MODEL UX-CL220 FACSIMILE OPERATION MANUAL 1. Installation 2. Setting Up and Using OpenLCR 3. Using the Answering System 4. Using the Cordless Handset 5. Sending Faxes 6. Receiving Faxes 7. Making Copies 8. Special Functions 9. Printing Lists 10. Maintenance 11. Troubleshooting UX-CL220 FACSIMILE WARNING - FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and the receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. IMPORTANT NOTICE Fax machine FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for at uncontrolled equipment. This equipment should be installed and operated with minimum distance at least 20cm between the radiator and persons body (excluding extremities: hands, wrists, feet and legs) and must not be co-located or operated with any other antenna or transmitter. Cordless handset For body worn operation, this phone has been tested and meets FCC RF exposure gudelines when used with an accessory that no metal and that positions the handset a minimum of 1.5cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. ABOUT THE TELEPHONE CONSUMER PROTECTION ACT OF 1991 "The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer or other electronic device to send any message via a telephone facsimile machine unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission the following information: (1) The date and time of transmission. (2) Identification of either the business, business entity or individual sending the message. (3) Telephone number of either the sending machine, business, business entity or individual. In order to program this information into your facsimile machine, please refer to the appropriate instructions in the operation manual." As an ENERGY STA R  partner, SHARP has determined that this product meets the ENERGY STA R  guidelines for energy efficiency. 1 Introduction Fax machine and general specifications. *Based on Sharp Standard No. 1 Chart at standard resolution in Sharp special mode, excluding time for protocol signals (i.e., ITU-T phase C time only). Automatic dialing30 numbers Imaging filmInitial starter roll (included with machine): 32 ft. (10 m) (approx. 30 letter-size pages) Replacement roll (not included): UX-5CR 164 ft. (50 m) (one roll yields approx. 150 letter-size pages) Memory size*504 KB (approx. 30 average pages with no voice messages recorded and ECM turned off, or 20 minutes of voice messages (including OGMs) with no faxes in memory) Modem speed14,400 bps with automatic fallback to lower speeds. Transmission time*Approx. 6 seconds (only when ECM is on) ResolutionHorizontal: 203 pels/inch (8 pels/mm) Vertical: Standard: 98 lines/inch (3.85 lines/mm) Fine /Halftone: 196 lines/inch (7.7 lines/mm) Super fine: 391 lines/inch (15.4 lines/mm) Automatic document feeder 10 pages max. (letter/A4, 20 lb paper) Recording systemThermal transfer recording Display16-digit LCD display Welcome, and thank you for choosing a Sharp fax machine! The features and specifications of your new Sharp fax are shown below. 2 Halftone (grayscale)64 levels Compression schemeMR, MH, MMR Applicable telephone linePublic switched telephone network Paper tray capacityLetter: Approx. 50 sheets (20-lb. copier paper at room temperature; maximum stack height should not be higher than the line on the tray) Legal: 5 sheets Recommended paper weight: 20-lb. Copy Bond CompatibilityITU-T (CCITT) G3 mode Input document sizeAutomatic feeding: Width: 5.8 to 8.5" (148 to 216 mm) Length: 5.5 to 11" (140 to 279 mm) Manual feeding: Width: 5.8 to 8.5" (148 to 216 mm) Length: 5.5 to 23.6" (140 to 600 mm) Effective scanning width8.3" (210 mm) max. Effective printing width8.3" (210 mm) max. Contrast controlAutomatic/Dark selectable Reception modesTEL/FAX/TAD Copy functionSingle / Multi (99 copies/page) Telephone functionYes (cannot be used if power fails) Power requirements120 V AC, 60 Hz Operating temperature41 - 95°F (5 - 35°C) Humidity25 - 85% RH Power consumptionStandby: 4.3 W Maximum: 100 W Dimensions (without attachments) Width: 13.9" (353 mm) Depth: 7.6" (193 mm) Height: 6.9" (174 mm) Weight (without attachments) Approx. 6.2 lbs. (2.8 kg) 3 Cordless handset specifications. Frequency2.4 GHz (2.405 to 2.475 GHz) Dimensions Width: 1.8" (46 mm) Depth: 1.7" (42 mm) Height: 7.1" (180 mm) (not including antenna) WeightApprox. 0.3 lbs. (115 g) (without battery) Battery3.6 V Ni-MH battery; capacity: 850 mAh Power consumption Initial charging Battery life Battery life in standby mode Approx. 1.0 W (in standby mode) Approx. 10 hours for initial charge Approx. 5 hours (300 minutes) Approx. 4 days with one full charge Battery life (both normal and in standby mode) …

Text truncated - open the document above for the full version.

