Read all instructions carefully before using the oven. TINSEB309MRK1 OVER THE RANGE CONVECTION MICROWAVE OVEN OPERATION MANUAL MODELS R-1874 / R-1875 To aid in reporting this microwave oven in case of loss or theft, please record below the model number and serial number located on the unit. We also suggest you record all the information listed and retain for future reference. MODEL NUMBER________________________SERIAL NUMBER______________ DATE OF PURCHASE______________________ DEALER____________________________TELEPHONE________________ SERVICER___________________________TELEPHONE________________ PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces. (d) The oven should not be adjusted or repaired by anyone except properly qualified service personnel. FOR CUSTOMER ASSISTANCE TO PHONE: DIAL 1-800-BE-SHARP ( 237-4277 ) for : SERVICE (for your nearest Sharp Authorized Servicer) PARTS (for your authorized parts distributor) ADDITIONAL CUSTOMER INFORMATION DIAL 1-800-642-2122 for : ACCESSORIES and COOKBOOK TO WRITE: Sharp Electronics Corporation Customer Assistance Center 1300 Naperville Drive Romeoville, IL 60446-1091 TO ACCESS INTERNET: www.sharp-usa.com Please provide the following information when you write or call: model number, serial number, date of pur- chase, your complete mailing address (including zip code), your daytime telephone number (including area code) and description of the problem. 1 CONTENTS INTERACTIVE COOKING SYSTEM The Interactive Cooking System offers step-by-step instructions in the display for using the oven, from setting the clock to programming each feature. It also includes Custom Help for instructions on using Child Lock, Audible Signal Elimination, Auto Start and Help. There is a choice of English, Spanish or French and a choice of U.S. Customary Unit-pound or Metric-kilograms. Touch CUSTOM HELP and follow the directions displayed or check page 25. For Customer Assistance ..... Inside Front Cover Precautions to Avoid Possible Exposure to Excessive Microwave Energy............. Inside Front Cover Contents ......................................................1 Consumer Limited Warranty .....................2 Product Information Card ..........................2 Important Safety Instructions ...................3 Unpacking Instructions .............................4 Accessories ................................................4 Grounding Instructions .............................4 Information You Need to Know .................5-7 About Your Oven ......................................5 About Food ...............................................5 About Microwave Cooking ........................6 About Safety .............................................6 About Children and the Microwave ...........7 About Utensils and Coverings ...................7 Part Names .................................................8 Touch-Control Panel ..................................9-10 Before Operating........................................11 To Set the Clock .......................................11 Stop/Clear .................................................11 Manual Operation .......................................11-12 Turntable On/Off .......................................11 Hood Light/Hood Fan ................................12 Time Cooking Microwave .........................12 Keep Warm ...............................................12 Microwave Features................................... 13-18 CompuDefrost ...........................................13 CompuDefrost Chart .................................13 Manual Defrost ..........................................14 Sensor Cooking ........................................14 Instant Sensors .........................................15 Instant Sensor Reheat ..............................15 Instant Sensor Popcorn ............................15 Popcorn Chart ...........................................15 Instant Sensor Chart .................................15 Sensor Cook .............................................16 Sensor Cook Chart ...................................16 Sensor Cook Recipes ............................... 17-18 Manual Convection/Automatic Mix Operation ....................................................19-23 Convection Cooking ..................................19 To Cook with Convection ..........................19 To Preheat and Cook with Convection .....19 To Broil .....................................................19 To Slow Cook ...........................................20 Automatic Mix Cooking .............................20 To Cook with Automatic Mix .....................20 To Preheat and Cook with Automatic Mix20 Convection Automatic Mix Operation ......21-23 CompuBroil ...............................................21 CompuBroil Chart .....................................21 CompuRoast .............................................22 CompuRoast Chart ...................................22 CompuBake ..............................................23 CompuBake Chart ....................................23 Other Convenient Features....................... 24-25 Multiple Sequence Cooking ......................24 More/Less Time Adjustment .....................24 Kitchen Timer ............................................24 Minute Plus ...............................................24 Demonstration Mode ............................…

Text truncated - open the document above for the full version.

