CR7015A Medley Entertainment Center Instruction Manual Questions, problems, missing parts? Before returning to the store, call Customer Service 8 a.m. – 6 p.m., EST, Monday – Friday 1-888-CROSLEY www.crosleyradio.com English 2 Safety Instructions Read and understand this entire manual before using this product. Keep these instructions for future reference. 1. Do not use this product near water. 2. This product should be operated only by the type of power source indicated on the marking label or in this instruction manual. 3. Do not defeat the safety purpose of the polarized plug. A polarized plug has two blades with one blade wider than the other. This plug will fit into the power outlet only one way. If you are unable to insert the plug fully into the outlet try reversing the plug. If the plug should still fail to fit, contact your electrician. 4. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the product. 5. Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock. 6. Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product. 7. Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 8. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 9. Do not use attachments not recommended by the product manufacturer as they may cause hazards. 10. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn. 11. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating. Do not block or cover these openings. 12. Unplug the product during lightning storms or when unused for long periods of time. English 3 Items in this package Before throwing away any packaging materials, please check thoroughly and make sure you find the following items that come along with this package:  Turntable  45 RPM adapter  3.5mm aux in cable Please contact Crosley customer service if there is any accessory missing from the package. Retain the original packaging materials for exchange or return purposes. Specifications Power 120V, 60Hz Power consumption 18W Speaker 3.5”, 8Ω, 5W x 2 Turntable speed 33 1 / 3 , 45, 78 RPM Replacement needle Crosley NP6 Note:  Design and specifications are subject to change without notice.  To help save power consumption, some models will comply with ERP energy saving standard. When there is no audio input for 20 minutes, their powers will automatically cut-off. To turn power back on and resume playing, you will need to turn off the power and turn it on again. English 4 Product Description 1. Speakers 2. Dial Scale 3. Volume Knob 4. CD Door Open/Close Button 5. Power Button 6. Aux In Jack 7. Play Indicator 8. Play/Pause Button 9. Stop Button 10. Repeat Indicator 11. Repeat Button 12. LED Display 13. Program Button 14. Program Indicator 15. Backward Skip Button 16. Forward Skip Button 17. CD Tray 18. Headphone Jack 19. Function Knob 20. AM/FM Button 21. Tuning Knob 22. Bluetooth Indicator 23. Turntable Platter 24. Turntable Spindle 25. 45 RPM Adapter 26. Tonearm Lever 27. Tonearm 28. Auto-stop Switch 29. Speed Switch 30. Hold Down Clip 31. Tonearm Rest English 5 32. External Antenna 33. Power Cord Plug 34. Cassette Eject/Fast Forward Button 35. Cassette Door English 6 Initial Setup Essential Setup 1. Place the unit on a flat and level surface. The selected location should be stable and free from vibration. 2. Remove the tie-wrap that is holding the tonearm. 3. Plug the power cord to the power outlet. Aux Input Connection You can connect an audio device to this unit and play your music through its speakers. To do this, connect the 3.5mm auxiliary cable between your audio device and the Aux In Jack of this unit and start playing the music. Note: The aux in connection has the highest priority of all the functions. When there is an auxiliary cable plugged in, the aux in connection will automatically override the Bluetooth, turntable, CD, radio or cassette mode. To resume using the other features of the unit, unplug the auxiliary cable from the aux in jack. Bluetooth Operation 1. Set the Function Knob to the Bluetooth position, you will hear an activation sound from the unit. 2. Turn on the Bluetooth feature of your audio device, search for “CROSLEY CR7015A” and pair. 3. Once your device is successfully paired with the unit, you will hear a short confirmation sound from the unit. 4. Play and stream music from your device to the unit. Note:  Bluetooth version – 5.0 English 7 Turntable Operation 1. Press the Power Button to turn on the power. 2. Set the Function Knob to the TAPE/PHONO position. Note: If a tape is inserted the tape will play instead of the turntable. 3. Set the Speed Switch accordingly. 4. Place the record on the turntable. Use the 45 RPM Adapter if necessary. 5. Remove the stylus protector from the stylus assembly. Note: To avoid stylus damage, make certain the included stylus guard is in place whenever the turntable is being moved or cleaned. 6. Release the tonearm Hold Down Clip. Note: When the turntable is not in use, remember to lock back the hold down clip. 7. Use the Tonearm Lever to lift up the tonearm. 8. Gently move the tonearm over the record where play is desired to begin. Set the Tonearm Lever back to the down position, the tonearm will descend slowly onto the record and begin to playback. 9. When the record is finished p…

Text truncated - open the document above for the full version.

Model Difference Declaration To Whom It May Concern, We, Modern Marketing Concepts, Inc. Product: Medley Entertainment Center Trademark: CROSLEY Model Number: CR7015A-WA, CR7015X-XXXX All model’s the function, software and electric circuit are the same, X-XXXX represents the color, they be replaced by letter from “A” to “Z”, number from “0” to “9” or blank Test sample model: CR7015A-WA Please contact me if you have any question. Name: Scott McWhorter Date: May 15, 2020 Title: Director of Engineering Signature of applicant:

Date: May 15, 2020 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: __ AUSCR7015A ____ Product Name: _ Medley Entertainment Center _ Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Scott McWhorter Title: Director of Engineering Company: Modern Marketing Concepts, Inc.

