APYDMR0170Household Microwave Oven

Sharp Corporation

Click to zoom

Application Details

Equipment Class: 8CC - Part 18 Consumer Device
Date of Grant: Mar 17, 2008
Application Purpose: Original Equipment
Date of Application: Mar 17, 2008
Equipment Note: Household Microwave Oven
Frequency Range: 2450.00000000 - 2450.00000000
Company: Sharp Corporation
Country: Japan

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

P/N 316495032 TINSEB156WRRZ-EL81 Use & Care Guide Over the Range Microwave Oven Guía de Uso y Cuidado Horno microondas sobre la estufa Mode d’emploi et d’entretien Four à micro-ondes au dessus de la cuisinière E 2 PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces. (d) The oven should not be adjusted or repaired by anyone except properly qualified service personnel. Purchase date Electrolux model number Electrolux serial number (see picture for location) Please read and save this guide Thank you for choosing Electrolux, the new premium brand in home appliances. This Use & Care Guide is part of our commitment to customer satisfaction and product quality throughout the service life of your new appliance. We view your purchase as the beginning of a relationship. To ensure our ability to continue serving you, please use this page to record important product information. Keep a record for quick reference Questions? For toll-free telephone support in the U.S.: 1-877-4ELECTROLUX (1-877-435-3287) For online support and Internet production information visit http://www.electroluxappliances.com ©2008 Electrolux Home Products, Inc.All rights reserved. Printed in Thailand FINDING INFORMATION NOTE Registering your product with Electrolux enhances our ability to serve you. You can register online at www.electroluxappliances.com or by dropping your Product Registration Card in the mail. E 3 FINDING INFORMATION .................................. 2 PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY ............... 2 TABLE OF CONTENTS .................................... 3 IMPORTANT SAFETY INSTRUCTIONS .......... 4 UNPACKING AND EXAMING YOUR OVEN .... 5 GROUNDING INSTRUCTIONS ........................ 6 INFORMATION YOU NEED TO KNOW ........... 7-10 About Your Oven ............................................ 7 About Microwave Cooking ............................. 7 About Safety ................................................. 8 About Children and the Microwave ................ 8 About Food .................................................... 9 About Utensils and Coverings ....................... 10 PART NAMES ................................................... 11 CONTROL PANEL ............................................ 12 BEFORE OPERATING ..................................... 13 To Set the Clock ............................................. 13 Stop/Clear ..................................................... 13 MANUAL OPERATION ..................................... 14-15 Time Cooking ................................................. 14 To Set Power Level ........................................ 14 Using the Rack ............................................... 14 Manual Defrost ............................................... 15 SENSOR MODES ............................................ 15-19 Sensor Cook .................................................. 16 Sensor Cook chart ......................................... 17 Popcorn/Fresh Veggies/Frozen Veggies/ Baked Potato/Sensor Reheat ........................ 18 Popcorn chart ............................................... 18 Fresh Veggies chart ....................................... 19 Frozen Veggies chart ..................................... 19 Baked Potato chart ....................................... 19 Sensor Reheat chart ..................................... 19 AUTO MODES ................................................. 20-26 Auto Cook ...................................................... 20 Auto Cook chart ............................................. 20 Dinner recipes ................................................ 21 Keep Warm..................................................... 22 Melt, Soften .................................................... 23 Melt, Soften chart ........................................... 23 Snacks ........................................................... 24 Snacks chart .................................................. 24 Auto Reheat ................................................... 25 Auto Reheat chart .......................................... 25 Auto Defrost ................................................... 26 Auto Defrost chart .......................................... 26 CONVENIENT FEATURES .............................. 27-29 User Pref ........................................................ 27 Multiple Sequence Cooking ........................... 28 More or Less Time Adjustment ...................... 28 Add 30 Seconds ............................................ 28 Help ................................................................ 29 Timer .............................................................. 29 Turntable ON/OFF .......................................... 29 Quick Start ..................................................... 29 Demonstration Mode ..................................... 29 Light ............................................................... 29 Fan ................................................................. 29 CLEANING AND CARE .................................... 30-31 SERVICE CALL CHECK .................................. 32 SPECIFICATIONS ............................................. 33 WARRANTY INFORMATIONS ......................... 34 TABLE OF CONTENTS E 4 When using electrical appliances basic safety precautions should be followed, including the following: To reduce…

Text truncated - open the document above for the full version.

