APYDMR0175Household Microwave/Steam Oven

Steam oven with microwave and grill function OPERATION MANUAL WITH COOKBOOK Read all instructions carefully before using the oven AX-1100S/1100R ® SHARP ELECTRONICS CORPORATION Sharp Plaza, Mahwah, NJ 07495-1163 TINSEB302WRRZ-D01 Printed in Thailand ® CONTENTS For Customer Assistance ................................................................................................ 1 Precautions to Avoid Possible Exposure to Excessive Microwave Energy ............... 1 Limited Warranty .............................................................................................................. 2 Product Information Card ................................................................................................ 2 Important Safety Instructions .......................................................................................... 3 Unpacking and Installation Instructions ........................................................................ 4 Grounding Instructions .................................................................................................... 5 Information You Need to Know .................................................................................. 6-11 Part Names ...................................................................................................................... 12 Control Panel .................................................................................................................. 13 Important Instructions .............................................................................................. 14-16 Before Operating ........................................................................................................... 17 Clean the Oven Before First Use ................................................................................... 17 Automatic Cooking .................................................................................................... 18-24 Manual Cooking ......................................................................................................... 25-28 Other Convenient Features ...................................................................................... 29-31 Cleaning and Care .......................................................................................................... 32 Troubleshooting Chart .............................................................................................. 33-35 Service Call Check ......................................................................................................... 36 Specifi cations ................................................................................................................. 36 Chart ................................................................................................................................ 37 Recipes ....................................................................................................................... 38-43 Touch Guide .................................................................................................................... 44 1 To aid in reporting this Steam Oven in case of loss or theft, please record below the model number and serial number located on the unit. We also suggest you record all the information listed and retain for future reference. FOR CUSTOMER ASSISTANCE PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. (c) Do not operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces. (d) The oven should not be adjusted or repaired by anyone except properly qualified service personnel. Please provide the following information when you write or call: model number, serial number, date of purchase, your complete mailing address (including zip code), your daytime telephone number (including area code) and description of the problem. TO PHONE: DIAL 1-800- BE-SHARP ( 237-4277 ) for : SERVICE (for your nearest Sharp Authorized Servicer) PARTS (for your authorized parts distributor) ADDITIONAL CUSTOMER INFORMATION DIAL 1-800-642-2122 for : REPLACEMENT ACCESSORIES TO WRITE: Sharp Electronics Corporation Customer Assistance Center 1300 Naperville Drive Romeoville, IL 60446-1091 TO ACCESS INTERNET: www.sharpusa.com MODEL NUMBER _______________________ SERIAL NUMBER _____________ DATE OF PURCHASE ______________________ DEALER ___________________________ TELEPHONE ________________ SERVICER ___________________________ TELEPHONE ________________ 2 The product information card, which is inside of the Steam Oven carton, should be completed within ten days of purchase and returned. We will keep it on fi le and help you access the information in case of loss, damage or theft. This will also enable us to contact you in the unlikely event that any adjustments or modifi cations are ever required for your oven. PRODUCT INFORMATION CARD LIMITED WARRANTY SHARP ELECTRONICS CORPORATION warrants to the fi rst consumer purchaser that this Sharp brand product (the Product), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or labor for the period(s) set forth below. This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below nor to any Product t…

Text truncated - open the document above for the full version.

SCHEMATIC DIAGRAM (DOOR CLOSED, COOK OFF CONDITION) MICROWAVE/STEAM OVEN AX-1100R, AX-1100S R O T S I M R E H T R O T S I M R E H T T/C TRANSFORMER T I N U L O R T N O C ) W 0 0 9 ( FUSE POWER SAVING RELAY N O R T E N G A M V 0 0 2 2 F u 4 9 . 0 R O T I C A P A C R E I F I T C E R . V . H R E W O P R E M R O F S N A R T MG THERMAL CUT-OUT ENGINE THERMAL CUT-OUT P M U P R O T O M N A F R O T O M VRS1 P M A L N E V O R E T A E H L L I R G ) W 0 0 1 1 ( R E P M A D H C T I W S R O O D G N I S N E S H C T I W S RY9 RY4RY1RY3RY2 7 Y R 6 Y R 5 Y R 9 B 7 B 1 B 8 B 0 1 B 5 B 2 1 B 1 1 B A5A7A1A11 N.C. H C T I W S R O T I N O M H C T I W S A3 A9 L O M D M F M A M P NOISE FILTER UNIT L N FUSE F20A L I O C N O I S S E R P P U S E S I O N R O T I C A P A C S S A P Y B E N I L V 0 5 2 / F p 0 0 3 3 z H 0 6 ~ V 0 2 1 C A V 0 5 2 / F u 2 2 . 0 R O T I C A P A C S S O R C E N I L R O T I C A P A C S S A P Y B E N I L V 0 5 2 / F p 0 0 3 3 6 B R E P M A D H C T I W S 8 Y R A13 M D D3D1D2 AH SENSOR OVEN THERMAL CUT-OUT MONITORED SWITCH . C . N REAR DAMPERMOTOR DAMPERMOTOR (STEAM HEATER) (OVEN) REAR PRIMARY INTERLOCK RELAY 3.15 SECONDARY INTERLOCK SWITCH STEAM HEATER REAR DAMPER STIRRER MOTOR STIRRER

