AMWUP8225.8GHz ISM BAND DIGITAL CORDLESS TELEPHONE

i 1 Table of ContentsWelcome....................................................................... 4 Accessibility ............................................................. 4Terminology Used in this Manual ............................. 5 Product Overview ........................................................ 6 Features: .................................................................. 6Answering System Features .................................... 6Parts of the Handset ................................................ 7 Parts of the Answering System Base/Charger ......... 8 Using the Interface ...................................................... 9 Reading the Display ................................................. 9 Using the Four-way Function Key .......................... 10Using the Handset Menus ..................................... 10Entering Text from Your Handset ........................... 11 Installing the Phone .................................................. 12 Choosing the Best Location ................................... 12Wall Mounting the Base ......................................... 12Installing the Battery .............................................. 13 Connecting the Base and Charging the Handset .. 14Connecting to the Phone Line ............................... 14 Testing the Connection .......................................... 14 Changing the Dial Mode ........................................ 15Installing the Belt Clip ............................................ 15 Basic Setup ................................................................ 16 Selecting a Language ............................................ 16 Activating Personal Ring ........................................ 16Activating the Key Touch Tone ............................... 16 Adding Accessory Handsets .................................... 17 Compatible Handsets ............................................ 17Charging Accessory Handsets ............................... 17Registering TCX930 Accessory Handsets ............. 18 Resetting Handsets ............................................... 19 Setting Up the Phonebook........................................ 20 Creating Phonebook Entries .................................. 20Finding a Phonebook Entry ................................... 21 Editing an Existing Phonebook Entry ..................... 21 Storing Caller ID or Redial Numbers in the Phonebook .22 Deleting Phonebook Entries .................................. 22Copying Phonebook Entries to Another Handset .. 23 2 Customizing Your Phone .......................................... 24 Selecting a Ring Tone (Handset Only) ................... 24 Activating AutoTalk (Handset only) ........................ 25Activating Any Key Answer (Handset only) ............ 25 Using Your Phone...................................................... 26 Making a Call from the Phonebook ........................ 27Chain dialing from the Phonebook ......................... 27 Switching to the Handset Speakerphone During a Call .27 Using Caller ID and Call Waiting .............................. 28 Using the Caller ID List ......................................... 28Making a Call from a Caller ID Record .................. 28Deleting Caller ID Numbers ................................... 29 Using Call Waiting .................................................. 29 Redialing a Number................................................... 30 Deleting a Redial Record ....................................... 30 Adjusting the Ringer, Earpiece and Speaker Volume .. 31 Adjusting the Ringer Volume ................................. 31Adjusting the Earpiece Volume .............................. 31Adjusting the Speaker Volume ............................... 31Adjusting the Audio Tone ....................................... 31Using the Clarity Boost Feature ............................. 32 Finding a Lost Handset............................................. 32Using Conference and Transfer ............................... 33 Conferencing ......................................................... 33Transferring a Call ................................................. 33 Using Special Features ............................................. 34 Muting the Ringer (One Call Only) ......................... 34 Muting the Microphone .......................................... 34Privacy Mode ......................................................... 34Seven-Digit Dialing ................................................ 35 Using the Intercom ................................................. 35Tone Dialing Switch Over ....................................... 36Installing the Optional Headset .............................. 36 Setting Up the Answering System ........................... 37 Features ................................................................. 37 Using the Answering System Interface .................. 38 Selecting the Language ......................................... 38Setting the Number of Rings .................................. 39Setting the Day & Time .......................................... 39 Recording a Personal Greeting ............................. 40Selecting a Greeting .............................................. 40Deleting Your Personal Greeting ........................... 41 3 Setting the Record Time (or Announce Only) ........ 41Activating the Message Alert ................................. 42 Activating Call Screening ....................................... 42Setting a Security Code or3HUVRQDO,GHQWL¿FDWLRQ1XPEHU 3,1 .................... 42 Using the Answering System ................................... 43 Turning Your Answering System On and Off ......... 43 Reviewing Messages ............................................. 44Screening Calls ...................................................... 45 Turning Off the Message Alert Tone....................... 45Operating the Answering SystemWhile You Are Away from Home ...…

Text truncated - open the document above for the full version.

