APYDMR0163Microwave Oven

OVER THE RANGE MICROWAVE OVEN Read all instructions carefully before using the oven. OPERATION MANUAL MODELS R-1600 R-1601 R-1602 TO PHONE: DIAL 1-800-BE-SHARP (237-4277) for : SERVICE (for your nearest Sharp Authorized Servicer) PARTS (for your authorized parts distributor) ADDITIONAL CUSTOMER INFORMATION DIAL 1-800-642-2122 for : ACCESSORIES and COOKBOOK DIAL (201)529-8703 for : COOKING ASSISTANCE TO WRITE: For cooking and operation questions: Susan Edwards/Test Kitchen Sharp Electronics Corporation Sharp Plaza, Box 650 Mahwah, NJ 07430-2135 For service problems, warranty information, missing items and other assistance: Sharp Electronics Corporation Customer Assistance Center 1300 Naperville Drive Romeoville, IL 60446-1091 Please provide the following information when you write or call: model number, serial number, date of purchase, your complete mailing address (including zip code), your daytime telephone number (including area code) and description of the problem. TO ACCESS INTERNET: www.sharp-usa.com To aid in reporting this microwave oven in case of loss or theft, please record below the model number and serial number located on the unit. We also suggest you record all the information listed and retain for future reference. MODEL NUMBER________________________SERIAL NUMBER______________ DATE OF PURCHASE______________________ DEALER____________________________TELEPHONE________________ SERVICER___________________________TELEPHONE________________ PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces. (d) The oven should not be adjusted or repaired by anyone except properly qualified service personnel. FOR CUSTOMER ASSISTANCE 1 CONTENTS For Customer Assistance ....Inside Front Cover Precautions to Avoid Possible Exposure to Excessive Microwave Energy............ Inside Front Cover Contents ......................................................1 Consumer Limited Warranty .....................2 Product Information Card ..........................2 Important Safety Instructions ...................3 Unpacking Instructions .............................4 Optional Accessories ................................4 Grounding Instructions .............................4 Information You Need to Know .................5-7 About Your Oven ......................................5 About Food ...............................................5 About Microwave Cooking ........................6 About Safety .............................................6 About Utensils and Coverings ..................7 About Children and the Microwave ...........7 Part Names .................................................8 Touch-Control Panel ..................................9 Before Operating........................................10 To Set the Clock .......................................10 Stop/Clear .................................................10 Manual Operation .......................................10-11 Time Cooking ............................................10 To Set Power Level .................................. 10-11 Turntable On/Off .......................................11 Special Features......................................... 12-16 Breakfast/Lunch/Dinner ............................12 Breakfast Chart .........................................12 Lunch Chart ..............................................13 Dinner Chart .............................................14 INTERACTIVE COOKING SYSTEM The Interactive Cooking System with 2-line, 16 digit display offers step-by-step instructions for using the oven, from setting the clock to programming each feature. It also includes Custom Help for instructions on using Child Lock, Audible Signal Elimination and Auto Start. There is a choice of English, Spanish or French and a choice of U.S. Customary Unit-pound or Metric-kilograms. Touch CUSTOM HELP and follow the directions displayed or check page 18. CompuDefrost ...........................................15 CompuDefrost Chart .................................15 Manual Defrost ..........................................16 Popcorn ....................................................16 Other Convenient Features....................... 17-19 Multiple Sequence Cooking ......................17 More or Less Time Adjustment .................17 Memory Cook ............................................17 Custom Help .............................................18 1. Child Lock ............................................18 2. Audible Signal Elimination ...................18 3. Auto Start .............................................18 4. & 5. Language/Weight Selection ..........18 Kitchen Timer ............................................18 Touch On ..................................................19 Minute Plus ...............................................19 Demonstration Mode ................................19 Help ..........................................................19 Work Light .................................................19 Night Light .................................................19 Fan ............................................................19 Reheating Chart .........................................20 Fish and Seafood Cooking Chart .............20 Service Call Check .....................................21 THE ULTIMATE ACCESSORY ...................21 Specifications .............................................22 Co…

Text truncated - open the document above for the full version.

1 Subject:FW: Sharp Corporation , FCC ID: APYDMR0163, Assessment NO.: AN05T4765, Notice#1 From: Yan Zheng Sent: Wednesday, May 04, 2005 12:39 PM Subject: RE: Sharp Corporation , FCC ID: APYDMR0163, Assessment NO.: AN05T4765, Notice#1 Please check the answer from Hitesh below, Thanks! Regards, -Yan Question #1: Test report - magnetron name: The test report says EUT is a 1000W microwave oven, however the user manual says output power is 950W. Please verify which one is correct and make necessary correction. ANS. - CHANGES MADE. Question #2: Test Report - Section 6.3 RF Output power: The test report indicates that 1200ml load was used during the testing, however, since the output power is below 1000W, 1000ml load should be used instead. Please correct. ANS. - CORRECTIONS MADE Question #3: Test Report - Section 6.3 RF output power: Please revisit the formula used for calculating the RF output power. The values listed in the table are incorrect. Please recalculate the RF output power. ANS. - CORRECTIONS MADE Question #4: Test Report - Section 6.4 Frequency Stability: The test report indicates that 1200ml load was used during the testing, however, since the output power is below 1000W, 1000ml load should be used instead. Please correct. ANS. - CORRECTIONS MADE Question #5: Test Report - Section 6.5 Radiated spurious emission limit: the limit is associated with measured RF output power. Since you need to recalculate RF output power (Q3), please recalculate the radiated spurious emission limit and apply the new limit in section 6.5 Radiated emisssion. ANS. - CHANGES MADE Question #6: Test Report - Section 6.5.1 Radiated emission below 1GHz: if there is any offset used during the test, please indicate in the test report. ANS. - CHANGES MADE Best Regards,

