B32VS100MPoint of Sale Terminal

VeriFone Inc
Point of Sale Terminal - FCC ID B32VS100M - VeriFone Inc
Click to zoom

Application Details

Equipment Class
PCE - PCS Licensed Transmitter held to ear
Date of Grant
Dec 03, 2025
Application Purpose
Original Equipment
Equipment Note
Point of Sale Terminal
Frequency Range
673.00000000 - 688.00000000
Company
VeriFone Inc
Country
United States

Documents & Files

Select a file to view

Users Manual

↗
↗

Attestation Statements

↗
↗
↗
↗

Cover Letter(s)

↗
↗
↗
↗

External Photos

↗

ID Label/Location Info

↗
↗

Internal Photos

↗

RF Exposure Info

↗
↗
↗
↗
↗
↗
↗
↗
↗
↗
↗
↗

Test Report

↗
↗
↗
↗
↗
↗
↗
↗
↗
↗
↗
↗
↗
↗
↗
↗
↗
↗

Test Setup Photos

↗
↗
↗
↗
↗
↗
↗
↗
↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

©2025VeriFone,Inc.Allrightsreserved. VeriFone,Inc. US:1-800-Verifone www.verifone.com VS100-MCertificationsandRegulations VerifonePartNumber:DOCXXX-XXX-EN-A,RevisionA00.2 *DOCXXX-XXX-EN-A* Electrical PowerSource Beforeyouconnecttheterminalpowerpacktoanelectricaloutlet,checkthatthepowerswitchontheterminalisoff.Iftheterminaldoesnothaveanon/offswitch,checkthatthepowercableconnectoris removedfromtheterminal'spowerport. Or, whenconnectingthe terminal to a powerpack, always connect theplugof thepower packto anelectricalwall outlet first. Thenconnect thepower cableto the terminal'spowerport. Thereferenceinput powerratingisasfollows: • InputVoltage:100-240VAC,50/60Hz • OutputVoltage:5VDC,2.2A ModelVS100-MisintendedtobeprovidedwithaULListedPowerSupplymodulehavinganoutputratingof5VDC,minimum2.2A,Tma45°C,ClassII,DPIUtypeandevaluatedasaLimitedPowerSource or PS2 orequivalent. ACAdapter TheACadapterisdesignedtoensureyoursafetyandtobecompatiblewiththisequipment.Pleasefollowtheseguidelines: • Donotusetheadapterinahigh-moistureenvironment.Nevertouchtheadapterwhenyourhandsorfeetarewet. • Allowadequateventilationaroundtheadapter.Avoidlocationswithrestrictedairflow. • Connecttheadaptertoaproperpowersource.Thevoltageandgroundingrequirementsarefoundontheproductcaseand/orpackaging. • Donotusetheadapterifthecordisdamaged. • Donotattempttoservicetheadapter.Therearenoserviceablepartsinside.Replacetheunitifitisdamagedorexposedtoexcessmoisture. DisconnectingPower Disconnectingpowerduringatransactionmaycausetransactiondatafilesthatarenotyetstoredintheterminalmemorytobelost. Equipment Location–ElectricalConsiderations WARNING!Thisdevicecontainssensitiveelectroniccomponentsthatcanbepermanentlydamagedifexposedtoexcessiveshock,electricalinterference,orvibration. AVERTISSEMENT! Cet appareil contient des composants électroniques sensibles qui peuvent être endommagés defaçon permanente si elle est exposée à des chocs excessifs, des interférences électriques ou des vibrations. CAUTION:Dueto theriskof electricshock,ordamagetotheterminal,donotusethisequipmentnearawatersource,forexamplenearabathtub,washbowl,kitchensink,orlaundrytub,inawet basement,ornearaswimmingpool.Likewise,avoidusingthisproductduringthunderstormscausingpowercuts.Avoidplacingtheterminalnearelectricaldevicesorotherunitsthat couldcauselargevoltagefluctuationsorelectricalinterference,suchasairconditioners,neonsigns,high-frequencysafetydevices,orelectricalequipment. ATTENTION:Du fait d'un risque d'électrocution ou d'une détérioration du terminal, ne pas utiliser cet équipement près d'une source d'eau, par exemple près d'une baignoire, d'un lavabo, d'un évier de cuisine ou d'un bac de lavage, dans un sous-sol humide ou à proximité d'une piscine. De même, éviter d'utiliser ce produit lors des orages provoquant des coupures électriques. Éviter de placer le terminal à proximité d'appareils électriques ou autres unités pouvant entraîner des fluctuations de tension importantes ou des interférences électriques, tels que les climatiseurs, enseignes au néon, dispositifs de sécurité à haute fréquence ou équipements électriques. Damage Carefullyinspecttheshippingcartonanditscontentsforanydamage.Iftheunitoranyproductcomponentappearsdamagedortohavebeentamperedwith,immediatelynotifytheshippingcompanyand yourVerifonedistributoror serviceprovider. Donot useVS100-M unitthathasbeentampered. Repairs Donot,underanycircumstances,attemptanyservice,adjustments,orrepairsonthisequipment.Instead,contactyourlocalVerifonedistributororserviceproviderforassistance.Failuretocomplymay void theproduct warranty. Location–EnvironmentalConsiderations Donotplugthepowerpackintoanoutdooroutlet.Anydamagetotheunitfromexposuretowaterordustmayvoidyourwarranty.Donotusetheterminalwherethereishighheat,dust,humidity,moisture, or causticchemicalsoroils. Keeptheterminalaway fromdirect sunlight andanythingthat radiatesheat, suchasa stoveoramotor. WARNING!YourPOS terminalcontainssensitiveelectronic componentsthat canbepermanently damagedif exposedtoexcessiveshockorvibration.Tominimizetheriskofdamagetoyour terminal,avoiddroppingyourterminalandoperatingitinhigh-shockandhigh-vibrationenvironments.Donotstoretheterminalwhereprolongedexposuretoextremetemperaturescan occurbecauseitcancausepermanentdamage.Donotexposetheterminaltowater.Contactwithwatercancausethisunittomalfunction. AVERTISSEMENT!Votre terminal de point de vente contient des composants électroniques sensibles, susceptibles de subir des dommages définitifs en cas d'exposition à des chocs ou à des vibrations excessives. Pour minimiser le risque de dommages pour votre terminal, éviter de le faire tomber ou de l'exposer à des environnements pouvant provoquer des chocs et des vibrations excessives. Ne pas stocker le terminal dans des lieux susceptibles d'entraîner une exposition prolongée à des températures extrêmes, du fait des dommages définitifs que cette situation peut provoquer. Ne pas exposer le terminal à l'eau. Un contact avec de l'eau peut provoquer un dysfonctionnement de l'unité. CleanersandSolvents Neverusethinner,trichloroethylene,orketone-basedsolventstocleantheVS100-Mdevice,thesemaydeteriorateplasticorrubberparts.Donotspraycleanersorothersolutionsdirectlyontothekeypad or display. Forbest results, useacleanclothdampenedwithwater andmildsoap. Toremovestubbornstains, usealcoholoranalcohol-basedcleaner. NoticeforWLAN ForCEWLAN:5250-5350MHz Thisdeviceis…

