AMWUT889Marine VHF Portable Transceiver

Uniden America Corporation

Click to zoom

Application Details

Equipment Class: TNF - Licensed Non-Broadcast Transmitter Held to Face
Date of Grant: Nov 07, 2002
Application Purpose: Original Equipment
Date of Application: Oct 22, 2002
Equipment Note: Marine VHF Portable Transceiver
Frequency Range: 156.05000000 - 157.42500000
Company: Uniden America Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Contents Controls and Indicators ...................................................................... 2 Warning! .............................................................................................. 4 Introduction ........................................................................................ 5 Features ........................................................................................... 5Technical Support and Service ........................................................ 6Maritime Radio Services Operation ................................................. 6 Parts and Accessories ...................................................................... 7 Getting Started ................................................................................... 8 Mounting the Drop-in Charger .......................................................... 8Attaching the Antenna ...................................................................... 8Attaching the Battery Pack ............................................................... 9Charging the Battery Pack ............................................................. 10 Operation .......................................................................................... 11 Turning on the Unit and Setting Squelch ....................................... 11Selecting a Channel ....................................................................... 12One-touch Channel 16/9 ................................................................ 12Monitoring Weather Channels ........................................................ 13Triple Watch ................................................................................... 14Weather Alert ................................................................................. 15NWR-SAME Alert ........................................................................... 16Registering FIPS Code .................................................................. 17USA, International and Canadian Channels .................................. 18Programming a Channel into Memory ........................................... 18Deleting a Channel from Memory .................................................. 19Scanning ........................................................................................ 19Transmitting ................................................................................... 20Lighted Keys and Display ............................................................... 20Battery Indicator ............................................................................. 21Key Lock ........................................................................................ 21 Marine Channels - USA ................................................................... 22 Marine Channels - International . .................................................... 24 Marine Channels - Canada .............................................................. 26 NWR-SAME Alert Leve l .................................................................... 28 Parts and Accessories . ................................................................... 30 Specifications ................................................................................... 31 Troubleshooting ............................................................................... 32 Warranty ........................................................................................... 33 VOYAGER.QX 8/20/2 11:22 AM Page 1 Controls and Indicators 2 1 Antenna2 Belt Clip3 Battery4 Knob5 PTT (Push to Talk) Key6 USA/International/Canadian button ( UIC ) 7 WX Mode/Weather Alert button ( WX/ALERT ) 8 TX Power button ( 1W/5W )//Lock Key ( LOCK ) 9 Microphone 10 Volume/Power Knob11 Squelch Knob12 LCD Display13 Memory button ( MEM ) 14 Scan button ( SCAN ) 15 Channel Up button ( ) 16 16/9 - Triple Watch button ( 16/9/TRI ) 17 Channel Down button ( ) 18 Speaker 1234 5 6879 10 11 12131415161718 VOYAGER.QX 8/20/2 11:22 AM Page 2 3 A Transmit IndicatorB TX Power Indicator C USA/International/Canadian ( US/INT/CAN ) Indicator D Channel Number Display E Memory Indicator F Scan Indicator G Battery Indicator H Triple Watch Indicator I Weather Mode Indicator J Weather Alert Indicator K Key Lock Indicator G IK BC D A E F J H LCD Display VOYAGER.QX 8/20/2 11:22 AM Page 3 Warning! • The VOYAGER is watertight only when both the antenna and the battery are properly attached. • Do not operate the transmitter of any radio equipment unless all the Radio Frequency (RF) connectors are secure and any openconnectors are properly terminated. • Do not operate the transmitter of any radio equipment near electrical blasting caps or in an explosive atmosphere. • Do not let children operate any transmitter-equipped radio equipment without proper supervision. • Have your radio equipment serviced by a qualified technician.• Do not operate the transmitter of any radio equipment with the antenna touching or close to the eyes, face, or exposed bodyparts. Lithium Ion Battery Pack Warning • This equipment contains a Lithium Ion Battery Pack.• Lithium is a chemical known to the State of California to cause cancer. • The Lithium Ion Battery Pack contained in this equipment may explode if disposed of in a fire. • Do not short-circuit the Battery Pack.• Do not charge the Lithium Ion Battery Pack used in this equipment in any charger other than the one designed to chargethis Battery Pack. Using another charger may damage theBattery Pack or cause the Battery Pack to explode. • Lithium Ion batteries must be disposed of properly. The exclamation point within an equilateral triangle is intendedto alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. 4 VOYAGER.QX 8/20/2 11:22 AM Page 4 Introduction The VOYAGER is a watertight, portable two-way VHF transceiver.It is compact, lightweight, rugged and fits easily in…

Text truncated - open the document above for the full version.