1 Helen Zhao Subject:FW: Sharp Corporation , FCC ID: APYDMR0162, Assessment NO.: AN05T4764, Notice#1 From: Yan Zheng Sent: Wednesday, May 04, 2005 12:32 PM Subject: RE: Sharp Corporation , FCC ID: APYDMR0162, Assessment NO.: AN05T4764, Notice#1 Please check the answer from Hitesh below. Thanks! Regards, -Yan Question #1: Test report - magnetron name: The test report refers to 2M253H all the time, however the internal photos show the magnetron name should be 2M253J(L). Please verify which name is correct and make necessary correction. ANS. - DONE. Question #2: Test Report - RF output power: Please revisit the formula used for calculating the RF output power. The values listed in the table are incorrect. Please recalculate the RF output power. ANS. - CORRECTED. Question #3: Test Report - Radiated spurious emission limit: the limit is associated with measured RF output power. Since you need to recalculate RF output power (Q2), please recalculate the radiated spurious emission limit and apply the new limit in section 6.5 Radiated emisssion. ANS. - CORRECTED Question #4: Test Report - Section 6.5.1 Radiated emission below 1GHz: if there is any offset used during the test, please indicate in the test report. ANS. - CHANGES MADE IN THE RADIATED EMISSIONS SECTION Question #5: Test Report - Section 6.5.2 Radiated emission above 1GHz: Test data with Magnetron 2M167B uses 74dBuv/m as peak limit and 54dBuV/m as Avg limit, which is incorrect. Test data with magnetron 2M253H is a plot that belongs to other project. Please check the report again. ANS.- CHANGES MADE Best Regards, Helen Zhao The items indicated above must be submitted before processing can continue on the above referenced application. Failure to provide the requested information within 30 days of the original e-mail date may result in application dismissal and forfeiture of the filing fee. Also, please note that partial responses increase processing time and should not be submitted. Any questions about the content of this correspondence should be directed to the e-mail address listed below the name of the sender. 2

