APYDMR0158Household Microwave Oven

1000 WATTS-LIGHT DUTY COMMERCIAL MICROWAVE OVEN OPERATION MANUAL ® FOR CUSTOMER ASSISTANCE TO PHONE: SERVICE and PARTS (for your nearest Sharp Authorized Servicer and Parts Distributor) United States ..................................... 1-800-BE-SHARP(237-4277) ADDITIONAL CUSTOMER INFORMATION ............................................... 201-529-8706 TO WRITE: For additional information: Commercial Microwave Oven Department Sharp Electronics Corporation Sharp Plaza, Box 650 Mahwah, NJ 07430-2135 For service problems, warranty information, missing items and other assistance: Sharp Electronics Corporation Customer Assistance Center 1300 Naperville Drive Romeoville, IL 60446-1091 Please provide the following information when you write or call: model number, serial number, date of purchase, your complete mailing address (including zip code), your daytime telephone number (including area code) and description of the problem. TO ACCESS INTERNET: WWW.sharp-usa.com To aid in reporting this commercial microwave oven in case of loss or theft, please record below the model number and serial number located on the unit. We also suggest you record all the information listed and retain for future reference. MODEL NUMBER________________________SERIAL NUMBER______________ DATE OF PURCHASE______________________ DEALER____________________________TELEPHONE________________ SERVICER___________________________TELEPHONE________________ MODELS R-21HT, R-21HV, R-21JV, R-21JCA 1 Manual Operations .................................... 11 Time cooking ........................................... 11 Multiple sequence cooking ...................... 11 Express Defrost ....................................... 12 Express Defrost Chart ............................. 12 Counter check ......................................... 13 To check times used ............................... 13 To clear the number of times .................. 13 Other Convenient Features ........................ 14 Signal setting ........................................... 14 Demonstration Mode ............................... 14 Service Call Check ........................................ 14 Care and Cleaning ........................................ 15 Cooking Guide .............................................. 16 Utensils ...................................................... 16 Guidelines for microwave heating .............. 17 Timing guide .............................................. 18 Heating and cooking time guide ................ 19 Reminders ..................................................... 21 Specifications ................................................ 21 Auto-Touch Guide ........................... 22-Back cover For Customer Assistance ................ Front cover Contents .......................................................... 1 Precautions to Avoid Possible Exposure to Excessive Microwave Energy ...................... 1 Limited Warranty ............................................. 2 Important Safety Instructions .......................... 3 Grounding Instructions .................................... 4 Installation ....................................................... 4 Part Names ..................................................... 5 Steps for Operating for R-21JCA .................... 7 Defrosting Frozen Foods Chart ................... 7 Steps for Operating for R-21HT/HV/JV ........... 8 Before Operation ......................................... 8 Memory Operation ....................................... 8 Cooking with memory ................................ 8 Cooking double quantity with memory ...... 8 Memory program entry .............................. 9 Setting time and power level ..................... 9 Setting magnification factor ...................... 9 Memory check ......................................... 10 Checking time and power level ............... 10 Checking magnification ........................... 10 (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces. (d) The oven should not be adjusted or repaired by anyone except properly qualified service personnel. CONTENTS PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY 2 LIMITED WARRANTY END-USER LIMITED WARRANTY SHARP ELECTRONICS CORPORATION warrants to the first end-user purchaser that this Sharp brand product (the "Product"), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part there of with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below. This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper voltage or other misuse, abnormal service or handling, or which has been altered or modified in design or construction. In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide proof of purchase to the servicer. To the extent permitted by applicable state law, the warranties set forth herein are in lieu of, and exclusive of, all other warranties, express or implied. Specifically, ALL OTHER WARRANTIES OTHER THAN THOSE SET FORTH ABOVE ARE EXCLUDED. ALL EXPRESS AND IMPLIED WARRANTI…

Text truncated - open the document above for the full version.

