APYDMR0153Household Microwave Oven

A31679 R-930AK/AW/CS O/M TINSEB008WRRZ-D31 SEC R-930AK/AW/CS SMART & EASY Read all instructions carefully before using your oven. MICROWAVE OVEN OPERATION MANUAL MODELS R-930AK R-930AW R-930CS CONTENTS • For Customer Assistance .............................. Inside Front Cover • Precautions to Avoid Possible Exposure to Excessive Microwave Energy .................. Inside Front Cover • Limited Warranty .............................. 1 • Important Safety Instructions ............ 2 • Installation Instructions ..................... 3 • Grounding Instructions ..................... 4 • Information You Need to Know ......... 5 • Part Names ....................................... 8 • Before Operating ............................ 11 • Manual Operation ........................... 11 • Special Features ............................. 16 • Other Convenient Features ............ 24 • Cleaning and Care .......................... 26 • Service Call Check ......................... 27 • Specifications ................................. 27 • Guia Auto-Touch ............................ 28 • Auto-Touch Guide ..... 29, Back Cover cover03.5.12, 5:33 PM1 A31679 R-930AK/AW/CS O/M TINSEB008WRRZ-D31 SEC R-930AK/AW/CS TO PHONE: DIAL 1-800-BE-SHARP (1-800-237-4277) for : SERVICE (for your nearest Sharp Authorized Servicer) PARTS (for your authorized parts distributor) ACCESSORIES ADDITIONAL CUSTOMER INFORMATION DIAL 1-800-642-2122 for : ACCESSORIES and MICROWAVE ONLY COOKBOOK DIAL(201)529-8703 for : COOKING ASSISTANCE TO WRITE: For cooking and operation questions: Susan Edwards/Test Kitchen Sharp Electronics Corporation Sharp Plaza, Box 650 Mahwah, NJ 07430-2135 For service problems, warranty information, missing items and other assistance: Sharp Electronics Corporation Customer Assistance Center 1300 Naperville Drive Romeoville, IL 60446-1091 Please provide the following information when you write or call: model number, serial number, date of purchase, your complete mailing address (including zip code), your daytime telephone number (including area code) and description of the problem. TO ACCESS INTERNET: www.sharp-usa.com To aid in reporting this microwave oven in case of loss or theft, please record below the model number and serial number located on the unit. We also suggest you record all the information listed and retain for future reference. MODEL NUMBER ___________SERIAL NUMBER __________ DATE OF PURCHASE ____________________________________ Dealer _____________________ Telephone ____________________ Servicer _____________________ Telephone _________________ FOR CUSTOMER ASSISTANCE PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces. (d) The oven should not be adjusted or repaired by anyone except properly qualified service personnel. PRECAUTIONS03.5.12, 5:27 PM1 A31679 R-930AK/AW/CS O/M 1 TINSEB008WRRZ-D31 SEC R-930AK/AW/CS The product information card which is on the inside of the microwave oven carton should be completed within ten days of purchase and returned. We will keep it on file and help you access the information in case of loss, damage or theft. This will also enable us to contact you in the unlikely event that any adjustments or modifications are ever required for your oven. LIMITED WARRANTY SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the “Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below. This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered or modified in design or construction. In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide proof of purchase to the servicer. The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law. ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABIL- ITY AND FITNESS FOR USE ARE LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp. The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise. In no event shall Sharp be liable, or in any way…

Text truncated - open the document above for the full version.