REQUEST FOR CONFIDENTIALITY November 9, 2006 To: Federal Communications Commission Equipment Authorization Branch, Lab Div., OET 7435 Oakland Mills Road Columbia, Maryland 21046 Subject: Data for FCC Certification Applicant: Uniden America Corporation 181 N. Country Club Road, P.O. Box 580 Lake City, South Carolina 29560 James R. Haynes, Vice President, Engineering and Regulatory Affairs TYPE OF EQUIPMENT: 5.8 GHz Cordless Telephone - Part 15.247 FCC IDENTIFIER: AMWUP822 Dear Sir or Madam: Some of the material included in this application contains trade secrets and proprietary information not customarily released to the public. Because public disclosure of the material might be harmful to the applicant and provide unjustified benefits to its competitors, it is requested that the following be withheld from public disclosure: Circuit Description - file: AMWUP822_CIRCUIT DESCRIPTION.pdf Schematic Diagrams - files: AMWUP822_BASE KEY sch.pdf AMWUP822_BASE MAIN sch.pdf AMWUP822_BASE RF sch.pdf AMWUP822 _PORT MAIN sch.pdf AMWUP822_PORT RF sch.pdf Block Diagrams - files AMWUP822_BASE MAIN blk.pdf AMWUP822_BASE RF blk.pdf AMWUP822_PORT MAIN blk.pdf AMWUP822_PORT RF blk.pdf Test Mode Instructions - file AMWUP822_TEST MODE INSTRUCTION.pdf Trade secrets and proprietary information can be held confidential. Therefore, we wish to invoke the act under the provisions of 47CFR, Sections 0.457(d) and 0.459. Please contact the undersigned if you have any questions or need any further information. Regards, James R. Haynes Vice President, Engineering and Regulatory Affairs

Equipment Identification Label Equipment Labels: The following Labels are permanently affixed to the Handset and the Base Unit respectively. 1) BASE UNIT: 40 mm (W) X 45 mm (H) 2) BASE UNIT(FCC STATEMENT): 40 mm (W) X 23 mm (H) 3) HANDSET: 31 mm (W) X 53 mm (H) LABEL LOCATION BASE UNIT FCC STATEMENT FCC LABEL HANDSET FCC LABEL

5800 MHz System Validation Brain Tissue Simulant Rev. 1.1 Celltech Labs Inc. 1955 Moss Court, Kelowna, B.C. Canada V1Y 9L3 Tel. 250-448-7047 • Fax. 250-448-7046 • e-mail: [email protected] www.celltechlabs.com 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 1 of 12 5800 MHz SYSTEM VALIDATION Type: Asset Number: Serial Number: Place of Validation: Date of Validation: Celltech Labs Inc. certifies that the 5800 MHz System Validation was performed on the date indicated above. Performed by: Approved by: 5800 MHz Validation Dipole 1031 Celltech Labs Inc. March 15, 2006 00126 Spencer Watson Sean Johnston 5800 MHz System Validation Brain Tissue Simulant Rev. 1.1 2006 Celltech Labs Inc. Page 2 of 12 1. Dipole Construction & Electrical Characteristics The validation dipole was constructed in accordance with the IEEE Std “Recommended Practice for Determining the Spatial-Peak Specific Absorption Rate (SAR) in the Human Body Due to Wireless Communications Devices: Experimental Techniques”. The electrical properties were measured using an HP 8753E Network Analyzer. The network analyzer was calibrated to the validation dipole N-type connector feed point using an HP85032E Type N calibration kit. The dipole was placed parallel to a planar phantom at a separation distance of 10.0mm from the simulating fluid using a loss-less dielectric spacer. The measured input impedance is: Feed point impedance at 5800 MHz