MHS050-2 RADIO VHF MARITIME FLOTTANTE GUIDE D’UTILISATION FLOATING VHF MARINE RADIO OWNER’S MANUAL E-2Uniden MHS050-2 Owner’s Manual Making a Distress Call For future reference, write your boat’s name & call sign here: Speak slowly - clearly - calmly. 1. Make sure your radio is on. 2. Press the 16/9-TRI button to switch to Channel 16 (156.8 MHz). (If the display does not show 16, press the 16/9-TRI button again until it does.) 3. Press the Push to Talk button and say: “MAYDAY -- MAYDAY -- MAYDAY.” 4. Say “THIS IS {name of your boat (three times) and call sign/ boat registration number (once)}.” 5. Repeat “MAYDAY {name of your boat}” once. 6. Tell where you are: (what navigational aids or landmarks are near, or read the latitude and longitude from your GPS). 7. State the nature of your distress (e.g. sinking, medical emergency, man overboard, on fire, adrift, etc.). 8. State the type of assistance you need (medical, towing, pumps, etc.). 9. Give the number of persons aboard and describe the condition of any injured persons. 10. Estimate present seaworthiness of your ship (e.g. how immediate is the danger due to flooding or fire). 11. Briefly describe your ship, giving ship name (i.e., “Blue Duck is 32 foot cabin cruiser, white hull, blue deck house”). 12. Say: “I WILL BE LISTENING ON CHANNEL 16.” 13. End the message by saying “THIS IS {name or call sign of your boat}, OVER.” 14. Release the Push to Talk button and listen. if you do not get an answer after 30 seconds, repeat your call beginning at step 3 above. E-3 Uniden MHS050-2 Owner’s Manual Faire un appel De Détresse Pour toute référence ultérieure, transcrivez ci-dessous le nom et l’indicatif d’appel de votre bateau: Parlez lentement – clairement – calmement. 1. Vérifiez si votre radio est en marche. 2. Appuyez sur la touche 16/9-TRI du microphone afin de commuter au canal 16 (156,8 MHz). (Si le canal 16 n’apparaît pas à l’affichage, appuyez de nouveau sur la touche 16/9-TRI jusqu’à ce qu’il soit affiché.) 3. Appuyez sur le bouton de microphone Push to Talk et dites:“MAYDAY -- MAYDAY -- MAYDAY”. 4. Donnez l’identité de votre navire en disant : “ICI {nom de votre bateau (trois fois) ou indicatif d’appel et le numéro d’identification de votre bateau (une fois)}”. 5. Dites “MAYDAY {nom ou indicatif d’appel de votre bateau} une fois”. 6. Donnez votre position : (quels sont les points de repère ou aides à la navigation près de vous ou lisez les coordonnées de longitude et de latitude apparaissant sur votre dispositif GPS). 7. Révélez la nature de votre détresse (par exemple, nous sommes en train de couler, urgence médicale, un homme à la mer, un incendie, nous sommes à la dérive, etc. 8. Révélez la nature de l’aide désirée (médicale, remorquage, essence, etc.) 9. Donnez le nombre de personnes à bord et les conditions des blessés, s’il y en a. 10. Don nez la condition de navigabilité actuelle de votre navire, tel que le degré de l’urgence par rapport une inondation, et une incendie. 11. Donnez une brève description de votre navire en donnant le nom du bateau (par exemple, “Blue Duck est un yacht de croisière de 32 pieds, avec une coque blanche et un rouffle bleu.). 12. Dites : “JE VAIS ÉCOUTER SUR LE CANAL 16”. 13. Terminez le message en disant “ICI {nom ou indicatif d’appel de votre bateau}, À VOUS”. 14. Rel âchez le bouton Push to Talk du microphone et écoutez. si v ous n’obtenez pas de réponse après 30 secondes, répétez l’appel encommençant à l’étape 3 ci-dessus . E-4Uniden MHS050-2 Owner’s Manual table oF Contents MHS050-2 INTRODUCTION ................................................................6 F EATURES ........................................................................................ 6 GETTING STARTED ............................................................................7 WHAT’S INCLUDED .........................................................................7 C ONTROLS AND INDICAT ORS ....................................................... 8 G ETTING STARTED ............................................................................9 CONNECTING POWER ....................................................................9 I NSTALL THE BATTER Y PACk ....................................................... 9 C HARGING THE BATTERY PACk .................................................10 B ATTERY LEVEL DISPLAY .............................................................11 ATTACHING THE BELTCLIP ..........................................................12 U SING THE CARABINER CLIP ...................................................... 12 O PERATION ......................................................................................12 BASICS ........................................................................................... 12 Power on/off ................................................................................12 Volume .............................................................................................12 Select a channel ........................................................................13 Set Squelch ...................................................................................13 Srt channel mode .......................................................................14 TRANSMITTING AND RECEIVING ................................................14 one-touch channel 16/9 ............................................................ 15 triPle watch ..................................................................................15 SCANNING ......................................................................................15 Storing Scanned channelS .................................................... 16 MONITOR ........................................................................................16 droP-out delay ............................................................................16 Battery SaVe ................................................................................…

Text truncated - open the document above for the full version.