Optional Answering System Settings 49 3. Answering Machine 1Press once and once. 2Press once and twice. 3Press . 4Press to turn on automatic fax reception, or to turn it off. 5Press to return to the date and time display. FUNCTION 1 2 STOP ON TAD FAILURE ♦Automatic fax reception YES: The reception mode will switch to FAX mode, allowing the machine to continue to receive faxes automatically. With this setting, you can still use the remote commands to listen to your messages and then erase them (see Remote Operations on page 55). Automatic fax reception is set to NO at the factory before shipping. If you want to set it to YES, press the panel keys as follows: Display: T.A.D. SETTING 1=YES, 2=NO The display briefly shows your selection, then: OGM ONLY MODE OGM only mode If needed, you can turn off recording of incoming messages. In this case, your outgoing message will play, but callers will not be able to leave a message. (The machine will still receive faxes sent by automatic dialing.) 1Press once and once. 2Press once and once. FUNCTION OGM ONLY MODE Display: T.A.D. SETTING Transfer Function 50 3Press . 4Press to turn on OGM only mode, or to turn it off. 5Press to return to the date and time display. 1 2 STOP The display briefly shows your selection, then: TOLL SAVER Transfer Function The Transfer function is used to have the machine automatically call you at a specified number every time it receives an incoming message. This lets you hear your messages immediately after they come in, even when you are at a remote location. To use the Transfer function, you must first program the number that you wish the machine to call (the transfer number), and record the transfer message that plays when you answer the phone at the remote location. When you go out and wish to use the transfer function, turn it on. When you return and no longer wish to use the transfer function, turn it off. Programming the transfer number To use the Transfer function, you must first give the machine the number to call (the transfer number). 1Press once and once. 2Press once and 4 times. 3Press . FUNCTION TRANSFER TEL # Display: T.A.D. SETTING ENTER TEL # Transfer Function 51 3. Answering Machine 4Press the number keys to enter the transfer number. •To insert a pause between any two digits of the number, press . 5Press . 6Press to return to the date and time display. FUNCTION START/MEMORY STOP Recording the transfer message The transfer message plays when you answer the telephone, and informs you that the call is a transfer call. It can be up to 15 seconds long. To record a transfer message, follow the steps below. The following is an example: “Hello. This is a transfer call for (YOUR NAME). Enter your remote code number now.” 1Press once and twice. 2Press once. 3Lift the handset. (If you have already recorded a message, you can press to listen to the message, or press to delete the message.) REC/ MEMO PLAY DELETE Display: OGM2(TRANSFER) Transfer Function 52 4Press and speak into the handset to record the message. •The transfer message can be up to 15 seconds long. While recording, the display will show the time left to record. 5When finished, replace the handset or press . START/MEMORY STOP Checking or erasing the transfer message To check or erase the transfer message, follow Steps 1 and 2 of the above procedure, and then press to check the message, or to erase the message. PLAY DELETE Turning the Transfer function on and off When you go out and wish to use the Transfer function, turn it on as follows: 1Press once and once. 2Press once and 3 times. 3Press . 4Press to turn on the Transfer function. (Press to turn the function off.) 5Press to return to the date and time display. FUNCTION 1 2 STOP TRANSFER FUNC Display: T.A.D. SETTING 1=YES, 2=NO The display briefly shows your selection, then: ON TAD FAILURE Override Ringing 53 3. Answering Machine 6Each time the machine receives an incoming message, it will call your programmed transfer number. When you answer, you will hear your recorded message telling you that the call is a transfer call. On the dial pad of your phone, enter , your remote code number (see page 55), and . The machine will play back your messages. •You can also perform any of the remote operations described in Remote Operations later in this chapter (see page 55). Note: When you hang up after a transfer call, the machine will not immediately resume normal operation. If you want the machine to accept calls immediately after a transfer call, enter twice before hanging up (if you want to hang up during message playback, first enter and to stop playback, then enter twice). 0 Override Ringing This function allows selected callers using a touch-tone telephone to override the answering system's outgoing message and cause the machine to make a special ringing sound, alerting you that they are calling. This is useful when you are near the machine but only want to talk with certain callers, taking all other calls on the answering system. Programming the override code To override the answering system, your callers must enter a 3-digit override code from their telephone. This code has been set to "009" at the factory. If you wish to change the code, press the panel keys as shown below. Important! Make sure the override code is different from the remote code used for remote operations. 1Press once and once. FUNCTION Display: T.A.D. SETTING Override Ringing 54 2Press once and 3 times. 3Press . 4Press the number keys to enter a 3-digit override code. 5Press to store the override code, and then to return to the date and time display. START/MEMORY STOP OVERRIDE CODE Overriding the answering machine Your callers should follow the steps below to override the answering system. 1The caller calls your machine from a touch-tone telephone. When the outgoing message begins, they should press the key on their telephone. •The caller will hear a short beep, and the outgoing message will stop. 2The caller should enter the override…

