ii is15sh_e_00.fm [ii/ii]~~~~ Thank you for buying the “AQUOS PHONE SL IS15SH” (simply called the “IS15SH” or the “product” from here on). Before using the product, be sure to read the “Basic Manual” (this PDF manual) on the au homepage to ensure correct use. After you have finished reading this PDF manual, be sure to store it and the printed manuals (Accessories) in safe places so that you can retrieve them whenever you need them. If you lose the printed manuals (Accessories), contact an au shop or Customer Service Center. “Basic Manual” (This PDF Manual) This manual describes basic operations of major functions. For detailed descriptions of various functions, refer to the “Instruction Manual application” (Japanese) that can be used on the product or “Full Instruction Manual” (Japanese) on the au homepage: (http://www.au.kddi.com/torisetsu/index.html) “Instruction Manual Application” (Japanese) You can use the “Instruction Manual application” on the product to check detailed operational procedures. Also, you can activate intended functions from an explanation screen depending on the functions. On the home screen, tap [] [[Settings] [[Instruction Manual]. •To use the application for the first time, you need to download and install it by following on-screen instructions. Downloading Manuals You can download the “Basic Manual” (this PDF manual) and the “Instruction Manual” (Accessory) (Japanese) or “Full Instruction Manual” (Japanese) in PDF format from the au homepage. Before you start using the product, be sure to read the “Safety Precautions” to ensure correct use. For troubleshooting, check the symptom of the product in au (au Customer Support) on the au homepage: (http://cs.kddi.com/support/komatta/kosho/index.html) Preface Operating Instructions Safety Precautions is15sh_e.book ii ページ ２０１２年６月８日 金曜日 午後３時５４分 1 is15sh_e_01.fm [1/5] •Communication is not possible even inside the service area in places where the signal does not reach (e.g. tunnels and basements). Also, communication may not be possible in poor reception areas. Communication may be interrupted if you move into poor reception areas during a communication. •A feature of digital communication made on the product is that consistent, high communications quality continues to be maintained down to a weak signal limit. Accordingly, communication may be interrupted if this limit has been reached during a communication. •Since the product uses radio waves, the possibility of communication intercepts by third parties cannot be eliminated. (Though the CDMA/GSM system has highly secured confidential communication features.) •The product is compatible with the international roaming service. Each network service described in this manual varies depending on the area and service content. For details, refer to “Global Passport Owner’s Guide”. •Since the product is a radio station under the Radio Law, you may be asked to temporarily submit the product for inspection in accordance with the Radio Law. •When you insert the micro au IC-Card, the product number information of your cell phone is automatically sent to KDDI CORPORATION for maintenance and monitoring operational status of your cell phone. •Take care not to inconvenience people around you when you use the product in a public place. •When the product is used by a child, parents or guardians should thoroughly read this PDF manual and teach the child how to use it. Cell phones always emit weak radio waves when power is on. Use cell phones in an enjoyable and safe manner without forgetting to be considerate of others around you. Use of cell phones is not allowed in the following places! •Do not use a cell phone while driving a car or riding a motorbike or bicycle. It may cause a traffic accident. Use of a cell phone while driving a car or motorbike is prohibited by law. Use of a cell phone while riding a bicycle may be punishable by some regulations. •Be sure to turn off the product while you are aboard an airplane. Otherwise, safety of your flight may be compromised. Be considerate of where you use the cell phone and how loudly you talk! Do not make calls in theaters, museums, libraries, and other similar places. Turn power off or turn on the manner mode so as not to disturb others around you by ringtones. •Do not use the cell phone on a street where you might interrupt the flow of pedestrians. •Move to areas where you will not inconvenience others on trains, in hotel lobbies, etc. •Refrain from talking in a loud voice. •Obtain the permission of other people before you take their photos with the cell phone’s camera. Be considerate of people around you! •Some people close to you in crowded places such as packed trains may be using a cardiac pacemaker. Turn the cell phone off in such places. •Abide by the rules of hospitals and other medical institutions where it is forbidden to use or carry cell phones. When Using the ProductCell Phone Etiquette is15sh_e.book 1 ページ ２０１２年６月８日 金曜日 午後３時５４分 2 is15sh_e_01.fm [2/5] Before you start using the product, make sure that you have all the following packaged items with the product. ●Instruction Manual (Japanese) ●Setting Guide (Japanese) ●Before Using the Product (Japanese) ●Global Passport Owner’s Guide (Japanese) The following items are not included in the package. •Purchase a specified charger (sold separately). •Illustrations in this manual are only for reference. They may look different from the actual product. au Disaster Countermeasure is an application in which you can use Disaster Message Board, Early warning mail (earthquake early warnings, disaster/evacuation information and tsunami warnings) and Disaster Voice Delivery Service. AOn the home screen, [] [[Settings] [[au ] (au Disaster Countermeasure). The au disaster countermeasure menu is displayed. Using Disaster Message Board Disaster Message Board is a service to enable customers in disaster areas to register their safety information via IS NET when large-scale disasters, such as an earth…

Text truncated - open the document above for the full version.