Text truncated - open the document above for the full version.

Users Manual

DRAFT www.verifone.com Victa SoftPOS Mobile Installation Guide Verifone Part Number: DOC573-008-EN-A, Revision A00.2 DRAFT VeriFone, Inc. US: 1-800-Verifone www.verifone.com Verifone Part Number: DOC573-008-EN-A, Revision A00.2 Victa SoftPOS Mobile Installation Guide © 2025 VeriFone, Inc. 2 © VeriFone, Inc. All rights reserved. Installation GuideVicta SoftPOS Mobile All rights reserved. No part of this document may be reproduced or transmitted in any form without the written permission of VeriFone, Inc (“Verifone”). The information contained in this document is subject to change without notice. Although Verifone has attempted to ensure the accuracy of the contents of this document, Verifone shall not be liable for technical or editorial errors or omissions contained herein. Verifone and the Verifone logo are registered trademarks of Verifone. Other brand names or trademarks associated with Verifone's products and services are trademarks of Verifone. All other brand names and trademarks appearing in this document are the property of their respective holders. Comments? Please e-mail all comments on this document to your local Verifone Support Team. DRAFT Contents 3 © VeriFone, Inc. All rights reserved. Installation GuideVicta SoftPOS Mobile Preface Audience. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Related Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 1. Device Overview Features and Benefits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 2. Device Setup Environmental & Safety Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 PIN Protection Measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Inside the Shipping Carton . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 To Unpack the Shipping Carton . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Inspecting the Features of the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Installing Micro SIM and or SAM Cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Battery Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Initial Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Using the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Battery Life. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Replacing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Charging the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Startup and Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Connecting the Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Connecting to a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 ECR Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Transaction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Wi-Fi/BT Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Camera/QR Code Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 3. Specifications Unit Power Requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 DRAFT Installation GuideVerifone Victa SoftPOS Mobile 4 © VeriFone, Inc. All rights reserved. External Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Weight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 Smart Card Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Integrated Contactless Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 SAM Card Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 4. Maintenance and Cleaning General Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . …

Text truncated - open the document above for the full version.