Text truncated - open the document above for the full version.

Caller ID (Requires Subscription to Service) 99 8. Special Functions 1Press once and 3 times. 2Press once and once. 3Press once. FUNCTION Priority Call If you have turned on Caller ID, you can set the machine to make a special ringing sound when you receive a call from a designated phone number. This lets you know immediately who is calling without having to look at the display. To use this function, enter the desired phone number by following the steps below (only one phone number can be entered). Display: ENTRY MODE PRIORITY # 1=SET, 2=CLEAR Erasing all calls using the cordless handset Follow these steps to erase all calls from the Caller ID list using the cordless handset. 1Press . 2Press . 3Press . •To cancel, press . REVIEW ERASE HOLD START OFF OFF REVIEW CALLS : REVIEW Cordless handset display: ERASE ALL? PRESS START KEY Caller ID (Requires Subscription to Service) 100 Blocking voice calls If you have turned on Caller ID, you can use the Anti Junk Fax function described in Blocking Reception of Unwanted Faxes in this chapter to block voice calls as well as faxes from your specified Anti Junk Number. In this case, when a voice call or a fax transmission comes in from the number you have specified as a "Junk Number", your fax will break the connection as soon as it receives the calling phone number from the caller ID service (before the second ring). To use this function, enter the number that you wish to block as explained in Blocking Reception of Unwanted Faxes (see page 102). Only one number can be blocked. Note: This function cannot be used if you are using the Distinctive Ring function. 4Press to store a number. (To clear a previously stored number, press and go to Step 6.) 5Enter the number by pressing the number keys (max. 20 digits). 6Press to store (or clear) the number. 7Press to return to the date and time display. 1 2 START/MEMORY STOP OWN NUMBER SET Distinctive Ring (Requires Subscription to Service) 101 8. Special Functions Distinctive Ring (Requires Subscription to Service) Important: ♦To use distinctive ring, you must subscribe to a distinctive ring service from your local phone company. ♦Your fax machine may not be compatible with some distinctive ring services. Distinctive ring is a service offered by some local telephone companies whereby they assign an additional second number to your regular single line. The second number rings differently from your normal number. If you subscribe to a distinctive ring service, you can set the fax machine to automatically answer when your second number is called. This allows you to use the second number as an exclusive fax number. To have your fax automatically answer when your second number is called, follow the steps below: 1Press once and twice. 2Press once and 3 times. 3Press once. 4Press a number from 1 to 3 to select the ring pattern below that matches your second number’s ring pattern. Or, press 4 to have your fax automatically answer your normal telephone number. Press 5 to turn off the distinctive ring function. RING PATTERN 1Two short rings RING PATTERN 2One short, one long, and one short ring RING PATTERN 3Two short rings and one long ring STANDARD RINGYour standard (normal) ring pattern OFF SETTINGTurn distinctive ring off FUNCTION Display: 1 2 3 4 5 OPTION SETTING DISTINCTIVE Blocking Reception of Unwanted Faxes 102 5Press to return to the date and time display. 6Set the reception mode to FAX. ♦When using distinctive ring, you must set the reception mode of your fax machine to FAX. When your designated fax number is dialed, your fax will automatically answer and begin reception after two rings. Note that other devices on the same line will also ring until your fax answers. If one of your other numbers is dialed, the fax will ring; however, it will not answer. STOP 1Press once and 3 times. 2Press once and twice. 3Press once. 4Press to store an Anti Junk number, or to clear a previously stored number (if you are clearing a number, go to Step 6). 5Enter the fax number by pressing the number keys (max. 20 digits). 6Press and then press to return to the date and time display. FUNCTION 1 2 START/MEMORY STOP Blocking Reception of Unwanted Faxes The Anti Junk Fax function allows you to block reception of faxes from a party that you specify. This saves paper by not printing out unwanted "junk" faxes. To use this function, follow the steps below to enter the fax number from which you do not wish to receive faxes. One fax number can be entered. The display briefly shows your selection, then: RESOLUTION/ RECEPTION MODE Display: FAX TEL TAD FAX SIGNAL RX ENTRY MODE ANTI JUNK # 1=SET, 2=CLEAR 103 9. Printing Lists 9. Printing Lists You can print lists showing settings and information entered in the fax machine. The lists are described below. To print a list, follow these steps. 1Press once and twice. 2Press once. 3Press or until the desired list appears in the display. 4Press once. 5Press to print the list. FUNCTION START/MEMORY Display: LISTING MODE TEL # LIST PRESS START KEY Printing Lists 104 Message List This list shows information about the messages currently recorded in the answering machine, including the date and time each messages was recorded, the length, and the type. Caller-ID List This list shows information about your 30 most recent calls. (This list is only available if you are using the Caller ID function.) Telephone Number List This list shows the fax and phone numbers that have been stored for automatic dialing. Setup List This list shows your current selections for the FUNCTION key settings. The list also shows your name and fax/telephone number as entered in the machine, and a sample of the header printed at the top of every page you transmit (HEADER PRINT). Printing Lists 105 9. Printing Lists Transaction Report This report is printed out automatically after an operation is completed to allow you to check the result. Your fax machine is set at the factory to print out the report only when an error occurs. ♦T…