FCC ID : APYDMR0158 IDENTIFICATION LABEL (Nameplate label) Label Material : Film with back side adhesion. FCC ID Code APY : FCC assigned grantee code for Sharp Corporation. DMR0158 : Number assigned by the grantee to the model or the model family in a technically identical products. Factory ID Mark T : Manufacturer identification marking for Sharp Appliances (Thailand) Ltd. FCC ID Code Model Number 95 mm Factory ID Mark 32 mm

MODELS R-21HV#/R-21HT#/R-21JV# OLFMAM OVEN LAMP FAN MOTOR ANTENNA MOTOR MONITOR FUSE 20A POWER TRANSFORMER CAPACITOR 0.94μF 2400V DOOR SENSING SWITCH SECONDARY INTERLOCK SWITCH CONTROL UNIT THERMAL CUT-OUT THERMAL CUT-OUT Y R A M I R P K C O L R E T N I Y A L E R L O R T N O C Y A L E R H C T I W S R O T I N O M N O R T E N G A M R E I F I T C E R 3 Y R 2 Y R A3 A7 B1B2 120V AC 60 Hz NOISE SUPPRESSION COIL LINE CROSS CAPACITOR 0.22 μ F / A C 250V LINE BYPASS CAPACITOR 0.0033 μ F / A C 250V LINE BYPASS CAPACITOR 0.0033 μ F / A C 250V L N NOISE FILTER SCHEMATIC DIAGRAM (DOOR CLOSEED,COOK OFF CONDITION) OLFMAM OVEN LAMP FAN MOTOR ANTENNA MOTOR POWER TRANSFORMER CAPACITOR 0.94 μF 2400V DOOR SENSING SWITCH SECONDARY INTERLOCK SWITCH CONTROL UNIT THERMAL CUT-OUT THERMAL CUT-OUT Y R A M I R P K C O L R E T N I Y A L E R K O O C Y A L E R H C T I W S R O T I N O M N O R T E N G A M R E I F I T C E R 1 Y R 2 Y R A5 A3A1 MONITOR FUSE 20A 120V AC 60 Hz NOISE SUPPRESSION COIL LINE CROSS CAPACITOR 0.22μ F / A C 250V L N NOISE FILTER MODELS R-21HC#/R-21JC#/R-21JCA# SCHEMATIC DIAGRAM (DOOR CLOSEED,COOK OFF CONDITION)

JAPAN QUALITY ASSURANCE ORGANIZATION JAPAN QUALITY ASSURANCE ORGANIZATION SHIKATSU BRANCH, CHUBU Testing Center 53-1, Yamaura, Yakushiji, Shikatsu-cho, Nishikasugai-gun, Aichi 481-0005 Japan Phone. +81-568-23-0023 / Facsimile. +81-568-23-0116 Issue Date : April 01, 2005 Page 1 of 28 EMI TEST REPORT JQA File No. 50-40512 Model/Type No. R-21JVF Type of Equipment Microwave Oven Regulation applied FCC Rules and Regulations Part 18 FCC ID APYDMR0158 Applicant Sharp Corporation, Reliability Control Group Address 22-22 Nagaike-Cho, Abeno-Ku, Osaka 545-8522, Japan Manufacturer Sharp Appliances (Thailand) Ltd. Address 64 Moo 5, Tambol Bangsamuk, Amphur Bangpakong, Chachoengsao, Province, Thailand Received date of EUT March 03, 2005 Final Judgment Passed TEST RESULT IN THIS REPORT are obtained in used of equipments that is traceable to National Institute of Advanced Industrial Science and Technology (AIST) of Japan and National Institute of Information and Communications Technology (NICT) of Japan. THE TEST RESULTS only responds to the test sample. THIS REPORT should not be reproduced, except in full, without the approval of the JQA Chubu Testing Center. JQA File No. 50-40512 FCC ID APYDMR0158 Model No. R-21JVF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 2 of 28 TABLE OF CONTENTS Page 1. Documentation 1.1 General Information 3 1.2 Test Regulation 3 1.3 Test Conditions 4 - 10 1.4 EUT Modifications / Deviation of Method 11 1.5 Test Results / Uncertainty 12 - 13 1.6 Summary 14 1.7 Configuration of EUT / Operation of EUT 15 – 16 1.8 Preliminary Test and Test Set-up(Drawings & Photographs) 17 – 22 2. Test Data 2.1 RF Power Output 23 2.2 ISM Frequency 24 2.3 AC Power Line Conducted Emission 150kHz - 30MHz 25 2.4 Radiated Emission (Magnetic Field) 9 KHz - 30 MHz 26 2.5 Radiated Emission (Electric Field) 30 MHz - 1000 MHz 27 2.6 Radiated Emission (Electric Field) 1 GHz - 24.5 GHz 28 JQA File No. 50-40512 FCC ID APYDMR0158 Model No. R-21JVF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 3 of 28 1.1 GENERAL INFORMATION 1.1.1 Test Facility : 1) Test Facility located at Chubu Testing Center SHIKATSU Branch : An anechoic Chamber (3 m and 10 m, on common plane) and a