AUSCT102AAM/FM RADIO CASSETTE RECORDER

CT102A Cassette Player Instruction Manual Questions, problems, missing parts? Before returning to the store, call Customer Service 8 a.m. – 6 p.m., EST, Monday – Friday 1-888-CROSLEY www.crosleyradio.com English 2 Safety Instructions Read and understand this entire manual before using this product. Keep these instructions for future reference. 1. Do not use this product near water. 2. This product should be operated only by the type of power source indicated on the marking label or in this instruction manual. 3. Do not defeat the safety purpose of the polarized plug. A polarized plug has two blades with one blade wider than the other. This plug will fit into the power outlet only one way. If you are unable to insert the plug fully into the outlet try reversing the plug. If the plug should still fail to fit, contact your electrician. 4. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the product. 5. Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock. 6. Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product. 7. Do not attempt to service this product yourself as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel. 8. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. 9. Do not use attachments not recommended by the product manufacturer as they may cause hazards. 10. A product and cart combination should be moved with care. Quick stops, excessive force, and uneven surfaces may cause the product and cart combination to overturn. 11. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from overheating. Do not block or cover these openings. 12. Unplug the product during lightning storm or when unused for long periods of time. 13. This equipment is a Class II or double insulated electrical appliance. 14. This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock. English 3 15. Warning: To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts inside. Refer servicing to qualified personnel. 16. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance instructions in the literature accompanying the appliance. 17. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable. 18. WARNING: replacement of a BATTERY with an incorrect type that can defeat a SAFEGUARD; 19. disposal of a BATTERY into fire or a hot oven, or mechanically crushing or cutting of a BATTERY, that can result in an EXPLOSION; 20. leaving a BATTERY in an extremely high temperature surrounding environment that can result in an EXPLOSION or the leakage of flammable liquid or gas; 21. A BATTERY subjected to extremely low air pressure that may result in an EXPLOSION or the leakage of flammable liquid or gas English 4 Items in this package Before throwing away any packaging materials, please check thoroughly and make sure you find the following items that come along with this package: • Cassette Player • Power plug Please contact Crosley customer service if there is any accessory missing from the package. Retain the original packaging materials for exchange or return purposes. Specifications Power AC 120V / 60Hz Battery Supply “C” X 4 (Not Included) Power Output 1.2 W Power consumption 5 W Speaker 8 Ω 2W 3” Frequency Range AM 540 – 1710 KHz FM 88 – 108 MHz Operational Temperature Range: 0°C to 70°C Note: • Design and specifications are subject to change without notice. • To help save power consumption, some models will comply with ERP energy saving standard. When there is no audio input for 20 minutes, their powers will automatically cut-off. To turn power back on and resume playing, you will need to turn off the power and turn it on again. English 5 Product Description 1. Dial Scale 2. Microphone 3. Cassette Tray 4. External Antenna 5. Function Switch 6. Pause Button 7. Stop/Eject Button 8. Rewind Button 9. Fast Forward Button 10. Play Button 11. Record Button 12. Band Switch 13. Volume Knob 14. Headphone Jack 15. Tuning Knob 16. Battery Compartment 17. Power Jack English 6 Radio Operation 1. Set the Function Switch to RADIO position 2. Set the Band Switch to FM or AM position. 3. Rotate the Tuning Knob for desired radio station. 4. To turn off the unit, set the Function Switch to the OFF/TAPE position and make sure none of the cassette button are pressed in. Note: • When operating FM band radio, pull up the TELESCOPIC ANTENNA, and adjust position to get better reception. Cassette Operation 1. Set the Function Switch to TAPE position. 2. Insert the prerecorded cassette into the cassette tray, and press the Play button. 3. To fast forward, press the Fast Forward button in. To stop fast forwarding and return to the playback mode, press the Play button. 4. To rewind, press the Rewind button in. To stop rewinding and return to the playback mode, press the Play button. 5. To stop the playback, press the Stop/Eject button once. To eject the cassette, press the Stop/Eject button again. 6. To turn off the unit, set the Function Switch to the OFF/TAPE position and make sure none of the cassette button are pressed in. Note: Remove the cassette from the cassette holder when it…

Text truncated - open the document above for the full version.

