk are used. Below is the terminology explanation. •Talk - The handset is off the base and [talk] has been pressed, enabling a dial tone. •Standby - The handset may be sitting on the base charging or out of the base cradle, but is NOT in use. [talk] has not been pressed and there is no dial tone. Accessibility Uniden provides a customer service hotline for accessibility questions. If you have a disability and need customer service assistance or if you have any questions about how Uniden's products accommodate persons with disabilities, please call the accessibility voice/TTY line: 1-800-874-9314 A representative is available to talk to you M-F, 8:00 am to 5:00 pm, CST. After hours, you can leave a message, and we will call you back. Information is also available on our web site, www.uniden.com, under the "Accessibility" link. Installing the Phone Do the following steps: A. Choose the best location B. Install the rechargeable battery pack into the handset C. Connect the base unit and charge the handset D. Mount the base unit on a wall E. Choose the dialing mode A. Choose the best location When choosing a location for your new phone, here are some important guidelines you should consider: Avoid noise sources such as a window by a street with heavy traffi c Avoid microwave ovens Avoid excessive moisture, extremely low temperatures, dust, mechanical vibration, or shock Avoid personal computers Avoid other cordless telephones Avoid heat sources, such as radiators, air ducts, and sunlight Avoid television sets and other electronic equipment Choose a central location • The location should be close to both a phone jack and a continuous power outlet (one which is not connected to a switch). • The base and handset should be kept away from sources of electrical noise such as motors and fl uorescent lighting. • The base can be placed on a desk, tabletop, or mounted on a standard wall plate. For better reception, place the base as high as possible. • The base should be placed in an open area for optimum range and reception. UP094BH.indd 2UP094BH.indd 29/28/2006 10:46:26 AM9/28/2006 10:46:26 AM 3 B. Install the rechargeable battery pack into the handset The handset is powered by a rechargeable battery pack. The battery recharges automatically when the handset is placed in the base unit. NOTE: If your home has specially wired alarm equipment connected to the telephone line, be sure that installing the system does not disable your alarm equipment. If you have questions about what will disable your alarm equipment, contact your telephone company or a qualifi ed installer. 1) Press down on the handset battery case cover (use the fi nger indention for a better grip) and slide the cover downward to remove. 2) Plug the battery pac…

Text truncated - open the document above for the full version.

REQUEST FOR CONFIDENTIALITY November 01, 2006 To: Federal Communications Commission Equipment Authorization Branch Laboratory Division Office of Engineering and Technology 7435 Oakland Mills Road Columbia, Maryland 21046 Subject: Data for FCC Certification Applicant: Uniden America Corporation 181 N. Country Club Road, P.O. Box 580 Lake City, South Carolina 29560 James R. Haynes, Vice President, Engineering and Regulatory Affairs TYPE OF EQUIPMENT: 900 MHz Cordless Telephone Remote Unit - Part 15.249 FCC IDENTIFIER: AMWUP094R Dear Sir or Madam: Some of the material included in this application contains trade secrets and proprietary information not customarily released to the public. Because public disclosure of the material might be harmful to the applicant and provide unjustified benefits to its competitors, it is requested that the following be withheld from public disclosure: Circuit Descriptions and Test Mode Information (file: AMWUP094R Circuit Description.pdf) Schematic Diagrams (file: AMWUP094R Schematic.pdf) Block Diagrams (file: AMWUP094R Block Diagram.pdf) Trade secrets and proprietary information can be held confidential. Therefore, we wish to invoke the act under the provisions of 47CFR, Sections 0.457(d) and 0.459. Please contact the undersigned if you have any questions or need any further information. Regards, James R. Haynes Vice President, Engineering and Regulatory Affairs

GENERAL INFORMATION General Information in accordance with the Federal Communications Commission Rules and Regulations, Volume II, Part 2. (1) Applicant: (2) FCC Identifier: (3) Instruction Manual: Refer to User Manual (4) Circuit Description: Refer to Operational Description (5) Circuit & Block Diagrams: Refer to Block Diagram / Schematics (6) Measurement Data: Refer to Test Report The following conditions and procedures were followed during testing of the equipment. Room Temperature: 23 - 27 Degrees Celsius Room Humidity: 40 - 60 % Power Supply: Ni-cd Battery for Handset (7) Photographs : Refer to External Photos (8) Peripheral or Accessory Device: Not used (9) Transition provisions in section 15.37 Rules: (10) Decoding the Emergency Broadcast System Attention Signal: Not Applicable (11) Direct Sequence Spread Spectrum Transmitter: Not Applicable (12) Digital Security Code Information: Refer to Operational Description Uniden America Corporation 181 N. Country Club Road Lake City, South Carolina 29560 Mr. James R. Ha ynes, Vice President FCC ID: AMWUP094R MODEL: EXP4541 (FOR HANDSET) This equipment complies with the new Part 15 of FCC Rules and is not affected by Section 15.37.