shielded Room Date of Listing : September 11, 2002 FCC filing No.:31040/SIT 1300F2 2) Chubu Testing Center SHIKATSU Branch is recognized under the National Voluntary Laboratory Accreditation Program for satisfactory compliance established in Title 15, Part 285 Code of Federal Regulations. NVLAP Lab Code : 200190-0 1.1.2 Description of the Equipment Under Test : 1) Type of Equipment Microwave Oven 2) Model/Type No. R-21JVF 3) Type of Magnetron 2M240H(L2) 4) Category ISM Frequency Device 5) EUT Authorization Certification 6) FCC ID APYDMR0158 7) Product Type Prototype 8) Serial No. N/A 9) Date of manufacturer February, 2005 10) Trade Name SHARP 11) Fundamental Frequency 4.0, 2450.0 MHz Generated in the EUT 12) Highest Frequency 2450.0 MHz Used in the EUT 13) Power Rating 120VAC 60Hz 1-Phase 14) Rated Power Output 1000 W 15) EUT Grounding Grounded at the plug end of the power line cord. 1.1.3 Definitions for symbols used in this test report : Black box indicates that the listed condition, Regulation or equipment is applicable for this report. Blank box indicates that the listed condition, Regulation or equipment is not applicable for this report. 1.2 TEST REGULATION FCC Rules and Regulations Part 18 Subpart A, B and C(October 1, 2002). Test Procedure : The test was performed according to the procedures in FCC/OET MP-5(1986). JQA File No. 50-40512 FCC ID APYDMR0158 Model No. R-21JVF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 4 of 28 1.3 TEST CONDITIONS 1.3.1 The measurement of the RF Power Output was performed in the following test site. Test Location : KITA KANSAI Testing Center 7-7, Ishimaru, 1-Chome, Mino-Shi, Osaka, 562-0027, JAPAN Used Test Instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval Clamp on Power Meter 3167 HIOKI 08011116 Jun, 2004 1 Year Stop Watch 8N5502 SEIKO Q47097350 July, 2004 1 Year Digital Thermometer 2455 YOKOGAWA Q47097361 March, 2004 1 Year Environmental Conditions : Temperature: 29.0 Humidity: 60.0 JQA File No. 50-40512 FCC ID APYDMR0158 Model No. R-21JVF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 5 of 28 1.3.2 The measurement of the ISM Frequency was performed for line voltage variation 80% to 125% of normal rated voltage, in the following test site. Test Location : Chubu Testing Center SHIKATSU Branch 53-1, Yamaura, Yakushiji, Shikatsu-cho, Nishikasugai-gun, Aichi 481-0005, JAPAN Anechoic Chamber No.2 Used Test Instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval Spectrum Analyzer 8566B Hewlett Packard 2937A06026 July, 2004 1 Year Horn Antenna 3160-03 EMCO 9911-1065 May, 2004 1 Year RF Cable - Hewlett Packard A-2 May, 2004 1 Year Environmental Conditions : Temperature: 24.0 Humidity: 40.0 JQA File No. 50-40512 FCC ID APYDMR0158 Model No. R-21JVF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 6 of 28 1.3.3 The measurement of the AC Power Line Conducted Emission was performed in the following test site. Test Location : Chubu Testing Center SHIKATSU Branch 53-1, Yamaura, Yakushiji, Shikatsu-cho, Nishikasugai-gun, Aichi 481-0005, JAPAN Anechoic Chamber No.1 Shielded Room Used Test Instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval Field Strength Meter ESH 2 Rohde & Schwarz 864125/007 May, 2004 1 Year LISN(for EUT) KNW-407 Kyoritsu Electrical 8-901-20 Jun, 2004 1 Year RF Cable 3D-2W Fujikura S-A May, 2004 1 Year RF Cable 3D-2W Fujikura S-B May, 2004 1 Year 50ohm Termination CT01 TME No.1 May, 2004 1 Year Environmental Conditions : Temperature: 18.0 Humidity: 50.0 JQA File No. 50-40512 FCC ID APYDMR0158 Model No. R-21JVF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 7 of 28 1.3.4 The measurement of the Radiated Emission(Magnetic Field) was perform…

Text truncated - open the document above for the full version.

