APYHRO00026Cordless Phone System

MODEL BB-HC1 Digital Phone OPERATION MANUAL 1. Setting Up 2. Using the Cordless Handset 3. Caller ID (Requires Subscription to Service) 4. Maintenance and Troubleshooting IN U S E / CH AR GE PA GE WARNING - FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and the receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. IMPORTANT NOTICE Base FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for at uncontrolled equipment. This equipment should be installed and operated with minimum distance at least 20 cm between the radiator and persons body (excluding extremities: hands, wrists, feet and legs) and must not be co-located or operated with any other antenna or transmitter. Cordless handset For body worn operation, this phone has been tested and meets FCC RF exposure gudelines when used with an accessory that no metal and that positions the handset a minimum of 1.5 cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. As an ENERGY STA R  partner, SHARP has determined that this product meets the ENERGY STA R  guidelines for energy efficiency. 1 Introduction Cordless handset specifications As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units. Important safety information Do not disassemble this product or attempt any procedures not described in this manual. Refer all servicing to qualified service personnel. Do not install or use the equipment near water, or when you are wet. For example, do not use the equipment near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool. Take care not to spill any liquids on the equipment. Frequency2.4 GHz (2.405 to 2.475 GHz) Dimensions Width: 1.8" (46 mm) Depth: 1.7" (42 mm) Height: 7.1" (180 mm) (not including antenna) WeightApprox. 0.3 lbs. (115 g) (without battery) Battery3.6 V Ni-MH battery; capacity: 850 mAh Power consumption Initial charging Battery life Battery life in standby mode Approx. 1.0 W (in standby mode) Approx. 10 hours for initial charge Approx. 4 hours (240 minutes) (at room temp.) Approx. 3 days with one full charge (at room temperature) Battery life (both normal and in standby mode) may vary depending on usage, range from base machine, and environmental conditions such as temperature. Welcome, and thank you for choosing a SHARP HZT2202B cordless handset! The HZT2202B allows you to make both analog and digital phone calls 2 Unplug the base from the power outlet and telephone jack and consult a qualified service representative if any of the following situations occur: - Liquid has been spilled into the base or the base has been exposed to rain or water. - The base produces odors, smoke, or unusual noises. - The power cord is frayed or damaged. - The base has been dropped or the housing damaged. Do not allow anything to rest on the power cord, and do not install the base where people may walk on the power cord. This base must only be connected to a 120 V, 60 Hz outlet. Connecting it to any other kind of outlet will damage the base and invalidate the warranty. Never insert objects of any kind into slots or openings on the equipment. This could create a risk of fire or electric shock. If an object falls into the equipment that you cannot remove, unplug the base and consult a qualified service representative. Never install telephone wiring during a lightning storm. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. Never touch bare telephone wires or terminals unless the telephone line has been disconnected at the network interface. Use caution when installing or modifying telephone lines. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. Do not use a telephone to report a gas leak in the vicinity of the leak. Battery Use only the battery specified in this manual. Use only the provided charger to charge the battery. Do not open or mutilate the battery pack. Corrosive fluid may leak out and cause injury or burns to the eyes and skin. The fluid may be toxic if swallowed. In case of contact with eyes, flush with clean water (do not rub), and seek medical attention immediately. Do not store or carry the battery with other metal objects such as keys or pins. These may short the battery and cause it to overheat. Do not allow the battery to become wet. Do not dispose of the battery in a fire or heat the battery. The battery may explode. Health care facilities and equip…

Text truncated - open the document above for the full version.

