APYHRO00027GSM/GPRS Cellular Phone Transceiver

1 Introd uction Introduc tion Co ngratulati ons a nd tha nk y ou for choosing t he G S - 200 . About This Us er Guide This user guide is carefully designed to help you l earn abo ut your phone’s featu res and operatio ns q uickly and effect ively. NO TICE • We strongly recom mend that you keep separate permanent written records of all important data. Data may be lost or alte red in vi rtually any elect ronic memo ry product under certain ci rcumstances. Therefor e, we assume no responsibility for d ata lost or othe rwise rende red unusable, wh ether as a result of improper use, repairs, defects, battery r eplacement, use a fter the s peci fied batte ry life has expi red or any other cause. • We as sume no responsibility, direc tly or indirectly, for financial losses or claims from third parties resulting from the use of this product and any of its functions, such as stol en credit ca rd numbers, the loss or alte ration of stored data, etc. • All company and/or product names are tradema rks and/or registe red tradema rks of the ir respe ctive hol ders. For Yo ur Recor ds Introduction 2 • Screen layout illustrated in this user guide may differ from the actual one.The information described in this user guide is subject to change without notice. • All the functions described in this user guide may not be supported in all networks. • We assume no responsibility for downloaded contents, information, etc. from network. CopyrightAccording to copyright laws, the reproduction, alteration and use of material which is protected by copyright (music, pictures, etc.) is only permitted for personal or private use. If the user is not in possession of more extensive copyright or has not received the explicit permission from the copyright owner to reproduce, alter or use a copy which has been made or modified in this way, this is considered to be a violation of the copyright laws and gives the copyright owner the right to claim for damages. For this reason, avoid the illegal use of material which is protected by copyright.Windows is a registered trademark of Microsoft Corporation in the United States and/or other countries. Lice nsed by I nter Di gital Technology Corporation und er one or more of the following United States Patents and/or their domestic or foreign counterparts and other patents pend-ing, including U.S. Patents: 4,675,863: 4,779,262: 4,785,450 & 4,811,420. 3 Introduction Useful functions and services of the phoneYour phone offers you the following features:• The built-in digital camera can take pictures.• Create and read SMS.• Multimedia Messaging Service (MMS) can personalise your phone in various ways: you can send and receive multimedia messages with graphical images, photographs or sound attached. • WAP browser helps you to access a variety of information on the mobile internet. • The maindisplay of colour TFT-LCD makes the screens clearer, more beautiful and easier to view. • Sub-Screen allowing you to see who is calling and new message indicators. • You can create the various melodies for your original ringing tones using up to 16 chords. • Voice memo function allows you to record and play back your vocal message. Licensed under U.S. Patent 4,558,302 and foreign counter-parts.T9 Text Input is covered by the United Kingdom Pat. No.2238414B, Euro. Pat. No. 0 842 463 (96927260.8) and other patents pending. Table of Contents 4 Table of ContentsIntroduction ................................................. 1 Useful functions and services of the phone ..3 Table of Contents ........................................ 4Your Phone .................................................. 7 Accessories....................................................7 Getting Started ............................................ 8 Inserting the SIM Card and the Battery .....10Charging the Battery ..................................13Turning Your Phone On and Off ...............15Display Indicators ......................................15Sub-Screen .................................................17 Call Functions ........................................... 19 Making a Call .............................................19Speed Dialling ............................................19Redialling ...................................................20Ending a Call ..............................................20Answering a Call ........................................20Incall Menus ...............................................21 Phonebook ................................................. 24 Entering Characters ....................................24Creating a New Entry .................................25 Finding a Name and Number .................... 28Editing Phonebook Entries ........................ 28Deleting Phonebook Entries ...................... 29Checking Your Own Numbers .................. 29View Groups .............................................. 29Memory Status ........................................... 30Speed Dial List .......................................... 30Sending Messages ..................................... 31 Using the Menu .......................................... 32 List of Menu Functions ............................. 33 Camera ...................................................... 34 Using the Timer ......................................... 36Sending Pictures ........................................ 37Deleting Pictures ....................................... 37 My Phone .................................................... 38 Image Gallery ........................................... 40 Sou nd Gallery . . ......................................... 43 Text Templates .................... ...... ................ 46 5 Table of Contents Memory Status ........................................... 47 Fun & Games ............................................. 48 Ga mes .......................... .......... ...................51 Melody Editor ........................................... 52Tone Editor ...........…

Text truncated - open the document above for the full version.