(TCB-STE) Sharp Telecommunications of Europe LTD 19 th June, 2012 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Declaration for FCC ID Label User Visibility for Sharp Cellular Phone Product FCC ID: APYHRO00171 Cellular Phone / FeliCa / W-LAN / Bluetooth Enabled In accordance with 47CFR §2.925 (d), Sharp Corporation hereby declares that the FCC ID label will be visible at the time of purchase (i.e. battery is not preinstalled and must be installed by the user prior to first use). Yours sincerely, Ken Newman Head of Business Systems Sharp Telecommunications of Europe LTD.

(TCB-BABT) Sharp Telecommunications of Europe LTD. 19 th June, 2012 BABT TCB Forsyth House, Churchfield Road, Walton-on-Thames, Surrey, KT12 2TD Confidentiality Request FCC ID: APYHRO00171 Cellular Phone with FeliCa / W-LAN / Bluetooth Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, Sharp Corporation hereby requests permanent confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematic Diagrams - Parts List - Tune-up / Output Power Alignment Procedure - Theory of operation - Model Description Sharp Corporation also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period until 18 th July 2012: - Test Setup Photos - External Photos - Internal Photos - Operation Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Ken Newman Head of Business Systems Sharp Telecommunications of Europe LTD.

Model Name: CDMA SHI15 Photo (External) FCC ID: APYHRO00171 1/5 Model Name: CDMA SHI15 Photo (External) FCC ID: APYHRO00171 2/5 Model Name: CDMA SHI15 Photo (External) FCC ID: APYHRO00171 3/5 Model Name: CDMA SHI15 Photo (External) FCC ID: APYHRO00171 4/5 Model Name: CDMA SHI15 Photo (External) FCC ID: APYHRO00171 5/5

Model Name: CDMA SHI15 FCC ID Location (On Spec Label) FCC ID:APYHRO00171 ○Spec Label ○ Location ①、② Production Years & Month ③、④ Products Code ⑤、⑥ Production Number ⑦ Barcode of Production Number ⑧、⑨ IMEI Number ⑩ Barcode of IMEI ⑪ Certification Number of TELEC ⑫ Approval Number of JATE ⑬ FCC ID Number ⑬ FCC ID: APYHRO00171 Don’t remove this label Caution: Turn off power in aircrafts and hospitals. Vendor:KDDI Corp.・Okinawa Cellular Corp. Manufacture/Applicant: SHARP Corp. Displayed in the bottom of the battery box.

Model Name: CDMA SHI15 Photo (Internal) FCC ID: APYHRO00171 1/6 Model Name: CDMA SHI15 Photo (Internal) FCC ID: APYHRO00171 2/6 Model Name: CDMA SHI15 Photo (Internal) FCC ID: APYHRO00171 3/6

Model Name: CDMA SHI15 Photo (Internal) FCC ID: APYHRO00171 4/6 Model Name: CDMA SHI15 Photo (Internal) FCC ID: APYHRO00171 5/6 Model Name: CDMA SHI15 Photo (Internal) FCC ID: APYHRO00171 6/6

