APYHRO00140CDMA Phone with BT/WLAN & NFC

Turning Power On Hold down f for at least two seconds. Turning Power Off Hold down f for at least two seconds. z Select [Power off]. z Select [OK]. On the desktop*: Select []. z Select []. z Select []. z Select []. z Select [English]. * The desktop represents the stand-by screen. On the desktop: Select []. z Select [Settings]. z Select [Profile]. English Simple Manual Earpiece External connection jack HDMI jack External connection jack cover Charging/Incoming indicator Internal antennas Proximity sensor/ Light sensor Power key Volume up/ down key Back key /GPW key 5GCTEJ key *QOG key Display Shutter key Internal antennas Microphone Strap eyelet Earphone jack coverEarphone jackTelevision antenna Out camera lens In camera lens Infrared port Mobile light FeliCa mark Speaker Battery pack microSD memory card slot au IC- Card Reset button Battery pack cover Turning Power On and OffSwitching the Screen to English Checking Your Own Phone Number and Mail Address as32_j.book 312 ページ ２０１０年１２月２２日 水曜日 午後８時３０分 Making a Call On the desktop: Select []. z Enter the phone number you want to call. z Select [Call]. To end a talk: Select [Disconnect]. To end a call: Select [Quit]. Answering a Call When the phone starts ringing, slide [] in the right direction. To adjust the earpiece volume during a call: Press u/d. Storing an Entry On the desktop: Select []. z Select [Address Book]. z Select [e]. z Select [Add New Item]. z Select the item you want to edit. z Select [Save]. z Select [Yes]. Recalling an Entry On the desktop: Select []. z Select [Address Book]. z Select the record you want to recall. Recording a Movie Clip On the desktop: Select []. z Select [Video Camera]. z Select []. z Select [] to stop recording. z Select [Save] to store the movie. To zoom in or out: Slide the touch screen left or right. Taking a Snapshot On the desktop: Select []. z Select [Camera]. z Select [] to take a snapshot. To zoom in or out: Slide the touch screen left or right. Ex: To call 212-123- in the USA On the desktop: Select []. Setting the Manner Mode Hold down f for at least a few seconds. z Select [Manner mode]. Repeat the above operation to disable the Manner Mode. Setting the Answer Memo (Voice Recording) On the desktop: Select []. z Select [Settings]. z Select [Call Settings]. z Select [Call/Message]. z Select [Answering memo setting]. Repeat the above operation to disable the Answer Memo. Making and Answering a Call Storing and Recalling Address Book Entries Using the Camera (Movie and Snapshot) Making an International Call 001010 z 1 z 212 International access code Area code Country code (USA) z 123 z zSelect [Call]. Number you want to call Other Handy Features For inquiries, please contact au Customer Service Center (General Information) If you are calling from a landline phone: (toll free) If you are calling from an au mobile phone: (toll free) as32_j.book 313 ページ ２０１０年１２月２２日 水曜日 午後８時３０分 -This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, inc luding interference t hat may cause undesired operation. -Changes or modifications not expressly approved by the manufac turer responsible for compliance could void the user's authority to o perate the equipment. This equipment has been tested and found to c omply with the lim its of a Class B digital device, pursuan t to Part 15 of the FCC Rules. T hese limits are designed to provide reasonable pr otection against harmful inter ference in a residential installation. This equipment generates, uses and ca n radiate radio frequency energy and, if not ins talled and used in accordance w ith the instructions, may cause harmful interference to radio communica tions. However, there is no guarantee t hat interference will not occur in a particular installation; if this equipment does cause harmful interference to radio or television reception, which c an be determined by turning the equipment off and on, the user is encouraged to try to correct the interf erence by one or more of the following measures: 1. Reorient/relocate the receiving antenna. 2. Increase the separ ation between the equi pment and receiver. 3. Connect the equipment i nto an outlet on a ci rcuit different from that to which the receiv er is connected. 4. Consult the dealer or an exper ienced radio/TV technician for help. Your handset is a radio transmitt er and receiver. It is designed and manufactured not to exceed the em ission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. The guidelines are based on st andards that were developed by in dependent scientific organizations throug h periodic and thorough evaluati on of scientific studies. The standards include a su bstantial safety margin desi gned to assure the safety of all persons, r egardless of age and health. The exposure standard for wirele ss handsets employs a unit of m easurement known as the Specific A bsorption Rate, or SAR. The SAR limit se t by the FCC is 1.6W/kg. Hi ghest SAR value Model FCC ID At the Ear On the Body CDMA SHI05 APYHRO00140 This device was tested for typica l body-worn operations with the back of the handset kept 1.5 cm from the body. T o maintain compliance with FCC RF exposure requirements, use accessories that maintain a 1.5 cm s eparation distance between the user's body and the back of the handset. T he use of beltclips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements m ay not comply with FCC RF exposure re quirements, and should be avoided . The FCC has granted an Equipment Authoriz ation for this model handset w ith all reported SAR levels evaluated as in compliance with the FCC RF emission guidelines. SAR information on this model handset is on file with the FCC a nd can be found at http://…

