SHAIIIP (TCB-BABT) Sham Telecommunications of Eurooe LID. l3th June 2011 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KTTZ 2TD Confidentiality Request FGG lD: APYHROOO151 Cellular Phone with Felica / W-LAN / Bluetooth Pursuant to Sections 0.457(dx1)(ii) and 0.459 of the Commission's Rules, Sharp Corporation hereby requests permanent confidential treatment of information accompanyrng this application as outlined below: - Block Diagram - Schematic Diagrams - Parts List - Tune-up / Output PowerAlignment Procedure - Theory of operation - Model Description Sharp Corporation also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period until l5th July 2011 - Test Setup Photos - Extemal Photos - Intemal Photos - Operation Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(dxl)(ii), disclosure of this Application and all accompanyrng materials will not be made before the date of the Grant for this Application. Head of Business Systems Sharp Telecommunications of Europe LTD. Yours sincerelv.

Model Name: CDMA SHX11 Photo (External) FCC ID: APYHRO00151 1/4 Model Name: CDMA SHX11 Photo (External) FCC ID: APYHRO00151 2/4 Model Name: CDMA SHX11 Photo (External) FCC ID: APYHRO00151 3/4 Model Name: CDMA SHX11 Photo (External) FCC ID: APYHRO00151 4/4

Model Name: CDMA SHX11 FCC ID Location (On Spec Label) FCC ID:APYHRO00151 ○Spec Label ○Location ①,② Production Years & Month ③,④ Products Code ⑤,⑥ Production Number ⑦ Barcode of Production Number ⑧,⑨ IMEI Number ⑩ Barcode of IMEI Number ⑪ Certification Number of TELEC ⑫ Approval Number of JATE Caution: Turn off power in aircrafts and hospitals. Don’t remove this label. Vendor:KDDI Corp.・Okinawa Cellular Corp. Manufacture/Applicant: SHARP Corp. ⑬ FCC ID: APYHRO00151

Model Name: CDMA SHX11 Photo (Internal) FCC ID: APYHRO00151 1/4 Model Name: CDMA SHX11 Photo (Internal) FCC ID: APYHRO00151 2/4 Model Name: CDMA SHX11 Photo (Internal) FCC ID: APYHRO00151 3/4 Model Name: CDMA SHX11 Photo (Internal) FCC ID: APYHRO00151 4/4

Document 75913577 Report 07 Issue 1 June 2011 Report On Radio Testing of the Sharp CDMA SHX11 Tri-band CDMA (850MHz_BC0/BC3, 1900MHz_BC6) & Tri-band GSM (GSM900/DCS1800/PCS1900) Dual mode Cellular Phone with Bluetooth, WLAN, FeliCa and GPS in accordance with FCC CFR 47 Part 15B COMMERCIAL-IN-CONFIDENCE FCC ID: APYHRO00151 TÜV SÜD Product Service Ltd, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuvps.co.uk COMMERCIAL-IN-CONFIDENCE Document 75913577 Report 07 Issue 1 Page 1 of 23 COMMERCIAL-IN-CONFIDENCE REPORT ON Radio Testing of the Sharp CDMA SHX11 Tri-band CDMA (850MHz_BC0/BC3, 1900MHz_BC6) & Tri-band GSM (GSM900/DCS1800/PCS1900) Dual mode Cellular Phone with Bluetooth, WLAN, FeliCa and GPS In accordance with FCC CFR 47 Part 15B Document 75913577 Report 07 Issue 1 June 2011 PREPARED FOR Sharp Communication Compliance Ltd Azure House Bagshot Road Bracknell Berkshire RG12 7QY PREPARED BY Michelle Hardy Senior Engineer APPROVED BY Mark Jenkins Authorised Signatory DATED 20 June 2011 ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC CFR 47 Part 15B. The sample tested was found to comply with the requirements defined in the applied rules. Test Engineer(s); A R Hubbard G Lawler Document 75913577 Report 07 Issue 1 Page 2 of 23 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE CONTENTS Section Page No 1 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction ................................................................................................................................... 4 1.2 Brief Summary of Results ............................................................................................................. 5 1.3 Application Form ........................................................................................................................... 6 1.4 Product Information ...................................................................................................................... 7 1.5 Test Conditions ............................................................................................................................. 7 1.6 Deviations from the Standard ....................................................................................................... 7 1.7 Modification Record ...................................................................................................................... 7 2 TEST DETAILS ............................................................................................................................ 8 2.1 AC Line Conducted Emissions ..................................................................................................... 9 2.2 Radiated Emissions .................................................................................................................... 12 3 TEST EQUIPMENT USED ......................................................................................................... 15 3.1 Test Equipment Used ................................................................................................................. 16 3.2 Measurement Uncertainty .......................................................................................................... 17 4 PHOTOGRAPHS ........................................................................................................................ 18 5 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................ 22 5.1 Accreditation, Disclaimers and Copyright ................................................................................... 23 Document 75913577 Report 07 Issue 1 Page 3 of 23 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE SECTION 1 REPORT SUMMARY Radio Testing of the Sharp CDMA SHX11 Tri-band CDMA (850MHz_BC0/BC3, 1900MHz_BC6) & Tri-band GSM (GSM900/DCS1800/PCS1900) Dual mode Cellular Phone with Bluetooth, WLAN, FeliCa and GPS In accordance with FCC CFR 47 Part 15B Document 75913577 Report 07 Issue 1 Page 4 of 23 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 1.1 INTRODUCTION The information contained in this report is intended to show verification of the Radio Testing of the Sharp CDMA SHX11 Tri-band CDMA (850MHz_BC0/BC3, 1900MHz_BC6) & Tri-band GSM (GSM900/DCS1800/PCS1900) Dual mode Cellular Phone with Bluetooth, WLAN, FeliCa and GPS to the requirements of FCC CFR 47 Part 15B. Objective To perform Radio Testing to determine the Equipment Under Test's (EUT’s) compliance with the Test Specification, for the series of tests carried out. Manufacturer Sharp Corporation Model Number(s) CDMA SHX11 Serial Number(s) IMEI 004401113384065 IMEI 004401113359901 Number of Samples Tested 2 Test Specification/Issue/Date FCC CFR 47 Part 15B (2010) Incoming Release Date Application Form 14 June 2011 Disposal Reference Number Date Held Pending Disposal Not Applicable Not Applicable Order Number Date 8492 14 April 2011 Start of Test 24 May 2011 Finish of Test 8 June 2011 Name of Engineer(s) T Hubbard G Lawler Document 75913577 Report 07 Issue 1 Page 5 of 23 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 1.2 BRIEF SUMMARY OF RESULTS A brief summary of the tests carried out in accor dance with FCC CFR 47 Part 15B is shown below. Section Spec Clause Test Description Result Comments/Base Standard AC Powered/USB Cable 2.1 15.107 AC Line Conducted Emissions Pass 2.2 15.109 Radiated Emissions Pass Document 75913577 Report 07 Issue 1 Page 6 of 23 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 1.3 APPLICATION FORM APPLICANT'S DETAILS COMPANY NAME : Sharp Telecommunications of Europe Ltd ADDRESS : Azure House, Bagshot Road Bracknell, Berkshire RG12 7QY NAME F…