PROPOSED FCC ID LABEL AND LOCATION SHARP CORPORATION FCC ID: APYDMR0162 FCC ID LABEL LOCATION

S H A R P R E V IS IO N S 4 3 2 1 MADE B YAP P R O V AL S MAT . N O .F IN . N O .P R O C E S S N O . DAT E MIC R O WAV E O V E N E N G IN E E R IN G * * S C AL E U N IT mm T IT L E L AS T L E T T E R U S E D 1s t2nd3rdthIS S U E T Y P . =T Y P IC AL R E F . =R E F E R E N C E MO DE L F AMIL Y IS S U E D MDL . N O . P AR T S N O . S H AR P MAN U F AC T U R IN G C O MP AN Y O F AME R IC A 155+2 95+2 T Y K O U C H F E B R U AR Y 16, 2005 1 1 S C H E MAT IC DIAG R AM L AB E L T MAP C 095MR R 0 P AP E R : ADH E S IV E : R E L E AS E L IN E R : P IG ME N T : V AR N IS H : AR T WO R K S U P P L IE D B Y S MC A F IT C H B U R G 60-lb White B ritekote F IT C H B U R G 630 perma nent F IT C H B U R G 40-lb S emi-blea ch K ra ft Wa ter Ink T echnologies WG 0421 (J et B la ck) B . A. S . F . 79U 5566 (F lexo G em O . P . ) P rohibited S ubs ta nces : C F C s /H a lon/C a rbon tetra chloride/1. 1. 1-T richloroetha ne (Methyl chloroform) 1 2 T his product, As s embly, or component mus t not conta in a ny of the a bove mentioned s ubs ta nces . T his product, As s embly, or component is not ma nufa ctured us ing a ny of the a bove mentioned s ubs ta nces . <P R O H IB IT IO N T O U S E O ZO N E DE P L E T IN G S U B S T AN C E S > O T R R -1870F N otes 1. C ircuits / Wire C olors s ubject to cha nge without notice. 2. T ermina l with projection or oppos ite blue ma rk on la mp s ocket mus t be connected to neutra l wire. 3. O nly certa in models us e the a bs olute humidity s ens or. 4. P ower tra ns former top (finis h lea d) termina l mus t be connected to the hot (B L K ) wire. Wire C olor C ode E a rth L ine N eutra l L ine H ot L ine B L K : B L AC K P N K : P IN K G R N : G R E E N G R Y : G R AY B L U : B L U E P P L : P U R P L E WH T : WH IT E B R N : B R O WN R E D: R E D O R G : O R AN G E Y L W: Y E L L O W H IG H V O L T AG E R E C T IF IE R H IG H V O L T AG E C AP AC IT O R X X X mF P O WE R T R AN S F O R ME R MAG N E T R O N B L K B L K or B R N W H T W H T W H T B L K / B L K or B R N MO N IT O R S WIT C H S T IR R E R MO T O R W H T B R N F 1F 2 F 3 E 3E 4E 6E 5 E 2 E 1 R Y 1R Y 7R Y 4R Y 5R Y 6R Y 8 DAMP E R S WIT C H H E AT IN G E L E ME N T DO O R S E N S IN G S WIT C H B L K or B R N G R N R E D or P N K R E D N . O . R Y 3 P P L C O M R Y 3 C O M R Y 2 N . O . R Y 1 DAMP E R MO T O R F AN MO T O R O V E N L AMP W H T O LC M F M T T M DM C O N V E C T IO N MO T O R S E C O N DAR Y IN T E R L O C K S WIT C H T U R N T AB L E MO T O R G R Y Y L W G R Y WH T G R Y WH T W H T W H T G R Y G R Y W H T B R N Y L W B R N P P L B L K or B R N B 7B 1B 3 B 5 A5 G R Y B L U O R G R E D H L H L H O O D L AMP H O O D MO T O R H O O D C AP AC IT O R G R Y B R NB R N C 1A3A1 W H T R E D Y L W G R Y G N D H O O D F AN T H E R MAL C U T O U T S R E DB L K G R N Y L W R E D MAG N E T R O N T E MP E R AT U R E F U S E C 3 B R N C 9 C 5 C 7 B L U P P L W H T R E D Y L W R E D or P N K R Y 10 C O M R Y 1 N . O . R Y 2 AH S E N S O R B L K B L K R Y 3R Y 2 R Y 9 C O N T R O L U N IT O T R MO DE L S T M B L K T MAP C B 095MR R 0 N O IS E R E S IS T O R P R IMAR Y IN T E R L O C K R E L AY B L K or B R N T H E R MIS T O R 120V AC 60H z H N C 3 C 2 C 1 N O IS E F IL T E R MO N IT O R F U S E (20A) R 2 "T O L O AD" "T O L O AD" "T O S O U R C E " "T O S O U R C E " B L K G R Y G R Y G R Y G R Y B L K G R N Y L W B R N P N K B L K G R Y G R Y W H T W H T W H T G R N S C H E MAT IC DIAG R AM (DO O R C L O S E D C O O K O F F C O N DIT IO N ) <E N V IR O N ME N T A L IMP A C T S U B S T A N C E S C O N T A IN E D 1) R es ult of " S urv ey of C hemic a l S ubs ta nc es C onta ined in P a rts a nd ma teria ls " (J G P F ile) 2) R eport on E nv ironmenta l Impa c t S ubs ta nc es C onta ined in P a rts a nd Ma teria ls . 3) F ood s a nita tion la w's tes t da ta R equired S urv ey S heets R eques t 1) P lea s e fill in the required ma tter in the R eport on E nv ironmenta l Impa c t S ubs ta nc e C onta ined in P a rts a nd Ma teria ls , a ppend to the C opy of the dra wing, a nd s ubmit to S ha rp 2) P lea s e fill in the required ma tter into the s urv ey s prea ds heet (J P G file) reques ted s epa ra tely , a nd s ubmit to S ha rp 3) P lea s e follow direc tions from S ha rp a bout other doc ument to s ubmit. R E D or P N K R E D or ADDE D AL T E R N AT E WIR E DM-6781 03-02-05 T K B L KB L K B L K (C O N V . S IDE ) WIR E MO D. & H O U S IN G P O S IT IO N DM-6787 03-09-05 T K