Photographs of appliance Model AX-1100R and AX-1100S FCC ID: APYDMR0175 Fig. 1: Front view of appliance D oor Control Panel Fig. 2: Rear view of appliance Identification Label (Nameplate label) Photographs of appliance Model AX-1100R and AX-1100S FCC ID: APYDMR0175 Fig. 3: Bottom view of appliance. Fig. 4: Inside oven cavity with door open. Photographs of appliance Model AX-1100R and AX-1100S FCC ID: APYDMR0175 Fig. 5: Internal right side view with outer enclosure removed. Waveguide Magnetron Photographs of appliance Model AX-1100R and AX-1100S FCC ID: APYDMR0175 Fig. 6: Control unit PWB assembly. Fig. 7: Back-side of control unit PWB assembly.

IDENTIFICATION LABEL (NAMEPLATE LABEL) FCC ID: APYDMR0175 Model Nubmer FCC ID Code 95.25 mm 31.75mm Identification Label (Nameplate label) on rear side of appliance FCC ID APY : FCC assigned grantee code for Sharp Corporation. DMR0175 : Number assigned by grantee to the models or the model family in a technically identical products. AXAX -- 11100100SS 6060HzHz TT THIS PRODUCTTHIS PRODUCTCOMPLIESCOMPLIESWITHWITHDHHSDHHSRULESRULES21CFR21CFRSUBCHAPTERSUBCHAPTERJ.J. QUESTIONS?1QUESTIONS?1 -- 800800 -- BEBE -- SHARPSHARP SHARPSHARP CORPORA CORPORATIONTION MARKET EDBYMARKETEDBY : SHARP : SHARP ELECTRONICSCORP ELECTRONICSCORP.MAHW.MAHWAH, NJ. 0749955AH, NJ. 074 MODELMODELNO.NO. SERIALSERIALNO.NO. 120120VVACAC MANUFMANUFACTUREDACTURED AA 1 3. 0 13. 0 MADE IN MADE IN THAILANDTHAILAND FCC ID FCC ID :: 285B285B APYDMR0175APYDMR0175 DECEMBER 2010 000001 Location of Identification Label (Nameplate label)

Photographs of appliance Model AX-1100R and AX-1100S FCC ID: APYDMR0175 Fig. 1: Front view of appliance D oor Control Panel Fig. 2: Rear view of appliance Identification Label (Nameplate label) Photographs of appliance Model AX-1100R and AX-1100S FCC ID: APYDMR0175 Fig. 3: Bottom view of appliance. Fig. 4: Inside oven cavity with door open. Photographs of appliance Model AX-1100R and AX-1100S FCC ID: APYDMR0175 Fig. 5: Internal right side view with outer enclosure removed. Waveguide Magnetron Photographs of appliance Model AX-1100R and AX-1100S FCC ID: APYDMR0175 Fig. 6: Control unit PWB assembly. Fig. 7: Back-side of control unit PWB assembly.