Text truncated - open the document above for the full version.

SHARP CORPORATION 22-22 Nagaike-cho, Abeno-ku, Osaka 545-8522 Japan Date: February 17, 2011 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. SIEMIC Inc. 2206 Ringwood Avenue San Jose, CA 95131, USA To whom it may concern: I, the undersigned, hereby authorize Mr. Keun-Ho Park of HCT Co., Ltd and hereafter referred to as HCT, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters with regards to CDMA SHI05 model only. Any and all acts carried out by Mr. Keun-Ho Park of HCT Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing HCT as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized;

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 Revised wording (current) 1.0 2.0 Sept–25-2007 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 SHARP CORPORATION 22-22 Nagaike-cho, Abeno-ku, Osaka 545-8522 Japan Date: February 21, 2011 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, SHARP CORPORATION. hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): CDMA Phone with BT/WLAN & NFC CDMA SHI05 FCC ID : APYHRO00140 We affirm that between SIEMIC and SHARP CORPORATION., any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, ---------------------------------------------- Keun Ho Park/Manager HCT Co., Ltd. cc. SHARP CORPORATION

SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 Confidentiality Request Letter Revision History Reason for Amendment (current / obsolete) From To Approved Date Initial Release (current) 1.0 1.0 Nov-14-2006 SCS-F19: Confidentiality Request Letter Rev 1.0 Nov 14, 2006 SHARP CORPORATION 22-22 Nagaike-cho, Abeno-ku, Osaka 545-8522 Japan Date: February 21, 2011 To: Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID : APYHRO00140 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, SHARP CORPORATION . hereby requests confidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as outlined in Public Notice DA 04-1705. This provision will give SHARP CORPORATION . temporary confidentiality of commercially sensitive information prior to product release. The requested Confidential and Temporary Confidential exhibits are listed as follows: CONFIDENTIAL AND SHORT-TERM CONFIDENTIAL LIST Exhibit Description 1 Block Diagram 2 Operational Descriptions 3 Parts Lists and Tune-Up Procedure CONFIDENTIAL 4 Schematics 5 External Photos 6 Internal Photos 7 Test-Setup Photos SHORT-TERM CONFIDENTIAL 8 User’s Manual The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely, ---------------------------------------------- Keun Ho Park/Manager HCT Co., Ltd. cc. SHARP CORPORATION

FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １ of 7 EXTERNAL PHOTOGRAPHS FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ２ of 7 ■ EXTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ３ of 7 ■ EXTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ４ of 7 ■ EXTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ５ of 7 ■ EXTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ６ of 7 ■ EXTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ７ of 7 ■ EXTERNAL PHOTO

CDMA SHI05Phone ID Label Label Location Label Note: The FCC Label will be visi ble at the time of purchase

FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １ of 15 INTERNAL PHOTOGRAPHS FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ２ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ３ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ４ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ５ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ６ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ７ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ８ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page ９ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １０ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １１ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １２ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １３ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １４ of 15 ■ INTERNAL PHOTO FCC ID: APYHRO00140 HCT CO., LTD SAN 136-1, AMI-RI , BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL : + 82 31 639 8518 FAX : + 82 31 639 8525 www.hct.co.kr Page １５ of 15 ■ INTERNAL PHOTO