Re{Z} = 54.244Ω Im{Z} = 0.9102Ω Return Loss at 5800 MHz -27.380 dB 5800 MHz System Validation Brain Tissue Simulant Rev. 1.1 2006 Celltech Labs Inc. Page 3 of 12 2. Validation Dipole VSWR Data 5800 MHz System Validation Brain Tissue Simulant Rev. 1.1 2006 Celltech Labs Inc. Page 4 of 12 3. Validation Dipole Dimensions Frequency (MHz) L (mm) H (mm) D (mm) 300 420.0 250.0 6.2 450 288.0 167.0 6.2 835 161.0 89.8 3.6 900 149.0 83.3 3.6 1450 89.1 51.7 3.6 1800 72.0 41.7 3.6 1900 68.0 39.5 3.6 2000 64.5 37.5 3.6 2450 51.8 30.6 3.6 3000 41.5 25.0 3.6 5200 - 5800 20.6 40.65 3.6 4. Validation Phantom The validation phantom is the SAM (Specific Anthropomorphic Mannequin) phantom manufactured by Schmid & Partner Engineering AG. The SAM phantom is a Fiberglass shell integrated in a wooden table. The shape of the shell corresponds to the phantom defined by SCC34-SC2. It enables the dosimetric evaluation of left and right hand phone usage as well as body mounted usage at the flat phantom region. A cover prevents evaporation of the liquid. Reference markings on the phantom allow the complete setup of all predefined phantom positions and measurement grids by manually teaching three points in the robot. Shell Thickness: 2.0 ± 0.1 mm Filling Volume: Approx. 25 liters Dimensions: 50 cm (W) x 100 cm (L) 5800 MHz System Validation Brain Tissue Simulant Rev. 1.1 2006 Celltech Labs Inc. Page 5 of 12 5. 5800 MHz System Validation Setup 5800 MHz System Validation Brain Tissue Simulant Rev. 1.1 2006 Celltech Labs Inc. Page 6 of 12 6. 5800 MHz Dipole Setup 5800 MHz System Validation Brain Tissue Simulant Rev. 1.1 2006 Celltech Labs Inc. Page 7 of 12 7. Measurement Conditions The SAM phantom was filled with 5800 MHz Brain tissue simulant. Relative Permittivity: 34.4 (-2.5% deviation from target) Conductivity: 5.27 mho/m (0% deviation from target) Fluid Temperature: 23 °C Fluid Depth: ≥ 15.0 cm Environmental Conditions: Ambient Temperature: 24.8°C Humidity: 30% Barometric Pressure: 101.1kPa The 5800 MHz Brain tissue simulant consisted of the following ingredients: Ingredient Percentage by weight Water 64 - 78% Mineral Oil 11 - 18% Emulsifiers 9 - 15% Additives and Salt 2 - 3% Target Dielectric Parameters at 22°C ε r = 35.3 (+/-5%) σ = 5.27 S/m (+/-5%) 5800 MHz System Validation Brain Tissue Simulant Rev. 1.1 2006 Celltech Labs Inc. Page 8 of 12 8. SAR Measurement The SAR measurement was performed with the E-field probe in mechanical detection mode only. The setup and determination of the forward power into the dipole was performed using the following procedures. PM1 Att1 x Dipole 3D Probe positioner Flat Phantom Field probe Signal Generator AmpLow Pass 3dB Att3 Dir.Coupler Att2 PM2 Cable PM3 d First the power meter PM1 (including attenuator Att1) is connected to the cable to measure the forward power at the location of the dipole connector (X). The signal generator is adjusted for the desired forward power at the dipole connector (taking into account the attenuation of Att1) as read by power meter PM2. After connecting the cable to the dipole, the signal generator is readjusted for the same reading at power meter PM2. If the signal generator does not allow adjustment in 0.01dB steps, the remaining difference at PM2 must be taken into consideration. PM3 records the reflected power from the dipole to ensure that the value is not changed from the previous value. The reflected power should be 20dB below the forward power. 