From: Shigeru Kinoshita To: Mike Kuo Cc: ?? ??; ?? ??; ?? ? Subject: Re: Sharp Corporation, FCC ID:APYHRO00027, AN03T2524 Dear Mr.Mike Kuo Thank you for good advice and your suggetions. Please confirmed the three Attaced files. 1.KL80020490S.pdf:Revised Test Report of part24 2.AntennaConductedPlot.pdf: Harmonics frequency plot in Antenna Conducted Emission 3.Additional Report.pdf: Spurious frequency plot in Antenna Conducted Emission Question #6: Please confirm page 5 of 46 Question #7: Please confirm page 30 of 46 Add items : Spectrum Anlyzer Setting RBW, VBW etc Question #9: Please confirm AntennaConductedPlot.pdf & Additional Report.pdf Best Regards Shigeru Kinoshita ----- Original Message ----- From: "Mike Kuo" <[email protected]> To: "'Shigeru Kinoshita'" Subject: RE: Sharp Corporation, FCC ID:APYHRO00027, AN03T2524 > Hi Shigeru: > > Question #6 : if the power was measured with power meter, please change the > revised test report to indicate the power was measured with power meter. ( > In the revised test report, it indicated the spectrum analyzer was used.) > > Best Regards > > Mike Kuo > > -----Original Message----- > From: Shigeru Kinoshita > To: Mike Kuo > Subject: Re: Sharp Corporation, FCC ID:APYHRO00027, AN03T2524 > > > Dear Mike Kuo > Thr JQA ansewrs for Question #6,#7,#9.of Part24 Test Report. > > > Question #6: Transmitting Power ( TP ):Page Page 5 of 46 of Part 24 test > > report. The description indicates that spectrum analyzer was used but the > > diagram indicates the power meter. Please explain. > > > > CCS : Received revised test report. Per the test report, Transmitting > power > > was measured with Spectrum Analyzer. Please provide spectrum plots with > > instrument setting indicated. > > > JQA: In the JQA, The transmitter Power is measurd with a power Meter, not > used the Spectrum Analyzer. > > > > Question #7: Transmitting Power ( EIRP ) : Page 30 of 46. Please provide > > the correction factor used to calculate the EIRP. Please indicate the > > spectrum analyzer reading, SG reading, the antenna gain and cable lost. > > Please also provide the instrument setting of spectrum analyzer used > during > > the tests. > > > > CCS: Per revised test report, all information have been included except > for > > the instrument setting. Please provide RBW and VBW used during EIRP > > measurement. > > > JQA : > Please refer to the attached file 'Description of EIRP.pdf', revised > paper(draft) of Page30. > > > > Question #9: Please provide antenna conducted spurious emission plots. > > > > CCS : No spectrum plots are included in the revised test report, please > > provide the plots. > > > JQA: The antenna conducted spurious emisiion test is re-testing now. > > Best Regards > > JAPAN QUALITY ASSURANCE ORGANIZATION(JQA) > KITA-KANSAI TESTING CENTER > TESTING DEPT. EMC DIV. > Shigeru Kinoshita > e-mail: [email protected] > ----- Original Message ----- > From: "Mike Kuo" <[email protected]> > To: "'Y.Uchida'" > Subject: FW: Sharp Corporation, FCC ID:APYHRO00027, AN03T2524 > > > > Hi Mr. Uchida: > > > > Please only address question #6, #7, and #9. All other replies to rest of > > questions are O.K. > > > > Best Regards > > > > Mike Kuo > > > > -----Original Message----- > > From: CERTADM > > Sent: Friday, January 17, 2003 4:04 PM > > To: '[email protected]' > > Subject: Sharp Corporation, FCC ID:APYHRO00027, AN03T2524 > > > > > > Notice_content > > ------------- > > This notice is to recap the previous questions asked and the replies you > > have provided so far: > > > > Administrative review portion: > > > > Question #1: Please provide EUT's Internal and External photos. > > > > CCS: Files received. No more question on this item. > > > > Question #2: Please provide EUT's Tune up procedure. Tune up procedure > > normally is confidential document to the manufacturer. If tune up > procedure > > is considered as confidential document, please also modify the request for > > confidentiality letter to include this document. > > > > CCS: Files received. Since there is no revised confidentiality letter > > provided, tune up procedure will not be granted as confidential document. > > > > Question #3: Please provide theory of operation to address the > requirements > > listed in section 2.1033( c ) (6)(8)(10)(13) of FCC rules. Theory of > > operation is normally considered as confidential document to the > > manufacturer. If request for confidential is desired, please modify > request > > for confidentiality letter to include this document. > > > > CCS : File received. Since there is no revised confidentiality letter > > provided, theory of operation will not be granted as confidential > document. > > > > Question #4: User Manual file titled ' GS-200-Safety ". In this 7 pages > > user manual, it mentioned RF Exposure wa rning statement. However, > > there is no place mentioned the body worn instruction to the end user. > > Please provide it. In addition, the Exposure to Radio Wave section, it > > listed some general guideline to the end user but with some blank > > information. If measured SAR value is not desired to list in the user > > manual, please modify this section. ( FCC does not require the > manufacturer > > to list the highest measured head and body worn SAR value in the user > manual > > ). > > > > CCS: Files received. No more question on this item. > > > > Question #5: FCC Part 24 report has security protection. Please provide > test > > setup photo file. > > > > CCS: File received. No more question on this item. > > > > FCC Part 24 technical portion: > > > > > > Question #6: Transmitting Power ( TP ):Page Page 5 of 46 of Part 24 test > > report. The description indicates that spectrum analyzer was used but the > > diagram indicates the power meter. Please explain. > > > > CCS : Received revised test report. Per the test report, Transmitting > power > > was measured with Spectrum Analyzer. Please provide spectrum plots with > > instrument setting indicated. > > > > Question #7:…

