~~~ Turning Power On Hold down F for at least a few seconds. Turning Power Off Hold down F for at least a few seconds. From the stand-by screen: Press c. z Press 3. z Press 6. z Press 2. From the stand-by screen: Press c. z Press 0. Making a Call From the stand-by screen: Enter the phone number you want to call. z Press N. To end a call: Press F. English Simple Manual Earpiece au IC-Card microSD memory card slot Lock slider Sub-display Direct/Veil View key Address book key Power/End key Microphone Application key Center key Light sensor Charging / Incoming indicator EZ key Clear/Memo key Mobile light/flash Infrared port Mail/Character key Talk key Quick key Main-display Cursor key External connection jack cover Camera lens Side manner key Strap eyelet Number keys External connection jack FeliCa mark Speaker Battery pack/ cover Internal antennas TV antenna Charging terminals Turning Power On and Off Switching the Screen to English Checking Your Own Phone Number and E-mail Address Making and Answering a Call c276_j.book 460 ページ ２０１０年１１月５日 金曜日 午後４時３１分 ~~~ Answering a Call When the phone starts ringing, press N. To adjust the earpiece volume during a call: Use j. Storing an Entry From the stand-by screen: Hold down & for at least a few seconds. z Use j to select the item you want to edit. z Press c (Select). z Enter the data. z Press % (Reg). Recalling an Entry From the stand-by screen: Press & to display the Address Book screen. z Use s to select the tab for the record you want to recall. z Use j to select the name of the record. z Press c (Detail) to view the record in detail. Recording a Movie Clip From the stand-by screen: Press c. z Use a to select “CAMERA”. z Press c (Select). z Select “Movie”. z Press c (Select). z Press c (Record) to start recording. z Press c (Stop) to stop recording. z Press c (Save) to store the movie. Press & () (Pause) during recording to pause recording. Press & () in the Movie mode to change to the Photo mode. Taking a Snapshot From the stand-by screen: Press c. z Use a to select “CAMERA”. z Press c (Select). z Select “Photo (W.paper Mode)”. z Press c (Select). z Press c (Shoot) to take a snapshot. z Press c (Save) to store the photo. P ress & () in the Photo mode to change to the Movie mode. Ex: To call 212-123- in the USA Setting the Manner Mode From the stand-by screen: Hold down # for at least a few seconds. Repeat the above operation to disable the Manner Mode. Setting the Answer Memo (Voice Recording) From the stand-by screen: Hold down C for at least a few seconds. Repeat the above operation to disable the Answer Memo. Storing and Recalling Address Book Entries Using the Camera (Movie and Snapshot) Making an International Call 001010 z 1 z 212 Area code International access codeCountry code (USA) z123z zN Number you want to call Other Handy Features For inquiries, please contact au Customer Service Center (General Information) If you are calling from a landline phone: (toll free) If you are calling from an au mobile phone: (toll free) c276_j.book 461 ページ ２０１０年１１月５日 金曜日 午後４時３１分

SHARP (TCB.STE) Sham Telecommunications of Eurooe LTD 26ft November 2010 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KTI2 2TD ATTESTATION STATEMENT FCC ID: APYI{RO00132 This device contains an embedded FeliCa(RFID) device that SHARP CORPORATION confirms compliance with the Part 15 regulations. I, the undersigned, hereby declare that the FeliCa function of the product listed below is a l3.56MHz Band used in Japan. It is controlled by software that can be used only in Japan and the FeliCa never radiates in USA/Europe. Method of observing FCC Part 15 regulation To activate FeliCa embedded in this product, the "AREA" setting of the phone must be "Domestic (:Japan)" and the phone must be connected to the KDDI (Japan) communication network. And, to make phone calls in the U.S.A., the "AREA" setting of the phone must be "Overseas", the FeliCa feature is inactive in this settins. Ken Newman Principal Business Systems Co-ordinator Sharp Telecommunications of Europe LID.

SHARP (TCB.STE) Sham Telecommunications of Eurooe LTD 26th November 2010 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KTI2 2TD ATTESTATION STATEMENT FCC ID: APYHRO00132 This device contains an embedded Bluetooth device that SHARP CORPORATION confirms compliance with the following Part 15 regulations. 8.247@)(r) The hopping sequence must be pseudorandom All Channels are used equally on average The receiver input bandwidth is approximately equal to the transmit bandwidth The receiver hops in sequence with the transmitted signal $.247(€) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) rs.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters Ken Newman Principal Business Systems Co-ordinator Sharp Telecommunications of Europe LTD.