Uniden America Corporation 4700 Amon Carter Blvd. Fort Worth, TX 76155 817-858-3300 Fax: 817-858-3328 LIMITED AGENCY AGREEMENT December 02, 2011 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 Attn: Director of Certification RE: Equipment Authorization for FCC Certification We, Uniden America Corporation (hereinafter “Uniden”), hereby authorize Jonathan Hughes, Project Manager of Celltech Labs, Inc., located at 21-364 Lougheed Road in Kelowna, BC V1X 7R8, to act as our agent for the purpose of testing and preparing an equipment authorization application for our device identified by the FCC Certification number AMWUT639 under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is today, December 02, 2011. This limited agency agreement expires on December 02, 2012, unless sooner terminated or extended by written notice to Celltech Labs, Inc. and Federal Communications Commission. Uniden certifies that equipment manufactured, imported, or marketed under the FCC Certification number AMWUT639 will comply with the parameters established in the application for equipment authorization unless the changes are in full compliance to the provisions in the FCC Rules and Regulations that allow such changes. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Celltech Labs, Inc., resides with Uniden America Corporation located at 4700 Amon Carter Blvd, Fort Worth, Texas 76155. Uniden America Corporation 4700 Amon Carter Blvd. Fort Worth, TX 76155 817-858-3300 Fax: 817-858-3328 If you have any questions or comments, please do not hesitate to contact me. Regards, Jon Suehiro Manager, Engineering and Regulatory Affairs

Uniden America Corporation 4700 Amon Carter Blvd. Fort Worth, TX 76155 817-858-3300 Fax: 817-858-3328 REQUEST FOR CONFIDENTIALITY December 2, 2011 To: Federal Communications Commission Equipment Authorization Branch Laboratory Division Office of Engineering and Technology 7435 Oakland Mills Road Columbia, Maryland 21046 Subject: Data for FCC Certification under Part 95 Applicant: Uniden America Corporation 4700 Amon Carter Blvd., Fort Worth, Texas 76155 Jon Suehiro, Manager – Engineering and Regulatory Affairs TYPE OF EQUIPMENT: Marine VHF Hand Held Transmitter FCC IDENTIFIER: AMWUT639 Dear Sir or Madam: Some of the material included in this application contains trade secrets and proprietary information not customarily released to the public. Because public disclosure of the material might be harmful to the applicant and provide unjustified benefits to its competitors, it is requested that the following be withheld from public disclosure: Circuit Description (MHS050_ Circuit Description - CONFIDENTIAL.pdf) Schem atic Diagrams (MHS050_SCHEMATIC - CONFIDENTIAL.pdf) Block Diagrams (MHS050_BLOCK_DIAGRAM - CONFIDENTIAL.pdf) Alignment Procedure (MHS050_ALIG NMENT_PROCEDURE - CONFIDENTIAL.pdf) Parts List (MHS050_Parts list - CONFIDENTIAL.pdf) Trade secrets and proprietary information can be held confidential. Therefore, we wish to invoke the act under the provisions of 47CFR, Sections 0.457(d) and 0.459. Please contact the undersigned if you have any questions or need any further information. Regards, Jon Suehiro Manager, Engineering and Regulatory Affairs

Label & Location info ID Label: (Size 25 x 20 mm) Location MODEL: MHS050 FCC ID: AMWUT639 IC: 513C-UT639