Modern Marketing Concepts Inc. August 12.2020 Federal Communications Commission 445 12th Street SW Washington, DC 20554 Subject: Limited Agency Agreement Modern Marketing Concepts Inc. FCC ID: AUSCT102A To Whom It May Concern: We, Modern Marketing Concepts Inc. hereby authorized Intertek Testing Services to act as our Agent for the purpose of preparing application for FCC ID number (AUSCT102A) under all applicable parts of the FCC rules and regulations. The effective date of this limited agency agreement is August 12, 2020. The Limited Agency Agreement expires on August 12, 2021, unless sooner terminated or extended by written notice to Intertek Testing Services and the Federal Communications Commission. This is to advise that we are in full compliance with the Anti-Drug Abuse Act. The applicant is not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 U.S.C. 862, and no party to the application is subject to a denial of federal benefits pursuant to that section. If you have any questions or comments, please do not hesitate to contact me. Sincerely, Scott McWhorter Vice President of Sourcing

Modern Marketing Concepts Inc. Attention: Certification reviewer RE: Request for Confidentiality FCC ID: AUSCT102A To Whom It May Concern: Permanent Confidentiality [Complete this section if permanent confidentiality is requested] Request to withhold permanently from public review certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept permanently confidential: [Select one or more of items below, as appropriate] Schematics Block Diagrams Operational Description Tune-up Procedure Parts List Internal Photos (see note) Users Manual (see note) Note 1: Internal Photos may be held confidential 1) if the circuit board or internal components are not accessible to users. For example, it is acceptable if the circuit board is enclosed in epoxy. 2) Also, it is acceptable if the device is not accessible to the public, for example, a device mounted on the top of a large tower (or in a fenced enclosure) such that it is only serviceable by professional designated technicians under a Non-Disclosure Agreement (NDA). All sales for these devices must be under a NDA restricting the disclosure of the propriety information, including internal photos. Users Manual may be held confidential only when the manual contains proprietary technical information intended for professional technicians obligated under a NDA. All sales and distribution of the user’s manual must be under a NDA that restricts the disclosure of the information. In the application cover letter requesting permanent confidentiality the following additional description and the NDA exhibit is required: 1. Describe in detail how internal photos and/or users manual information are controlled to prevent them from becoming public or disclosed to unauthorized persons. 2. Describe how public access is restricted for products serviceable by professional designated technicians. 3. A statement that all sales of the non-consumer device will be under a NDA to include third party sales and that the final user of the device is subject to the NDA. 4. Provide an example of the NDA between the grantee and a purchaser. The request for confidentiality must Note 2: For scanning receiver, the schematics, block diagrams, operational description, tune-up procedure, parts list and internal photos are always held permanently confidential. Short-term Confidentiality [Complete this section if short-term confidentiality is requested] Request to withhold from public review for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing, certain portions of the application for equipment certification for the referenced FCC identifiers. This request for confidentiality is made pursuant to 47 CFR 0.457(d) and 0.459 of the FCC Rules. In particular, the following sections of the application are to be kept short-term confidential for a period above from the date of the grant [Select one or more of items below that are not selected in the list above, as appropriate] Schematics Block diagrams Operational Description Tune-up Procedure Parts List Test Setup Photos External Photos Internal Photos Users Manual Rationale for request for confidentiality: We have invested considerable time and materials in research and development to produce the referenced product. Permanent confidentiality: Disclosure of the permanently confidential portions of this application to competitors would not only give them significant competitive advantages in developing similar products, but would also disclose successful implementation of unpublished, leading edge technology developed by us. Short-term confidentiality: Disclosure of the short-term confidential portions of this application during the period of importation and/or distribution would reveal key aspects of proprietary technology to competitors and diminish the value of our investment in research and development. If you have questions or need further information, please contact the undersigned. Sincerely, _________________ Scott McWhorter Vice President of Sourcing 8/19/2020

