AUSCR8009TMDiscovery Turntable

CR8009B-GLC Discovery Turntable Instruction Manual Questions, problems, missing parts? Before returning to the store, call Customer Service 8 a.m. – 6 p.m., EST, Monday – Friday 1-888-CROSLEY www.crosleyradio.com English 2 Safety Instructions Read and understand this entire manual before using this product. Keep these instructions for future reference. 1. Do not use this product near water. 2. This product should be operated only by the type of power source indicated on the marking label or in this instruction manual. 3. Do not defeat the safety purpose of the polarized plug. A polarized plug has two blades with one blade wider than the other. This plug will fit into the power outlet only one way. If you are unable to insert the plug fully into the outlet try reversing the plug. If the plug should still fail to fit, contact your electrician. 4. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the product. 5. Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock. 6. Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product. 7. Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 8. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 9. Do not use attachments not recommended by the product manufacturer as they may cause hazards. 10. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn. 11. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating. Do not block or cover these openings. 12. Unplug the product during lightning storm or when unused for long periods of time. English 3 Items in this package Before throwing away any packaging materials, please check thoroughly and make sure you find the following items that come along with this package: • Turntable • 45 RPM adapter • Power adaptor Please contact Crosley customer service if there is any accessory missing from the package. Retain the original packaging materials for exchange or return purposes. Specifications Power AC power adaptor, DC output 5 V 1 A Power consumption 9 W Speaker 4Ω, 3W x 2 Turntable speed 33 1 / 3 , 45, 78 RPM Replacement needle Crosley NP6 Note: • Design and specifications are subject to change without notice. • To help save power consumption, some models will comply with ERP energy saving standard. When there is no audio input for 20 minutes, their powers will automatically cut-off. To turn power back on and resume playing, you will need to turn off the power and turn it on again. English 4 Product Description 1. Turntable Platter 2. Turntable Spindle 3. Tonearm Lever 4. Tonearm 5. Function Switch 6. Function Indicator 7. Auto-stop Switch 8. Speed Switch 9. Pitch Control 10. Hold Down Clip 11. On/Off-Volume Knob 12. Headphone Jack 13. Aux In Jack 14. RCA Jacks 15. Power Jack 16. 45 RPM Adapter English 5 Initial Setup Essential Setup 1. Place the unit on a flat and level surface. The selected location should be stable and free from vibration. 2. Remove the tie-wrap that is holding the tonearm. 3. Connect AC adaptor to the Power Jack of the unit. Note: Do not plug the AC power adaptor to power outlet before all the assembly is completed. Before turning the power on, make sure again all the connection settings are correct. Always turn off the power when connecting or disconnecting. Stereo System Connection RCA Jacks • The RCA Jacks output analog line-level signals and could be connected directly with a pair of active/powered speakers or the appropriate input of your stereo system. • The Red plug connects with the Right channel and the White plug connects with the Left channel. Note: The RCA Jacks are not designed to be connected directly to passive/unpowered speakers. If connected to passive speakers, the volume level will be very low. Aux Input Connection You can connect an audio device to this unit and play your music through its speakers. To do this, connect the 3.5mm auxiliary cable between your audio device and the Aux In Jack of this unit and start playing the music. Note: The aux in connection will automatically override the turntable and Bluetooth functions. To resume using the turntable or Bluetooth functions, unplug the auxiliary cable from the aux in jack. The Function Indicator will be purple. English 6 Turntable Operation 1. Rotate the On/Off Volume Knob to turn on the power. 2. Set the Function Switch to PHONO position. Note: The Function Indicator will be red. 3. Set the Speed Switch accordingly. 4. Place the record on the turntable. Use the 45 RPM Adapter if necessary. 5. Remove the stylus protector from the stylus assembly. Note: To avoid stylus damage, make certain the included stylus guard is in place whenever the turntable is being moved or cleaned. 6. Release the tonearm Hold Down Clip. Note: when the turntable is not in use, remember to lock back hold down clip. 7. Use the Tonearm Lever to lift up the tonearm. 8. Gently move the tonearm over the record where play is desired to begin. Set the Tonearm Lever back to the down position, the tonearm will descend slowly onto the record and begin to playback. 9. When the record is finished playing, use the Tonearm Lever again to raise the tonearm and then return it to the Tonearm Rest. Release the lever to let the tonearm sit back at its rest. To suspend the playback, repeat the same steps. 10.…

Text truncated - open the document above for the full version.