Text truncated - open the document above for the full version.

CONFIDENTIAL CONFIDENTIAL

CONFIDENTIAL CONFIDENTIAL

Model Description Model Name : GS-200 Type of Emission : 300KGXW Brand Name : T-Mobile by SHARP Type of Equipment : Tri-Band (GSM/DCS/PCS) cellular Phone Specification Frequency Band Tri Band GSM900/DCS1800/PCS1900 900MHz: Tx880.2 to 914.8MHz Rx925.2 to 959.8MHz 1800MHz: Tx1710.2 to 1784.8MHz Rx1805.2 to 1879.8MHz 1900MHz: Tx1851.25 – 1908.75MHz Rx1930.2 to 1989.8MHz (900/1800 Band do not operate in USA) Tx Power900MHz 33dBm2dB 1800MHz 30dBm±2dB 1900MHz 30dBm±2dB Avera ge Power = Tx Power / 8 Type of ModulationGXW Transmission TechnologyTDMA (8 slot) Voice CodecEFR/ FR/ HR GPRSClass B, Multislot Class 8 AntennaIntegarated Antenna SIMPlug-in 3V SIM card slot SIM application toolkit release 99, class 3 Display Main LCD65,536color TFT, 120(w) x 160(H) with Backlight Sub LCDMonochrome FSTN, 96(w) x 26(H) with Backlight Status LEDUsing 2-colour LED module (Green and Red) CameraIntegrated CMOS Resolution110K pixcel WAP BrowserWAP ver. 1.2.1 Battery/ Talktime Capacity720mAh Battery typeRechargable Lithium Ion Battery Target standby timeTBD Target talk timeTBD Dimensions Target size94(H) x 49(W) x 26(D)mm Target weight107g Target volume(P)cc Key LayoutSoft key 1, Soft key 2, Navigationkey, Menu key, 0 - 9 numeric key, Send/ End key, *, # and 2 side keys. IrDA Ver 1.2 Head set jack PDC shared connector SIM card terminal Integrated charger circuit Head set AC Charger Input AC 110 to 230V Output DC 5.2V Battery DC3.7V 720mAh Items Accessory MAIN SPECIFICATION IrDA External I/F