External Photos

MOdel:CT102A-RO 5W 35mm 42.5mm

Internal Photos Bluetooth Antenna

INTERTEK TESTING SERVICES RF Exposure The equipment under test (EUT) is an AM/FM RADIO CASSETTE RECORDER with Bluetooth 5.0 function operating in 2402-2480MHz. The EUT is powered by DC 4*1.5V UM-2 battery and charged by AC 120V/60Hz. For more detail information pls. refer to the user manual. Standalone SAR evaluation for BT function Bluetooth Version: 5.0 BR/EDR mode Antenna Type: Integral antenna Modulation Type: GFSK, p/4-DQPSK Antenna Gain: -0.58dBi Max The nominal conducted output power specified: -3.42dBm (+/-3dB) The nominal radiated output power (e.i.r.p) specified: -4dBm (+/- 3dB) According to the KDB 447498: The maximun peak radiated emission for the EUT is 93.6dBμV/m at 3m in the frequency 2402MHz The EIRP = [(FS*D) ^2 / 30] mW = -1.63dBm which is within the production variation. The minimum peak radiated emission for the EUT is 88.9dBμV/m at 3m in the frequency 2441MHz The EIRP = [(FS*D) ^2 / 30] mW = -6.33dBm which is within the production variation. The maximun conducted output power specified is -0.42dBm = 0.91mW The source- based time-averaging conducted output power = 0.91 * Duty factor mW (where Duty Factor≤1) = 0.91mW The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.480) mW = 9.53 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. FCC ID: AUSCT102A INTERTEK TESTING SERVICES Bluetooth Version: 5.0 BLE mode Antenna Type: Integral antenna Modulation Type: GFSK Antenna Gain: -0.58dBi Max The nominal conducted output power specified: -0.42dBm (+/-3dB) The nominal radiated output power (e.i.r.p) specified: -1dBm (+/- 3dB) According to the KDB 447498: The maximun peak radiated emission for the EUT is 94.5dBμV/m at 3m in the frequency 2402MHz The EIRP = [(FS*D) ^2 / 30] mW = -0.73dBm which is within the production variation. The minimum peak radiated emission for the EUT is 91.8dBμV/m at 3m in the frequency 2480MHz The EIRP = [(FS*D) ^2 / 30] mW = -3.43dBm which is within the production variation. The maximun conducted output power specified is 2.58dBm = 1.81mW The source- based time-averaging conducted output power = 1.81 * Duty factor mW (where Duty Factor≤1) = 1.81mW The SAR Exclusion Threshold Level: = 3.0 * (min. test separation distance, mm) / sqrt(freq. in GHz) = 3.0 * 5 / sqrt (2.480) mW = 9.53 mW Since the source-based time-averaging conducted output power is well below the SAR low threshold level, so the EUT is considered to comply with SAR requirement without testing. FCC ID: AUSCT102A

Modern Marketing Concepts Inc. TEST REPORT SCOPE OF WORK FCC TESTING–CT102, CT102A-XX, CT102X-XX (X/XX represents the color, they can be replaced by letter from A to Z or blank) REPORT NUMBER 200713014SZN-001 ISSUE DATE [REVISED DATE] August 6, 2020 [---------------------] PAGES 27 DOCUMENT CONTROL NUMBER FCC ID 249_C © 2017 INTERTEK Intertek Report No.: 200713014SZN-001 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen, P.R. China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01-November-2017 Page: 1 of 27 FCC ID 249_C Test Report Modern Marketing Concepts Inc. Application For Certification FCC ID: AUSCT102A AM/FM RADIO CASSETTE RECORDER Model: CT102, CT102A-XX, CT102X-XX (X/XX represents the color, they can be replaced by letter from A to Z or blank) Brand Name: CROSLEY 2.4GHz Transceiver Report No.: 200713014SZN-001 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-19] Prepared and Checked by: Approved by: Leo Li Project Engineer Kidd Yang Technical Supervisor Date: August 6, 2020 Intertek Report No.: 200713014SZN-001 Version: 01-November-2017 Page: 2 of 27 FCC ID 249_C Test Report MEASUREMENT/TECHNICAL REPORT This report concerns (check one:) Original Grant X Class II Change Equipment Type: DXX - Part 15 Low Power Communication Device Transmitter Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator − the new 47 CFR [10-1-19 Edition] provision. Report prepared by: Leo Li Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen, P.R. China Tel / Fax: 86-755-8614 0743/86-755-8601 6661 Intertek Report No.: 200713014SZN-001 Version: 01-November-2017 Page: 3 of 27 FCC ID 249_C Test Report Table of Contents 1.0 Summary of Test Result ................................................................................................. 4 2.0 General Description ...................................................................................................... 5 2.1 Product Description .................................................................................................... 5 2.2 Related Submittal(s) Grants ......................................................................................... 5 2.3 Test Methodology ...................................................................................................... 5 2.4 Test Facility ............................................................................................................... 5 3.0 System Test Configuration ............................................................................................. 6 3.1 Justification ............................................................................................................... 6 3.2 EUT Exercising Software .............................................................................................. 6 3.3 Special Accessories ..................................................................................................... 6 3.4 Equipment Modification .............................................................................................. 6 3.5 Measurement Uncertainty .......................................................................................... 7 3.6 Support Equipment List and Description ........................................................................ 7 4.0 Emission Results ........................................................................................................... 8 4.1 Radiated Test Results .................................................................................................. 8 4.1.1 Field Strength Calculation ......................................................................................... 8 4.1.2 Radiated Emission Configuration Photograph .............................................................. 9 4.1.3 Radiated Emissions .................................................................................................. 9 4.1.4 Transmitter Spurious Emissions ............................................................................... 12 4.2 Conducted Emission Configuration Photograph ............................................................ 16 4.2.1 Conducted Emission ............................................................................................... 16 5.0 Equipment Photographs .............................................................................................. 19 6.0 Product Labelling .......................................…