FCC CFR47 PART 18 SUBPART C ISM EQUIPMENT TEST REPORT FOR MICROWAVE OVEN MODEL NUMBER: OTR4 MAGNETRON MODEL: 2M167B and 2M253J(L) FCC ID: APYDMR0162 REPORT NUMBER: 05U3348-1 ISSUE DATE: MAY 4, 2005 Prepared for SHARP CORPORATION 22-22 NAGAIKE-CHO, ABENO-KU RELIABILITY CONTROL GROUP OSAKA, JAPAN, 545-8522 Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 05U3348-1 DATE: MAY 4, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0162 Page 2 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Revisions Revised By REPORT NO: 05U3348-1 DATE: MAY 4, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0162 Page 3 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1 ATTESTATION OF TEST RESULTS............................................................................................. 4 2 PRODUCT DESCRIPTION .............................................................................................................. 5 3 TEST FACILITY................................................................................................................................ 5 4 ACCREDITATION AND LISTING ................................................................................................. 5 5 MEASUREMENT EQUIPMENT LIST ........................................................................................... 6 6 LIMITS AND RESULTS ................................................................................................................... 7 6.1 RADIATION HAZARD MEASUREMENT .................................................................................... 7 6.2 INPUT POWER .......................................................................................................................... 10 6.3 RF OUTPUT POWER MEASUREMENT ................................................................................... 11 6.4 OPERATING FREQUENCY MEASUREMENTS ....................................................................... 12 6.4.1 VARIATION IN OPERATING FREQUENCY WITH TIME........................................... 13 6.4.2 VARIATION IN OPERATING FREQUENCY WITH VOLTAGE ................................. 16 6.5 RADIATED EMISSIONS.............................................................................................................23 6.5.1 RADIATED EMISSIONS – BELOW 1GHz ..................................................................... 25 6.5.2 RADIATED EMISSIONS – ABOVE 1GHz ...................................................................... 33 6.6 CONDUCTED EMISSIONS ....................................................................................................... 35 7 SETUP PHOTO ................................................................................................................................ 41 REPORT NO: 05U3348-1 DATE: MAY 4, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0162 Page 4 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1 ATTESTATION OF TEST RESULTS COMPANY NAME: SHARP ELECTRONIC CORP 22-22 NAGAIKE-CHO, ABENO-KU RELIABILITY CONTROL GROUP OSAKA, JAPAN, 545-8522 EUT DESCRIPTION: MICROWAVE OVEN MODEL NUMBER: OTR4 . SERIAL NUMBER: 128719, 128720 MAGNETRON MODELS: 2M167B, 2M253J(L) DATE TESTED: APRIL 16 - 18, 2005 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 18 SUBPART C & FCC METHEROD OF MEASUREMENTS OF RADIO NOISE EMISSION FROM INDUSTRIAL, SCIENTIFIC, AND MEDICAL EQUIPMENT FCC / OST MP-5 NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Approved & Released For CCS By: Tested By: YAN ZHENG HITESH H. SOLANKI EMC SUPERVISOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 05U3348-1 DATE: MAY 4, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0162 Page 5 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 2 PRODUCT DESCRIPTION The equipment under test is a microwave oven sold for consumer use. Model: OTR4 is an 850W microwave oven with digital controls panel. Magnetron Model: 2M167B AND 2M253J(L) 3 TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at 561F Monterey Road, Morgan Hill, California, USA. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 4 ACCREDITATION AND LISTING The test facilities used to perform radiated and cond…

Text truncated - open the document above for the full version.

REPORT NO: 05U3348-1 DATE: APRIL 19, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0162 Page 41 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 7 SETUP PHOTO Radiation Hazard Measurement Operating Frequency Measurements REPORT NO: 05U3348-1 DATE: APRIL 19, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0162 Page 42 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. AC Line Conduction Front AC Line Conduction back REPORT NO: 05U3348-1 DATE: APRIL 19, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0162 Page 43 of 43 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Radiation Measurement front Radiation Measurements back END OF REPORT