Text truncated - open the document above for the full version.

A- PEX INTERNATIONAL CO., LTD. HeadOffice: 4383-326 Asama-cho, Ise-shi, Mie-ken, 516-0021, Japan TEL:0596-24-8116/FAX:0596-248124 February 8, 2002 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 To Whom It May Concern: We, A-Pex International Co., Ltd., hereby authorize Compliance Certification Services to act on our behalf in all matters relating to applications for equipment authorizations, including the signing of all documents relating to these matters. Any and all acts carried out by Compliance Certification Services on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefit, pursuant to Section 5301 of the Anti-Drug Act of 1988. This authorization expires one year from the current date. FCC ID: APYHRO00023 Applicant: Sharp Corporation Very truly yours, Tetsuya Hashimoto, Site Manager A-Pex International Co.,LTD.

FCC ID: APYHRO00023Page:1/23 Photographs for Complete Set Sharp Corporation, Communication Systems Group Cordless Handset Model UX-CL220 (May have suffix K) Cordless Handset Charger AC Adapter Facsimile Model UX-CL220 FCC ID: APYHRO00023Page:2/23 Photographs for Facsimile, Front Side Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:3/23 Photographs for Facsimile, Left Side Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:4/23 Photographs for Facsimile, Right Side Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:5/23 Photographs for Facsimile, Rear Side Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:6/23 Photographs for Facsimile, Bottom Side Sharp Corporation, Communication Systems Group

FCC ID: APYHRO00023Page:14/23 Photographs for Cordless Handset, Front Side / Back Side Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:15/23 Photographs for Cordless Handset, Front Side / Back Side Sharp Corporation, Communication Systems Group

5. Product Label Informations Sharp Facsimile, Model UX-CL220 FCC ID: APYHRO00023 AS-001-01-FC NOTE: The Product Marking shown below is to be affixed or molded to the products pursuant to the FCC Rules. FACSIMILE PRODUCT MARKING NOTE: The Product Marking shown below is to be affixed or molded or printed to the products pursuant to the FCC Rules. CORDLESS HANDSET PRODUCT MARKING