External Photos

Photographs of appliance FCC ID: APYDMR0170 Fig. 1 Shows a front view of appliance Door Touch-key Control Door Handle Photographs of appliance FCC ID: APYDMR0170 Fig. 2 Shows oven cavity inside with door open. And shows identification label (nameplate) location. Stirrer Cover Oven Cavity Identification Label (Nameplate label) Turntable Photographs of appliance FCC ID: APYDMR0170 Fig. 3 Shows rear side of appliance Photographs of appliance FCC ID: APYDMR0170 Fig. 4 Shows bottom side of appliance. Photographs of appliance FCC ID: APYDMR0170 Fig. 5 Shows top side view of appliance with outer enclosure and internal duct removed., and shows waveguide location. Waveguide Photographs of appliance FCC ID: APYDMR0170 Fig. 6 Shows right side view of appliance with enclosure is removed, and shows magnetron. Magnetron Photographs of appliance FCC ID: APYDMR0170 Fig. 7 Shows relay unit P.W.B. assembly. Photographs of appliance FCC ID: APYDMR0170 Fig. 8 Shows back-side of relay unit PWB assembly. Photographs of appliance FCC ID: APYDMR0170 Fig. 9 Shows touch-key control PWB assembly. Photographs of appliance FCC ID: APYDMR0170 Fig. 10 Shows back-side of touch-key control PWB assembly.

ID Label/Location Info

IDENTIFICATION LABEL (NAMEPLATE LABEL) FCC ID: APYDMR0170 Model Nubmer Factory ID FCC ID Code 175 mm 25 mm FCC ID APY : FCC assigned grantee code for Sharp Corporation. DMR0170 : Number assigned by grantee to the models or the model family in a technically identical products. Factory ID T : Manufacturer identification marking for Sharp Appliances (Thailand) Ltd. Identification Label (Nameplate label) TT COMPLIES WITH DHHS RADICOMPLIES WITH DHHS RADIAATION PERFORMANCE STION PERFORMANCE STTANDARDS 21 CFRANDARDS 21 CFR SUBCHAPTERSUBCHAPTER J.J. 120 120 VV.A.C. 1.65kW 60Hz SINGLE PHASE OUTPU.A.C. 1.65kW 60Hz SINGLE PHASE OUTPUTT 1000W 2450MHz 1000W 2450MHz MADE INMADE IN THAILANDTHAILAND SERIASERIALL NO. MANU NO. xxxxx1 MANUFFACTURED ACTURED :: MARCH 2008 ELECTROLUX HOME PRODUCTS INC. ELECTROLUX HOME PRODUCTS INC. EI30BM55HS EI30BM55HSAA FCC ID FCC ID :: APYDMRAPYDMR01700170 285B285B HOUSEHOLDHOUSEHOLD MICROMICROWWAAVV EE OVENOVEN ELECTROLUX HOME PRODUCTS NOELECTROLUX HOME PRODUCTS NORRTHTH AMERICAMERICAA INC. , SPRINGFIELD , INC. , SPRINGFIELD , TN 37172 TN 37172