Identification Label (Nameplate Label) Label Material: Film with back side adhesion. Model Number 95 mm Factory ID Mark 32 mm FCC ID Code FCC ID : APYDMR0153 FCC ID Code APY : FCC assigned grantee code for Sharp Corporation. DMR0153 : Number assigned by the grantee to the model or the model family in a technically identical products. Factory ID Mark T : Manufacturer identification marking for Sharp Appliances (Thailand) Ltd. RR -- 930CS930CS--FF 6060 HzHz TT THIS PRODUCTTHIS PRODUCT COMPLIESCOMPLIES WITHWITH DHHSDHHS RULESRULES 21 CFR21 CFR SUBCHAPTERSUBCHAPTER J.J. QUESTIONS? 1QUESTIONS? 1 -- 800800 -- BEBE -- SHARP SHARP CORPORATIONSHARP SHARP CORPORATION MARKETED BY : SHARP ELECTRONICS CORP. MAHWAH, NJ. 07430MARKETED BY : SHARP ELECTRONICS CORP. MAHWAH, NJ. 07430 HOUSEHOLDHOUSEHOLD MICRMICR OWAVOWAV EE OVENOVEN MODELMODEL NO.NO. SERIALSERIAL NO.NO. INSTALLATION KITINSTALLATION KIT RKRK -- 93S27/93S27/ -- 93S3093S30 120120 VACVAC MANUFACTUREDMANUFACTURED AA 13.013.0 MADE IN THAILANDMADE IN THAILAND FCC ID FCC ID :: APYDMR0APYDMR0153153 285B285B JUNE 2005JUNE 2005 x x x x 1x x x x 1

FCC Label Location

ＴＴＭ ＯＬ Ａ１ Ａ７ Ｅ１ Ｅ２ Ｅ３ Ｅ４ Ｅ５ Ｅ６Ｆ３ Ｆ２ Ｆ１ Ａ９ Ａ３Ａ５ ＣＯＭ ． （ＲＹ１） ＣＯＭ .(ＲＹ３） ＣＯＭ .ＲＹ２） Ｎ .Ｏ.( ＲＹ１） ＡＨ ＳＥＮＳＯＲ ＧＲＹ ＷＨＴ Ｎ .Ｏ.( ＲＹ２） Ｎ .Ｏ.( ＲＹ３） ＲＹ４ NOISE SUPRESSION COIL LINE CROSS CAPACITOR 0.22μF 250V LINE BYPASS CAPACITOR0.0033μF 250V LINE BYPASS CAPACITOR0.0033μF 250V FUSE20A OVEN LAMP HEATINGELEMENT ＲＹ２ＲＹ３ DAMPER SWITCHDOOR SENSING SWITCH THER-MISTOR MONITOR SWITCHＨＶ RECTIFIER MAGNETRON POWERTRANSFORMAR ＯＲＧ CAPACITOR０．９４μF TUEN TABLE MOTORＦＡＮ MOTORＣＯＮＶＥＣＴＩＯＮ MOTORＤＡＮＰＥＲ MOTOR Ｌ Ｎ ＲＹ５ＲＹ６ＲＹ１ ～ ～ ～ ～ ～ ～ ～～ ～～ CONTROL UNIT SECONDARY INTERLOCK SWITCH SCHEMATIC DIAGRAM (DOOR CLOSED, COOK OFF CONDITION) TMAPCA*** MODEL NO. R-930AK/R-930AW/R-930CS/DCM24B/DCM24R/DMC24S AC 120 V 60HZ CONV. THERMAL CUT-OUT MAGNETRON TEMP. FUSE ＦＭ ＤＭ ＣＭ