Attestation Statements

Unwgn’ c October 10, 2002 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Uniden America Corporation FCC ID: AMWUT889 FCC Part 80 Certification Request for Confidentiality Gentlemen: In accordance with 0.459 of CFR 47, Uniden America Corporation hereby requests confidentiality of the Block Diagrams, Circuit Diagrams, Circuit Description, and T une-up P rocedure attachments for the subject application. These documents contain detailed system and equipment description and related information about the product, which Uniden America Corporation considers to be proprietary, confidential, and a custom design and, otherwise, would not release to the general public. Since this design is a basis from which future technological products will evolve, Uniden America Corporation considers that this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Sincerely, JmS R. m-8 Vice President, Engineering and Regulatory Affairs UNIDEW AMERICA CORPORATIOH

Cover Letter(s)

October 23, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 SUBJECT: UNIDEN ENGINEERING SERVICES FCC ID: AMWUT889 Part 80 Certification Gentlemen: Submitted herewith, on behalf of UNIDEN ENGINEERING SERVICES, is an application for Part 80 Certification of the Portable VHF Marine Radio Transceiver. Attached is the applicant’s Letter of Authorization, Confidentiality Request, measurement report test data and plots, RF Exposure measurement report and data, FCC ID label and location, test setup photographs, internal and external photographs, block diagram (confidential), circuit diagrams & description (confidential), operational description (confidential), parts list, tune-up procedure (confidential), and the user's manual. Should you have any questions or comments concerning the above, please contact the undersigned. cc: UNIDEN ENGINEERING SERVICES

Cover Letter(s)

November 7, 2002 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Andy Leimer SUBJECT: Uniden America Corporation FCC ID: AMWUT889 731 Confirmation No.: EA651544 Correspondence Reference No.: 24289 Request for Tech. Info.: 11/06/02 Dear Andy: Transmitted herewith, on behalf of Uniden America Corporation is an amendment provided in response to the request for technical information dated November 6, 2002. 1. Please find attached the revised page 7 of the users manual. 2. Please find attached the 300MHz probe certification. 3. Please find attached the assessment performed using the FDTD numerical code SEMCAD by Schmid & Partner Engineering AG. 4. Please find attached the revised SAR report (page 16). We would like to inform you that the target was derived according to the IEEE P1528 standards (please refer to Table 7.1). Please also find attached the network analyzer plots. 5. Please find attached the revised uncertainty budget. We trust this information is sufficient to resolve FCC questions in this application. If you have any further questions, please do not hesitate to contact us. cc: Uniden America Corporation

External Photos

ID Label/Location Info

© 2002PCTEST Lab FCC ID SAMPLE LABEL & LOCATION LABELLING REQUIREMENTS PER §§ 2.925 The Label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time of purchase. (SEE NEXT PAGE)

Internal Photos

RF Exposure Info

© 2002 PCTEST Lab UNIDEN FCC ID: AMWUT889 NVLAP Lab Code: 100431-0 2-Way Portable VHF Marine Radio Transceiver (GMDSS) © 2002 PCTEST Lab UNIDEN FCC ID: AMWUT889 NVLAP Lab Code: 100431-0 2-Way Portable VHF Marine Radio Transceiver (GMDSS) © 2002 PCTEST Lab UNIDEN FCC ID: AMWUT889 NVLAP Lab Code: 100431-0 2-Way Portable VHF Marine Radio Transceiver (GMDSS) © 2002 PCTEST Lab UNIDEN FCC ID: AMWUT889 NVLAP Lab Code: 100431-0 2-Way Portable VHF Marine Radio Transceiver (GMDSS) © 2002 PCTEST Lab UNIDEN FCC ID: AMWUT889 NVLAP Lab Code: 100431-0 2-Way Portable VHF Marine Radio Transceiver (GMDSS) © 2002 PCTEST Lab UNIDEN FCC ID: AMWUT889 NVLAP Lab Code: 100431-0 2-Way Portable VHF Marine Radio Transceiver (GMDSS) © 2002 PCTEST Lab UNIDEN FCC ID: AMWUT889 NVLAP Lab Code: 100431-0 2-Way Portable VHF Marine Radio Transceiver (GMDSS) © 2002 PCTEST Lab UNIDEN FCC ID: AMWUT889 NVLAP Lab Code: 100431-0 2-Way Portable VHF Marine Radio Transceiver (GMDSS)