MODEL BB-HC1 Digital Phone OPERATION MANUAL 1. Setting Up 2. Using the Cordless Handset 3. Caller ID (Requires Subscription to Service) 4. Maintenance and Troubleshooting IN U S E / CH AR GE PA GE WARNING - FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and the receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. IMPORTANT NOTICE Base FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for at uncontrolled equipment. This equipment should be installed and operated with minimum distance at least 20 cm between the radiator and persons body (excluding extremities: hands, wrists, feet and legs) and must not be co-located or operated with any other antenna or transmitter. Cordless phone For body worn operation, this phone has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the handset a minimum of 1.5 cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. 1 Introduction Cordless phone specifications Frequency2.4 GHz (2.405 to 2.475 GHz) Dimensions Width: 1.8" (46 mm) Depth: 1.7" (42 mm) Height: 7.1" (180 mm) (not including antenna) WeightApprox. 0.3 lbs. (115 g) (without battery) Battery3.6 V Ni-MH battery; capacity: 850 mAh Power consumption Initial charging Battery life Battery life in standby mode Approx. 35 mW (when not in base) Approx. 10 hours for initial charge Approx. 4 hours (240 minutes) (at room temp.) Approx. 3 days with one full charge (at room temperature) Battery life (both normal and in standby mode) may vary depending on usage, range from base and environmental conditions such as temperature. Welcome, and thank you for choosing a SHARP BB-HC1 cordless phone! The BB-HC1 allows you to make both analog and digital phone calls. Important: To use the BB-HC1 to make digital phone calls, you must subscribe to a digital phone service from your Internet service provider. 2 Base specifications As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be some deviations from these values in individual units. Important safety information Do not disassemble this product or attempt any procedures not described in this manual. Refer all servicing to qualified service personnel. Do not install or use the equipment near water, or when you are wet. For example, do not use the equipment near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement, or near a swimming pool. Take care not to spill any liquids on the equipment. Unplug the base from the power outlet and telephone jack and consult a qualified service representative if any of the following situations occur: - Liquid has been spilled into the base or the base has been exposed to rain or water. - The base produces odors, smoke, or unusual noises. - The power cord is frayed or damaged. - The base has been dropped or the housing damaged. Do not allow anything to rest on the power cord, and do not install the base where people may walk on the power cord. The base must only be connected to a 120 V, 60 Hz outlet using the provided AC adapter. Connecting it to any other kind of outlet through any other adapter will damage the base and invalidate the warranty. Never insert objects of any kind into slots or openings on the equipment. This could create a risk of fire or electric shock. If an object falls into the equipment that you cannot remove, unplug the base and consult a qualified service representative. Dimensions Width: 5.3" (134 mm) Depth: 5.3" (135 mm) Height: 2.4" (60 mm) (not including antenna) WeightApprox. 0.6 lbs. (270 g) (not including AC adapter) Power supply120 V, 60 Hz (only the provided AC adapter can be used) Power consumption Charging: 6.7 W Standby: 4.3 W In use: 4.8 W Maximum: 6.7 W 3 Never install telephone wiring during a lightning storm. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. Never touch bare telephone wires or terminals unless the telephone line has been disconnected at the network interface. Use caution when installing or modifying telephone lines. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be a remote risk of electric shock from lightning. Do not use a telephone to report a gas leak in the vicinity of the leak. Battery Use only the battery specified in this manual. Use only the provided base unit to charge the battery. Do not open or mutilate the battery pack. Corrosive fluid may leak out and cause injury or burns to the eyes and skin. The fluid may be toxic if swallowed. In case of co…

Text truncated - open the document above for the full version.

FCC ID: APYHRO00026Page:2/16 Photographs for BB-HC1, Front Side Sharp Corporation, Communication Systems Group FCC ID: APYHRO00026Page:3/16 Photographs for BB-HC1 , Left Side Sharp Corporation, Communication Systems Group FCC ID: APYHRO00026Page:4/16 Photographs for BB-HC1, Right Side Sharp Corporation, Communication Systems Group FCC ID: APYHRO00026Page:5/16 Photographs for BB-HC1, Rear Side Sharp Corporation, Communication Systems Group FCC ID: APYHRO00026Page:6/16 Photographs for BB-HC1, Bottom Side Sharp Corporation, Communication Systems Group

FCC ID: APYHRO00026Page:1/16 Photographs for Complete Set Sharp Corporation, Communication Systems Group AC Adapter Digital Phone Model BB-HC1 Digital Phone Handset Model BB-HC1 (May have suffix K) FCC ID: APYHRO00026Page:10/16 Photographs for Cordless Handset BB-HC1K, Front Side / Back Side Sharp Corporation, Communication Systems Group FCC ID: APYHRO00026Page:11/16 Photographs for Cordless Handset BB-HC1K, Front Side / Back Side Sharp Corporation, Communication Systems Group FCC ID: APYHRO00026Page:12/16 Photographs for Cordless Handset BB-HC1K, Without Battery Cover Sharp Corporation, Communication Systems Group