in accordance with the requirements of FCC Report and Order: ET Docket 93-62, and OET Bulletin 65 Supplement C for Tri-Bands (GSM/DCS/PCS) Cellular Phone MODEL: GS-200 FCC ID: APYHRO00027 November 27, 2002 REPORT NO: 02I1666-1 Prepared for Sharp Corporation 2-13-1, Iida Hachihonmatsu Higashihiroshima-City Hiroshima, 739-0192 Japan Prepared by COMPLIANCE CERTIFICATION SERVICES 561F MONTEREY ROAD, MORGAN HILL, CA 95037, USA TEL: (408) 463-0885 REPORT NO: 02I1666-1 DATE: November 27, 2002 FCC ID: APYHRO00027 COMPLIANCE CERTIFICATION SERVICES Page: 2 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. CERTIFICATE OF COMPLIANCE (SAR EVALUATION) DATES OF TEST: November 26-27, 2002 REPORT NO: 02I1666-1 APPLICANT: Sharp Corporation 2-13-1, Iida Hachihonmatsu Higashihiroshima-City, Hiroshima 739-0192 Japan MODEL: GS-200 FCC ID: APYHRO00027 DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Modulation type: GSM+GPRS Operating Mode: Maximum continuous output Tx Frequency: 1850.2 ~ 1909.8 MHz Max.O/P Power: 29.58 dBm (1880.0 MHz) Max. SAR (1g): 0.931 W/Kg (at 1850.2 MHz; Left head, touch position) 0.251 W/Kg (at 1850.2 MHz; Body-worn position) Application Type: Certification FCC Rule Part(s): 24 (E) Note: This device contains 900MHz and 1800GSM functions not operational in US territories. This report is only applicable for 1900MHz PCS band. This wireless portable device has been shown to be capable of compliance for localized specific absorption rate (SAR) for uncontrolled environment/general population exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in FCC OET 65 Supplement C (released on 6/29/2001 see Test Report). I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. Steve Cheng EMC Engineering Manager REPORT NO: 02I1666-1 DATE: November 27, 2002 FCC ID: APYHRO00027 COMPLIANCE CERTIFICATION SERVICES Page: 3 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. TABLE OF CONTENT 1. EUT DESCRIPTION..............................................................................................4 2. REQUIREMENTS FOR COMPLIANCE TESTING DEFINED BY THE FCC.....................5 3. DOSIMETRIC ASSESSMENT SETUP.....................................................................5 3.1. MEASUREMENT SYSTEM DIAGRAM..............................................................................................................6 3.2. SYSTEM COMPONENTS..................................................................................................................................7 4. EVALUATION PROCEDURE.................................................................................9 5. MEASUREMENT UNCERTAINTY.........................................................................12 6. EXPOSURE LIMIT..............................................................................................13 7. EUT ARRANGEMENT........................................................................................14 8. MEASUREMENT RESULTS................................................................................15 8.1. SYSTEM VALIDATION.....................................................................................................................................15 8.2. TEST LIQUID CONFIRMATION.......................................................................................................................16 8.3. EUT TUNE-UP PROCEDURE..........................................................................................................................17 8.4. EUT SETUP PHOTOS......................................................................................................................................18 8.5. SAR MEASUREMENT RESULTS....................................................................................................................21 9. EUT PHOTOS....................................................................................................22 10. EQUIPMENTS LIST & CALIBRATION INFORMATION............................................23 11. REFERENCES..................................................................................................24 12. ATTACHMANTS................................................................................................25 REPORT NO: 02I1666-1 DATE: November 27, 2002 FCC ID: APYHRO00027 COMPLIANCE CERTIFICATION SERVICES Page: 4 of 25 This report shall not be reproduced except in full, without the written approval of CCS. This document may be altered or revised by Compliance Certification Services personnel only, and shall be noted in the revision section of the document. 1. EUT DESCRIPTION APPLICANT: Sharp Corporation 2-13-1, Iida Hachihonmatsu Higashihiroshima-City, Hiroshima 739-0192 Japan MODEL: GS-200 FCC ID: APYHRO00027 DEVICE CATEGORY: PORTABLE DEVICES EXPOSURE CATEGORY: GENERAL POPULATION/UNCONTROLLED EXPOSURE Test Sample is a: Production unit Modulation type: GSM+GPRS Operating Mode: Maximum continuous output Tx Frequency: 1850.2 ~ 1909.8 MHz Max. O/P Power: 29.58 dBm (1880.0 MHz) Max. SAR (1g): 0.931 W/Kg (at 1850.2 MHz; Left head, touch position) 0.251 W/Kg (at 1850.2 MHz; Body-worn position) Application Type: Certification FCC Rule Part(s): 24 (E) Antenna …