********** INFORMATION FOR CERTIFICATION (1) ********** APPLICANT: Name : Sharp Corporation, CS Promotion Group, Product Safety Promotion Center Address 22-22 Nagaike-Cho, Abeno-Ku Osaka 545-8522, Japan Grantee Code: : APY Applicant Rep. : M. Nishikawa CONTACT PERSON: Name : Sharp Electronics Corporation Address : Sharp Plaza, Mahwah, New Jersey 07430 Applicant Rep. : Steve Petruska, Product Safety Dept. Telephone No. : 201-529-9689 MEASUREMENT SITE: Name : Japan Quality Assurance Organization Kita-Kansai Testing Center Address : 7-1 Ishimaru 1-chome, Minoh-shi, Osaka 562-0027, Japan MANUFACTURER: Name : Sharp Appliances (Thailand) Ltd. Address : 64 Moo 5, Tambol Bangsamuk Amphur Bangpakong Chachoengsao Province, Thailand FCC IDENTIFICATION : APYDMR0175 EQUIPMENT Model Name : Microwave/Steam Oven, Model AX-1100R Brand : Sharp Electronics Corp. Importer : Sharp Electronics Corp. ----------------------------------------------------------------------------------------------------------------------------------------- ********** INFORMATION FOR CERTIFICATION (2) ********** (1) Type(s) of emission: Not Applicable (2) Frequency range: 2450 MHz (3) Range of operating power and description of means provided for variation of operating power: RF output power 900 W (Average power output is controlled by ON/OFF switching cycles.) (4) Max. power rating as described in the applicable rules: 900 W (by IEC method) (5) The voltage and current to magnetron: Magnetron Cat. No. 2M253H(L) : 4.06 kV peak, 310 mA (6) Function of each electro tube, semiconductor or other active circuit device: Fixed Magnetrons, Type 2M253H(L) as power generator (7) Complete circuit diagram: Attached (8) Instruction book: Attached (9) Tune up procedure over the power range or at specific operating power levels: Not adjustable. (10) A description of all circuitry and devices provided for determining and stabilizing frequency: Fixed by magnetron and oven design (11) A description of any circuit or devices employed for suppression of spurious radiation, for limiting modulation, and for limiting the operating power: Suppression obtained by shielding design (12) Identification plate or label: Illustration attached Location of identification plate or label: Photo. Attached ********** INFORMATION FOR CERTIFICATION (3) ********** DESCRIPTION OF THE MICROWAVE OVEN Unit Body Dimensions : 520 mm wide, 330 mm high, 500 mm deep Door Dimensions : 417 mm wide, 296 mm high (Viewing Area: 262 mm wide, 139 mm high) Oven Cavity Dimensions : 343 mm wide, 204 mm high, 373 mm deep Feed Type and Location : Supplied by waveguide located bottom of oven. Door Seal Type : Choke and Capacitive Seals Magnetron Type : 2M253H(L) mfd by Toshiba

SCHEMATIC DIAGRAM (DOOR CLOSED, COOK OFF CONDITION) MICROWAVE/STEAM OVEN AX-1100R, AX-1100S R O T S I M R E H T R O T S I M R E H T T/C TRANSFORMER T I N U L O R T N O C ) W 0 0 9 ( FUSE POWER SAVING RELAY N O R T E N G A M V 0 0 2 2 F u 4 9 . 0 R O T I C A P A C R E I F I T C E R . V . H R E W O P R E M R O F S N A R T MG THERMAL CUT-OUT ENGINE THERMAL CUT-OUT P M U P R O T O M N A F R O T O M VRS1 P M A L N E V O R E T A E H L L I R G ) W 0 0 1 1 ( R E P M A D H C T I W S R O O D G N I S N E S H C T I W S RY9 RY4RY1RY3RY2 7 Y R 6 Y R 5 Y R 9 B 7 B 1 B 8 B 0 1 B 5 B 2 1 B 1 1 B A5A7A1A11 N.C. H C T I W S R O T I N O M H C T I W S A3 A9 L O M D M F M A M P NOISE FILTER UNIT L N FUSE F20A L I O C N O I S S E R P P U S E S I O N R O T I C A P A C S S A P Y B E N I L V 0 5 2 / F p 0 0 3 3 z H 0 6 ~ V 0 2 1 C A V 0 5 2 / F u 2 2 . 0 R O T I C A P A C S S O R C E N I L R O T I C A P A C S S A P Y B E N I L V 0 5 2 / F p 0 0 3 3 6 B R E P M A D H C T I W S 8 Y R A13 M D D3D1D2 AH SENSOR OVEN THERMAL CUT-OUT MONITORED SWITCH . C . N REAR DAMPERMOTOR DAMPERMOTOR (STEAM HEATER) (OVEN) REAR PRIMARY INTERLOCK RELAY 3.15 SECONDARY INTERLOCK SWITCH STEAM HEATER REAR DAMPER STIRRER MOTOR STIRRER