Text truncated - open the document above for the full version.

Modern Marketing Concepts Inc. TEST REPORT SCOPE OF WORK FCC TESTING–CT102, CT102A-XX, CT102X-XX (X/XX represents the color, they can be replaced by letter from A to Z or blank) REPORT NUMBER 200713014SZN-002 ISSUE DATE [REVISED DATE] August 6, 2020 [---------------------] PAGES 26 DOCUMENT CONTROL NUMBER FCC ID 249_C © 2017 INTERTEK Intertek Report No.: 200713014SZN-002 This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to permit copying or distribution of this report and then only in its entirety. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results in this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen, P.R. China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01-November-2017 Page: 1 of 26 FCC ID 249_C Test Report Modern Marketing Concepts Inc. Application For Certification FCC ID: AUSCT102A AM/FM RADIO CASSETTE RECORDER Model: CT102, CT102A-XX, CT102X-XX (X/XX represents the color, they can be replaced by letter from A to Z or blank) Brand Name: CROSLEY 2.4GHz Transceiver Report No.: 200713014SZN-002 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-19] Prepared and Checked by: Approved by: Leo Li Project Engineer Kidd Yang Technical Supervisor Date: August 6, 2020 Intertek Report No.: 200713014SZN-002 Version: 01-November-2017 Page: 2 of 26 FCC ID 249_C Test Report MEASUREMENT/TECHNICAL REPORT This report concerns (check one:) Original Grant X Class II Change Equipment Type: DXX - Part 15 Low Power Communication Device Transmitter Deferred grant requested per 47 CFR 0.457(d)(1)(ii)? Yes No X If yes, defer until: date Company Name agrees to notify the Commission by: date of the intended date of announcement of the product so that the grant can be issued on that date. Transition Rules Request per 15.37? Yes No X If no, assumed Part 15, Subpart C for intentional radiator − the new 47 CFR [10-1-19 Edition] provision. Report prepared by: Leo Li Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community, GuanHu Subdistrict, LongHua District, ShenZhen, P.R. China Tel / Fax: 86-755-8614 0743/86-755-8601 6661 Intertek Report No.: 200713014SZN-002 Version: 01-November-2017 Page: 3 of 26 FCC ID 249_C Test Report Table of Contents 1.0 Summary of Test Result ................................................................................................. 4 2.0 General Description ...................................................................................................... 5 2.1 Product Description .................................................................................................... 5 2.2 Related Submittal(s) Grants ......................................................................................... 5 2.3 Test Methodology ...................................................................................................... 5 2.4 Test Facility ............................................................................................................... 5 3.0 System Test Configuration ............................................................................................. 6 3.1 Justification ............................................................................................................... 6 3.2 EUT Exercising Software .............................................................................................. 6 3.3 Special Accessories ..................................................................................................... 6 3.4 Equipment Modification .............................................................................................. 6 3.5 Measurement Uncertainty .......................................................................................... 7 3.6 Support Equipment List and Description ........................................................................ 7 4.0 Emission Results ........................................................................................................... 8 4.1 Radiated Test Results .................................................................................................. 8 4.1.1 Field Strength Calculation ......................................................................................... 8 4.1.2 Radiated Emission Configuration Photograph .............................................................. 9 4.1.3 Radiated Emissions .................................................................................................. 9 4.1.4 Transmitter Spurious Emissions ............................................................................... 12 4.2 Conducted Emission Configuration Photograph ............................................................ 16 4.2.1 Conducted Emission ............................................................................................... 16 5.0 Equipment Photographs .............................................................................................. 19 6.0 Product Labelling .......................................…

Text truncated - open the document above for the full version.

Radiated Emission (Up to 1GHz) Radiated Emission (Above 1GHz)

Conducted Emission