Internal Photos

Schematics

MAGNETRON TEMP.FUSE 2 13 632451 RY5 C1 HOOD FAN MOTOR RY6 RY7 RY9 N. O. OVEN LAMP RELAY COM. CONTROL DOOR UNIT ANTENNAMOTOR N.C. MODEL: EI30BM55H E1 D40 40W 40W D29 E2 RED GRN DOOR SENSINGSWITCH WHT RY1 A1 T1 VRS1 RY8 A5 A3 B7 B5 B3 C7 B1 C5 C100 6.8 C3 HUMIDITY SENSOR F3 F2 F1 PRIMARY INTERLOCK RELAY LOW VOLTAGE TRANSFORMER RY2 N.O. RY3 TURN- TABLE MOTOR RELAY C9 1 1 1 1 6 12 CN-L CN-J CN-G 11 11 FAN MOTOR MONITORSWITCH SECONDARY INTERLOCK SWITCH OVEN LAMP TURNTABLEMOTOR TTM FM ATM OL CL HM COM. HIGH VOLTAGE RECTIFIER HIGH VOLTAGE CAPACITOR POWER TRANSFORMER MAGNETRON POWER UNIT OVEN THERMAL CUT OUT HOOD FAN THERMOSTAT THERMOSTAT High Low Med. COOK TOP LAMP N.O. RY4 135 150 145 N.O. CN-M CN-N CN-D R100 GND SCHEMATIC DIAGRAM (DOOR CLOSED COOK OFF CONDITION) 120VAC 60Hz 0.9 4uF 23 00VA C COM N.O. N O I S E S U P R E S S I O N C O I L 1 . 0 m H R E S I S T O R 4 7 0 k 1 / 2 W 1/2W 30k L I N E C R O S S C A P A C I T O R 1 . 0 F 2 5 0 V L I N E B Y P A S S C A P A C I T O R 3 3 0 0 p F 2 5 0 V F U S E 2 0 A L I N E B Y P A S S C A P A C I T O R 3 3 0 0 p F 2 5 0 V NOISE FILTER UNIT UNIT SWITCH UNIT ILL.-1

Test Report

JAPAN QUALITY ASSURANCE ORGANIZATION Page 1 of 27 Technical document No. 23663-0601 JQA File No. : KL80070489 Issued Date : February 29, 2008 TEST REPORT APPLICANT : Sharp Corporation, CS Promotion Group, Quality Assurance Center ADDRESS : 22-22 Nagaike-cho, Abeno-ku, Osaka, 545-8522, Japan PRODUCTS : Microwave Oven MODEL NO. : EI30BM55H SERIAL NO. : -- FCC ID : APYDMR0170 TEST STANDARD : CFR 47 FCC Rules and Regulations Part 18 TESTING LOCATION : Japan Quality Assurance Organization KITA-KANSAI Testing Center 1-7-7, Ishimaru, Minoh-shi, Osaka 562-0027, Japan TEST RESULTS : Passed DATE OF TEST : January 18, 2008 - February 23, 2008 This report must not used by the client to claim product endorsement by NVLAP or Yuichi Fukumoto NIST or any agency of the U.S. Government. Manager Japan Quality Assurance Organization KITA-KANSAI Testing Center Testing Dept. EMC Division NVLAP LAB CODE 200191-0 1-7-7, Ishimaru, Minoh-shi, Osaka 562-0027, Japan ● The measurement values stated in Test Report was made with traceable to National Institute of Advanced Industrial Science and Technology (AIST) of Japan and National Institute of Information and Communications Technology (NICT) of Japan. ● The applicable standard, testing condition and testing method which were used for the tests are based on the request of the applicant. ● The test results presented in this report relate only to the offered test sample. ● The contents of this test report cannot be used for the purposes, such as advertisement for consumers. ● This test report shall not be reproduced except in full without the written approval of JQA. JAPAN QUALITY ASSURANCE ORGANIZATION JQA File No. : KL80070489 Issue Date : February 29, 2008 Model No. : EI30BM55H FCC ID : APYDMR0170 Regulation : CFR 47 FCC Rules and Regulations Part 18 Page 2 of 27 Technical document No. 23663-0601 TABLE OF CONTENTS Page Documentation ................................................................................................................................................. 