PROPOSED FCC ID LABEL AND LOCATION SHARP CORPORATION FCC ID: APYDMR0163 FCC ID LABEL LOCATION

SHARP REVISIONS 4 3 2 1 MADE BYAPPROVALS MAT. NO.FIN. NO.PROCESS NO. DATE MICROWAVE OVEN ENGINEERING * * SCALE UNIT mm TITLE LAST LETTER USED 1st2nd3rdthISSUE TYP.=TYPICAL REF.=REFERENCE MODEL F AMILY ISSUED MDL. NO. PARTS NO. SHARP MANUFACTURING COMPANY OF AMERICA 155+2 95+2 JULIAN MARTIN 03 / 18 / 2005 1 1 SCHEMATIC DIAGRAM TMAPCB101MRR0 PAPER: ADHESIVE: RELEASE LINER: PIGMENT: VARNISH: ARTWORK SUPPLIED BY SMCA FITCHBURG 60-lb White Britekote FITCHBURG 630 permanent FITCHBURG 40-lb Semi-bleach Kraft Water Ink Technologies WG0421 (Jet Black) B.A.S.F. 79U5566 (Flexo Gem O. P.) Prohibited Substances: CFCs/Halon/Carbon tetrachloride/1.1.1-Trichloroethane (Methyl chloroform) 1 2 This product, Assembly, or component must not contain any of the above mentioned substances. This product, Assembly, or component is not manufactured using any of the above mentioned substances. <PROHIBITION TO USE OZONE DEPLETING SUBSTANCES> OTR7 RED BLK RED WHT BLK BLK MAG. TEMP FUSE ORG RED A5 RY3 A7 WHT BLK BLK WHT HOOD CAPACITOR HOOD MOTOR RED YL W WHT RY4 RY5 WHT BLU BLU WHT PPL or BLU ORG WHT N. O. OVEN LAMP RELAY COM. GR Y WHT BLK GRY WHT WHT STIRRER MOTOR WHT RED WHT BLK N .C . RED WHT OR7 OEM MODEL ORG E1 E2 RED GRN STOP SWITCH TMAPCB101MRR0 BLU WHT RY1 RED BLK C3 B1 RY6 C5 B3 A1 A3 A9 HUMIDITY SENSOR F3 F2 F1 ORG BLK SECONDARY INTERLOCK RELAY RY2 N. O COM BLK ORG BLK ORG RED RY7 TURN- TABLE RELAY C1 COM FAN MOTOR WHT WHT BLK WHT MONITOR SWITCH WHT WHT PRIMARY INTERLOCK SWITCH OVEN LAMP TURN- TABLE MOTOR TTM FM STM OL COM HIGH VOLTAGE RECTIFIER HIGH VOLTAGE CAPACITOR POWER TRANSFORMER RED ELECTROLUX R16xx 4. Power Transformer (Start Lead) terminal must be connected to hot wire (RED) 3. Only certain models use the absolute humidity sensor. 1. Circuits subject to change without notice 2. Terminal with projection or opposite blue mark on lamp socket must be connected to neutral wire. . NOTES: MAGNETRON HOOD FAN THERMAL CUT OUT CONTROL UNIT OVEN THERMAL CUT OUT High Low HOOD LAMP NC GRN GND SCHEMATIC DIAGRAM (DOOR CLOSED COOK OFF CONDITION) ORG : ORANGE BLK : BLACK BRN : BROWN PNK : PINK RED : RED YLW : YELLOW PPL : PURPLE BLU : BLUE GRY : GRAY WHT : WHITE LEAD WIRE COLOR CODE GRN : GREEN 120VAC 60 Hz YLW BLK BLU YL W RED WHT BLK xx uF COM N.O. BLK WHT BLK BLU N O I S E S U P R E S S I O N C O I L R E S I S T O R 4 7 0 k W 1 / 2 W L I N E C R O S S C A P A C I T O R 1 . 0 u F 2 7 5 V L I N E B Y P A S S C A P A C I T O R 0 . 0 0 3 3 u F 2 5 0 V F U S E 2 0 A L I N E B Y P A S S C A P A C I T O R 0 . 0 0 3 3 u F 2 5 0 V NOISE FILTER N L GND BLU