Test Report

Sporton International Inc. (Kunshan) Page Number : 1 of 28 TEL : +86-512-57900158 Report Issued Date : Nov. 19, 2025 FCC ID : B32VS100M Report Version : Rev. 01 Report Template No.: BU5-FGLTE Version 2.0 FCC RF Test Report Report No. : FG572113B FCC RF Test Report APPLICANT : VeriFone, Inc. EQUIPMENT : Point of Sale Terminal BRAND NAME : Verifone or VERIFONE or verifone MODEL NAME : VS100-M FCC ID : B32VS100M STANDARD : 47 CFR Part 22(H), 24(E), 27(L) CLASSIFICATION : PCS Licensed Transmitter Held to Ear (PCE) TEST DATE(S) : Sep. 01, 2025 ~ Sep. 19, 2025 We, Sporton International Inc. (Kunshan), would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.26-2015 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International Inc. (Kunshan), the test report shall not be reproduced except in full. Approved by: Jason Jia Sporton International Inc. (Kunshan) No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International Inc. (Kunshan) Page Number : 2 of 28 TEL : +86-512-57900158 Report Issued Date : Nov. 19, 2025 FCC ID : B32VS100M Report Version : Rev. 01 Report Template No.: BU5-FGLTE Version 2.0 FCC RF Test Report Report No. : FG572113B TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Manufacturer ...................................................................................................................................... 5 1.3 Product Feature of Equipment Under Test ........................................................................................ 5 1.4 Product Specification of Equipment Under Test ................................................................................ 6 1.5 Modification of EUT ........................................................................................................................... 6 1.6 Maximum ERP/EIRP and Emission Designator ................................................................................ 7 1.7 Testing Location ................................................................................................................................ 9 1.8 Test Software ..................................................................................................................................... 9 1.9 Applicable Standards ......................................................................................................................... 9 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ...................................................................... 10 2.1 Test Mode ........................................................................................................................................ 10 2.2 Connection Diagram of Test System ............................................................................................... 11 2.3 Support Unit used in test configuration and system ........................................................................ 11 2.4 Measurement Results Explanation Example ................................................................................... 12 2.5 Frequency List of Low/Middle/High Channels ................................................................................. 12 3 CONDUCTED TEST ITEMS ...................................................................................................................... 16 3.1 Measuring Instruments .................................................................................................................... 16 3.2 Test Setup ....................................................................................................................................... 16 3.3 Test Result of Conducted Test ........................................................................................................ 16 3.4 Conducted Output Power and ERP/EIRP ....................................................................................... 17 3.5 Peak-to-Average Ratio .................................................................................................................... 18 3.6 Occupied Bandwidth ........................................................................................................................ 19 3.7 Conducted Band Edge .................................................................................................................... 20 3.8 Conducted Spurious Emission ........................................................................................................ 22 3.9 Frequency Stability .......................................................................................................................... 23 4 RADIATED TEST ITEMS .......................................................................................................................... 24 4.1 Measuring Instruments .................................................................................................................... 24 4.2 Test Setup ....................................................................................................................................... 24 4.3 Test Result of Radiated Test .............................................................................…

Text truncated - open the document above for the full version.