Modern Marketing Concepts, Inc. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2021-09-15 Subject; Request for Long Term Confidentiality FCC ID: AUSCR8009TM To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Scott McWhorter Title: Director of Engineering

Modern Marketing Concepts, Inc. 1220 E Oak, St. Louisville, KY 40204 United States Statement Product: Discovery Turntable Model: CR8009B-GLC Additional Model: CR8009XX-XXXX (XX-XXXX can be replaced by letter from "A" to "Z", number from "0" to "9" or blank) Trademark : Crosley We hereby state that All models above are identical in interior structure, electrical circuits and components, and just model names and color are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, Signature: Date: 2021/09/15 Name: Scott McWhorter Company Name: Modern Marketing Concepts, Inc. Address: 1220 E Oak, St. Louisville, KY 40204 United States Tel / Fax: +1-502-212-4291/+1-502-212-4291 E-Mail: [email protected]

Modern Marketing Concepts, Inc. Company: Modern Marketing Concepts, Inc. Address: 1220 E Oak, St. Louisville, KY 40204 United States Product Name: Discovery Turntable According to KDB484596 D01 Referencing Test Data v01 requirements ， We Modern Marketing Concepts, Inc. Statement FCC ID: AUSCR8005DP, FCC ID: AUSCR8009TM and FCC ID: AUSCR8017TM that use identical internal printed circuit board layouts, have a common design and components, and where the separate FCC IDs differ only in appearance. The three separate FCC IDs adopt the same test data for different new equipment authorization application. We certify that the product meets the requirements of FCC part 15.247 and take full responsibility for the quoted test data. Technology frequency range (MHz) Original FCC ID and Test Report No. Reference FCC ID and Test Report No. emission designator BT2402-2480 FCC ID : AUSCR8005DP Test Report No.: TCT210728E020 FCC ID : AUSCR8009TM Test Report No.: TCT210728E022 FCC ID: AUSCR8017TM Test Report No.: TCT210728E024 DSS BLE2402-2480 FCC ID : AUSCR8005DP Test Report No.: TCT210728E034 FCC ID : AUSCR8009TM Test Report No.: TCT210728E035 FCC ID: AUSCR8017TM Test Report No.: TCT210728E036 DTS Signature: Date: 2021-09-15 Name: Scott McWhorter Title: Director of Engineering Company: Modern Marketing Concepts, Inc.

Page 1 of 5 Appendix C: Photographs of EUT Product: MOTO BUDS Product: Discovery Turntable Model: CR8009B-GLC External Photos Page 2 of 5 Page 3 of 5 Page 4 of 5 Page 5 of 5

Label Artwork and Location Model: CR8009B-GLC Label: Size: L*W=170*80mm Location

Page 1 of 5 Appendix C: Photographs of EUT Product: Discovery Turntable Model: CR8009B-GLC Internal Photos Page 2 of 5 Antenna Page 3 of 5 Page 4 of 5 Page 5 of 5

Maximum Permissible Exposure Applicable Standard According to §1.1307(b), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. Remark: 1)For BT: The maximum output power for antenna is 1.58dBm (1.44mW) at 2480MHz, 0dBi antenna gain(with 1.00 numeric antenna gain.) For BLE: The maximum output power for antenna is -2.75dBm (0.53mW) at 2402MHz, 0dBi antenna gain(with 1.00 numeric antenna gain.) 2) For mobile or fixed location transmitters, no SAR consideration applied. The minimum separation generally be used is at least 20cm, even if the calculation indicate that the MPE distance would be lesser. For BT: Maximum Permissible Exposure output power= 1.44mW Numeric Antenna gain= 1.00 Substituting the MPE safe distance using d=20cm into above equation. Yields: S=0.000199*P*G Where P=Power in mW G=Numeric antenna gain S=Power density in mW/cm 2 Power density= 0.000287mW/cm 2 For BLE: Maximum Permissible Exposure output power= 0.53mW Numeric Antenna gain= 1.00 Substituting the MPE safe distance using d=20cm into above equation. Yields: S=0.000199*P*G Where P=Power in mW G=Numeric antenna gain S=Power density in mW/cm 2 Power density= 0.000105mW/cm 2 (For mobile or fixed location transmitters, the maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger.)

Page 1 of 2 Appendix A: Photographs of Test Setup Product: Discovery Turntable Model: CR8009B-GLC Radiated Emission Page 2 of 2 Conducted Emission