JAPAN QUALITY ASSURANCE ORGANIZATION SHIKATSU BRANCH, CHUBU Testing Center 53-1, Yamaura, Yakushiji, Shikatsu-cho, Nishikasugai-gun, Aichi 481-0005 Japan Phone. +81-568-23-0023 / Facsimile. +81-568-23-0116 Issue Date : April 01, 2005 Page 1 of 28 EMI TEST REPORT JQA File No. 50-40474 Model/Type No. R-930CSF Type of Equipment Household Microwave Oven Regulation applied FCC Rules and Regulations Part 18 FCC ID APYDMR0153 Applicant Sharp Corporation, Reliability Control Group Address 22-22 Nagaike-Cho, Abeno-Ku, Osaka 545-8522, Japan Manufacturer Sharp Appliances (Thailand) Ltd. Address 64 Moo 5, Tambol Bangsamuk, Amphur Bangpakong, Chachoengsao, Province, Thailand Received date of EUT February 17, 2005 Final Judgment Passed TEST RESULT IN THIS REPORT are obtained in used of equipments that is traceable to National Institute of Advanced Industrial Science and Technology (AIST) of Japan and National Institute of Information and Communications Technology (NICT) of Japan. THE TEST RESULTS only responds to the test sample. THIS REPORT should not be reproduced, except in full, without the approval of the JQA Chubu Testing Center. JQA File No. 50-40474 FCC ID APYDMR0153 Model No. R-930CSF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 2 of 28 JAPAN QUALITY ASSURANCE ORGANIZATION TABLE OF CONTENTS Page 1. Documentation 1.1 General Information 3 1.2 Test Regulation 3 1.3 Test Conditions 4 - 10 1.4 EUT Modifications / Deviation of Method 11 1.5 Test Results / Uncertainty 12 - 13 1.6 Summary 14 1.7 Configuration of EUT / Operation of EUT 15 – 16 1.8 Preliminary Test and Test Set-up(Drawings & Photographs) 17 – 22 2. Test Data 2.1 RF Power Output 23 2.2 ISM Frequency 24 2.3 AC Power Line Conducted Emission 150kHz - 30MHz 25 2.4 Radiated Emission (Magnetic Field) 9 KHz - 30 MHz 26 2.5 Radiated Emission (Electric Field) 30 MHz - 1000 MHz 27 2.6 Radiated Emission (Electric Field) 1 GHz - 24.5 GHz 28 JQA File No. 50-40474 FCC ID APYDMR0153 Model No. R-930CSF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 3 of 28 JAPAN QUALITY ASSURANCE ORGANIZATION 1.1 GENERAL INFORMATION 1.1.1 Test Facility : 1) Test Facility located at Chubu Testing Center SHIKATSU Branch : An anechoic Chamber (3 m and 10 m, on common plane) and a shielded Room Date of Listing : September 11, 2002 FCC filing No.:31040/SIT 1300F2 2) Chubu Testing Center SHIKATSU Branch is recognized under the National Voluntary Laboratory Accreditation Program for satisfactory compliance established in Title 15, Part 285 Code of Federal Regulations. NVLAP Lab Code : 200190-0 1.1.2 Description of the Equipment Under Test : 1) Type of Equipment Household Microwave Oven 2) Model/Type No. R-930CSF 3) Type of Magnetron 2M167B 4) Category ISM Frequency Device 5) EUT Authorization Certification 6) FCC ID APYDMR0153 7) Product Type Prototype 8) Serial No. N/A 9) Date of manufacturer February, 2005 10) Trade Name SHARP 11) Fundamental Frequency 4.0, 2450.0 MHz Generated in the EUT 12) Highest Frequency 2450.0 MHz Used in the EUT 13) Power Rating 120VAC 60Hz 1-Phase 14) Rated Power Output 900 W 15) EUT Grounding Grounded at the plug end of the power line cord. 1.1.3 Definitions for symbols used in this test report : Black box indicates that the listed condition, Regulation or equipment is applicable for this report. Blank box indicates that the listed condition, Regulation or equipment is not applicable for this report. 1.2 TEST REGULATION FCC Rules and Regulations Part 18 Subpart A, B and C(October 1, 2002). Test Procedure : The test was performed according to the procedures in FCC/OET MP-5(1986). JQA File No. 50-40474 FCC ID APYDMR0153 Model No. R-930CSF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 4 of 28 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3 TEST CONDITIONS 1.3.1 The measurement of the RF Power Output was performed in the following test site. Test Location : KITA KANSAI Testing Center 7-7, Ishimaru, 1-Chome, Mino-Shi, Osaka, 562-0027, JAPAN Used Test Instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval Clamp on Power Meter 3167 HIOKI 08011116 Jun, 2004 1 Year Stop Watch 8N5502 SEIKO Q47097355 July, 2004 1 Year Digital Thermometer 2455 YOKOGAWA Q47097361 March, 2004 1 Year Environmental Conditions : Temperature: 29.0 Humidity: 60.0 JQA File No. 50-40474 FCC ID APYDMR0153 Model No. R-930CSF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 5 of 28 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3.2 The measurement of the ISM Frequency was performed for line voltage variation 80% to 125% of normal rated voltage, in the following test site. Test Location : Chubu Testing Center SHIKATSU Branch 53-1, Yamaura, Yakushiji, Shikatsu-cho, Nishikasugai-gun, Aichi 481-0005, JAPAN Anechoic Chamber No.2 Used Test Instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval Spectrum Analyzer 8566B Hewlett Packard 2937A06026 July, 2004 1 Year Horn Antenna 3160-03 EMCO 9911-1065 May, 2004 1 Year RF Cable - Hewlett Packard A-2 May, 2004 1 Year Environmental Conditions : Temperature: 20.0 Humidity: 48.0 JQA File No. 50-40474 FCC ID APYDMR0153 Model No. R-930CSF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 6 of 28 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3.3 The measurement of the AC Power Line Conducted Emission was performed in the following test site. Test Location : Chubu Testing Center SHIKATSU Branch 53-1, Yamaura, Yakushiji, Shikatsu-cho, Nishikasugai-gun, Aichi 481-0005, JAPAN Anechoic Chamber No.1 Shielded Room Used Test Instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval Field Strength Meter ESH 2 Rohde & Schwarz 864125/007 May, 2004 1 Year LISN(for EUT) KNW-407 Kyoritsu Electrical 8-901-20 Jun, 2004 1 Year RF Cable 3D-2W Fujikura S-A May, 2004 1 Year RF Cable 3D-2W Fujikura S-B May, 2004 1 Year 50ohm Termination CT01 TME No.1 May, 2004 1 Year Environmental Conditions : Temperature: 20.0 Humidity: 34.0 JQA File No. 50-40474 FCC ID APYD…