NOTE: The Product Marking shown below is to be affixed or molded to the products pursuant to the FCC Rules. or or BB-HC1 PRODUCT MARKING NOTE: The Product Marking shown below is to be affixed or molded or printed to the products pursuant to the FCC Rules. CORDLESS HANDSET PRODUCT MARKING

FCC ID: APYHRO00026Page:7/16 Photographs for BB-HC1, Internal View Sharp Corporation, Communication Systems Group FCC ID: APYHRO00026Page:8/16 Photographs for BB-HC1, MAIN PWB Sharp Corporation, Communication Systems Group FCC ID: APYHRO00026Page:9/16 Photographs for BB-HC1, PNA PWB Sharp Corporation, Communication Systems Group

Product Description [1] General: This product is a telephone equipment for PSTN and VoHPNA LAN. This product is named Cordless Telephone, Model BB-HC1. Specification for DSSS Cordless Phone: No.ItemsDescription 1 Frequency Range 2404.8 – 2475.0MHz 2 Frequency Tolerance 1ppm 3 Number Of Channel 40ch 4 ChannelSpacing 1.8MHz 5 AccessMethod FDMA-TDD Frequency Division Multiple Access, Time Division Duplex) 6 SpreadMethod DSSS (Direct Sequence Spread Spectrum 7 ChipRate 12chips/bit 8 DataTransferRate 100kbps 9 Rate Of Base BandData 1200kbps 10 ModulationMethod DBPSK (Differential Binary Phase Shift Keyed) [2] Circuit Description: 1.General Description The compact design of the Main PWB is obtained by using CONEXANT DSSS ASIC in the main control section and high density printing of surface mounting parts. The compact design of the HPNA PWB is obtained by using AGERE HPNA ASIC and high density printing of surface mounting parts. 2.PWB Configuration 1)MAIN PWB The Main PWB has TEL/LIU circuit, Power Supply circuit and DSSS Cordless system circuit. TEL/LIU circuit controls connection of the telephone line to the unit. Power Supply circuit provides voltages of +3.3V and +6V to the other circuits. This PWB controls HPNA PWB. 2)HPNA PWB This PWB controls connection of the VoHPNA LAN to the unit. 3) Power Supply ( AC adapter ) This adapter provides voltages of +9V/500mA to the MAIN PWB. MAIN PWB HPNA PWB POWER SUPPLY (AC adapter) 3.Operation Description Operational descriptions are given below: •RF Block Description The communication using radio is performed TDD operation between the sets of keeping a commonsystem ID. The system ID is stored nonvolatile memory of each set. The ID code are kinds of 224. Transmission Voice signal is inputted from microphone and headset is adjusted the level of signal and converted from analog signal to digital signal in the CODEC, and is sent to Merlin (Baseband IC). In Merlin, the inputted signal is converted ADPCM data and scrambled by XORed PN sequence. The scrambled signal is differentially encoded and spreaded. A 12chip spreading code is used to meet FCC part 15.247 requirements for a DSS(Digital Spread Spectrum) system. The spreaded signal is modulated by BPSK(Binary Phase Shift Keying) and is sent to RF109(2.4GHz Digital Spread Spectrum Transceiver). RF109 generates the Local Oscillator(LO) frequencies using a PLL(Phase Lock Loop ) frequency synthesizer and external 2.4GHz VCO(Voltage Controlled Oscillator). The baseband signalfrom Merlin is mixed LO frequency. The mixed signal pass through Matching Network Circuits and is sent to RF110(RF Power Amplifier). The Amplified signal in RF110 pass through Antenna Matching Circuit and is sent to Antenna. Reception The signal from radio pass through BPF (Band Pass Filter) of 2.4GHz band width and is sent to RF109. RF109 adjust the level of signal in LNALow Noise Amplifer) and downconverted to Baseband I/Q signals. Baseband I/Q signals is sent to the Merlin and despread, demodulated and descrambled to ADPCM data. The ADPCM data is converted analog signal in CODEC. Channel NumberChannel Center Frequency (MHz) Channel NumberChannel Center Frequency (MHz) 12404.8212440.8 22406.6222442.6 32408.4232444.4 42410.2242446.2 52412.0252448.0 62413.8262449.8 72415.6272451.6 82417.4282453.4 92419.2292455.2 102421.0302457.0 112422.8312458.8 122424.6322460.6 132426.4332462.4 142428.2342464.2 152430.0352466.0 162431.8362467.8 172433.6372469.6 182435.4382471.4 192437.2392473.2 202439.0402475.0