3 1 Test Regulation......................................................................................................................................3 2 Test Location..........................................................................................................................................3 3 Recognition of Test Laboratory.............................................................................................................3 4 Description of the Equipment Under Test...........................................................................................4 5 Test Condition........................................................................................................................................5 6 Preliminary Test and Test Setup.........................................................................................................7 7 Equipment Under Test Modification..................................................................................................12 8 Responsible Party................................................................................................................................12 9 Deviation from Standard.....................................................................................................................12 10 Test Results..........................................................................................................................................13 11 Summary..............................................................................................................................................15 12 Operating Condition............................................................................................................................16 13 Test Configuration...............................................................................................................................16 14 Equipment Under Test Arrangement (Drawings)............................................................................17 15 Equipment Under Test Arrangement (Photographs).......................................................................18 Appendix A: Test Data ................................................................................................................................... 20 A.1 Power Output.......................................................................................................................................20 A.2 ISM Frequency.....................................................................................................................................21 A.3 Conducted Powerline...........................................................................................................................22 A.4 Radiated Emission...............................................................................................................................23 Appendix B: Test Instruments....................................................................................................................... 26 DEFINITIONS FOR ABBREVIATION AND SYMBOLS USED IN THIS TEST REPORT “EUT” means Equipment Under the Test. “N/A” means that Not Applicable. “N/T” means that Not Tested. - indicates that the listed condition, standard or equipment is applicable for this report. - indicates that the listed condition, standard or equipment is not applicable for this report. JAPAN QUALITY ASSURANCE ORGANIZATION JQA File No. : KL80070489 Issue Date : February 29, 2008 Model No. : EI30BM55H FCC ID : APYDMR0170 Regulation : CFR 47 FCC Rules and Regulations Part 18 Page 3 of 27 Technical document No. 23663-0601 Documentation 1 Test Regulation Applied Standard : CFR 47 FCC Rules and Regulations Part 18 Industrial, Scientific, and Medical Equipment Test Procedure : FCC/OET MP-5 (1986) FCC Methods of Measurements of Radio Noise Emissions from Industrial, Scientific, and Medical equipment 2 Test Loc…