JAPAN QUALITY ASSURANCE ORGANIZATION JAPAN QUALITY ASSURANCE ORGANIZATION SHIKATSU BRANCH, CHUBU Testing Center 53-1, Yamaura, Yakushiji, Shikatsu-cho, Nishikasugai-gun, Aichi 481-0005 Japan Phone. +81-568-23-0023 / Facsimile. +81-568-23-0116 Issue Date : April 01, 2005 Page 1 of 28 EMI TEST REPORT JQA File No. 50-40512 Model/Type No. R-21JVF Type of Equipment Microwave Oven Regulation applied FCC Rules and Regulations Part 18 FCC ID APYDMR0158 Applicant Sharp Corporation, Reliability Control Group Address 22-22 Nagaike-Cho, Abeno-Ku, Osaka 545-8522, Japan Manufacturer Sharp Appliances (Thailand) Ltd. Address 64 Moo 5, Tambol Bangsamuk, Amphur Bangpakong, Chachoengsao, Province, Thailand Received date of EUT March 03, 2005 Final Judgment Passed TEST RESULT IN THIS REPORT are obtained in used of equipments that is traceable to National Institute of Advanced Industrial Science and Technology (AIST) of Japan and National Institute of Information and Communications Technology (NICT) of Japan. THE TEST RESULTS only responds to the test sample. THIS REPORT should not be reproduced, except in full, without the approval of the JQA Chubu Testing Center. JQA File No. 50-40512 FCC ID APYDMR0158 Model No. R-21JVF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 2 of 28 TABLE OF CONTENTS Page 1. Documentation 1.1 General Information 3 1.2 Test Regulation 3 1.3 Test Conditions 4 - 10 1.4 EUT Modifications / Deviation of Method 11 1.5 Test Results / Uncertainty 12 - 13 1.6 Summary 14 1.7 Configuration of EUT / Operation of EUT 15 – 16 1.8 Preliminary Test and Test Set-up(Drawings & Photographs) 17 – 22 2. Test Data 2.1 RF Power Output 23 2.2 ISM Frequency 24 2.3 AC Power Line Conducted Emission 150kHz - 30MHz 25 2.4 Radiated Emission (Magnetic Field) 9 KHz - 30 MHz 26 2.5 Radiated Emission (Electric Field) 30 MHz - 1000 MHz 27 2.6 Radiated Emission (Electric Field) 1 GHz - 24.5 GHz 28 JQA File No. 50-40512 FCC ID APYDMR0158 Model No. R-21JVF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 3 of 28 1.1 GENERAL INFORMATION 1.1.1 Test Facility : 1) Test Facility located at Chubu Testing Center SHIKATSU Branch : An anechoic Chamber (3 m and 10 m, on common plane) and a shielded Room Date of Listing : September 11, 2002 FCC filing No.:31040/SIT 1300F2 2) Chubu Testing Center SHIKATSU Branch is recognized under the National Voluntary Laboratory Accreditation Program for satisfactory compliance established in Title 15, Part 285 Code of Federal Regulations. NVLAP Lab Code : 200190-0 1.1.2 Description of the Equipment Under Test : 1) Type of Equipment Microwave Oven 2) Model/Type No. R-21JVF 3) Type of Magnetron 2M240H(L2) 4) Category ISM Frequency Device 5) EUT Authorization Certification 6) FCC ID APYDMR0158 7) Product Type Prototype 8) Serial No. N/A 9) Date of manufacturer February, 2005 10) Trade Name SHARP 11) Fundamental Frequency 4.0, 2450.0 MHz Generated in the EUT 12) Highest Frequency 2450.0 MHz Used in the EUT 13) Power Rating 120VAC 60Hz 1-Phase 14) Rated Power Output 1000 W 15) EUT Grounding Grounded at the plug end of the power line cord. 1.1.3 Definitions for symbols used in this test report : Black box indicates that the listed condition, Regulation or equipment is applicable for this report. Blank box indicates that the listed condition, Regulation or equipment is not applicable for this report. 