Applicant: SHARP Corporation Type of Equipment: Cordless Telephone Equipment Model No.: BB-HC1 FCC ID: APYHRO00026 FCC Radiation Exposure Statement: Sharp Corporation Cordless Telephone Equipment (BB-HC1) complies with FCC radiation exposure requirement specified in the FCC Rules 15.247(b)(4). Notice in Installation Manual FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for at uncontrolled equipment. This equipment should be installed and operated with minimum distance at least 20cm between the radiator and persons body (excluding extremities: hands, wrists, feet and legs) and must not be co-located or operated with any other antenna or transmitter. RF Exposure Calculations: The following information provides the minimum separation distance for the highest gain antenna provided with the “Cordless Telephone Equipment (BB-HC1)” as calculated from FCC OET Bulletin 65 Appendix B, Table (B) Limits for General Population / Uncontrolled Exposure. This calculation is based on the highest EIRP possible from the system, considering maximum power and antenna gain, and considering a 1.0m W/cm 2 uncontrolled exposure limit. The Fires formula used was: S = (P * G) / (4* * r 2 ) or r = (P * G) / (4 * * S) Where S = 1.00 mW/cm 2 for 2400 MHz P = 31.00 mW (Maximum peak output power(Conducted) G = 1.10 (antenna gain : Converted absolute value) r = Minimum safe distance from antenna (cm) For: Cordless Telephone Equipment (BB-HC1)r =1.65 cm A-PEX International Co., Ltd. YOKOWA LAB. 108 Yokowa-cho, Ise-shi, Mie-ken 516-1106 JAPAN Telephone: int +81 596 39 1485 Facsimile: int +81 596 39 0232Page 1 RF Exposure Statement No. : 22HE0078-YW

(Duplicated) in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C for 2.4 GHZ DIRECT SEQUENCE SPREAD SPECTRUM CORDLESS PHONE MODEL: BB-HC1 FCC ID: APYHRO00026 ( Identical Device with FCC ID:APYHRO00025) MARCH 27, 2002 REPORT NO: 02U1238-1 Prepared for SHARP CORPORATION 429 MINOSHO-CHO YAMATOKORIYAMA-SHI, NARA 639-1186, JAPAN Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 02U1238-1 DATE: March 27, 2002 FCC ID: APYHRO00026 COMPLIANCE CERTIFICATION SERVICES Page: 2 of 27 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) Dates of Tests: March 27, 2002 Report No: 02U1238-1 APPLICANT: SHARP CORPORATION 429 MINOSHO-CHO YAMATOKORIYAMA-SHI, NARA 639-1186, JAPAN TRADE NAME: SHARP CORPORATION MODEL: BB-HC1 FCC ID: APYHRO00026 DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Operating Mode: Maximum continuous output Tx Frequency: 2404.8 - 2475 MHz Rx Frequency: 2404.8 - 2475 MHz Max. RF Output Power (Conducted): 13.0 dBm (2404.8 MHz) Max. SAR (1g): 0.164 mW/g (2439 MHz, Tilt position) Application Type: Stub type FCC Rule Part(s): § 15.247 This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (released on 6/29/2001 see Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Steve Cheng EMC Engineering Manager REPORT NO: 02U1238-1 DATE: March 27, 2002 FCC ID: APYHRO00026 COMPLIANCE CERTIFICATION SERVICES Page: 3 of 27 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. EUT DESCRIPTION................................................................................................................4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC........................5 3. DOSIMETRIC ASSESSMENT SETUP...................................................................................5 3.1. MEASUREMENT SYSTEM DIAGRAM....................................................................................................................6 3.2. SYSTEM COMPONENTS...........................................................................................................................................7 3.3. EUT ARRANGEMENT...............................................................................................................................................11 3.4. MEASUREMENT UNCERTAINTY..........................................................................................................................16 4. EUT TUNE-UP PROCEDURE..............................................................................................16 5. EVALUATION PROCEDURE...............................................................................................17 5.1. SIMULATED TISSUE LIQUID PARAMETER CONFIRMATION........................................................................18 5.2. SYSTEM VALIDATION DATA..................................................................................................................................19 5.3. SAR EVALUATION PROCEDURE.........................................................................................................................20 5.4. EXPOSURE LIMIT.....................................................................................................................................................20 5.5. DEVIATION FROM OET 65 SUPPLEMENTAL C (6/29/2001)...........................................................................21 6. MEASUREMENT RESULTS................................................................................................22 7. EUT PHOTOS........................................................................................................................23 8. REFERENCES......................................................................................................................26 9. ATTACHMANTS...................................................................................................................27 REPORT NO: 02U1238-1 DATE: March 27, 2002 FCC ID: APYHRO00026 COMPLIANCE CERTIFICATION SERVICES Page: 4 of 27 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. EUT DESCRIPTION APPLICANT: SHARP CORPORATION 429 MINOSHO-CHO YAMATOKORIYAMA-SHI, NARA 639-1186, JAPAN TRADE NAME: SHARP CORPORATION MODEL: BB-HC1 FCC ID: APYHRO00026 DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Operating Mode: Maximum continuous output Tx Frequency: 2404.8 - 2475 MHz Rx Frequency: 2404.8 - 2475 MHz Max. RF Output Power (Conducted): 13.0 dBm (2404.8 MHz) Max. SAR (1g): 0.164 mW/g (2439 MHz, Tilt position) Application Type: Stub type FCC Rule Part(s): § 15.247 Antenna Dimensions: Length = 17 mm; Diamet…