FCC ID: APYHRO00023Page:7/23 Photographs for Facsimile, Internal View Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:8/23 Photographs for Facsimile, Power Supply PWB Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:9/23 Photographs for Facsimile, TEL / LIU PWB Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:10/23 Photographs for Facsimile, Control PWB Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:11/23 Photographs for Facsimile, RF PWB Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:12/23 Photographs for Facsimile, Operation Panel PWB Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:13/23 Photographs for Facsimile, Connector PWB Sharp Corporation, Communication Systems Group

FCC ID: APYHRO00023Page:16/23 Photographs for Cordless Handset, Without Battery Cover Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:17/23 Photographs for Cordless Handset, Internal View Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:18/23 Photographs for Cordless Handset, Internal View Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:19/23 Photographs for Cordless Handset, PWB Sharp Corporation, Communication Systems Group FCC ID: APYHRO00023Page:23/23 RF Unit, PWB Sharp Corporation, Communication Systems Group

Product Description [1] General: This product is a facsimile equipment for PSTN and transmits/receives documents in the G3 mode of operation. It has a Cordless Telephone(Cordless Handset), and also has a Telephone Answering Machine function. This product is named Facsimile, Model UX-CL220, and Cordless Handset may have Model Number of UX-CL220K (suffix “K2” is optional, so may be followed by K, or no suffix.) Specification for Facsimile: No.ItemsDescription 1 Applicable Telephone Line Public Switched Telephone Network 2 Compatibility ITU-T (CCITT) G3 mode 3 Configuration Half-Duplex, Desktop Transceiver 4 Compression Scheme MH, MR, MMR 5 Recording System Thermal Transfer Recording 6 Modem Speed 14,400 bps with automatic fallback to lower speed 7 Power Requirements 120V ac, 60Hz, 100W, 1.4A 8 Operating Environment 5 to 35ºC 9 Humidity 25 – 85% RH Specification for DSSS Cordless Phone: No.ItemsDescription 1 Frequency Range 2404.8 – 2475.0MHz 2 Frequency Tolerance 1ppm 3 Number Of Channel 40CH 4 ChannelSpacing 1.8MHz 5 AccessMethod FDMA-TDD Frequency Division Multiple Access, Time Division Duplex) 6 SpreadMethod DSSS (Direct Sequence Spread Spectrum 7 ChipRate 12chips/bit 8 DataTransferRate 100kbps 9 Rate Of Base BandData 1200kbps 10 ModulationMethod DBPSK (Differential Binary Phase Shift Keyed) [2] Circuit Description: Facsimile Part 1.General Description The compact design of the control PWB is obtained by using CONEXANT fax engine in the main control section and high density printing of surface mounting parts. Each PWB is independent according to its function as shown in Fig. 1. 2.PWB Configuration AC CORD MOTOR CONTROL PWB CIS LCD PWB PANEL PWB INTERFACE PWB DSS BS PWB TEL/LIU PWB POWER SUPPLY PWB 1)Control PWB The Control PWB controls peripheral PWBs, mechanical parts, transmission, and performs overall control of the unit. This machine employs a 1-chip modem (SCE214V) which is installed on the control PWB. 2)TEL/LIU PWB This PWB controls connection of the telephone line to the unit. 3)Power Supply PWB This PWB provides voltages of Vreg(+5V) and +24V to the other PWBs. 4)Panel PWB The Panel PWB allows input of the operation keys. 5)LCD PWB This PWB controls the LCD display. 6)Interface PWB This PWB connect Control PWB with Panel PWB. 3.Operation Description Operational descriptions are given below: •Transmission Operation When a document is loaded in stand-by mode, the state of the document sensor is sensed via the 1 chip fax engine (SCE214V). With depression of the START key in the off-hook state, transmission takes place. Then, the procedure is sent out from the modem and the motor is rotated to move the document down to the scan line. In the scan processor, the signal scanned by the CIS is sent internal image processor and the AD converter to convert the analog signal into binary data. This binary data is transferred from the scan processor to the image buffer within the RAM and encoded and stored in the transmit buffer of the RAM. The data is then converted from parallel to serial form by the modem where the serial data is modulated and sent onto the line. •Receive Operation There are two ways of starting reception, manual and automatic. Depression of the START key in the off-hook mode in the case of manual receive mode, or CI signal detection by the automatic receive mode. First, the SCE214V controls the procedure signals from the modem to be ready to receive data. When the program goes into phase C, the serial data from the modem is converted to parallel form in the modem interface of the 1 chip fax engine (SCE214V) which is stored in the receive buffer of the RAM. The data in the receive buffer is decoded software-wise to it as binary image data in the image buffer. The data is DMA transferred to the recording processor within the SCE214V which is then converted from parallel to serial form to be sent to the thermal head. The data is printed line by the SCE214V which is assigned to control the motor rotation and strobe signal. •Copy Operation To make a copy on this facsimile, the COPY key is pressed when the machine is in stand-by with a document on the document table and the telephone set is in the on-hook state. First, depression of the COPY key advances the document to the scan line. Similar to the transmitting operation, the image signal from the CIS is converted to a binary signal in the DMA mode via the 1 chip fax engine (SCE214V) which is then sent to the image buffer of the RAM. Next, the data is transferred to the recording processor in the DMA mode to send the image data to the thermal head which is printed line by line. The copying takes place as the operation is repeated. •RF Block Description The communication using radio is performed TDD operation between the sets of keeping a common system ID. The system ID is stored nonvolatile memory of each set. The ID code are kinds of 224. Transmission Voice signal is inputted from microphone and headset is adjusted the level of signal and converted from analog signal to digital signal in the CODEC, and is sent to Merlin (Baseband IC). In Merlin, the inputted signal is converted ADPCM data and scrambled by XORed PN sequence. The scrambled signal is differentially encoded and spreaded. A 12chip spreading code is used to meet FCC part 15.247 requirements for a DSS(Digital Spread Spectrum) system. The spreaded signal is modulated by BPSK(Binary Phase Shift Keying) and is sent to RF109(2.4GHz Digital Spread Spectrum Transceiver). RF109 generates the Local Oscillator(LO) frequencies using a PLL(Phase Look Loop ) frequency synthesizer and external 2.4GHz VCO(Voltage Controlled Oscillator). The baseband signalfrom Merlin is mixed LO frequency. The mixed signal pass through Matching Network Circuits and is sent to RF110(RF Power Amplifier). The Amplified signal in RF110 pass through Antenna Matching Circuit and is sent to Antenna. Reception The signal from radio pass through BPF (Band Pass Filter) of 2.4GHz band width and is sent to …

