Uniden America Corporation 4700 Amon Carter Blvd. Fort Worth, TX 76155 817-858-3300 Fax: 817-858-3328 February 8, 2012 TIMCO Engineering, Inc. 849 NW State Road 45 P.O. Box 370 Newberry, Florida 32669 Re.: Letter of Explanation for Uniden Model D3580 1.9 GHz UPCS Cordless Phone – Handset Unit SAR exemption FCC ID: AMWUU260 Product Type: 1.9 GHz UPCS Cordless Headset Unit To Whom It May Concern: UPCS DECT 6.0 Cordless Handset SAR exemption for FCC TCB Certification under Part 15D: These handsets operate at a very low source-based time-averaged duty cycle with a typical source-based time- averaged output power of < 6 mW. For FCC TCB Certification of these handsets, SAR testing has been excluded since the maximum source-based time-averaged output power is < 60/f mW per it operates with a maximum of 1 TDMA slot out of the 24 total slots. This document serves as the RF exposure exhibit in the FCC Form 731 application in lieu of a SAR report and has been reviewed and accepted by the FCC prior to submittal to the TCB. Operational Description: Above mentioned model is a DECT 6.0 Cordless Handset. It operates at frequency range of 1920 to 1930 MHz with 5 channels. RF Exposure Conditions: The Handset is intended for use in the portable exposure condition and the General Population / Uncontrolled RF exposure environment. Transmission Mode: This DECT 6.0 Cordless Handset utilizes a DECT wireless communication technology with a maximum of 1 TDMA slot out of the 24 total slots. Uniden America Corporation 4700 Amon Carter Blvd. Fort Worth, TX 76155 817-858-3300 Fax: 817-858-3328 Duty Cycle: DECT 6.0 Cordless Handset operates with a maximum of 1 TDMA slot out of the 24 total slots. The length of time for each single slot is 416.7μ Seconds and the 24 total slots is 10m Seconds as a transmission period. RF Output Power: Tx frequency range: 1920 – 1930 MHz Antenna-to-tissue phantom separation: 2mm Maximum Output Power: 18.8 dBm (75.9mW) Maximum Duty Factor: 4.16% 60/f(GHz) mW = 31.17mW Source-based time-averaged conducted output power is 3.157mW = < 60/f Please contact the undersigned if you have any questions or need any further information regarding this matter. Regards, Jon Suehiro Manager, Engineering and Regulatory Affairs

Uniden America Corporation 4700 Amon Carter Blvd. Fort Worth, TX 76155 817-858-3300 Fax: 817-858-3328 REQUEST FOR CONFIDENTIALITY February 8, 2012 To: Federal Communications Commission Equipment Authorization Branch Laboratory Division Office of Engineering and Technology 7435 Oakland Mills Road Columbia, Maryland 21046 Subject: Data for FCC Certification Applicant: Uniden America Corporation 4700 Amon Carter Blvd., Fort Worth, Texas 76155 Jon Suehiro, Manager – Engineering and Regulatory Affairs TYPE OF EQUIPMENT: UPCS 1.9 GHz Cordless Telephone Headset Unit FCC IDENTIFIER: AMWUU260 Dear Sir or Madam: Some of the material included in this application contains trade secrets and proprietary information not customarily released to the public. Because public disclosure of the material might be harmful to the applicant and provide unjustified benefits to its competitors, it is requested that the following be withheld from public disclosure: Circuit Description (AMWUU260_Circuit Description.pdf) Schematic Diagrams (AMWUU260_Schematic Diagram.pdf) Block Diagrams (AMWUU260_Block Diagram.pdf) Trade secrets and proprietary information can be held confidential. Therefore, we wish to invoke the act under the provisions of 47CFR, Sections 0.457(d) and 0.459. Please contact the undersigned if you have any questions or need any further information. Regards, Jon Suehiro Manager, Engineering and Regulatory Affairs

FCC ID: AMWUU260 1 External Photos Front View FCC ID: AMWUU260 2 Rear View

FCC ID: AMWUU260 1 Equipment Identification Label Equipment Labels: The following labels are permanently affixed to the Unit: 1) 12 mm(W) x 5 mm(H) 2) 12 mm(W) x 4.2 mm(H)

FCC ID: AMWUU260 1 Internal Photos Front Cover opened FCC ID: AMWUU260 2 Main PCB Top View FCC ID: AMWUU260 3 Main PCB Top View (Shield Cover removed) FCC ID: AMWUU260 4 Main PCB Bottom View