Text truncated - open the document above for the full version.

System Validation - D1800V2 S/N: 294 Iuput power: 250 mW SAM; Flat Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); Crest factor: 1.0; Head 1800 MHz: σ = 1.40 mho/m ε r = 39.2 ρ = 1.00 g/cm 3 Cube 5x5x7: Peak: 17.0 mW/g, SAR (1g): 9.27 mW/g, SAR (10g): 4.89 mW/g, (Worst-case extrapolation) Penetration depth: 8.4 (8.0, 9.3) [mm] Powerdrift: 0.00 dB SAR Tot [mW/g] 9.86E-1 2.96E+0 4.93E+0 6.90E+0 8.87E+0 03/27/02 COMPLIANCE CERTIFICATION SERVICES System Validation - D1800V2 S/N: 294 Iuput power: 250 mW SAM; Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); Crest factor: 1.0; Head 1800 MHz: σ = 1.40 mho/m ε r = 39.2 ρ = 1.00 g/cm 3 : , , () Penetration depth: 8.4 (7.9, 9.2) [mm] 03/27/02 COMPLIANCE CERTIFICATION SERVICES 0 2 4 6 8 10 12 14 16 18 010203040506070 SAR tot [mW/g] [mm]

Sharp BB-HC1 (Middle channel - Tilt position) Frequency: 2450 MHz; Crest factor: 2.0 Medium: Head 2450MHz: σ = 1.87 mho/m ε r = 39.5 ρ = 1.00 g/cm 3 SAM Phantom; Left Hand Section; Position: (80°,60°) Probe: ET3DV6 - SN1578; ConvF(4.50,4.50,4.50); SAR:Cube 5x5x7: Peak: 0.237 mW/g, SAR (1g): 0.124 mW/g, SAR (10g): 0.0646 mW/g, (Worst-case extrapolation) Penetration depth: 7.7 (7.2, 8.8) [mm]; Powerdrift: -0.05 dB Coarse: Dx = 14.0, Dy = 14.0, Dz = 10.0 SAR Tot [mW/g] 1.33E-2 3.99E-2 6.65E-2 9.31E-2 1.20E-1 03/27/02 FCC ID:APYHRO00026 COMPLIANCE CERTIFICATION SERVICES Sharp BB-HC1 (High channel - Touch position) Frequency: 2450 MHz; Crest factor: 2.0 Medium: Head 2450MHz: σ = 1.87 mho/m ε r = 39.5 ρ = 1.00 g/cm 3 SAM Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(4.50,4.50,4.50); SAR:: , , () Penetration depth: 8.0 (7.9, 8.2) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 03/27/02 FCC ID:APYHRO00026 COMPLIANCE CERTIFICATION SERVICES -0.02 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0.16 0.18 102030405060708090 SAR tot [mW/g] [mm] Sharp BB-HC1 (High channel - Touch position) Frequency: 2450 MHz; Crest factor: 2.0 Medium: Head 2450MHz: σ = 1.87 mho/m ε r = 39.5 ρ = 1.00 g/cm 3 SAM Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(4.50,4.50,4.50); SAR:: , , () Penetration depth: 8.0 (7.9, 8.2) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 03/27/02 FCC ID:APYHRO00026 COMPLIANCE CERTIFICATION SERVICES -0.02 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0.16 0.18 102030405060708090 SAR tot [mW/g] [mm] Sharp BB-HC1 (Middle channel - Tilt position) Frequency: 2450 MHz; Crest factor: 2.0 Medium: Head 2450MHz: σ = 1.87 mho/m ε r = 39.5 ρ = 1.00 g/cm 3 