RF Exposure Info

ET3DV6 – SN:1677Page 1 of 22. October 2002 Additional Conversion Factors for Dosimetric E-Field Probe Type: Serial Number: Place of Assessment: Date of Assessment: Probe Calibration Date: Schmid & Partner Engineering AG hereby certifies that conversion factor(s) of this probe have been evaluated on the date indicated above. The assessment was performed using the FDTD numerical code SEMCAD of Schmid & Partner Engineering AG. Since the evaluation is coupled with measured conversion factors, it has to be recalculated yearly, i.e., following the re- calibration schedule of the probe. The uncertainty of the numerical assessment is based on the extrapolation from measured value at 900 MHz or at 1800 MHz. Assessed by: ET3DV6 1677 Zurich October 2, 2002 April 10, 2002

RF Exposure Info

PCTEST ENGINEERING LABORATORY, INC. 6660 — B Dobbin Road • Columbia, MD 21045 • USA Telephone 410.290.6652 / Fax 410.290.6654 http://www.pctestlab.com (email: [email protected]) CERTIFICATE OF COMPLIANCE (SAR EVALUATION) PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-220911484.AMW Test Dates: Oct. 1-2, 2002 EUT Type: 2-Way VHF Marine Radio FCC ID: AMWUT889 Page 1 of 22 © 2002 PCTEST Engineering Laboratory, Inc APPLICANT NAME & ADDRESS: DATE & LOCATION OF TESTING: UNIDEN ENGINEERING SERVICES Dates of Tests: Oct. 1-2, 2002 216 John Street Test Report S/N: SAR.220911484.AMW P.O. Box 580 Test Site: PCTEST Lab, Columbia MD Lake City, SC 29560-0580 Attention: Mr. Jim Haynes, Vice President- Engineering & Regulatory Affairs FCC ID: AMWUT889 APPLICANT: UNIDEN ENGINEERING SERVICES EUT Type: 2-Way Portable VHF Marine Radio Transceiver (GMDSS) Tx Frequency Range: 156.050 ~ 157.425MHz Rx Frequency Range: 156.050 ~ 163.275MHz Max. RF Output Power: 5.0 W (HI) / 1.0 W (LOW); 36.4 dBm Conducted Max. SAR Measurement: 0.890W/kg Body SAR; 0.743W/kg Mouth SAR Trade Name/Model(s): VOYAGER FCC Classification: Licensed Non-Broadcast Transmitter Held to Face (TNF) FCC Rule Part(s): §2.1093; FCC/OET Bulletin 65 Supplement C [July 2001] Application Type: Certification Test Device Serial No.: identical prototype This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC/OET Bulletin 65 Supplement C (2001) and IEEE Std. 1528-200X (Draft 6.4, July 2001). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. PCTEST certifies that no party to this application has been denied the FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. 220911484.AMW PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-220911484.AMW Test Dates: Oct. 1-2, 2002 EUT Type: 2-Way VHF Marine Radio FCC ID: AMWUT889 Page 2 of 22 © 2002 PCTEST Engineering Laboratory, Inc TABLE OF CONTENTS 1. INTRODUCTION .................................................................................................. 3 SAR DEFINITION ................................................................................................. 3 2. SAR MEASUREMENT SETUP .................................................................................. 4 Robotic System ....................................................................................................... 4 System Hardware ................................................................................................... 4 System Electronics .................................................................................................. 4 3. DASY3 E-FIELD PROBE SYSTEM ............................................................................ 5 Probe Measurement System.................................................................................... 5 Probe Specifications ............................................................................................... 5 4. Probe Calibration Process....................................................................................... 6 Dosimetric Assessment Procedure .......................................................................... 6 Free Space Assessment ........................................................................................... 6 Temperature Assessment ........................................................................................ 6 5. PHANTOM & EQUIVALENT TISSUES .................................................................... 7 SAM Phantom ........................................................................................................ 7 Brain & Muscle Simulating Mixture Characterization ............................................. 7 Device Holder for Transmitters............................................................................... 7 6. TEST SYSTEM SPECIFICATIONS ............................................................................. 8 Automated Test System Specifications .................................................................... 8 7. DOSIMETRIC ASSESSMENT & PHANTOM SPECS ................................................. 9 Measurement Procedure......................................................................................... 9 Specific Anthropomorphic Mannequin (SAM) Specifications.................................. 9 8. DEFINITION OF REFERENCE POINTS ................................................................. 10 EAR Reference Point............................................................................................. 10 Handset Reference Points ..................................................................................... 10 9. TEST CONFIGURATION POSITIONS .................................................................. 11 Positioning for Cheek/Touch ................................................................................ 11 Positioning for Ear / 15° Tilt .................................................................................. 12 Body Holster /Belt Clip Configurations ................................................................. 13 10. ANSI/IEEE C95.1 - 1992 RF EXPOSURE LIMITS ................................................... 14 Uncontrolled Environment ................................................................................... 14 Controlled Environment................................................................................…

Text truncated - open the document above for the full version.