Text truncated - open the document above for the full version.

Sharp (Model: GS-200), Frequency: 1850.2 MHz (Left Touch) Frequency: 1900 MHz; Crest factor: 8.5 Medium: Head 1900 MHz: σ = 1.40 mho/m ε r = 39.2 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (71°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 2.07 mW/g, SAR (1g): 0.931 mW/g, SAR (10g): 0.408 mW/g, (Worst-case extrapolation) Penetration depth: 7.9 (6.9, 10.1) [mm]; Powerdrift: -0.05 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 21.0 Liquid Temperature (degree C): 19.2 SAR Tot [mW/g] 6.67E-2 2.00E-1 3.34E-1 4.67E-1 6.00E-1 11/26/02 COMPLIANCE CERTIFICATION SERVICES Sharp (Model: GS-200), Frequency: 1850.2 MHz (Left Touch) Frequency: 1900 MHz; Crest factor: 8.5 Medium: Head 1900 MHz: σ = 1.40 mho/m ε r = 39.2 ρ = 1.00 g/cm 3 SAM-1 Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:: , , () Penetration depth: 7.4 (6.6, 9.4) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 Ambient Temperature (degree C): 21.0 Liquid Temperature (degree C): 19.2 11/26/02 COMPLIANCE CERTIFICATION SERVICES 0.0 0.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 0102030405060708090 SAR tot [mW/g] [mm] Sharp (Model: GS-200), Frequency: 1880.0 MHz (Left Touch) Frequency: 1900 MHz; Crest factor: 8.5 Medium: Head 1900 MHz: σ = 1.40 mho/m ε r = 39.2 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (71°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 2.10 mW/g, SAR (1g): 0.927 mW/g, SAR (10g): 0.405 mW/g, (Worst-case extrapolation) Penetration depth: 6.8 (6.1, 8.9) [mm]; Powerdrift: -0.03 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 21.0 Liquid Temperature (degree C): 19.3 SAR Tot [mW/g] 7.02E-2 2.11E-1 3.51E-1 4.91E-1 6.32E-1 11/26/02 COMPLIANCE CERTIFICATION SERVICES Sharp (Model: GS-200), Frequency: 1909.8 MHz (Left Touch) Frequency: 1900 MHz; Crest factor: 8.5 Medium: Head 1900 MHz: σ = 1.40 mho/m ε r = 39.2 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (71°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.45 mW/g, SAR (1g): 0.696 mW/g, SAR (10g): 0.330 mW/g, (Worst-case extrapolation) Penetration depth: 7.2 (6.6, 8.7) [mm]; Powerdrift: 0.03 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 21.0 Liquid Temperature (degree C): 19.0 SAR Tot [mW/g] 6.01E-2 1.80E-1 3.00E-1 4.21E-1 5.41E-1 11/26/02 COMPLIANCE CERTIFICATION SERVICES Sharp (Model: GS-200), Frequency: 1850.2 MHz (Left Tilt) Frequency: 1900 MHz; Crest factor: 8.5 Medium: Head 1900 MHz: σ = 1.40 mho/m ε r = 39.2 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (86°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 0.139 mW/g, SAR (1g): 0.0887 mW/g, SAR (10g): 0.0552 mW/g, (Worst-case extrapolation) Penetration depth: 11.8 (11.1, 12.6) [mm]; Powerdrift: -0.08 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 21.0 Liquid Temperature (degree C): 19.0 SAR Tot [mW/g] 9.30E-3 2.79E-2 4.65E-2 6.51E-2 8.37E-2 11/26/02 COMPLIANCE