AUIFRS300A114 Channel Family Radio Service (FRS)

Modulation Frequency Response 0.00 0.20 0.40 0.60 0.80 1.00 1.20 1.40 1.60 1.80 2.00 200300400500600700800900 10001250150017502000225025002750300031253250350040005000 Modulation Frequency (Hz) Frquency Deviation (kHz) Modulation Frequency Response -0.10 0.10 0.30 0.50 0.70 0.90 1.10 1.30 1.50 200300400500600700800900 10001250150017502000225025002750300031253250350040005000 Modulation Frequency (Hz) Modulation index (%)

Modulation Limiting Characteristic 0.00 0.20 0.40 0.60 0.80 1.00 1.20 1.40 1.60 1.80 2.00 475767778797107117127 Modulation Input (dBSPL) Frequency Deviation (kHz) 500Hz 1000Hz 2500Hz 3125Hz

• Inte rte k Te sting Se rvice s Hong Kong Ltd. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Tel: (852) 2173 8888 Fax: (852) 2785 5487 Musical Electronics Limited Application For Certification (FCC ID: AUIFRS300A1) 14 June, 2000 WO# 0006098 WL/at 14 June, 2000 INTERTEK TESTING SERVICES FCC ID: AUIFRS300A1 i SUMMARY OF CONTENTS LIST OF EXHIBITS EXHIBIT 1 :General Description EXHIBIT 2 :System Test Configuration EXHIBIT 3 :RF Power Output EXHIBIT 4 :Modulation Characteristics EXHIBIT 5 :Occupied Bandwidth EXHIBIT 6 :Emission Spurious EXHIBIT 7 :Frequency Stability EXHIBIT 8 :Technical Specifications EXHIBIT 9 :Product Labelling EXHIBIT 10 :Photographs EXHIBIT 11: Instruction Manual INTERTEK TESTING SERVICES FCC ID: AUIFRS300A1 ii MEASUREMENT/TECHNICAL REPORT Application : Musical Electronics Limited Trade Name/Model No : Family Radio Service: 14 Channel Transceiver Date : 14 June, 2000 This report concerns (check one:)Original Grant X Class II Change Equipment Type: Family Radio Service, FRS Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Report prepared by:Wilson Loke Intertek Testing Services. 2/F., Garment Centre, 576 Castle Peak Road, Kowloon, Hong Kong. Phone: 852-2173-8575 Fax:852-2745-8306 INTERTEK TESTING SERVICES FCC ID: AUIFRS300A1 iii Table of Contents 1.0 General Description ................................................................................................................ 2 1.1 Product Description ............................................................................................................2 1.2 Ralated Submittal(s) Grants ................................................................................................ 3 1.3 Test Methodology ...............................................................................................................3 1.4 Test Facility......................................................................................................................... 3 2.0 System Test Configuration ...................................................................................................... 5 2.1 Justification ......................................................................................................................... 5 2.2 EUT Exercising Software .................................................................................................... 6 2.3 Special Accessories .............................................................................................................6 2.4 Equipment Modification ..................................................................................................... 6 3.0 RF Output Power (Section 95.639(d) ..................................................................................... 8 4.0 Modulation Characteristics (Section 95.637(a)) ................................................................. 12 4.1 Modulation Frequiency Response ..................................................................................... 14 4.2 Modulation Limiting Characteristic................................................................................... 16 5.0 Occupied Bandwidth (Section 95.633(c) .............................................................................. 17 6.0 Spurious Emission (Section 95.635(b)) ................................................................................ 20 6.1 Field Strength of Spurious Radiation ................................................................................ 21 7.0 Frequency Stanility (Section 95.627) ................................................................................... 27 7.1 Frequency Tolerance ......................................................................................................... 28 7.2 Voltage Extreme Condition ............................................................................................... 30 7.3 Temperature Extreme Condition ....................................................................................... 33 8.0 Technical Specifications ........................................................................................................ 36 9.0 Product Labelling .................................................................................................................. 40 10.0 Equipment Photographs ..................................................................................................... 43 11.0 Instruction Mannal .............................................................................................................. 45 INTERTEK TESTING SERVICES FCC ID: AUIFRS300A1 iv List of attached file Exhibit typeFile DescriptionFilename Cover LetterLetter of Agencyletter.pdf Operation DescriptionTechnical Descriptiondescri.pdf Test ReportBandwidth Plotbw.pdf Test ReportModulation Frequency Responsemfr.pdf Test ReportModulation Limit Characteristicmlc.pdf Test ReportSpurious Emissionspurious.pdf Block DiagramBlock Diagramblock.pdf SchematicsCircuit Diagramcircuit.pdf ID Label/LocationLabel Artwork and Locationlabel.pdf User ManualUser Manualmanual.pdf Test ReportTest Reportreport.doc Test Setup PhotoRadiated Emissionradiated1.jpg to radiated2.jpg Internal PhotoInternal Photoiphoto1.jpg to iphoto2.jpg External PhotoExternal Photoophoto1.jpg to ophoto2.jpg INTERTEK TESTING SERVICES FCC ID: AUIFRS300A1 1 EXHIBIT 1 GENERAL DESCRIPTION INTERTEK TESTING SERVICES FCC ID: AUIFRS300A1 2 1.0 General Description 1.1 Product Description The Equipment Under Test (EUT) is a 14 Channel Family Radio Service (FRS) Transceiver operating from 462.5625 MHz to 467.7125 MHz. The EUT is powered by 6V battery (4 x “AAA” battery). Transmitter portion: i) Type of Emission: F3E ii) Frequency Range: 462.5625 MHz to 467.7125 MHz iii) Maximum Power Rating: 0.…