FCC CFR47 PART 18 SUBPART C ISM EQUIPMENT TEST REPORT FOR MICROWAVE OVEN MODEL NUMBER: OTR7 MAGNETRON MODEL: 2M214 FCC ID: APYDMR0163 REPORT NUMBER: 05U3349-1 ISSUE DATE: MAY 4, 2005 Prepared for SHARP CORPORATION 22-22 NAGAIKE-CHO, ABENO-KU RELIABILITY CONTROL GROUP OSAKA, JAPAN, 545-8522 Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 FAX: (408) 463-0888 REPORT NO: 05U3349-1 DATE: MAY 4, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0163 Page 2 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Revision History Rev. Revisions Revised By REPORT NO: 05U3349-1 DATE: MAY 4, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0163 Page 3 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. TABLE OF CONTENTS 1. ATTESTATION OF TEST RESULTS............................................................................................. 4 2. PRODUCT DESCRIPTION .............................................................................................................. 5 3. TEST FACILITY................................................................................................................................ 5 4. ACCREDITATION AND LISTING ................................................................................................. 5 5. MEASUREMENT EQUIPMENT LIST ........................................................................................... 6 6. LIMITS AND RESULTS ................................................................................................................... 7 6.1. RADIATION HAZARD MEASUREMENT .................................................................................... 7 6.2. INPUT POWER ............................................................................................................................ 9 6.3. RF OUTPUT POWER MEASUREMENT ................................................................................... 10 6.4. OPERATING FREQUENCY MEASUREMENTS ....................................................................... 11 6.4.1. VARIATION IN OPERATING FREQUENCY WITH TIME........................................... 12 6.4.2. VARIATION IN OPERATING FREQUENCY WITH VOLTAGE ................................. 14 6.5. RADIATED EMISSIONS.............................................................................................................18 6.5.1. RADIATED EMISSIONS – BELOW 1GHz ..................................................................... 20 6.5.2. RADIATED EMISSIONS – ABOVE 1GHz ...................................................................... 24 6.6. CONDUCTED EMISSIONS ....................................................................................................... 25 7. SETUP PHOTO ................................................................................................................................ 29 REPORT NO: 05U3349-1 DATE: MAY 4, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0163 Page 4 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 1. ATTESTATION OF TEST RESULTS COMPANY NAME: SHARP ELECTRONIC CORP 22-22 NAGAIKE-CHO, ABENO-KU RELIABILITY CONTROL GROUP OSAKA, JAPAN, 545-8522 EUT DESCRIPTION: MICROWAVE OVEN MODEL NUMBER: OTR7 . SERIAL NUMBER: 7G51101540 & 7G51101106 MAGNETRON MODEL: 2M214 DATE TESTED: APRIL 18-28, 2005 APPLICABLE STANDARDS STANDARD TEST RESULTS FCC PART 18 SUBPART C & FCC METHEROD OF MEASUREMENTS OF RADIO NOISE EMISSION FROM INDUSTRIAL, SCIENTIFIC, AND MEDICAL EQUIPMENT FCC / OST MP-5 NO NON-COMPLIANCE NOTED Compliance Certification Services, Inc. tested the above equipment in accordance with the requirements set forth in the above standards. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Note: The results documented in this report apply only to the tested sample, under the conditions and modes of operation as described herein. This document may not be altered or revised in any way unless done so by Compliance Certification Services and all revisions are duly noted in the revisions section. Any alteration of this document not carried out by Compliance Certification Services will constitute fraud and shall nullify the document. No part of this report may be used to claim product certification, approval, or endorsement by NVLAP, NIST, or any government agency. Approved & Released For CCS By: Tested By: YAN ZHENG WILLIAM ZHUANG EMC SUPERVISOR EMC ENGINEER COMPLIANCE CERTIFICATION SERVICES COMPLIANCE CERTIFICATION SERVICES REPORT NO: 05U3349-1 DATE: MAY 4, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0163 Page 5 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 2. PRODUCT DESCRIPTION The equipment under test is a microwave oven sold for consumer use. Model: OTR7 is a 950 W microwave oven with digital controls panel. Magnetron Model: 2M214 3. TEST FACILITY The open area test sites and conducted measurement facilities used to collect the radiated data are located at 561F Monterey Road, Morgan Hill, California, USA. The sites are constructed in conformance with the requirements of ANSI C63.7, ANSI C63.4 and CISPR Publication 22. 4. ACCREDITATION AND LISTING The test facilities used to perform radiated and conducted emissions t…

Text truncated - open the document above for the full version.

REPORT NO: 05U3349-1 DATE: APRIL 28, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0163 Page 29 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. 7. SETUP PHOTO Radiation Hazard Measurement Operating Frequency Measurements REPORT NO: 05U3349-1 DATE: APRIL 28, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0163 Page 30 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. AC Line Conduction Front AC Line Conduction back REPORT NO: 05U3349-1 DATE: APRIL 28, 2005 EUT: MICROWAVE OVEN FCC ID: APYDMR0163 Page 31 of 31 COMPLIANCE CERTIFICATION SERVICES DOCUMENT NO: CCSUP4031A 561F MONTEREY ROAD, MORGAN HILL, CA 95037 USA TEL: (408) 463-0885 FAX: (408) 463-0888 This report shall not be reproduced except in full, without the written approval of CCS. Radiation Measurement front Radiation Measurements back END OF REPORT