Text truncated - open the document above for the full version.

7. Digital Security Code System Sharp Facsimile, Model UX-CL220 FCC ID: APYHRO00023 AS-001-01-FC

in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C for 2.4 GHZ DIRECT SEQUENCE SPREAD SPECTRUM CORDLESS PHONE MODEL: UX-CL220 FCC ID: APYHRO00023 DECEMBER 03, 2001 REPORT NO: 01U1067-1 Prepared for SHARP CORPORATION 492 MINOSHO-CHO YAMATOKORIYAMA-SHI, NARA 639-1186, JAPAN Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 01U1067-1 DATE: DECEMBER 03, 2001 FCC ID: APYHRO00023 EUT: 2.4GHZ DIRECT SEQUENCE SPREAD SPECTRUM CORDLESS PHONE Page 2 of 42 CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Dates of Tests: November 29-30, 2001 Report No: 01U1005-1 Test Sample is a: Production Unit Tx Frequency: 2404.8 – 2475MHz Rx Frequency: 2404.8 – 2475MHz Max. RF Output Power: 10.74dBm (Low Channel), 10.73dBm (Middle Channel), and 11.23dBm (High Channel), all based on Conducted Output Power Measurements FCC Classification: Unlicensed Intentional Radiator RF Exposure environment: General Population/Uncontrolled Application Type: Certification FCC Rule Part(s): § 15.247 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (released on 6/29/2001 see Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Steve Cheng EMC Engineering Manager APPLICANT: SHARP CORPORATION 492 MINOSHO-CHO YAMATOKORIYAMA-SHI, NARA 639-1186, JAPAN TRADE NAME: SHARP CORPORATION MODEL: UX-CL220 SERIAL NUMBER: N/A (PRODUCTION) FCC ID: APYHRO00023 CATEGORY: PORTABLE DSSS…