SAM Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(4.50,4.50,4.50); SAR:: , , () Penetration depth: 7.5 (7.2, 8.0) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 03/27/02 FCC ID:APYHRO00026 COMPLIANCE CERTIFICATION SERVICES -0.05 0.00 0.05 0.10 0.15 0.20 0.25 102030405060708090 SAR tot [mW/g] [mm] Sharp BB-HC1 (High channel - Touch position) Frequency: 2450 MHz; Crest factor: 2.0 Medium: Head 2450MHz: σ = 1.87 mho/m ε r = 39.5 ρ = 1.00 g/cm 3 SAM Phantom; Righ Hand Section; Position: (80°,300°) Probe: ET3DV6 - SN1578; ConvF(4.50,4.50,4.50); SAR:Cube 5x5x7: Peak: 0.234 mW/g, SAR (1g): 0.115 mW/g, SAR (10g): 0.0585 mW/g, (Worst-case extrapolation) Penetration depth: 7.0 (6.8, 7.3) [mm]; Powerdrift: -0.14 dB Coarse: Dx = 14.0, Dy = 14.0, Dz = 10.0 SAR Tot [mW/g] 1.25E-2 3.75E-2 6.25E-2 8.75E-2 1.13E-1 03/27/02 FCC ID:APYHRO00026 COMPLIANCE CERTIFICATION SERVICES Sharp BB-HC1 (High channel - Touch position) Frequency: 2450 MHz; Crest factor: 2.0 Medium: Head 2450MHz: σ = 1.87 mho/m ε r = 39.5 ρ = 1.00 g/cm 3 SAM Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(4.50,4.50,4.50); SAR:: , , () Penetration depth: 6.5 (6.3, 7.1) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 03/27/02 FCC ID:APYHRO00026 COMPLIANCE CERTIFICATION SERVICES -0.05 0.00 0.05 0.10 0.15 0.20 0.25 102030405060708090100110 SAR tot [mW/g] [mm] Sharp BB-HC1 (Middle channel - Tilt position) Frequency: 2450 MHz; Crest factor: 2.0 Medium: Head 2450MHz: σ = 1.87 mho/m ε r = 39.5 ρ = 1.00 g/cm 3 SAM Phantom; Righ Hand Section; Position: (80°,300°) Probe: ET3DV6 - SN1578; ConvF(4.50,4.50,4.50); SAR:Cube 5x5x7: Peak: 0.322 mW/g, SAR (1g): 0.164 mW/g, SAR (10g): 0.0811 mW/g, (Worst-case extrapolation) Penetration depth: 7.1 (6.8, 7.8) [mm]; Powerdrift: -0.10 dB Coarse: Dx = 14.0, Dy = 14.0, Dz = 10.0 SAR Tot [mW/g] 1.81E-2 5.43E-2 9.05E-2 1.27E-1 1.63E-1 03/27/02 FCC ID:APYHRO00026 COMPLIANCE CERTIFICATION SERVICES Sharp BB-HC1 (Middle channel - Tilt position) Frequency: 2450 MHz; Crest factor: 2.0 Medium: Head 2450MHz: σ = 1.87 mho/m ε r = 39.5 ρ = 1.00 g/cm 3 SAM Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(4.50,4.50,4.50); SAR:: , , () Penetration depth: 7.1 (6.8, 7.7) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 03/27/02 FCC ID:APYHRO00026 COMPLIANCE CERTIFICATION SERVICES -0.1 0.0 0.1 0.2 0.3 0.4 102030405060708090100110 SAR tot [mW/g] [mm] Sharp BB-HC1 (High Channel - Body) Frequency: 2450 MHz; Crest factor: 2.0 Medium: Muscle 2450 MHz: σ = 2.01 mho/m ε r = 53.2 ρ = 1.00 g/cm 3 SAM Phantom; Flat Section; Position: (270°,90°…

Text truncated - open the document above for the full version.
