To: Ben Ho ITS/ES-HKG Cc: Wilson Loke ITS/ES-HKG Subject: RE: Musical Electronics FCC ID: AUIBU80 Dear Ben: Thank you for this clarification, and for indicating where the DC power information is found. We can proceed to certification today. Regards, Roland -----Original Message----- From: Ben Ho ITS/ES-HKG Sent: Wednesday, September 05, 2001 2:17 AM To: Roland Gubisch ITS/ES-Box Cc: Wilson Loke ITS/ES-HKG Subject: RE: Musical Electronics FCC ID: AUIBU80 Dear Roland, Our reply is as follow: (1) The input current to the EUT at 6.0V d.c. is 200mA and this information has already mentioned in 1.1 Product description. (2) Since the worst case configuration is not the one that the EUT is connected with the external microphone and headset, the configuration photo only showed the EUT connected with the adaptor during the test and we will revise 2.3 as follow: "A special headset provided by client has been used during testing but the worst case configuration was the one with the EUT not connected with the headset." We hope that they can help to complete the review of the captioned application. Thanks. Best regards Ben Ho << File: report(revised).doc >> -----Original Message----- From: Roland Gubisch ITS/ES-Box Sent: Wednesday, September 05, 2001 5:01 AM To: Wilson Loke ITS/ES-HKG Cc: Danielle Gravelle ITS/ES-Box Subject: Musical Electronics FCC ID: AUIBU80 Dear Wilson: Technical review of this application is complete, and we note the following: 1) 2.1033(c)(8) DC voltage and current into final RF stage is missing or cannot be found, please provide. 2) Instruction manual indicates that external microphone and headset are available for this device, but the configuration photos do not show the device tested with them. The test report mentions a "special headset" but does not indicate that the EUT was tested with one. Attachment of these devices might affect spurious emissions compliance. Please explain. Regards, Roland

Test SetupFCCID : AUIBU80 External Photo -front External Photo - rear

Test SetupFCCID : AUIBU80 Internal Photo - 1 Internal Photo - 2 Test SetupFCCID : AUIBU80 Internal Photo - 3 Internal Photo - 4

Inte rte k Te sting Se rvice s Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 August 31, 2001 Musical Electronics Limited 5/F., Wider Industrial Building, 58 Tsun Yip Street, Kwun Tong, Kowloon, Hong Kong. Dear Mr. C. Cheuk: Enclosed you will find your file copy of a Part 95 Certification (FCC ID: AUIBU80). For your reference, TCB will normally take another 20 days for reviewing the report. Approval will then be granted when no query is sorted. Please contact me if you have any questions regarding the enclosed material. Sincerely, Wilson Loke Manager Enclosure • The test results rep orted in this rep ort shall refer only to the samp le actually tested and shall not refer or be deemed a refer to bulk from which such a samp le may be said to have been obtained. • This rep ort shall not be rep roduced excep t in full without p rior authorization from Intertek Testing Services Hong Kong Limit ed • For Terms And Conditions of the services, it can be p rovided up on request. Inte rte k Te sting Se rvice s Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Musical Electronics Limited Application For Certification (FCC ID: AUIBU80) August 31, 2001 WO# 0109969 WL/Sandy August 31, 2001 INTERTEK TESTING SERVICES FCC ID: AUIBU80 i SUMMARY OF CONTENTS LIST OF EXHIBITS EXHIBIT 1 :General Description EXHIBIT 2 :System Test Configuration EXHIBIT 3 :RF Power Output EXHIBIT 4 :Modulation Characteristics EXHIBIT 5 :Occupied Bandwidth EXHIBIT 6 :Spurious Emission and Conducted Emission EXHIBIT 7 :Frequency Stability EXHIBIT 8 :Technical Specifications EXHIBIT 9 :Product Labelling EXHIBIT 10 :Photographs EXHIBIT 11: Instruction Manual EXHIBIT 12: Tune Up Procedure EXHIBIT 13: Part List INTERTEK TESTING SERVICES FCC ID: AUIBU80 ii MEASUREMENT/TECHNICAL REPORT Application: Musical Electronics Limited Trade Name/Model No : MUSICAL BU80 MEMOREX MK1800 Date: August 31, 2001 This report concerns (check one:)Original Grant X Class II Change Equipment Type: Family Radio Service, FRS Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Report prepared by:Wilson Loke Intertek Testing Services 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Phone: 852-2173-8575 Fax:852-2745-8306 INTERTEK TESTING SERVICES FCC ID: AUIBU80 iii Table of Contents 1.0 General Description ...........................................................................................................2 1.1 Product Description .......................................................................................................2 1.2 Ralated Submittal(s) Grants ...........................................................................................3 1.3 Test Methodology ..........................................................................................................3 1.4 Test Facility....................................................................................................................3 2.0 System Test Configuration .................................................................................................5 2.1 Justification ....................................................................................................................5 2.2 EUT Exercising Software ...............................................................................................6 2.3 Special Accessories ........................................................................................................6 2.4 Equipment Modification ................................................................................................6 3.0 RF Output Power (Section 95.639(d)) ..............................................................................8 4.0 Modulation Characteristics (Section 95.637(a)) ............................................................12 4.1 Modulation Frequiency Response ................................................................................14 4.2 Modulation Limiting Characteristic..............................................................................16 4.3 Audio Low Pass Filter Response..................................................................................17 5.0 Occupied Bandwidth (Section 95.633(c) .........................................................................19 6.0 Spurious Emission (Section 95.635(b)) and Conducted Emission (Section 15.207) ....21 6.1 Field Strength of Spurious Radiation ...........................................................................22 6.2 Conducted Emission ....................................................................................................27 7.0 Frequency Stability (Section 95.627) ..............................................................................29 7.1 Frequency Tolerance ....................................................................................................30 7.2 Temperature Extreme Condition ..................................................................................33 7.3 Voltage Extreme Condition ..........................................................................................36 8.0 Technical Specifications ...................................................................................................39 9.0 Product Labelling .............................................................................................................43 10.0 Equipment Photographs ................................................................................................46 11.0 Instruction Mannal .........................................................................................................48 12.0 Tune Up Procedure ............................…

Text truncated - open the document above for the full version.

Modulation Frequency Response 0.00 0.50 1.00 1.50 2.00 2.50 3.00 20070012001700220027003200370042004700 Modulation Frequency (Hz) Frequency Deviation (kHz) Modulation Frequency Response 0.00 1.00 2.00 3.00 4.00 5.00 6.00 20070012001700220027003200370042004700 Modulation Frequency (Hz) Modulation Index (%)

Modulation Limiting Characteristic 0.00 0.50 1.00 1.50 2.00 2.50 3.00 475767778797107117127137 Modulation Input (dBSPL) Frequency Deviation (kHz) 500Hz 1000Hz 2500Hz 3125Hz

Audio Low Pass Filter Response -60.0 -50.0 -40.0 -30.0 -20.0 -10.0 0.0 110100 Frequency (kHz) dB relative to 1 kHz LPF Response TIA/EIA-603