Test Report

Sporton International Inc. (Kunshan) Page Number : A37 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C Conducted Band Edge LTE Band 13 / 5MHz / QPSK Lowest Band Edge / 1 RB Highest Band Edge / 1 RB Lowest Band Edge / Full RB Highest Band Edge / Full RB Sporton International Inc. (Kunshan) Page Number : A38 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C LTE Band 13 / 10MHz / QPSK Middle Band Edge / Full RB Sporton International Inc. (Kunshan) Page Number : A39 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C Conducted Spurious Emission LTE Band 13 / 5MHz Lowest Channel / QPSK Middle Channel / QPSK Highest Channel / QPSK Sporton International Inc. (Kunshan) Page Number : A40 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C LTE Band 13 / 10MHz Middle Channel / QPSK Sporton International Inc. (Kunshan) Page Number : A41 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C Frequency Stability Test Conditions LTE Band 13 (QPSK) / Middle Channel Limit Temperature (°C) Voltage (Volt) BW 10MHz Note 2. Deviation (ppm) Result 50 Normal Voltage 0.0027 PASS 40 Normal Voltage 0.0022 30 Normal Voltage 0.0029 20(Ref.) Normal Voltage 0.0000 10 Normal Voltage 0.0028 0 Normal Voltage 0.0033 -10 Normal Voltage 0.0037 -20 Normal Voltage 0.0025 -30 Normal Voltage 0.0020 20 Maximum Voltage 0.0019 20 Normal Voltage 0.0013 20 Battery End Point 0.0024 Note: 1. Normal Voltage =3.8 V.;Battery End Point (BEP) =3.5 V.;Maximum Voltage =4.35 V. 2. Note: The frequency fundamental emissions stay within the authorized frequency block. Sporton International Inc. (Kunshan) Page Number : A42 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C LTE Band 41 Peak-to-Average Ratio Mode LTE Band 41 / 20MHz Mod. QPSK 16QAM 64QAM Limit: 13dB RB Size Full RB Full RB Full RB Result Middle CH 5.25 6.26 6.2 PASS LTE Band 41 / 20MHz Middle Channel / Full RB / QPSK Middle Channel / Full RB / 16QAM Sporton International Inc. (Kunshan) Page Number : A43 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C Middle Channel / Full RB / 64QAM Sporton International Inc. (Kunshan) Page Number : A44 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C 26dB Bandwidth Mode LTE Band 41 : 26dB BW(MHz) BW 5MHz Mod. QPSK 16QAM Middle CH 4.91 4.96 BW 10MHz Mod. QPSK 16QAM Middle CH 9.81 9.75 BW 15MHz Mod. QPSK 16QAM Middle CH 13.34 13.33 BW 20MHz Mod. QPSK 16QAM Middle CH 18.62 18.66 LTE Band 41 Middle Channel / 5MHz / QPSK Middle Channel / 5MHz / 16QAM Sporton International Inc. (Kunshan) Page Number : A45 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C LTE Band 41 Middle Channel / 10MHz / QPSK Middle Channel / 10MHz / 16QAM LTE Band 41 Middle Channel / 15MHz / QPSK Middle Channel / 15MHz / 16QAM LTE Band 41 Middle Channel / 20MHz / QPSK Middle Channel / 20MHz / 16QAM Sporton International Inc. (Kunshan) Page Number : A46 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C Occupied Bandwidth Mode LTE Band 41 : 99%OBW(MHz) BW 5MHz Mod. QPSK 16QAM Middle CH 4.47 4.50 BW 10MHz Mod. QPSK 16QAM Middle CH 9.05 9.05 BW 15MHz Mod. QPSK 16QAM Middle CH 13.43 13.40 BW 20MHz Mod. QPSK 16QAM Middle CH 17.82 17.90 LTE Band 41 Middle Channel / 5MHz / QPSK Middle Channel / 5MHz / 16QAM Sporton International Inc. (Kunshan) Page Number : A47 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C LTE Band 41 Middle Channel / 10MHz / QPSK Middle Channel / 10MHz / 16QAM LTE Band 41 Middle Channel / 15MHz / QPSK Middle Channel / 15MHz / 16QAM LTE Band 41 Middle Channel / 20MHz / QPSK Middle Channel / 20MHz / 16QAM Sporton International Inc. (Kunshan) Page Number : A48 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C Conducted Band Edge LTE Band 41 / 5MHz / QPSK Lowest Band Edge / 1 RB Highest Band Edge / 1 RB Lowest Band Edge / Full RB Highest Band Edge / Full RB Sporton International Inc. (Kunshan) Page Number : A49 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C LTE Band 41 / 10MHz / QPSK Lowest Band Edge / Full RB Highest Band Edge / Full RB LTE Band 41 / 15MHz / QPSK Lowest Band Edge / Full RB Highest Band Edge / Full RB Sporton International Inc. (Kunshan) Page Number : A50 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C LTE Band 41 / 20MHz / QPSK Lowest Band Edge / Full RB Highest Band Edge / Full RB Sporton International Inc. (Kunshan) Page Number : A51 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C Conducted Spurious Emission LTE Band 41 / 5MHz Lowest Channel / QPSK Middle Channel / QPSK Highest Channel / QPSK Sporton International Inc. (Kunshan) Page Number : A52 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C LTE Band 41 / 10MHz Lowest Channel / QPSK Middle Channel / QPSK Highest Channel / QPSK Sporton International Inc. (Kunshan) Page Number : A53 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C LTE Band 41 / 15MHz Lowest Channel / QPSK Middle Channel / QPSK Highest Channel / QPSK Sporton International Inc. (Kunshan) Page Number : A54 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C LTE Band 41 / 20MHz Lowest Channel / QPSK Middle Channel / QPSK Highest Channel / QPSK Sporton International Inc. (Kunshan) Page Number : A55 of A69 TEL : +86-512-57900158 FCC ID : B32VS100M FCC RF Test Report Report No. : FG572113C Frequency Stability Test Conditions LTE Band 41 (QPSK) / Middle Channel Limit Temperature (°C) Voltage (Volt) BW 10MHz Note 2. D…