Test Report Serial No.: 112211AMW-T1134-E80V Test Report Issue Date: December 13, 2011 Measurement Date(s): November 25-29, 2011 Test Report Revision No.: Rev. 1.1 (2nd Release) Rule Part(s) Applied: FCC 47 CFR §2, §80 Industry Canada RSS-182 Issue 4, RSS-Gen Issue 3 Test Site Registration(s): FCC Accredited Site Industry Canada Test Site Registration No. 3874A-1 Applicant: Uniden America Corporation FCC ID: AMWUT639 IC: 513C-UT639 DUT Type: Portable VHF PTT Marine Radio Transceiver Model: MHS050 Freq.: 156.025-157.425 MHz 2011 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 1 of 28 DECLARATION OF COMPLIANCE FCC PART 80 IC RSS-182 (Issue 4) Name CELLTECH LABS INCORPORATED Test Lab Information Address 21-364 Lougheed Road, Kelowna, British Columbia V1X 7R8 Canada FCC Accredited Site (ISO 17025:2005 - A2LA Test Lab Certificate No. 2470.01) Test Site Registration No.(s) IC 3874A-1 Name UNIDEN AMERICA CORPORATION Applicant Information Address 4700 Amon Carter Boulevard, Fort Worth, Texas 76155 United States FCC 47 CFR Part 2; Part 80 IC RSS-182 Issue 4; RSS-Gen Issue 3 Standard(s) & Procedure(s) ANSI TIA/EIA-603-C-2004 C63.4-2003 FCC Licensed Non-Broadcast Transmitter Held to Face (TNF) 47 CFR §80 Device Classification(s) IC Maritime Radio Transmitter/Receiver in the Band 156-162.5 MHz RSS-182 Issue 4 RF Exposure Category FCC/IC General Population / Uncontrolled Application Type(s) FCC/IC New Certification FCC ID: AMWUT639 Device Identifier(s) IC: 513C-UT639 Device Under Test (DUT) Portable Push-To-Talk (PTT) VHF Marine Radio Transceiver Date of Sample Receipt November 22, 2011 Date(s) of Evaluation November 25-29, 2011 Device Model(s) MHS050 Test Sample Serial No.(s) UT639BK (Identical Prototype) Hardware Revision No. EPP Stage Firmware Revision No. EPP Stage Transmit Frequency Range(s) 156.025 - 157.425 MHz (VHF Marine Band) 2.5 Watts Conducted + 0.2 W) – Hi Power Manuf. Rated Output Power 0.7 Watts Conducted + 0.1 W) – Lo Power Max. RF Output Power Tested 2.6 Watts Conducted Modulation Type(s) FM Emission Designator(s) 14K4F3E Antenna Type(s) Tested Permanent (Non-detachable) -1 dBi Gain Power Source(s) Tested Ni-MH Battery Pack (4.8V, 700mAh) Model: BP38 This wireless device has demonstrated compliance with the applicable technical standards as indicated in the measurement report and was tested in accordance with the measurement procedures specified in FCC 47 CFR Rule Parts 2 and Part 80; Industry Canada RSS- 182 Issue 4 and RSS-Gen Issue 3; ANSI TIA/EIA-603-C-2004 and ANSI C63.4-2003. I attest to the accuracy of data. All measurements were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. The results and statements contained in this report pertain only to the device(s) evaluated. This test report shall not be reproduced partially, or in full, without the prior written approval of Celltech Labs Inc. Test Report Approved By Sean Johnston Lab Manager Celltech Labs Inc. Test Report Serial No.: 112211AMW-T1134-E80V Test Report Issue Date: December 13, 2011 Measurement Date(s): November 25-29, 2011 Test Report Revision No.: Rev. 1.1 (2nd Release) Rule Part(s) Applied: FCC 47 CFR §2, §80 Industry Canada RSS-182 Issue 4, RSS-Gen Issue 3 Test Site Registration(s): FCC Accredited Site Industry Canada Test Site Registration No. 3874A-1 Applicant: Uniden America Corporation FCC ID: AMWUT639 IC: 513C-UT639 DUT Type: Portable VHF PTT Marine Radio Transceiver Model: MHS050 Freq.: 156.025-157.425 MHz 2011 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the prior written permission of Celltech Labs Inc. Page 2 of 28 TABLE OF CONTENTS 1.0 SCOPE ................................................................................................................................................................ 5 2.0 REFERENCES .................................................................................................................................................... 5 2.1 Normative References ......................................................................................................................................... 5 3.0 PASS/FAIL CRITERIA......................................................................................................................................... 5 4.0 FACILITIES AND ACCREDITATIONS ................................................................................................................ 6 5.0 GENERAL INFORMATION ................................................................................................................................. 6 5.1 Applicant Information ........................................................................................................................................... 6 5.2 DUT Description .................................................................................................................................................. 6 5.3 Rule Part(s) & Classification(s)............................................................................................................................ 6 5.4 Mode(s) of Operation Tested............................................................................................................................... 7 5.5 Modification(s) ..................................................................................................................................................... 7 6.0 RANGE OF OPERATING POWER (FCC §2.1033(C)(6))................................................................................... 7 Appendix A RF Output Power Measurement...................................................................................................... 8 Appendix B Spuri…