RF EXPOSEURE EXHIBIT Medical Alarm Concepts Model: MED01 Product Description: MediPendant (Handset Unit) Device FCC ID: XWI200910P Per FCC KDB Inquiry Tracking Number 234651 This device has been excluded from SAR testing based on source-based time-averaged conducted output power is less than 60/f per the operates with a maximum of 1 TDMA slot out of the 24 total slots. This document serves as the RF exposure exhibit in the FCC Form 731 application in lieu of a SAR report and has been reviewed and accepted by the FCC prior to submittal to the TCB. RF Exposure Conditions: The MediPendant device is intended for use in the portable exposure condition and the General Population / Uncontrolled RF exposure environment. Operational Description: The Medi Pendant is a device that will enable a person to call the preprogrammed phone number in an emergency situation, and speak directly with people without having to be near a phone, saving precious time during a crisis. This device can also be programmed to call a family or friend number . The function will be similar to a cordless phone. The base unit should have two jacks in the back. one will connect the base unit to the wall phone outlet with a phone cord and the other one is used if the customers wants to plug in a normal phone into it to make normal phone calls. In an emergency, the user activates the pendent by pressing the central button. This turns on the pendent and initiates the emergency call. Transmission Mode: The MediPendant device utilizes a DECT wireless communication technology with a maximum of 1 TDMA slot out of the 24 total slots. Duty Cycle: In DECT mode, the MediPendant operate with a maximum of 1 TDMA slot out of the 24 total slots, a slot is only 400us and the 24 total slots is 10ms as a transmission period. RF Output Power Tx frequency range: 1921.536~1928.448MHz Antenna-to-tissue separation: 2.5 mm Maximum Output Power: 20.08dBm(101.86mW) Maximum Duty Factor: 4.0% 60/f(GHz) mW = 31.12 mW Source-based time-averaged conducted output power is 0.1633 mW = < 60/f

Nemko AS, Gaustadalléen 30, P.O.Box 73 Blindern, NO-0314 Oslo Norway T +47 22 96 03 30 F +47 22 96 05 50 Enterprise number NO974404532 Visiting address: Nemko Kjeller, Instituttveien 6, P.O.Box 96, NO-2027 Kjeller Norway T +47 64 84 57 00 F +47 64 84 57 05 Test report no. : 193681-2 Item tested : DHS100 Type of equipment : UPCS Headset FCC ID : AMWUU260 Client : Uniden America Corporation FCC Part 15, subpart D Isochronous UPCS Device 1920 - 1930 MHz Industry Canada RSS-213, Issue 2 2 GHz Licence-exempt Personal Communications Service Devices (LE-PCS) 15 February 2012 Authorized by : .............................................. G. Suhanthakumar Technical Verificator TEST REPORT FCC part 15D Report no.: 193681-2 FCC ID: AMWUU260 Nemko AS, N-2007 Kjeller Page 2 (51) CONTENTS 1 GENERAL INFORMATION ............................................................................................................... 3 1.1 Testhouse Info ................................................................................................................................... 3 1.2 Client Information .............................................................................................................................. 3 1.3 Manufacturer (if other than client) ...................................................................................................... 3 2 TEST INFORMATION ....................................................................................................................... 4 2.1 Tested Item........................................................................................................................................ 4 2.2 Description of Tested Device ............................................................................................................. 4 2.3 Test Environment .............................................................................................................................. 5 2.4 Test Period ........................................................................................................................................ 5 2.5 Test Engineer(s) ................................................................................................................................ 5 2.6 Test Equipment ................................................................................................................................. 5 2.7 Other Comments ............................................................................................................................... 5 3 TEST REPORT SUMMARY .............................................................................................................. 6 3.1 General .............................................................................................................................................. 6 3.2 Test Summary ................................................................................................................................... 7 4 TEST RESULTS ................................................................................................................................ 8 4.1 Power Line Conducted Emissions ..................................................................................................... 8 4.2 Coordination with fixed microwave .................................................................................................. 10 4.3 Digital Modulation Techniques ........................................................................................................ 10 4.4 Labeling Requirements ................................................................................................................... 10 4.5 Antenna Requirement...................................................................................................................... 11 4.6 Channel Frequencies ...................................................................................................................... 11 4.7 Automatic Discontinuation of Transmission .................................................................................... 12 4.8 Peak Power Output ......................................................................................................................... 13 4.9 Emission Bandwidth B ..................................................................................................................... 18 4.10 Power Spectral Density ................................................................................................................... 21 4.11 In-Band Unwanted Emissions, Conducted ...................................................................................... 24 4.12 Out-of-band Emissions, Conducted................................................................................................. 26 4.13 Carrier Frequency Stability .............................................................................................................. 32 4.14 Frame Repetition Stability ............................................................................................................... 33 4.15 Frame Period and Jitter ................................................................................................................... 33 4.16 Monitoring Threshold, Least Interfered Channel ............................................................................. 35 4.17 Threshold Monitoring Bandwidth ..................................................................................................... 37 4.18 Reaction Time and Monitoring Interval ............................................................................................ 38 4.19 Time and Spectrum Window Access Procedure ............................................................................. 40 4.20 Acknowledgements and Transmission Duration ............................................................................. 41 4.21 Dual Access Criteria Ch…

Text truncated - open the document above for the full version.

FCC ID: AMWUU260 Project no.: 193681 Page 1 of 1 PHOTOS OF TEST SET-UP – DHS100 Headset Antenna Gain Test Set-up Power line Conducted Emissions Test Set-up

FCC ID: AMWUU260 Project no.: 193681 Page 1 of 1 PHOTOS OF TEST SET-UP – DHS100 Headset Power line Conducted Emissions Test Set-up
