AMWUT916Portable FRS/GMRS Transceiver

Choosing a Channel Your radio has 22 channels and 38 CTCSS codes you can use to talk to others. In order to speak to someone, each of you must be set to the same channel and CTCSS code. To choose a channel: With the radio in "Normal" operating mode press the ch/scankey and press the or key to increase or decrease the channel number displayed. Note:Channels 1-7 have an expectancy range of up to 6 miles. Channels 8-14 have an expectancy range of up to 2 miles. Channels 15-22 have an expectancy range of up to 6 miles. Choosing a CTCSS Code Each of the channels 1-22 may have any one of the codes, OFF or 1-38 selected. Code oF(OFF) indicates no CTCSS code selected and your radio can receive a signal regardless of the code settings of the transmitting radio. 1) Enter the Menu. The CTCSS code on the LCD display will appear. 2) Press the or key to increase or decrease the code number displayed. You can also select oF(OFF) at this stage. 3) Exit the Menu. Talking on Your Radio To talk to others using the radio: 1) Press and hold the PTTbutton and speak in a clear, normal voice about 2-3 inches away from the microphone. While you are transmitting, the icon will appear on the display. To avoid cutting off the first part of your transmission, pause slightly after pressing the PTTbutton before you start talking. 2) When you are finished speaking, release the PTT button. You can now receive incoming calls. While receiving, the icon will appear on the display. Voice Operated Transmission Your GMR645-2CK radio is equipped with a user selectable Voice Operated Transmitter (VOX) that can be used for automatic voice transmissions. The VOX feature is designed to be used with a headset with a microphone. Transmission is initiated by speaking into the remote microphone instead of pushing the PTTbutton. GMR645-2CK *Range may vary depending on environmental and/or topographical conditions. • 15 GMRS / 7 FRS Channels • 38 CTCSS Codes • Up to 6 Mile Range* • Internal VOX Circuitry • 5 Selectable Call Tone Alerts • Backlit LCD Display • Optional Headset Accessories • Headset Jack • Roger Beep 1 Antenna 2 PTT (Push-To-Talk) Button 3 Monitor Key 4 Call Key 5 WX/Alert Key 6 Channel/Scan Key 7 Speaker 8 Headset Jack 9 Up Key 10 On/Off/Select Key 11 Microphone 12 Down Key 13 Battery Level Meter 14 Receive Indicator 15 Call Indicator 16 Scan Indicator 17 Channel Indicator 18 Alert Indicator 19 Weather Indicator 20 Transmit Indicator 21 Volume Setting Indicator 22 VOX Indicator 23 GMRS/FRS Indicator 24 Keypad Lock Indicator 25 CTCSS Indicator 26 Charging LED’s Congratulations on your purchase of the Uniden GMR645-2CK (General Mobile Radio Service) radio. This product is a lightweight, palm-sized radio. Use it at sporting events to stay in contact with family and friends, hiking, skiing, outdoors, or in a neighborhood watch for vital communication. This compact, state-of-the-art device is equipped with many features. PACKAGE CONTENTS Your package contains two GMR645-2CK radios, two rechargeable NiMH battery packs (#BP38), AC adapter (#AC6248), Recharging cradle (#RC6348), two belt clips and this reference guide. You may operate the unit using the rechargeable NiMH battery pack or 4 AAA alkaline batteries (not included). The following optional accessories may be purchased from your participating Uniden dealer or call1-800-554-3988 or visit us on the web at www.uniden.com.Use only Uniden accessories. • NiMH Battery Pack - #BP38 • Recharging Cradle - #RC6348 • Headset - #HS2467 FCC GMRS LICENSE The GMR645-2CK radio operates on the General Mobile Radio Service (GMRS) frequencies which require a Federal Communication Commission license to operate. For licensing information and application forms, visit the FCC online at: www.fcc.gov/wtb/uls or call the FCC hotline at 1-800-418-3676. If you have any questions, you can contact the FCC direct at 1-888-225-5322. INSTALL THE BATTERY Your GMR645-2CK radio uses the NiMH battery pack or 4 AAA alkaline batteries (not included). To install the NiMH battery pack: 1) Make sure your radio is OFF. 2) Remove the battery compartment door by pressing the tab at the bottom of the compartment door allowing the door to be removed. 3) Install the NiMH battery pack into the battery compartment. Be certain to follow the instruction written on the label on the battery pack. Installing the battery pack incorrectly will prevent the unit from operating. 4) Replace the battery compartment door. USING THE RADIO In order to get the most out of your new radio, read this reference guide completely before attempting to operate the unit. Turning the Radio On and Adjusting the Volume 1) Press and hold the sel/key to turn the radio ON, and increase the speaker volume by pressing the  key. To decrease the volume, press the key. 2) Press and hold the sel/key again to turn the radio OFF. Adjusting the Sound (Key Beeps) Your radio emits a beep each time one of the buttons or keys (except for the PTTbutton and callkey) are pressed. To turn this sound OFF, press and hold the callkey while turning ON the radio. Repeat this step to turn the sound ON. Navigating through the Menu To access the advanced features of the GMR645-2CK, your radio has a Menu function. • Battery Charger • Battery Level Meter • Channel Monitor • Channel Scan • Keypad Lock • NOAA Emergency / Weather Channels • Emergency Weather Alert BATTERY LEVEL AND LOW BATTERY ALERT This unit has a battery level meter on the display to indicate the status of the batteries. When the battery in the unit is low, the battery level meter icon will flash. Recharge the NiMH battery pack immediately or if you are using the alkaline batteries, you must replace the alkaline batteries in order to continue using the radio. Warning!To avoid the risk of personal injury or property damage from fire or electrical shock, only use the Uniden accessories specifically designated for this product. 1) To enter the Menu, press the sel/key. 2) Additional presses of the sel/key wil…