Text truncated - open the document above for the full version.

JAPAN QUALITY ASSURANCE ORGANIZATION SHIKATSU BRANCH, CHUBU Testing Center 53-1, Yamaura, Yakushiji, Shikatsu-cho, Nishikasugai-gun, Aichi 481-0005 Japan Phone. +81-568-23-0023 / Facsimile. +81-568-23-0116 Issue Date : April 01, 2005 Page 1 of 28 EMI TEST REPORT JQA File No. 50-40474 Model/Type No. R-930CSF Type of Equipment Household Microwave Oven Regulation applied FCC Rules and Regulations Part 18 FCC ID APYDMR0153 Applicant Sharp Corporation, Reliability Control Group Address 22-22 Nagaike-Cho, Abeno-Ku, Osaka 545-8522, Japan Manufacturer Sharp Appliances (Thailand) Ltd. Address 64 Moo 5, Tambol Bangsamuk, Amphur Bangpakong, Chachoengsao, Province, Thailand Received date of EUT February 17, 2005 Final Judgment Passed TEST RESULT IN THIS REPORT are obtained in used of equipments that is traceable to National Institute of Advanced Industrial Science and Technology (AIST) of Japan and National Institute of Information and Communications Technology (NICT) of Japan. THE TEST RESULTS only responds to the test sample. THIS REPORT should not be reproduced, except in full, without the approval of the JQA Chubu Testing Center. JQA File No. 50-40474 FCC ID APYDMR0153 Model No. R-930CSF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 2 of 28 JAPAN QUALITY ASSURANCE ORGANIZATION TABLE OF CONTENTS Page 1. Documentation 1.1 General Information 3 1.2 Test Regulation 3 1.3 Test Conditions 4 - 10 1.4 EUT Modifications / Deviation of Method 11 1.5 Test Results / Uncertainty 12 - 13 1.6 Summary 14 1.7 Configuration of EUT / Operation of EUT 15 – 16 1.8 Preliminary Test and Test Set-up(Drawings & Photographs) 17 – 22 2. Test Data 2.1 RF Power Output 23 2.2 ISM Frequency 24 2.3 AC Power Line Conducted Emission 150kHz - 30MHz 25 2.4 Radiated Emission (Magnetic Field) 9 KHz - 30 MHz 26 2.5 Radiated Emission (Electric Field) 30 MHz - 1000 MHz 27 2.6 Radiated Emission (Electric Field) 1 GHz - 24.5 GHz 28 JQA File No. 50-40474 FCC ID APYDMR0153 Model No. R-930CSF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 3 of 28 JAPAN QUALITY ASSURANCE ORGANIZATION 1.1 GENERAL INFORMATION 1.1.1 Test Facility : 1) Test Facility located at Chubu Testing Center SHIKATSU Branch : An anechoic Chamber (3 m and 10 m, on common plane) and a shielded Room Date of Listing : September 11, 2002 FCC filing No.:31040/SIT 1300F2 2) Chubu Testing Center SHIKATSU Branch is recognized under the National Voluntary Laboratory Accreditation Program for satisfactory compliance established in Title 15, Part 285 Code of Federal Regulations. NVLAP Lab Code : 200190-0 1.1.2 Description of the Equipment Under Test : 1) Type of Equipment Household Microwave Oven 2) Model/Type No. R-930CSF 3) Type of Magnetron 2M167B 4) Category ISM Frequency Device 5) EUT Authorization Certification 6) FCC ID APYDMR0153 7) Product Type Prototype 8) Serial No. N/A 9) Date of manufacturer February, 2005 10) Trade Name SHARP 11) Fundamental Frequency 4.0, 2450.0 MHz Generated in the EUT 12) Highest Frequency 2450.0 MHz Used in the EUT 13) Power Rating 120VAC 60Hz 1-Phase 14) Rated Power Output 900 W 15) EUT Grounding Grounded at the plug end of the power line cord. 1.1.3 Definitions for symbols used in this test report : Black box indicates that the listed condition, Regulation or equipment is applicable for this report. Blank box indicates that the listed condition, Regulation or equipment is not applicable for this report. 