Text truncated - open the document above for the full version.

Test Report

Sporton International Inc. Kunshan) Page Number : 1 of 21 TEL : +86-512-57900158 Report Issued Date : Nov. 19, 2025 FCC ID : B32VS100M Report Version : Rev. 01 Report Template No.: BU5-FG22/24/27 Version 2.0 FCC RF Test Report Report No. : FG572113A FCC RF Test Report APPLICANT : VeriFone, Inc. EQUIPMENT : Point of Sale Terminal BRAND NAME : Verifone or VERIFONE or verifone MODEL NAME : VS100-M FCC ID : B32VS100M STANDARD : 47 CFR Part 22(H), 24(E), 27(L) CLASSIFICATION : PCS Licensed Transmitter Held to Ear (PCE) TEST DATE(S) : Sep. 02, 2025 ~ Sep. 19, 2025 We, Sporton International Inc. (Kunshan), would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.26-2015 and shown compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of Sporton International Inc. (Kunshan), the test report shall not be reproduced except in full. Approved by: Jason Jia Sporton International Inc. (Kunshan) No. 1098, Pengxi North Road, Kunshan Economic Development Zone Jiangsu Province 215300 People’s Republic of China Sporton International Inc. Kunshan) Page Number : 2 of 21 TEL : +86-512-57900158 Report Issued Date : Nov. 19, 2025 FCC ID : B32VS100M Report Version : Rev. 01 Report Template No.: BU5-FG22/24/27 Version 2.0 FCC RF Test Report Report No. : FG572113A TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1 GENERAL DESCRIPTION .......................................................................................................................... 5 1.1 Applicant ............................................................................................................................................ 5 1.2 Manufacturer ..................................................................................................................................... 5 1.3 Product Feature of Equipment Under Test ....................................................................................... 5 1.4 Product Specification of Equipment Under Test ............................................................................... 6 1.5 Modification of EUT ........................................................................................................................... 6 1.6 Maximum ERP/EIRP and Emission Designator ................................................................................ 6 1.7 Testing Location ................................................................................................................................ 7 1.8 Test Software .................................................................................................................................... 7 1.9 Applicable Standards ........................................................................................................................ 7 2 TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 8 2.1 Test Mode.......................................................................................................................................... 8 2.2 Connection Diagram of Test System ................................................................................................ 8 2.3 Support Unit used in test configuration ............................................................................................. 9 2.4 Measurement Results Explanation Example .................................................................................... 9 2.5 Frequency List of Low/Middle/High Channels ................................................................................... 9 3 CONDUCTED TEST RESULT ................................................................................................................... 10 3.1 Measuring Instruments .................................................................................................................... 10 3.2 Test Setup ....................................................................................................................................... 10 3.3 Test Result of Conducted Test ........................................................................................................ 10 3.4 Conducted Output Power and ERP/EIRP ....................................................................................... 11 3.5 Peak-to-Average Ratio .................................................................................................................... 12 3.6 99% Occupied Bandwidth and 26dB Bandwidth Measurement...................................................... 13 3.7 Conducted Band Edge .................................................................................................................... 14 3.8 Conducted Spurious Emission ........................................................................................................ 15 3.9 Frequency Stability .......................................................................................................................... 16 4 RADIATED TEST ITEMS .......................................................................................................................... 17 4.1 Measuring Instruments .................................................................................................................... 17 4.2 Test Setup ....................................................................................................................................... 17 4.3 Test Result of Radiated Test .................................................................................................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Kenji Chao(Sr. Director, Hardware Engineering)
[email protected]Fax: 886-2-26553168

Test Firm

Sporton International Inc. (Kunshan)Mark Qu
[email protected]