RF Exposure Info

UNIDEN FCC ID: AMWUT889 -- 150MHz. Body SAR SAM Phantom; Flat Section; Probe:ET3DV6 - SN1677; ConvF(8.60,8.60,8.60) Med. Parameters 150 MHz He: σ = 0.83 mho/m ε r = 61.3 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.890 mW/g, SAR (10g): 0.629 mW/g UNIDEN Handheld VHF Radio Model: VOYAGER 150MHz. Ch.88 [ 157.425MHz.]; Standard Battery; Ambient Temp. = 22.3°C / Meas.Tissue Temp. = 22.2°C Conducted Power = 36.4dBm.; Spacing = 2.5cm from back [antenna side] of EUT to flat phantom; w/Beltclip Test Date --10/01/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 9.04E-2 2.71E-1 4.52E-1 6.33E-1 8.14E-1 PCTEST Engineering Laboratory, Inc. UNIDEN FCC ID: AMWUT889 -- 150MHz. Mouth SAR SAM Phantom; Flat Section; Probe:ET3DV6 - SN1677; ConvF(8.60,8.60,8.60) Med. Parameters 150 MHz Brain: σ = 0.78 mho/m ε r = 51.9 ρ = 1.00 g/cm 3 ; Antenna Position -- Out; Crest Factor 1.0 SAR (1g): 0.743 mW/g, SAR (10g): 0.285 mW/g UNIDEN Handheld VHF Radio Model: VOYAGER 150MHz. Ch.01 [ 156.050MHz.]; Standard Battery; Ambient Temp. = 22.3°C / Meas.Tissue Temp. = 22.2°C Conducted Power = 36.4dBm.; Spacing = 2.5cm (1.0inch) from front [LCD side] of EUT to flat phantom Test Date --10/01/2002 [FCC/OET Bulletin 65 - Supplement C, July 2001] SAR Tot [mW/g] 4.88E-2 1.46E-1 2.44E-1 3.42E-1 4.39E-1 PCTEST Engineering Laboratory, Inc.