1.2 TEST REGULATION FCC Rules and Regulations Part 18 Subpart A, B and C(October 1, 2002). Test Procedure : The test was performed according to the procedures in FCC/OET MP-5(1986). JQA File No. 50-40474 FCC ID APYDMR0153 Model No. R-930CSF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 4 of 28 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3 TEST CONDITIONS 1.3.1 The measurement of the RF Power Output was performed in the following test site. Test Location : KITA KANSAI Testing Center 7-7, Ishimaru, 1-Chome, Mino-Shi, Osaka, 562-0027, JAPAN Used Test Instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval Clamp on Power Meter 3167 HIOKI 08011116 Jun, 2004 1 Year Stop Watch 8N5502 SEIKO Q47097355 July, 2004 1 Year Digital Thermometer 2455 YOKOGAWA Q47097361 March, 2004 1 Year Environmental Conditions : Temperature: 29.0 Humidity: 60.0 JQA File No. 50-40474 FCC ID APYDMR0153 Model No. R-930CSF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 5 of 28 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3.2 The measurement of the ISM Frequency was performed for line voltage variation 80% to 125% of normal rated voltage, in the following test site. Test Location : Chubu Testing Center SHIKATSU Branch 53-1, Yamaura, Yakushiji, Shikatsu-cho, Nishikasugai-gun, Aichi 481-0005, JAPAN Anechoic Chamber No.2 Used Test Instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval Spectrum Analyzer 8566B Hewlett Packard 2937A06026 July, 2004 1 Year Horn Antenna 3160-03 EMCO 9911-1065 May, 2004 1 Year RF Cable - Hewlett Packard A-2 May, 2004 1 Year Environmental Conditions : Temperature: 20.0 Humidity: 48.0 JQA File No. 50-40474 FCC ID APYDMR0153 Model No. R-930CSF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 6 of 28 JAPAN QUALITY ASSURANCE ORGANIZATION 1.3.3 The measurement of the AC Power Line Conducted Emission was performed in the following test site. Test Location : Chubu Testing Center SHIKATSU Branch 53-1, Yamaura, Yakushiji, Shikatsu-cho, Nishikasugai-gun, Aichi 481-0005, JAPAN Anechoic Chamber No.1 Shielded Room Used Test Instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval Field Strength Meter ESH 2 Rohde & Schwarz 864125/007 May, 2004 1 Year LISN(for EUT) KNW-407 Kyoritsu Electrical 8-901-20 Jun, 2004 1 Year RF Cable 3D-2W Fujikura S-A May, 2004 1 Year RF Cable 3D-2W Fujikura S-B May, 2004 1 Year 50ohm Termination CT01 TME No.1 May, 2004 1 Year Environmental Conditions : Temperature: 20.0 Humidity: 34.0 JQA File No. 50-40474 FCC ID APYD…

Text truncated - open the document above for the full version.