Equipment Identification Label Equipment Label: The following label is permanently affixed to the Handset. HANDSET: 30 mm (W) X 20 mm (H) FCC STATEMENT: To be described in user manual

Test Report TEST PROCEDURES AND TEST SITE DESCRIPTION MEASUREMENT ITEMS Section No. 5-1 Field Strength of Radiated Emissions 15.249(a)(b) 15.205 / 15.209 5-2 Power Line Conducted Emissions 15.207 SUPPLEMENT DATA - BAND EDGE EMISSIONS FCC ID: AMWUP094R MODEL: EXP4541 (for HANDSET) EQUIPMENT: 2.4 GHz ISM BAND ANALOG TRANSMITTER DATE: October 26, 2006 Tested by: Mr. Y. Takahashi, Uniden Corporation 5-1 Field Strength of Radiated Emissions 15.249(a)(b) 15.205 / 15.209 The measurements were performed in accordance with the ANSI C63.4-2003. Field Strength measurements of radiated spurious emissions were made at the open test site of a 3 meter range maintained by Uniden Corporation in Japan. Complete description and measurement data of this test site have been placed on file with the Commission. The radio frequency spectrum was scanned in the range of 30 MHz to the 10 th harmonic in accordance with the section 15.33(a) of the FCC Rules. The frequency below 1 GHz, the measurement was carried out by using CISPR quasi-peak detector, AGILENT E7400A the Spectrum Analyzer in accordance with the sections 15.33(a) and 15.35(a). The frequency above 1 GHz, using the AGILENT E7400A Spectrum Analyzer in accordance with the section 15.35(b) carried out the measurement. A bilog antenna CBL6112A was used to cover the range from 30 MHz to 1000 MHz. Narrowband tuned dipole antennas were used over the entire 30 to 1000 MHz range for precision measurements of field strength. Above 1000 MHz, a horn antenna EMCO 3115 was used. For each spurious or harmonic frequency, the antenna was raised and lowered to obtain a maximum reading on the Spectrum Analyzer with antenna horizontally polarized. Then the turntable, on which the equipment under test was placed, was rotated a minimum of 360 degrees to further increase the reading on the Spectrum Analyzer. For testing small and/or handheld product, the measurement was performed in 3 orthogonal planes(X, Y, Z). This procedure was repeated with the antenna vertically polarized. The equipment under test was placed in its normal operating position on a turntable approximately 1 meter in height. In order to convert the measured emission levels into field strength in dBuV/m, the actual field strength (Ef) is determined by algebraically adding the measured emission level (Em) and the antenna correction factor (ACF) including the cable loss at the appropriate frequency. Ef [dBuV/m] = Em [dBuV/m] + ACF [dB] FCC Limits: a) Fundamental emission: 94 dBuV/m (50,000 uV/m) b) Spurious emissions: 30 - 88 MHz 40 dBuV/m (100 uV/m) 88 - 216 MHz 43.5 dBuV/m (150 uV/m) 216 - 960 MHz 46 dBuV/m (200 uV/m) Above 960 MHz 54 dBuV/m (500 uV/m) Test Results: Refer to the attached test reports. All emissions not reported were more than 20 dB below the limits. NOTE: For measurement of the handset, all of the testing were made with the internal battery that is fully charged. For measurement of base unit, all of the testing weremade with the AC Adapter which connected to a standardvoltage source. 5-2 Power Line Conducted Emissions 15.207 Test Procedure: The measurements were performed in accordance with the ANSI C63.4- 2003 . During the measurements, a standard voltage source is fed into the unit under test through a power line impedance stabilization network. FCC Limit: The radio frequency voltage that is conducted back into the AC power line on any frequencies within the band from 150kHz to 30MHz shall not exceed the following limitation. REQUIREMENTS: FREQUENCY(MHz) LEVEL (dBuV) 0.150-0.50 66 to 56 QP 56 to 46 Ave 0.50-5.0 56 QP 46 Ave 5.0-30.0 60 QP 50 Ave Test Results: Refer to the attached test reports. All emissionsnot reported were more than 20 dB below the limits. NOTE: Regarding the Handset, this FCC requirement is notapplicable to it since the Handset is intended to use thebattery only. SUPPLEMENT DATA - BAND EDGE EMISSION Attached data show the handset’s transmission on lowest channel and base unit’s transmission on highest channel. At the outside of emission bands, those emissions are well reduced against the operational channel frequency of the units.