RF Exposure Info

PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-220911484.AMW Test Dates: Oct. 1-2, 2002 EUT Type: 2-Way VHF Marine Radio FCC ID: AMWUT889 Page 16 of 22 © 2002 PCTEST Engineering Laboratory, Inc 12. SYSTEM VERIFICATION Tissue Verification Table 12.1 Simulated Tissue Verification [5] Test System Validation Prior to assessment, the system is verified to the ±10% of the specifications at 300MHz by using the system validation kit(s). (Graphic Plots Attached) Table 12.2 System Validation [5] MEASURED TISSUE PARAMETERS Date(s) 09/30/02 150MHz Brain 150MHz Muscle 300MHz Brain 300MHz Muscle Liquid Temperature (°C) 22.9 Target Measured Target Measured Target Measured Target Measured Dielectric Constant: ε 52.30 51.9 61.90 61.30 45.3 45.4 58.20 N/A Conductivity: σ 0.760 0.780 0.800 0.830 0.870 0.890 0.920 N/A SYSTEM DIPOLE VALIDATION TARGET & MEASURED System Validation Kit: D-300V2, S/N: 301 300MHz Brain Targeted SAR 1g (mW/g) 0.750 Measured SAR 1g (mW/g) 0.805 Deviation (%) + 7.3 PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-220911484.AMW Test Dates: Oct. 1-2, 2002 EUT Type: 2-Way VHF Marine Radio FCC ID: AMWUT889 Page 20 of 22 © 2002 PCTEST Engineering Laboratory, Inc 15. SAR TEST EQUIPMENT Equipment Calibration Table 15.1 Test Equipment Calibration NOTE: The E-field probe was calibrated by SPEAG, by temperature measurement procedure. Dipole Validation measurement is performed by PCTEST Lab. before each test. The brain simulating material is calibrated by PCTEST using the dielectric probe system and network analyzer to determine the conductivity and permittivity (dielectric constant) of the brain-equivalent material. EQUIPMENT SPECIFICATIONS Type Calibration Date Serial Number Stäubli Robot RX60L February 2002 599131-01 Stäubli Robot Controller February 2002 PCT592 Stäubli Teach Pendant (Joystick) February 2002 3323-00161 Micron Computer, 450 MHz Pentium III, Windows NT February 2002 PCT577 SPEAG EDC3 February 2002 321 SPEAG DAE3 February 2002 330 SPEAG E-Field Probe ET3DV6 April 2002 1677 SPEAG Dummy Probe February 2002 PCT583 SPEAG SAM Twin Phantom V4.0 February 2002 PCT666 SPEAG Light Alignment Sensor February 2002 205 PCTEST Validation Dipole D300V2 September 2002 PCT301 SPEAG Validation Dipole D835V2 February 2002 PCT512 SPEAG Validation Dipole D1900V2 February 2002 PCT613 Brain Equivalent Matter (150MHz) October 2002 PCTBEM501 Brain Equivalent Matter (300MHz) October 2002 PCTBEM601 Muscle Equivalent Matter (150MHz) October 2002 PCTMEM501 Microwave Amp. Model: 5S1G4, (800MHz - 4.2GHz) January 2002 22332 Gigatronics 8651A Power Meter January 2002 1835299 HP-8648D (9kHz ~ 4GHz) Signal Generator January 2002 PCT530 Amplifier Research 5S1G4 Power Amp January 2002 PCT540 HP-8753E (30kHz ~ 3GHz) Network Analyzer January 2002 PCT552 HP85070B Dielectric Probe Kit January 2002 PCT501 Ambient Noise/Reflection, etc. <12mW/kg/<3%of SAR January 2002 Anechoic Room PCT01 PCTEST SAR REPORT FCC CERTIFICATION Reviewed by: Quality Manager SAR Filename: SAR-220911484.AMW Test Dates: Oct. 1-2, 2002 EUT Type: 2-Way VHF Marine Radio FCC ID: AMWUT889 Page 15 of 22 © 2002 PCTEST Engineering Laboratory, Inc 11. MEASUREMENT UNCERTAINTIES abcde= fgh = i =k f(d,k) cxf/ecxg/e UncertaintyTol. Prob. c i c i 1 - g10 - g ComponentSec.(± %) Dist.Div.(1 - g)(10 - g) u i u i v i (± %)(± %) Measurement System Probe CalibrationE1.14.0N1114.04.0 g Axial IsotropyE1.24.88R f 30.50.51.41.4 g Hemishperical IsotropyE1.29.6R f 30.50.52.82.8 g Boundary EffectE1.311.0Rf311 6.46.4g LinearityE1.44.7R f 311 2.72.7 g System Detection LimitsE1.51.0R f 311 0.60.6 g Readout ElectronicsE1.61.0R1111.01.0 g Response TimeE1.70.8R f 311 0.50.5 g Integration TimeE1.81.7R f 311 1.01.0 g RF Ambient ConditionsE5.11.2R f 311 0.70.7 g Probe Positioner Mechanical ToleranceE5.20.4R f 311 0.20.2 g Probe Positioning w/ respect to PhantomE5.32.9Rf311 1.71.7g Extrapolation, Interpolation & IntegrationE4.23.9R f 311 2.32.3 g Algorithms for Max. SAR Evaluation Test Sample Related Test Sample PositioningE3.2.110.6R f 311 6.16.111 Device Holder UncertaintyE3.1.18.7R f 311 5.05.08 Output Power Variation - SAR drift5.6.25.0R f 311 2.92.9 g measurement Phantom & Tissue Parameters Phantom Uncertainty (Shape & Thickness E2.14.0R f 311 2.32.1 g tolerances) Liquid Conductivity - deviation fromE2.25.0R f 30.70.52.01.4 g target values Liquid Conductivity - measurement E2.210.0R f 30.70.54.02.9 g uncertainty Liquid Permittivity - deviation fromE2.25.0R f 30.60.51.71.4 g target values Liquid Permittivity - measurement E2.25.0Rf30.60.51.71.4g uncertainty Combined Standard Uncertainty (k=1)RSS13.713.2 Expanded Uncertainty (k=2)27.426.4 (95% CONFIDENCE LEVEL) The above measurement uncertainties are according to IEEE Std. 1528-200x (July, 2001)