CERTIFICATION SERVICES Sharp (Model: GS-200), Frequency: 1850.2 MHz (Left Tilt) Frequency: 1900 MHz; Crest factor: 8.5 Medium: Head 1900 MHz: σ = 1.40 mho/m ε r = 39.2 ρ = 1.00 g/cm 3 SAM-1 Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:: , , () Penetration depth: 11.7 (11.1, 12.4) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 Ambient Temperature (degree C): 21.0 Liquid Temperature (degree C): 19.0 11/26/02 COMPLIANCE CERTIFICATION SERVICES -0.02 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 102030405060708090 SAR tot [mW/g] [mm] Sharp (Model: GS-200), Frequency: 1880.0 MHz (Left Tilt) Frequency: 1900 MHz; Crest factor: 8.5 Medium: Head 1900 MHz: σ = 1.40 mho/m ε r = 39.2 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (86°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 0.128 mW/g, SAR (1g): 0.0810 mW/g, SAR (10g): 0.0490 mW/g, (Worst-case extrapolation) Penetration depth: 11.3 (10.8, 11.8) [mm]; Powerdrift: -0.17 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 21.0 Liquid Temperature (degree C): 19.0 SAR Tot [mW/g] 7.80E-3 2.34E-2 3.90E-2 5.46E-2 7.02E-2 11/26/02 COMPLIANCE CERTIFICATION SERVICES Sharp (Model: GS-200), Frequency: 11909.8 MHz (Left Tilt) Frequency: 1900 MHz; Crest factor: 8.5 Medium: Head 1900 MHz: σ = 1.40 mho/m ε r = 39.2 ρ = 1.00 g/cm 3 SAM-1 Phantom; Left Hand Section; Position: (86°,60°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 0.112 mW/g, SAR (1g): 0.0699 mW/g, SAR (10g): 0.0411 mW/g, (Worst-case extrapolation) Penetration depth: 11.0 (10.8, 11.4) [mm]; Powerdrift: -0.02 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 21.0 Liquid Temperature (degree C): 19.1 SAR Tot [mW/g] 7.10E-3 2.13E-2 3.55E-2 4.97E-2 6.39E-2 11/26/02 COMPLIANCE CERTIFICATION SERVICES Sharp (Model: GS-200), Frequency: 1850.2 MHz (Right Touch) Frequency: 1900 MHz; Crest factor: 8.5 Medium: Head 1900 MHz: σ = 1.40 mho/m ε r = 39.2 ρ = 1.00 g/cm 3 SAM-1 Phantom; Righ Hand Section; Position: (71°,301°) Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:Cube 5x5x7: Peak: 1.48 mW/g, SAR (1g): 0.767 mW/g, SAR (10g): 0.386 mW/g, (Worst-case extrapolation) Penetration depth: 7.8 (7.1, 9.4) [mm]; Powerdrift: -0.04 dB Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0 Ambient Temperature (degree C): 21.0 Liquid Temperature (degree C): 19.2 SAR Tot [mW/g] 6.68E-2 2.00E-1 3.34E-1 4.68E-1 6.01E-1 11/26/02 COMPLIANCE CERTIFICATION SERVICES Sharp (Model: GS-200), Frequency: 1850.2 MHz (Right Touch) Frequency: 1900 MHz; Crest factor: 8.5 Medium: Head 1900 MHz: σ = 1.40 mho/m ε r = 39.2 ρ = 1.00 g/cm 3 SAM-1 Phantom; Section; Position: Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); SAR:: , , () Penetration depth: 8.4 (7.7, 9.6) [mm]; Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 2.0 Ambient Temperature (degree C): 21.0 Liquid Temperature (degree C): 19.2 11/26/02 COMPLIANCE CERTIFICAT…

Text truncated - open the document above for the full version.

