TABLE OF CONTENTS LIST APPLICANT: MUSICAL ELECTRONICS LTD. FCC ID: AUIFRS-100 TEST REPORT: PAGE 1......COVER SHEET - GENERAL INFORMATION & TECHNICAL DESCR. PAGE 2......TECHNICAL DESCRIPTION CONTD. & RF POWER OUTPUT PAGE 3......MODULATION CHARACTERISTICS & OCCUPIED BANDWIDTH PAGE 4......OCCUPIED BANDWIDTH METHOD OF MEASUREMENT PAGE 5......SPURIOUS EMISSIONS AT ANTENNA TERMINALS AND FIELD STRENGTH OF SPURIOUS EMISSIONS PAGE 6......METHOD OF MEASURING RADIATED SPURIOUS EMISSIONS PAGE 7......FREQUENCY STABILITY PAGE 8......LIST OF TEST EQUIPMENT EXHIBITS CONTAINING: EXHIBIT 1.........POWER OF ATTORNEY LETTER EXHIBIT 2.........FCC ID LABEL SAMPLE EXHIBIT 3.........SKETCH OF FCC ID LABEL LOCATION EXHIBIT 4A........EXTERNAL FRONT VIEW PHOTOGRAPH EXHIBIT 4B........EXTERNAL REAR VIEW PHOTOGRAPH EXHIBIT 4C........EXTERNAL SIDE VIEW PHOTOGRAPH EXHIBIT 4D........EXTERNAL TOP VIEW PHOTOGRAPH EXHIBIT 4E-F......INTERNAL CHASSIS/COMPONENT VIEW PHOTOGRAPH EXHIBIT 4G........INTERNAL SOLDER SIDE PHOTOGRAPH EXHIBIT 5.........BLOCK DIAGRAM EXHIBIT 6A-6H.....PARTS LIST EXHIBIT 7A-7B.....SCHEMATICS EXHIBIT 8A-8L.....USER'S MANUAL EXHIBIT 9.........AUDIO FREQUENCY RESPONSE GRAPH EXHIBIT 10A.......MODULATION LIMITING GRAPH - 300 Hz EXHIBIT 10B.......MODULATION LIMITING GRAPH - 1000 Hz EXHIBIT 10C.......MODULATION LIMITING GRAPH - 3000 Hz EXHIBIT 11........AUDIO LOW PASS FILTER GRAPH EXHIBIT 12........OCCUPIED BANDWIDTH CW PLOT EXHIBIT 13........OCCUPIED BANDWIDTH DEVIATION & CW PLOT EXHIBIT 14........OCCUPIED BANDWIDTH PLOT APPLICANT: MUSICAL ELECTRONICS LTD. FCC ID: AUIFRS-100 DATE: February 20, 2000 REPORT #: T:\CUS\M\MUSICAL\MUS46AK0\MUS46A0.RPT PAGE: TABLE OF CONTENTS GENERAL_INFORMATION_REQUIRED FOR_TYPE_ACCEPTANCE 2.1033(c)(1)(2)MUSICAL ELECTRONICS LTD. will manufacture the FCCID: AUIFRS-100 FAMILY RADIO SERVICES 14 CHANNEL TRANSCEIVER in quantity, for use under FCC RULES PART 95. 2.1033 (c) TECHNICAL_DESCRIPTION 2.1033(c)(3) Instruction book. A draft copy of the instruction manual is included as EXHIBIT 8. 2.1033(c) (4) Type of Emission: 9K6F3E 95.629 Bn = 2M + 2DK M = 3000 D = 1.9K Bn = 2(3.0)+2(1.9) = 9.8K Authorized Bandwidth 12.5KHz 2.1033(c)(5) Frequency Range: 1. 462.5625 8. 467.5625 95.627 2. 462.5875 9. 467.5875 3. 462.6125 10. 467.6125 4. 462.6375 11. 467.6375 5. 462.6625 12. 467.6625 6. 462.6875 13. 467.6875 7. 462.7125 14. 467.7125 MHz 2.1033(c)(6)(7) Power Output shall not exceed 0.500Watts effective 95.637 radiated power. There can be no provisions for 95.647 increasing the power or varing the power. The Maximum Output Power Rating: 500 milliWatts effective radiated power. 95.645 The antenna is an intergral part to the unit, it cannot be removed without rendering the unit inoperative. In order to remove the antenna the case must unscrewed, then the PCB assemblies must be removed then the antenna can be removed. 2.1033(c)(8) DC Voltages and Current into Final Amplifier: FINAL AMPLIFIER ONLY Vce = 4.5 Volts DC Ice = 0.12A. Pin = 0.54 Watts 2.1033(c)(9) Tune-up procedure. The tune-up procedure is included INCLUDED IN USER'S MANUAL. APPLICANT: MUSICAL ELECTRONICS LTD. FCC ID: AUIFRS-100 REPORT #: T:\CUS\M\MUSICAL\MUS46AK0\MUS46A0.RPT PAGE #: 1 2.1033(c)(10) Complete Circuit Diagrams: The circuit diagram is included as EXHIBIT 7 of this report. The block diagrams are included as EXHIBIT 5 of this report. 