JAPAN QUALITY ASSURANCE ORGANIZATION Page 1 of 26 Technical document No. 23162-0701 JQA File No. : KL80100328 Issue Date : November 15, 2010 TEST REPORT APPLICANT : Sharp Corporation, CS Promotion Group, Product Safety Promotion Center ADDRESS : 22-22 Nagaike-cho, Abeno-ku, Osaka 545-8522, Japan PRODUCTS : Household Microwave/Steam Oven MODEL NO. : AX-1100R SERIAL NO. : 000007 FCC ID : APYDMR0175 TEST STANDARD : CFR 47 FCC Rules and Regulations Part 18 TESTING LOCATION : Japan Quality Assurance Organization KITA-KANSAI Testing Center 1-7-7, Ishimaru, Minoh-shi, Osaka 562-0027, Japan TEST RESULTS : Passed DATE OF TEST : October 25, 2010 ~ November 12, 2010 Kousei Shibata Manager Japan Quality Assurance Organization KITA-KANSAI Testing Center Testing Dept. EMC Division 1-7-7, Ishimaru, Minoh-shi, Osaka 562-0027, Japan ● The measurement values stated in Test Report was made with traceable to National Institute of Advanced Industrial Science and Technology (AIST) of Japan and National Institute of Information and Communications Technology (NICT) of Japan. ● The applicable standard, testing condition and testing method which were used for the tests are based on the request of the applicant. ● The test results presented in this report relate only to the offered test sample. ● The contents of this test report cannot be used for the purposes, such as advertisement for consumers. ● This test report shall not be reproduced except in full without the written approval of JQA. ● VLAC does not approve, certify or warrant the product by this test report. VLAC-001-2 JAPAN QUALITY ASSURANCE ORGANIZATION JQA File No. : KL80100328 Issue Date : November 15, 2010 Model No. : AX-1100R FCC ID : APYDMR0175 Regulation : CFR 47 FCC Rules and Regulations Part 18 Page 2 of 26 Technical document No. 23162-0701 TABLE OF CONTENTS Page Documentation ................................................................................................................................................. 3 1 Test Regulation......................................................................................................................................3 2 Test Location..........................................................................................................................................3 3 Recognition of Test Laboratory.............................................................................................................3 4 Description of the Equipment Under Test...........................................................................................4 5 Test Condition........................................................................................................................................5 6 Preliminary Test and Test Setup.........................................................................................................7 7 Equipment Under Test Modification..................................................................................................12 8 Responsible Party................................................................................................................................12 9 Deviation from Standard.....................................................................................................................12 10 Test Results..........................................................................................................................................13 11 Summary..............................................................................................................................................15 12 Operating Condition............................................................................................................................16 13 Test Configuration...............................................................................................................................16 14 Equipment Under Test Arrangement (Drawings)............................................................................16 Appendix A: Test Data ................................................................................................................................... 17 Appendix B: Test Arrangement (Photographs) ............................................................................................. 23 Appendix C: Test Instruments....................................................................................................................... 25 DEFINITIONS FOR ABBREVIATION AND SYMBOLS USED IN THIS TEST REPORT EUT : Equipment Under Test EMC : Electromagnetic Compatibility AE : Associated Equipment EMI : Electromagnetic Interference N/A : Not Applicable EMS : Electromagnetic Susceptibility N/T : Not Tested - indicates that the listed condition, standard or equipment is applicable for this report. - indicates that the listed condition, standard or equipment is not applicable for this report. JAPAN QUALITY ASSURANCE ORGANIZATION JQA File No. : KL80100328 Issue Date : November 15, 2010 Model No. : AX-1100R FCC ID : APYDMR0175 Regulation : CFR 47 FCC Rules and Regulations Part 18 Page 3 of 26 Technical document No. 23162-0701 Documentation 1 Test Regulation Applied Standard : CFR 47 FCC Rules and Regulations Part 18 Industrial, Scientific, and Medical Equipment Test Procedure : FCC/OET MP-5 (1986) FCC Methods of Measurements of Radio Noise Emissions from Industrial, Scientific, and Medical equipment 2 Test Location KITA-KANSAI Testing Center 1-7-7, Ishimaru, Minoh-shi, Osaka 562-0027, Japan KAMEOKA EMC Branch 9-1, Ozaki, Inukanno, Nishibetsuin-cho, Kameoka-shi, Kyoto 621-0126, Japan 3 Recognition of Test Laboratory JQA KITA-KANSAI Testing Center Testing Department EMC Division is accredited under ISO/IEC 17025 by following accreditation bodies and the test facility of Testing Division is registered by the following bodies. VLAC Code : VLAC-001-2 (Effective through : March 30, 2012) NVLAP Lab Code : 200191-0 (Effective through : J…

Text truncated - open the document above for the full version.

JAPAN QUALITY ASSURANCE ORGANIZATION JQA File No. : KL80100328 Issue Date : November 15, 2010 Model No. : AX-1100R FCC ID : APYDMR0175 Regulation : CFR 47 FCC Rules and Regulations Part 18 Page 23 of 26 Technical document No. 23162-0701 Appendix B: Test Arrangement (Photographs) B.1 Conducted Powerline Photograph present configuration with maximum emission JAPAN QUALITY ASSURANCE ORGANIZATION JQA File No. : KL80100328 Issue Date : November 15, 2010 Model No. : AX-1100R FCC ID : APYDMR0175 Regulation : CFR 47 FCC Rules and Regulations Part 18 Page 24 of 26 Technical document No. 23162-0701 B.2 Radiated Emission – Front View – – Rear View – Photograph present configuration with maximum emission