Date: May 15, 2020 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen CTB Testing Technology Co., Ltd. Add: Floor 1&2, Building A, No. 26 of Xinhe Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Modern Marketing Concepts, Inc. Add: 1220 E Oak, St. Louisville, Kentucky, United States 40204 <Signature> Name: Scott McWhorter Title: Director of Engineering Company: Modern Marketing Concepts, Inc.

M/N: CR7015A-WA M/N: CR7015A-WA M/N: CR7015A-WA

FCC ID LABEL: Label Location: FCC ID: AUSCR7015A Product name: Eclipse Entertainment Center Model No.: CR7015A-WA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Long:3cm Width:2cm

M/N: CR7015A-WA M/N: CR7015A-WA M/N: CR7015A-WA M/N: CR7015A-WA M/N: CR7015A-WA M/N: CR7015A-WA PCB Ant.

RF EXPOSURE EVALUATION 1. Standard Requirement According to KDB447498D01 General RF Exposure Guidance v06 Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1- g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 2. Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] .[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. 3. Test Result The max conducted power including tune-up tolerance is 4.391dBm (2.749mW). [(max.power of channel, mw)/(min. test separation distance, mm)][ √f(GHz)] =2.749/5*(√2.402)=0.852<3.0 Then SAR evaluation is not required

Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB200429010RFX TEST REPORT Compiled by: Reviewed by: Approved by: Victory Rita Xiao Sherwin Qian/ Director The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen HUAK Testing Technology Co., Ltd. this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Medley Entertainment Center FCC ID: AUSCR7015A Trademark: CROSLEY Model Number: CR7015A-WA, CR7015X-XXXX (X-XXXX can be replaced by letter from “A” to “Z”, number from “0” to “9” or blank) Prepared For: Modern Marketing Concepts, Inc Address: 1220 E Oak, St. Louisville, KY 40204 United States Manufacturer: Timsen Development Limited Address: 5F, 447# Tianhebei Road, Guangzhou, China Prepared By: Shenzhen CTB Testing Technology Co., Ltd. Address: Floor 1&2, Building A, No. 26 of Xinhe Road, Xinqiao Community, Xinqiao Street, Baoan District, Shenzhen, Guangdong China Sample Received Date: Apr. 26, 2020 Sample tested Date: Apr. 26, 2020 to Apr. 30, 2020 Issue Date: Apr. 30, 2020 Report No.: CTB200429010RFX Test Standards FCC Part15.247 ANSI C63.10:2013 Test Results PASS Remark: This is Bluetooth radio test report. Report Tel: 4008-258-120 Web: http://www.ctb-lab.com Page 1 of 36 Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB200429010RFX TABLE OF CONTENT Test Report Declaration Page 1. VERSION ............................................................................................................ 4 2. TEST SUMMARY ............................................................................................... 5 3. MEASUREMENT UNCERTAINTY ...................................................................... 6 4. PRODUCT INFORMATION AND TEST SETUP ................................................. 7 4.1 Product Information .............................................................................................. 7 4.2 Test Setup Configuration ...................................................................................... 7 4.3 Support Equipment ............................................................................................... 7 4.4 Channel List .......................................................................................................... 8 4.5 Test Mode ............................................................................................................. 8 4.6 Test Environment .................................................................................................. 8 5. TEST FACILITY AND TEST INSTRUMENT USED ............................................. 9 5.1 Test Facility .......................................................................................................... 9 5.2 Test Instrument Used ........................................................................................... 9 6. AC POWER LINE CONDUCTED EMISSION ..................................................... 11 6.1 Block Diagram Of Test Setup ............................................................................. 11 6.2 Limit .................................................................................................................... 11 6.3 Test procedure.................................................................................................... 11 6.4 Test Result ......................................................................................................... 13 7. RADIATED SPURIOUS EMISSION .................................................................. 15 7.1 Block Diagram Of Test Setup ............................................................................. 15 7.2 Limit .................................................................................................................... 15 7.3 Test procedure.................................................................................................... 16 7.4 Test Result ......................................................................................................... 17 8. BAND EDGE AND RF COUNDUCTED SPURIOUS EMISSIONS ..................... 24 8.1 Block Diagram Of Test Setup ............................................................................. 24 8.2 Limit .................................................................................................................... 24 8.3 Test procedure.................................................................................................... 24 8.4 Test Result ......................................................................................................... 25 9. COUDUCTED PEAK OUTPUT POWER ........................................................... 27 9.1 Block Diagram Of Test Setup ............................................................................. 27 Report Tel: 4008-258-120 Web: http://www.ctb-lab.com Page 2 of 36 Shenzhen CTB Testing Technology Co., Ltd. Report No.: CTB200429010RFX 9.2 Limit .................................................................................................................... 27 9.3 Test procedure.................................................................................................... 27 9.4 Test Result ......................................................................................................... 28 10. 6DB OCCUPIED BANDWIDTH ........................................................................ 30 10.1 Block Diagram Of Test Setup ........................................................................... 30 10.2 Limit .................................................................................................................. 30 10.3 Test procedure .................................................................................................. 30 10.4 Test Result........................................…

Text truncated - open the document above for the full version.