System Validation - D1800V2 S/N: 294 (Antenna input power: 250 mW) SAM-1; Flat Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); Crest factor: 1.0 Head 1800 MHz: σ = 1.42 mho/m ε r = 38.7 ρ = 1.00 g/cm 3 Cube 5x5x7: Peak: 17.7 mW/g, SAR (1g): 9.47 mW/g, SAR (10g): 4.92 mW/g, (Worst-case extrapolation) Penetration depth: 8.2 (7.8, 9.0) [mm] Powerdrift: 0.01 dB Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.0 SAR Tot [mW/g] 1.03E+0 3.09E+0 5.15E+0 7.20E+0 9.26E+0 11/26/02 COMPLIANCE CERTIFICATION SERVICES System Validation - D1800V2 S/N: 294 (Antenna input power: 250 mW) SAM-1; Probe: ET3DV6 - SN1578; ConvF(5.50,5.50,5.50); Crest factor: 1.0 Head 1800 MHz: σ = 1.42 mho/m ε r = 38.7 ρ = 1.00 g/cm 3 : , , () Penetration depth: 8.2 (7.8, 9.1) [mm] Ambient Temperature (degree C): 22.0 Liquid Temperature (degree C): 20.0 11/26/02 COMPLIANCE CERTIFICATION SERVICES 0 2 4 6 8 10 12 14 16 18 0102030405060708090 SAR tot [mW/g] [mm]

Spectrum lots to demonstrate the duty cycle that was used during the tests Duty Cycle: 100 (0.54/4.6) = 11.73%

Spectrum lots to demonstrate the duty cycle that was used during the tests Duty Cycle: 100 (0.54/4.6) = 11.73%

Issue Date : January 15, 2003 Page 1 of 46 EMC EMISSION - TEST REPORT JQA APPLICATION No.: KL80020490S Name of Product: Tri-Band(PCS&GSM,DCS) Cellular Phone Model/Type No.: GS-200 FCC ID: APYHRO00027 Applicant: Sharp Corporation Address: 2-13-1, Iida Hachihonmatsu, Higashihiroshima-city, : Hiroshima 739-0192, JAPAN Manufacturer: Sharp Corporation Address: 2-13-1, Iida Hachihonmatsu, Higashihiroshima-city, : Hiroshima 739-0192, JAPAN Receive date of EUT: November 18, 2002 Final Judgement :passed TEST RESULTS IN THIS REPORT are obtained in use of equipment that is traceable to National Institute of Advanced Industrial Science and Technology(AIST) under METI Japan and Communications Research Lab.(CRL) under MPHPT Japan. THE TEST RESULTS only responds to the test sample. This test report shall not be reproduced except in full. Authorized by: Takashi Yamanaka, Director JQA KITA-KANSAI Testing Center Page 2 of 46 DIRECTORY Page A) Documentation Directory2 Test Regulation / General Information3 - 4 Test Conditions5-18 Configuration of EUT / Operation mode of the EUT19 - 20 EUT Modification / Responsible Party / Deviation from Standard21 Test results / Measurement Uncertainty22 - 23 Summary24 Test System-Arrangement (Drawings) 25 Test-setup (Photographs) at worst case 26 B) Test data Transmitter Power(TP)27 Antenna Conducted Spurious Emission28 - 29 Maximum Transmitter Power(EIRP)30 Unwanted Radiation31 - 37 Occupied Bandwidth38 - 41 Band-Edge Emission42 - 44 Frequency Stability45 - 46 JQA Application No.: KL80020490SRegulation : CFR 47 FCC Rules Part 24 Model No.: GS-200Issue Date : January 15, 2003 FCC ID: APYHRO00027 JQA Application No.: KL80020490SRegulation : CFR 47 FCC Rules Part 24 Model No.: GS-200Issue Date : January 15, 2003 FCC ID: APYHRO00027 Page 3 of 46 TEST REGULATION FCC Rules and Regulations Part 24 (October 1, 2001) 1900 MHz systems ô- Narrowband PCS ò- Broadband PCS Test procedure: The tests were performed according to FCC Rules and Regulations Part 2 (October 1, 2001), and ANSI C63.4 (1992). GENERAL INFORMATION Test facility: 1) Test Facility located at Kita-Kansai : 1st and 2nd Open Sites (3 m Site) Test Facility located at Kameoka: 1st Open Site (3, 10 and 30 m, on common plane) : 2nd …