Text truncated - open the document above for the full version.

Test Report

JAPAN QUALITY ASSURANCE ORGANIZATION Page 1 of 27 Technical document No. 23663-0601 JQA File No. : KL80070488 Issued Date : February 29, 2008 TEST REPORT APPLICANT : Sharp Corporation, CS Promotion Group, Quality Assurance Center ADDRESS : 22-22 Nagaike-cho, Abeno-ku, Osaka, 545-8522, Japan PRODUCTS : Microwave Oven MODEL NO. : EI30BM55H SERIAL NO. : -- FCC ID : APYDMR0170 TEST STANDARD : CFR 47 FCC Rules and Regulations Part 18 TESTING LOCATION : Japan Quality Assurance Organization KITA-KANSAI Testing Center 1-7-7, Ishimaru, Minoh-shi, Osaka 562-0027, Japan TEST RESULTS : Passed DATE OF TEST : January 18, 2008 - February 23, 2008 This report must not used by the client to claim product endorsement by NVLAP or Yuichi Fukumoto NIST or any agency of the U.S. Government. Manager Japan Quality Assurance Organization KITA-KANSAI Testing Center Testing Dept. EMC Division NVLAP LAB CODE 200191-0 1-7-7, Ishimaru, Minoh-shi, Osaka 562-0027, Japan ● The measurement values stated in Test Report was made with traceable to National Institute of Advanced Industrial Science and Technology (AIST) of Japan and National Institute of Information and Communications Technology (NICT) of Japan. ● The applicable standard, testing condition and testing method which were used for the tests are based on the request of the applicant. ● The test results presented in this report relate only to the offered test sample. ● The contents of this test report cannot be used for the purposes, such as advertisement for consumers. ● This test report shall not be reproduced except in full without the written approval of JQA. JAPAN QUALITY ASSURANCE ORGANIZATION JQA File No. : KL80070488 Issue Date : February 29, 2008 Model No. : EI30BM55H FCC ID : APYDMR0170 Regulation : CFR 47 FCC Rules and Regulations Part 18 Page 2 of 27 Technical document No. 23663-0601 TABLE OF CONTENTS Page Documentation ................................................................................................................................................. 3 1 Test Regulation......................................................................................................................................3 2 Test Location..........................................................................................................................................3 3 Recognition of Test Laboratory.............................................................................................................3 4 Description of the Equipment Under Test...........................................................................................4 5 Test Condition........................................................................................................................................5 6 Preliminary Test and Test Setup.........................................................................................................7 7 Equipment Under Test Modification..................................................................................................12 8 Responsible Party................................................................................................................................12 9 Deviation from Standard.....................................................................................................................12 10 Test Results..........................................................................................................................................13 11 Summary..............................................................................................................................................15 12 Operating Condition............................................................................................................................16 13 Test Configuration...............................................................................................................................16 14 Equipment Under Test Arrangement (Drawings)............................................................................17 15 Equipment Under Test Arrangement (Photographs).......................................................................18 Appendix A: Test Data ................................................................................................................................... 20 A.1 Power Output.......................................................................................................................................20 A.2 ISM Frequency.....................................................................................................................................21 A.3 Conducted Powerline...........................................................................................................................22 A.4 Radiated Emission...............................................................................................................................23 Appendix B: Test Instruments....................................................................................................................... 26 DEFINITIONS FOR ABBREVIATION AND SYMBOLS USED IN THIS TEST REPORT “EUT” means Equipment Under the Test. “N/A” means that Not Applicable. “N/T” means that Not Tested. - indicates that the listed condition, standard or equipment is applicable for this report. - indicates that the listed condition, standard or equipment is not applicable for this report. JAPAN QUALITY ASSURANCE ORGANIZATION JQA File No. : KL80070488 Issue Date : February 29, 2008 Model No. : EI30BM55H FCC ID : APYDMR0170 Regulation : CFR 47 FCC Rules and Regulations Part 18 Page 3 of 27 Technical document No. 23663-0601 Documentation 1 Test Regulation Applied Standard : CFR 47 FCC Rules and Regulations Part 18 Industrial, Scientific, and Medical Equipment Test Procedure : FCC/OET MP-5 (1986) FCC Methods of Measurements of Radio Noise Emissions from Industrial, Scientific, and Medical equipment 2 Test Loc…

Text truncated - open the document above for the full version.

Test Setup Photos

JAPAN QUALITY ASSURANCE ORGANIZATION JQA File No. : KL80070489 Issue Date : February 29, 2008 Model No. : EI30BM55H FCC ID : APYDMR0170 Regulation : CFR 47 FCC Rules and Regulations Part 18 Page 18 of 27 Technical document No. 23663-0601 15 Equipment Under Test Arrangement (Photographs) 15.1 Conducted Powerline Photograph present configuration with maximum emission JAPAN QUALITY ASSURANCE ORGANIZATION JQA File No. : KL80070489 Issue Date : February 29, 2008 Model No. : EI30BM55H FCC ID : APYDMR0170 Regulation : CFR 47 FCC Rules and Regulations Part 18 Page 19 of 27 Technical document No. 23663-0601 15.2 Radiated Emission – Front View – – Rear View – Photograph present configuration with maximum emission

Test Setup Photos

JAPAN QUALITY ASSURANCE ORGANIZATION JQA File No. : KL80070488 Issue Date : February 29, 2008 Model No. : EI30BM55H FCC ID : APYDMR0170 Regulation : CFR 47 FCC Rules and Regulations Part 18 Page 18 of 27 Technical document No. 23663-0601 15 Equipment Under Test Arrangement (Photographs) 15.1 Conducted Powerline Photograph present configuration with maximum emission JAPAN QUALITY ASSURANCE ORGANIZATION JQA File No. : KL80070488 Issue Date : February 29, 2008 Model No. : EI30BM55H FCC ID : APYDMR0170 Regulation : CFR 47 FCC Rules and Regulations Part 18 Page 19 of 27 Technical document No. 23663-0601 15.2 Radiated Emission – Front View – – Rear View – Photograph present configuration with maximum emission