5800 MHz System Validation Brain Tissue Simulant Rev. 1.1 2006 Celltech Labs Inc. Page 9 of 12 9. Validation Dipole SAR Test Results Ten SAR measurements were performed in order to achieve repeatability and to establish an average target value (W/kg). Validation Measurement SAR @ 0.25W Input averaged over 1g SAR @ 1W Input averaged over 1g SAR @ 0.25W Input averaged over 10g SAR @ 1W Input averaged over 10g Max SAR @ 0.25W Input Test 1 20.40 81.60 5.72 22.88 40.00 Test 2 20.40 81.60 5.70 22.80 40.00 Test 3 20.50 82.00 5.72 22.88 39.90 Test 4 20.30 81.20 5.68 22.72 40.20 Test 5 20.80 83.20 5.81 23.24 40.40 Test 6 20.50 82.00 5.75 23.00 39.70 Test 7 20.50 82.00 5.74 22.96 39.40 Test 8 20.50 82.00 5.73 22.92 39.60 Test 9 20.50 82.00 5.73 22.92 39.60 Test10 20.40 81.60 5.71 22.84 39.40 Average SAR 20.48 81.92 5.73 22.92 39.82 The results have been normalized to 1W (forward power) into the dipole. Target SAR @ 1 Watt Input averaged over 1 gram (W/kg) Measured SAR @ 1 Watt Input averaged over 1 gram Deviation from Target T…

Text truncated - open the document above for the full version.

Company: Uniden America Corporation FCC ID: AMWUP822 IC ID: 513C-UP822 Model(s): UP822BH / TRU9380 Portable 5.8 GHz Cordless Telephone Handset 5725.8-5848.9 MHz 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 1 of 48 Date(s) of Evaluation September 14, 2006 Test Report Serial No. 091206AMW -T774-S15T Report Revision No. Revision 1.0 Report Issue Date September 22, 2006 Description of Test(s) RF Exposure - SAR RF Exposure Category General Population Certificate No. 2470.01 RF EXPOSURE EVALUATION SPECIFIC ABSORPTION RATE S S S A A A R R R T T T E E E S S S T T T R R R E E E P P P O O O R R R T T T FOR UNIDEN AMERICA CORPORATION PORTABLE 5.8 GHz CORDLESS TELEPHONE HANDSET Model(s): UP822BH / TRU9380 FCC ID: AMWUP822 IC ID: 513C-UP822 Test Report Serial No. 091206AMW-T774-S15T Test Report Revision No. Revision 1.0 (Initial Release) Test Location Celltech Compliance Testing & Engineering Lab (Celltech Labs Inc.) 1955 Moss Court Kelowna, BC Canada V1Y 9L3 TEST STANDARD(S) & PROCEDURE(S) APPLIED FCC OET Bulletin 65, Supplement C (01-01) Industry Canada RSS-102 Issue 2 IEEE 1528-2003 Certificate No. 2470.01 Test Report Prepared By: Cheri Frangiadakis Test Report Writer Celltech Labs Inc. Test Report Reviewed By: Jonathan Hughes General Manager Celltech Labs Inc. Company: Uniden America Corporation FCC ID: AMWUP822 IC ID: 513C-UP822 Model(s): UP822BH / TRU9380 Portable 5.8 GHz Cordless Telephone Handset 5725.8-5848.9 MHz 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 2 of 48 Date(s) of Evaluation September 14, 2006 Test Report Serial No. 091206AMW -T774-S15T Report Revision No. Revision 1.0 Report Issue Date September 22, 2006 Description of Test(s) RF Exposure - SAR RF Exposure Category General Population Certificate No. 2470.01 Celltech Labs Inc. declares under its sole responsibility that this wireless device is compliant with the Specific Absorption Rate (SAR) RF exposure requirements specified in FCC 47 CFR §2.1093 and Health Canada’s Safety Code 6. The device was tested in accordance with the measurement standards and procedures specified in FCC OET Bulletin 65, Supplement C (Edition 01-01), Industry Canada RSS-102 Issue 2 and IEEE Standard 1528-2003 for the General Population / Uncontrolled Exposure environment. All measurements were performed in accordance with the SAR system manufacturer recommendations. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. The results and statements contained in this report pertain only to the device(s) evaluated. DECLARATION OF COMPLIANCE SAR RF EXPOSURE EVALUATION Test Lab and Location CELLTECH LABS INCORPORATED Testing and Engineering Services 1955 Moss Court Kelowna, B.C. Canada V1Y 9L3 Phone: 250-448-7047 Fax: 250-448-7046 e-mail: [email protected] web site: www.celltechlabs.com Company Information UNIDEN AMERICA CORPORATION Engineering Services Office 181 N. Country Club Road Lake City, SC 29560 United States FCC IDENTIFIER: AMWUP822 IC IDENTIFER: 513C-UP822 Model No.(s): UP822BH / TRU9380 Test Standard(s): FCC 47 CFR §2.1093; Health Canada Safety Code 6 Test Procedure(s): FCC OET Bulletin 65, Supplement C (01-01) Industry Canada RSS-102 Issue 2 IEEE 1528-2003 FCC Device Classification: Digital Transmission System (DTS) IC Device Classification: Low Power License-Exempt Radiocommunication Device (RSS-210 Issue 6) Device Description: 5.8 GHz Cordless Telephone Handset Transmit Frequency Range(s): 5725.8 - 5848.9 MHz (ISM Band) Mode of Operation: TDMA/TDD Max. Duty Cycle Tested: 10.5 % Max. RF Output Power Tested: 245.44 mW / 23.90 dBm (5787.3503 MHz) - Source-Based Time-Averaged Power Measurement Method: Radiated Free Space Power Battery Type(s) Tested: Ni-MH 3.6 V, 600 mAh (P/N: BT909) Antenna Type(s) Tested: Internal Body-Worn Accessories Tested: Plastic Belt-Clip (P/N: GBCT3C8645Z) Headset with Boom-Microphone (P/N: TRUC46) Max. SAR Level(s) Evaluated: Head: 0.037 W/kg (Peak SAR measured from Area Scan) Body: 0.274 W/kg (1g average) Test Report Approved By: Sean Johnston SAR Lab Manager Celltech Labs Inc. Company: Uniden America Corporation FCC ID: AMWUP822 IC ID: 513C-UP822 Model(s): UP822BH / TRU9380 Portable 5.8 GHz Cordless Telephone Handset 5725.8-5848.9 MHz 2006 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc.Page 3 of 48 Date(s) of Evaluation September 14, 2006 Test Report Serial No. 091206AMW -T774-S15T Report Revision No. Revision 1.0 Report Issue Date September 22, 2006 Description of Test(s) RF Exposure - SAR RF Exposure Category General Population Certificate No. 2470.01 TABLE OF CONTENTS 1.0 INTRODUCTION ___________________________________________________________________ 4 2.0 DESCRIPTION of DEVICE UNDER TEST (DUT)_________________________________________ 4 3.0 SAR MEASUREMENT SYSTEM ______________________________________________________ 5 4.0 MEASUREMENT SUMMARY ________________________________________________________ 6 MEASUREMENT SUMMARY (Cont.)______________________________________________________ 7 5.0 DETAILS OF SAR EVALUATION _____________________________________________________ 8 DETAILS OF SAR EVALUATION (Cont.) __________________________________________________ 9 6.0 EVALUATION PROCEDURES _______________________________________________________ 9 EVALUATION PROCEDURES (Cont.)____________________________________________________ 10 7.0 SYSTEM PERFORMANCE CHECK ______________________________…

Text truncated - open the document above for the full version.