2.1033(c)(11) A photograph or a drwaing of the equipment identifica- tion label is included as exhibit No. 2. 2.1033(c)(12) Photographs(8"X10") of the equipment of sufficient clarity to reveal equipment construction and layout, including meters, labels for controls, including any view under shields. 2.1033(c)(13) Digital modulation is not allowed. 2.1033(c)(14) The data required by 2.1046 through 2.1057 is submitted below. 2.1046(a) RF_power_output. 95.637 RF power is measured by measuring the radiated power at 3 meters and then replacing the transmitter with a signal generator to determine the effective radiated power. The ERP shall not exceed 0.500 Watts. MEASURED POWER OUTPUT = 500 milliWatts ERP R.F. POWER OUTPUT HP TEST SET UP Spectrum Analyzer /-------\ /-----------------\ | | | | TRANSMITTER | | | | | UNDER TEST WITH | \--| | | INTERNAL ANTENNA| | | | \-----------------/ | | | | | \-------/ | | |<-- 3.0 meters-->| /-------------\ | SIGNAL | DIPOLE | Tuned, Calibrated | GENERATOR | ANTENNA | Antenna which may | |----------/ be raised from 1 \-------------/ to 4 meters above ground and changed in polarization Equipment placed 1 meter above ground on a rotatable platform. APPLICANT: MUSICAL ELECTRONICS LTD. FCC ID: AUIFRS-100 REPORT #: T:\CUS\M\MUSICAL\MUS46AK0\MUS46A0.RPT PAGE #: 2 2.1047(a)(b) Modulation_characteristics: AUDIO_FREQUENCY_RESPONSE The audio frequency response was measured in ac- cordance with TIA/EIA Specification 603. The audio frequency response curve is shown on the next page. The audio signal was fed into a dummy microphone circuit and into the microphone connector. The input required to produce 30 percent modulation level was measured. See exhibit 9. 2.1047(b) Audio_input_versus_modulation The audio input level needed for a particular per- percentage of modulation was measured in accor- dance with TIA/EIA Specification 603. The audio input curves versus modulation are on the following pages. Curves are provided for audio input frequen- cies of 300, 1000, and 3000 Hz. See Exhibit 10A-10C. 95.635(b) Post Limiter Filter. The filter must be between the modulation limiter and the modulated stage. At any frequency between 3 & 20KHz the filter must have an attenuation of 60log (f/3) greater tha the attenuation at 1KHz. See exhibit 11. 2.989(c) EMISSION BANDWIDTH: 95.633(b)(1)(3)(7) Data in the plots shows that the sidebands from greater than 50% to 100% of the authorized bandwidth must be attenuated by at least 25dB and from 100 to 250% the sidebands must be attenuated by at least 35dB. Beyond 250% the sidebands must be attenuated by at least 43+log10(TP). The transmitter was mo…

Text truncated - open the document above for the full version.

Musical Electronics AUIFRS-100 0 5 10 15 20 25 30 100100010000 Frequency rms mVolts audio response

Modulation Limiting Musical Electronics AUIFRS-100 0 500 1000 1500 2000 00.050.10.150.20.250.3 rms Volts Deviation 300 Hz

Modulation Limiting Musical Electronics AUIFRS-100 0 500 1000 1500 2000 00.010.020.030.040.050.06 rms Volts Deviatio n 1000 Hz

Modulation Limiting Musical Electronics AUIFRS-100 0 500 1000 1500 2000 00.0020.0040.0060.0080.01 rms Volts Deviation 3000 Hz