1.2 TEST REGULATION FCC Rules and Regulations Part 18 Subpart A, B and C(October 1, 2002). Test Procedure : The test was performed according to the procedures in FCC/OET MP-5(1986). JQA File No. 50-40512 FCC ID APYDMR0158 Model No. R-21JVF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 4 of 28 1.3 TEST CONDITIONS 1.3.1 The measurement of the RF Power Output was performed in the following test site. Test Location : KITA KANSAI Testing Center 7-7, Ishimaru, 1-Chome, Mino-Shi, Osaka, 562-0027, JAPAN Used Test Instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval Clamp on Power Meter 3167 HIOKI 08011116 Jun, 2004 1 Year Stop Watch 8N5502 SEIKO Q47097350 July, 2004 1 Year Digital Thermometer 2455 YOKOGAWA Q47097361 March, 2004 1 Year Environmental Conditions : Temperature: 29.0 Humidity: 60.0 JQA File No. 50-40512 FCC ID APYDMR0158 Model No. R-21JVF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 5 of 28 1.3.2 The measurement of the ISM Frequency was performed for line voltage variation 80% to 125% of normal rated voltage, in the following test site. Test Location : Chubu Testing Center SHIKATSU Branch 53-1, Yamaura, Yakushiji, Shikatsu-cho, Nishikasugai-gun, Aichi 481-0005, JAPAN Anechoic Chamber No.2 Used Test Instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval Spectrum Analyzer 8566B Hewlett Packard 2937A06026 July, 2004 1 Year Horn Antenna 3160-03 EMCO 9911-1065 May, 2004 1 Year RF Cable - Hewlett Packard A-2 May, 2004 1 Year Environmental Conditions : Temperature: 24.0 Humidity: 40.0 JQA File No. 50-40512 FCC ID APYDMR0158 Model No. R-21JVF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 6 of 28 1.3.3 The measurement of the AC Power Line Conducted Emission was performed in the following test site. Test Location : Chubu Testing Center SHIKATSU Branch 53-1, Yamaura, Yakushiji, Shikatsu-cho, Nishikasugai-gun, Aichi 481-0005, JAPAN Anechoic Chamber No.1 Shielded Room Used Test Instruments : Type Model No. Manufacturer Serial No. Last Cal. Interval Field Strength Meter ESH 2 Rohde & Schwarz 864125/007 May, 2004 1 Year LISN(for EUT) KNW-407 Kyoritsu Electrical 8-901-20 Jun, 2004 1 Year RF Cable 3D-2W Fujikura S-A May, 2004 1 Year RF Cable 3D-2W Fujikura S-B May, 2004 1 Year 50ohm Termination CT01 TME No.1 May, 2004 1 Year Environmental Conditions : Temperature: 18.0 Humidity: 50.0 JQA File No. 50-40512 FCC ID APYDMR0158 Model No. R-21JVF Issue DateApril 01, 2005 Regulation CFR 47 FCC Rules Part 18 Page 7 of 28 1.3.4 The measurement of the Radiated Emission(Magnetic Field) was perform…

Text truncated - open the document above for the full version.