Technical Specifications

#Rule PartsFrequency RangePower OutputEmissionTolerance
122H826.4 MHz - 846.6 MHz69.70 mW4M11F9W2.5ppm
224E1.85 GHz - 1.91 GHz87.50 mW4M12F9W2.5ppm
3271.71 GHz - 1.75 GHz87.90 mW4M11F9W2.5ppm
424E1.86 GHz - 1.90 GHz78.70 mW17M8G7D2.5ppm
524E1.86 GHz - 1.90 GHz76.20 mW17M9W7D2.5ppm
624E1.86 GHz - 1.91 GHz80.50 mW17M8G7D2.5ppm
724E1.86 GHz - 1.91 GHz79.30 mW17M9W7D2.5ppm
822H829 MHz - 844 MHz69.20 mW9M05G7D2.5ppm
922H829 MHz - 844 MHz68.90 mW8M99W7D2.5ppm
122H831.5 MHz - 841.5 MHz72.10 mW13M4G7D2.5ppm
1122H831.5 MHz - 841.5 MHz71.10 mW13M4W7D2.5ppm
12271.72 GHz - 1.75 GHz83.80 mW17M9G7D2.5ppm
13271.72 GHz - 1.75 GHz83.20 mW17M8W7D2.5ppm
14271.72 GHz - 1.77 GHz87.10 mW17M9G7D2.5ppm
15271.72 GHz - 1.77 GHz86.30 mW17M8W7D2.5ppm
16272.51 GHz - 2.56 GHz138.40 mW17M9G7D2.5ppm
17272.51 GHz - 2.56 GHz136.50 mW17M4W7D2.5ppm
1827704 MHz - 711 MHz65.50 mW9M03G7D2.5ppm
1927704 MHz - 711 MHz46.90 mW8M99W7D2.5ppm
227782 MHz - 782 MHz70.10 mW9M03G7D2.5ppm
2127782 MHz - 782 MHz69.20 mW8M97W7D2.5ppm
2227709 MHz - 711 MHz65.00 mW9M03G7D2.5ppm
2327709 MHz - 711 MHz50.60 mW8M99W7D2.5ppm
24272.51 GHz - 2.68 GHz173.80 mW17M8G7D2.5ppm
25272.51 GHz - 2.68 GHz129.70 mW17M9W7D2.5ppm
2627673 MHz - 688 MHz67.50 mW17M9G7D2.5ppm
2727673 MHz - 688 MHz55.80 mW17M8W7D2.5ppm
289793 MHz - 793 MHz69.20 mW9M99G7D1.25ppm
299793 MHz - 793 MHz67.10 mW9M03W7D1.25ppm
39824 MHz - 824 MHz155.20 mW13M3G7D2.5ppm
319824 MHz - 824 MHz83.00 mW13M5W7D2.5ppm
329815.5 MHz - 822.5 MHz105.00 mW2M70W7D2.5ppm
Confidentiality
Long Term
Grant Notes
Output Power is EIRP and ERP for above and below 1 GHz, respectively, except for Part 90 LTE Band 26 emissions, which are conducted. SAR compliance for body-worn operating configurations is limited to belt-clips and holsters that have no metallic components in the assembly and cause the device to operate with the minimum separation distance of 5.0 mm, as described in this filing. End-users must be informed of the body- worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, simultaneous transmission and product specific (10g SAR) exposure conditions are 0.59 W/kg, 1.14 W/kg, 1.59 W/kg and 1.38 W/kg, respectively. This device supports LTE of 1.4, 3, 5, 10, 15 and 20 MHz bandwidth modes for FDD LTE Bands 2, 4, 25 and 66; LTE of 5, 10, 15 and 20 MHz bandwidth modes for FDD LTE Bands 7 and 71; LTE of 1.4, 3, 5 and 10 MHz bandwidth modes for FDD LTE Bands 5 and 12; LTE of 5 and 10 MHz bandwidth modes for FDD LTE Bands 13, 14 and 17; LTE of 1.4, 3, 5, 10 and 15 MHz bandwidth modes for FDD LTE Band 26; and LTE of 5, 10, 15 and 20 MHz bandwidth modes for TDD LTE Band 41. HAC-2019, under the waiver DA 23-914. The lowest conversational gain is 13.0 dB with a hearing aid and 18.6 dB without a hearing aid. This device contains functions that are not operational in U.S. Territories; this filing is applicable only for U.S. operations.