FCC PT.15.225 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1101FR19 Date of Issue: January 21, 2010 EUT Type: CDMA Phone with BT/WLAN & NFC FCC ID: APYHRO00140 Page ２ of 24 Version TEST REPORT NO. DATE DESCRIPTION HCTR1101FR19 January 21, 2011First Approval Report FCC PT.15.225 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1101FR19 Date of Issue: January 21, 2010 EUT Type: CDMA Phone with BT/WLAN & NFC FCC ID: APYHRO00140 Page ３ of 24 Table of Contents 1. GENERAL INFORMATION ..........................................................................................................................４ 2. EUT DESCRIPTION .....................................................................................................................................４ 3. TEST METHODOLOGY ...............................................................................................................................５ 3.1 EUT CONFIGURATION ......................................................................................................................５ 3.2 EUT EXERCISE ..................................................................................................................................５ 3.3 GENERAL TEST PROCEDURES ......................................................................................................５ 3.4 DESCRIPTION OF TEST MODES .....................................................................................................５ 3.5 STANDARDS ......................................................................................................................................６ 4. INSTRUMENT CALIBRATION.....................................................................................................................７ 5. FACILITIES AND ACCREDITATIONS .........................................................................................................７ 5.1 FACILITIES .........................................................................................................................................７ 5.2 EQUIPMENT .......................................................................................................................................７ 6. ANTENNA REQUIREMENTS ......................................................................................................................７ 7. TEST SUMMARY .........................................................................................................................................８ 8. RADIATED EMISSION MEASUREMENT ...................................................................................................９ 8.1. RADIATED EMISSION 9 kHz – 30 MHz .......................................................................................１０ 8.2. RADIATED EMISSION 30 MHz – 1000 MHz ................................................................................１２ 9. EMISSION BANDWIDTH PLOT...............................................................................................................１３ 10. FREQUENCY TOLERANCE..................................................................................................................１４ 11. POWERLINE CONDUCTE EMISSIONS................................................................................................１５ 12. LIST OF TEST EQUIPMENT .................................................................................................................２４ FCC PT.15.225 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1101FR19 Date of Issue: January 21, 2010 EUT Type: CDMA Phone with BT/WLAN & NFC FCC ID: APYHRO00140 Page ４ of 24 1. GENERAL INFORMATION Applicant: SHARP CORPORATION Address: 22-22 Nagaike-cho, Abeno-ku, Osaka 545-8522 Japan FCC ID: APYHRO00140 EUT: CDMA Phone with BT/WLAN & NFC Model: CDMA SHI05 Date of Test: January 18, 2011 ~ January 20, 2011 Contact person: Tel/ Fax: Name: Masaaki Nishil Phone #: +81-743-55-4091 Fax #: +81-743-55-2553 2. EUT DESCRIPTION Product CDMA Phone with BT/WLAN & NFC Model Name CDMA SHI05 Power Supply DC 3.7 V Battery Type Li-ion Battery(Standard) Frequency of Operation 13.56305 MHz Transmit Power 15.11 dBuV/m Modulation Type ASK Manufacturer SHARP CORPORATION Antenna Specification Manufacturer: E.M.W. Antenna Co., Ltd. Antenna type: Internal Antenna FCC PT.15.225 TEST REPORT FCC CERTIFICATION REPORT www.hct.co.kr Test Report No. HCTR1101FR19 Date of Issue: January 21, 2010 EUT Type: CDMA Phone with BT/WLAN & NFC FCC ID: APYHRO00140 Page ５ of 24 3. TEST METHODOLOGY The measurement procedure described in the American National Standard for Methods of Measurement of Radio-Noise Emission from Low-Voltage Electrical and Electronic Equipment in the Range of 9kHz to 40GHz(ANSI C63.4-2003) 3.1 EUT CONFIGURATION The EUT configuration for testing is installed on RF field strength measurement to meet the Commissions requirement and operating in a manner that intends to maximize its emission characteristics in a continuous normal application. 3.2 EUT EXERCISE The EUT was operated in the engineering mode to fix the Tx frequency that was for the purpose of the measurements. According to its specifications, the EUT must comply with the requirements of the Section 15.207, 15.209 and 15.225 under the FCC Rules Part 15 Subpart C. 3.3 GENERAL TEST PROCEDURES Conducted Emissions The EUT is placed on the turntable, which is 0.8 m above ground plane. According to the requirements in Section 13.1.4.1 of ANSI C63.4. (Version :2003) Conducted emissions from the EUT measured in the frequency range between 0.15 MHz and 30MHz using CISPR Quasi-peak and average detector modes. Radiated Emissions The EUT is placed on a turn table, which is 0.8 m above ground plane. The turntable shall rotate 360 degrees to determine the position of maximum emission level. EUT is set 3 m away from the receiving antenna, which varied from 1 m to 4 m to find out the highest emission. And also, each emi…