Document 75917027 Report 13 Issue 2 June 2012 Report On Specific Absorption Rate Testing of the Sharp CDMA SHI15 Dual-band CDMA (BC0, BC6) and Tri-band GSM (GSM900/DCS1800/PCS1900) Dual mode Cellular Phone with Bluetooth, Felica, WLAN and GPS FCC ID: APYHRO00171 COMMERCIAL-IN-CONFIDENCE TÜV SÜD Product Service Ltd, Octagon House, Concorde Way, Segensworth North, Fareham, Hampshire, United Kingdom, PO15 5RL Tel: +44 (0) 1489 558100. Website: www.tuvps.co.uk COMMERCIAL-IN-CONFIDENCE Document 75917027 Report 13 Issue 2 Page 1 of 50 COMMERCIAL-IN-CONFIDENCE REPORT ON Specific Absorption Rate Testing of the Sharp CDMA SHI15 Dual-band CDMA (BC0, BC6) and Tri-band GSM (GSM900/DCS1800/PCS1900) Dual mode Cellular Phone with Bluetooth, Felica, WLAN and GPS Document 75917027 Report 13 Issue 2 June 2012 PREPARED FOR Sharp Communication Compliance Ltd Azure House Bagshot Road Bracknell Berkshire RG12 7QY PREPARED BY M Jenkins Business Manager APPROVED BY N Grigsby Authorised Signatory DATED 22 June 2012 This report has been up issued to Issue 2 to correct a typing error Document 75917027 Report 13 Issue 2 Page 2 of 50 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE CONTENTS Section Page No 1 2 REPORT SUMMARY ................................................................................................................... 3 1.1 Introduction .................................................................................................................................... 4 1.2 Brief Summary of Results .............................................................................................................. 5 1.3 Test Results Summary .................................................................................................................. 5 1.4 Product Information ....................................................................................................................... 9 1.5 FCC Power Measurements ......................................................................................................... 11 3 TEST DETAILS .......................................................................................................................... 13 2.1 SARA 2 SAR Measurement System ........................................................................................... 14 2.2 CDMA2000 800MHz Head SAR Test Results and Course Area Scans – 2D ............................ 20 2.3 CDMA2000 800MHz Head SAR Test Results and Course Area Scans – 2D ........................... 24 2.4 CDMA2000 800MHz Body SAR Test Results and Course Area Scans – 2D ............................. 25 2.5 PCS 1900MHz Head SAR Test Results and Course Area Scans – 2D ...................................... 27 2.6 PCS 1900MHz Head SAR Test Results and Course Area Scans – 2D ...................................... 31 2.7 PCS 1900MHz Body SAR Test Results and Course Area Scans – 2D ...................................... 32 2.8 WLAN 2450MHz Head SAR Test Results and Course Area Scans – 2D ................................... 34 2.9 WLAN 2450MHz Head SAR Test Results and Course Area Scans – 2D .................................. 38 2.10 WLAN 2450MHz Body SAR Test Results and Course Area Scans – 2D ................................... 39 4 TEST EQUIPMENT USED ......................................................................................................... 41 3.1 Test Equipment Used .................................................................................................................. 42 3.2 Test Software ............................................................................................................................... 43 3.3 Dielectric Properties of Simulant Liquids ..................................................................................... 44 3.4 Test Conditions ............................................................................................................................ 45 3.5 Measurement Uncertainty............................................................................................................ 46 5 ACCREDITATION, DISCLAIMERS AND COPYRIGHT ............................................................ 49 4.1 Accreditation, Disclaimers and Copyright .................................................................................... 50 ANNEX A Probe Calibration Report .......................................................................................................... A.2 Document 75917027 Report 13 Issue 2 Page 3 of 50 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE SECTION 1 REPORT SUMMARY Specific Absorption Rate Testing of the Sharp CDMA SHI15 Dual-band CDMA (BC0, BC6) and Tri-band GSM (GSM900/DCS1800/PCS1900) Dual mode Cellular Phone with Bluetooth, Felica, WLAN and GPS Document 75917027 Report 13 Issue 2 Page 4 of 50 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE 1.1 INTRODUCTION The information contained in this report is intended to show verification of the Specific Absorption Rate Testing of the Sharp CDMA SHI15 Dual-band CDMA (BC0, BC6) and Tri-band GSM (GSM900/DCS1800/PCS1900) Dual mode Cellular Phone with Bluetooth, Felica, WLAN and GPS Mobile Handset to the requirements of OET Bulletin 65 Supplement C Edition 01-01. Objective To perform Specific Absorption Rate Testing to determine the Equipment Under Test's (EUT’s) compliance with the requirements specified of OET Bulletin 65 Supplement C Edition 01-01, for the series of tests carried out. Applicant Sharp Communication Compliance Ltd Manufacturer Sharp Corporation Manufacturing Description Mobile Handset Model Number CDMA SHI15 Power Class CDMA2000 Class 0 PCS 1900 MHz Class 1 GPRS Class B GPRS Multi-slot Class 10 Serial/IMEI Number(s) 004401114000181 004401114000199 004401114000231 Number of Samples Tested 3 Hardware Version PP2 Software Version D4232/A4200/A5220 Battery Cell Manufacturer Sharp Corporation Battery Model Number SHI15UAA Test Specification/Issue/Date FCC OET65 C:2001 S…