SHARP (TCB.STE) Sham Telecommunications of Eurooe LTD 26th November 2010 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KTI2 2TD ATTESTATION STATEMENT FCC ID: APYHRO00132 This device contains an embedded FM Transmitter device that SHARP CORPORATION confirms compliance with the Part 15 regulations. I, the undersigned, hereby declare that the FM Transmitter function of the product listed below is 80-92MHz Band used in Japan. It is controlled by software that can be used only in Japan and the FM Transmitter never radiates in USA/Europe. Method of observing FCC Part 15 regulation To activate FM Transmitter embedded in this product, the area setting of the phone must be "Domestic (:Japan)" and the phone must be connected to the KDDI (Japan) communication network. And, to make phone calls in the U.S.A., the "AREA" setting of the phone must be "Overseas", the FM Transmitter feature is inactive in this settins. Principal Business Systems Co-ordinator Sharp Telecommunications of Europe LTD.

SHARP (TCB.BABT) Sham Telecommunications of Europe LTD. 26th November 2010 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KTI2 2TD Confidentiality Request FCC lD: APYHRO00132 Gellular Phone / Bluetooth Enabled Pursuant to Sections 0.457(dXl)(ii) and 0.459 of the Commission's Rules, Sharp Corporation hereby requests permanent confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematic Diagrams - Parts List - Tune-up / Output PowerAlignment Procedure - Theory of operation Sharp Corporation also hereby requests short-term confidential treatment of information accompanying this application as outlined below for the period untrl24th January 20ll - Test Setup Photos - External Photos - Internal Photos - Operation Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(dX1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Principal Business Systems Co-ordinator Sharp Telecommunications of Europe LTD. Yours sincerely,

Model Name: CDMA SH011 Photo (External) FCC ID: APYHRO00132 1/4 Model Name: CDMA SH011 Photo (External) FCC ID: APYHRO00132 2/4 Model Name: CDMA SH011 Photo (External) FCC ID: APYHRO00132 3/4 Model Name: CDMA SH011 Photo (External) FCC ID: APYHRO00132 4/4

SHARP (TCB-STE) Sharp Telecommunications of Eurooe LID 15ft November 2010 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KTTZ zTD Declaration for FCC ID Label User Visibilify for Sharp Cellular Phone Product FCC ID: APYHRO00132 Cellular Phone / Bluetooth Enabled In accordance with 47CFR 52.925 (d), Sharp Corporation hereby declares that the FCC ID label will be visible at the time of purchase (i.e. battery is not preinstalled and must be installed by the user prior to first use). Principal Business Systems Co-ordinator Sharp Telecommunications of Europe LTD.

Model Name: CDMA SH011 FCC ID Location (On Spec Label) FCC ID:APYHRO00132 ○Spec Label ○Location ①,② Production Years & Month ③,④ Products Code ⑤,⑥ Production Number ⑦ Barcode of Production Number ⑧ Certification Number of TELEC ⑨ Approval Number of JATE ⑪ Country of origin Caution: Turn off power in aircrafts and hospitals. Don’t remove this label. Vendor:KDDI Corp.・Okinawa Cellular Corp. Manufacture/Applicant: SHARP Corp. ⑩ FCC ID: APYHRO00132

Model Name: CDMA SH011 Photo (Internal) FCC ID: APYHRO00132 1/6 Model Name: CDMA SH011 Photo (Internal) FCC ID: APYHRO00132 2/6 Model Name: CDMA SH011 Photo (Internal) FCC ID: APYHRO00132 3/6 Model Name: CDMA SH011 Photo (Internal) FCC ID: APYHRO00132 4/6 Model Name: CDMA SH011 Photo (Internal) FCC ID: APYHRO00132 5/6 Model Name: CDMA SH011 Photo (Internal) FCC ID: APYHRO00132 6/6

Model Name: CDMA SH011 Photo (Antennas) FCC ID: APYHRO00132 1/1 Distance between CDMA Main antenna and Bluetooth antenna Sub Antenna （Receive Only） Bluetooth Antenna 91 mm CDMA Main TX Antenna
