B94-CEB005RHyperX Cirro Buds Pro True Wireless Earbuds

    Charging It is recommended that the earbuds and charging case be fully charged before rst use. To charge the earbuds, place them in the charging case and close the lid. If the charging case is not connected to a power source, the charging case status LED will show which earbuds are charging. CHARGING CASE STATUS LEDEARBUDS CHARGING YellowLeft PurpleRight CyanLeft & Right CHARGING CASE STATUS LEDCHARGING CASE BATTERY LEVEL Green71% - 100% White30% - 70% Red< 30% To charge the charging case, connect a power source to the USB-C port on the bottom of the case. The charging case status LED will ash the current battery level. The LED will then breath to indicate the charging status until turning solid, indicating a full charge. Once fully charged, if the charging case’s lid is opened or the button is pushed, the LED will turn o. CHARGING CASE STATUS LED CHARGING CASE BATTERY LEVEL Solid Green100% Breathing Green71% - 99% Breathing White30% - 70% Breathing Red< 30% Powering on and off the Earbuds To power on the earbuds, open the charging case. The earbuds will power on and the charging case status LED will ash to indicate the battery level of the charging case. The earbuds can also be powered on outside of the case by holding the touch sensors for 3 seconds. To power o the earbuds, return them to the charging case and close the lid. The earbuds will power o and the charging case status LED will indicate which earbuds are charging. The earbuds can also be powered o outside of the case by holding the touch sensors for 8 seconds. Earbud Controls Left Earbud Right Earbud STATUS1 PRESS Playing MediaPlay/Pause 2 PRESSES Previous Track 3 PRESSES Toggle Gaming Mode/ Noise Control O LONG PRESS Activate Mobile Assistant Receiving CallAnswer CallReject CallXX In CallXEnd CallXX STATUS1 PRESS Playing MediaPlay/Pause 2 PRESSES Next Track 3 PRESSES X LONG PRESS Toggle Ambient Mode/ANC Receiving CallAnswer CallReject CallXX In CallXEnd CallXX MODEFUNCTION Ambient Mode (Power-On Default) Allows hearing external sound while wearing the earbuds MAXIMUM BATTERY LIFE 5 hours ANCEnables hybrid active noise cancellation to greatly reduce background noise4.5 hours Gaming ModeReduces audio latency and enables ANC for an improved gaming experience.4 hours Noise Control ODisables ambient sound, ANC, and low latency mode for the best battery life.7 hours Audio and Noise Control Modes Charging Case Button Press the charging case button to check the charging case’s battery level, indicated by ashing the case’s status LED. Questions or Setup Issues? Contact the HyperX support team or see the user manual at : hyperx.com/support WARNING: Permanent hearing damage can occur if a headset is used at high volumes for extended periods of time. FRANÇAIS Présentation A - Contacts de charge B - Capteur de proximité C - Microphone Charge Il est recommandé de charger complètement les écouteurs et le boîtier de charge avant leur première utilisation. Pour charger les écouteurs, les placer dans le boîtier de charge et fermer le couvercle. Si le boîtier de charge n’est pas connecté à une source d’alimentation, son voyant LED indique le ou les écouteurs en cours de charge. Pour charger le boîtier de charge, connecter une source d’alimentation au port USB-C situé au bas de ce dernier. Le voyant LED du boîtier de charge s’allume pour indiquer le niveau actuel de la batterie. Le voyant LED clignote pour indiquer le statut de charge jusqu’à devenir xe, ce qui indique une charge complète. Une fois entièrement chargé, si vous ouvrez le couvercle du boîtier ou si vous appuyez sur le bouton, le voyant LED s’éteint. Allumer et éteindre les écouteurs Pour allumer les écouteurs, ouvrir le boîtier de charge. Les écouteurs s’allument et le voyant LED du boîtier de charge clignote pour indiquer le niveau de sa batterie. Les écouteurs peuvent être allumés en dehors du boîtier en touchant les capteurs tactiles pendant 3 secondes. Pour éteindre les écouteurs, les remettre dans le boîtier de charge et fermer le couvercle. Les écouteurs s’éteignent et le voyant LED du boîtier de charge indique le ou les écouteurs en cours de charge. Les écouteurs peuvent aussi être éteints en dehors du boîtier en touchant les capteurs tactiles pendant 8 secondes. Couplage des écouteurs 1. Allumez les écouteurs. Les écouteurs tenteront automatiquement de se reconnecter à leur(s) dernier(s) appareil(s) compatible(s) Bluetooth®. 2. Les écouteurs passent automatiquement en mode de couplage chaque fois qu’ils ne sont pas connectés à un appareil Bluetooth®. Pour passer en mode de couplage lorsque vous êtes connecté à un appareil Bluetooth®, utilisez les paramètres de cet appareil pour le déconnecter des écouteurs. 3. Sur l’appareil compatible Bluetooth®, recherchez HyperX Cirro Buds Pro pour vous y connecter. 4. À ce stade, un appareil supplémentaire compatible Bluetooth® qui avait été couplé aux écouteurs précédemment peut être reconnecté pour permettre une connectivité multipoint. Commandes des écouteurs Écouteur gauche VOYANT LED DU BOÎTIER DE CHARGE ÉCOUTEURS EN CHARGE JauneGauche VioletDroit CyanGauche et droit VOYANT LED DU BOÎTIER DE CHARGE NIVEAU DE BATTERIE DU BOÎTIER DE CHARGE Vert xe100 % Vert - Respiration71 % - 99 % Blanc - Respiration30 % - 70 % Rouge - Respiration< 30 % Écouteur droit Modes de contrôle du son et du bruit Bouton du boîtier de charge Appuyez sur le bouton du boîtier de charge pour vérier le niveau de sa batterie, indiqué par le voyant LED. Des questions ou des problèmes de conguration ? Contacter l’équipe d’assistance HyperX ou consulter le manuel d’utilisation sur : hyperx.com/support AVERTISSEMENT : L’exposition prolongée à des niveaux sonores élevés peut provoquer une détérioration irréversible de la capacité auditive. ITALIANO Descrizione generale del prodotto A - Contatti di ricarica B - Sensore di prossimità C - Microfono In carica In occasione del primo utilizzo, si consiglia di lasciare co…

Text truncated - open the document above for the full version.

Date: 2022-12-12 FCC ID: B94-CEB005R To the attention of Federal Communications Commission Authorization and Evaluation Division Permanent Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely yours, ----------------------------------------------- Name: Vanessa Tsai Title: Product Compliance Engineer Tel: +886 932285270 E-mail: [email protected]

Date: 2022-12-12 FCC ID: B94-CEB005R To the attention of Federal Communications Commission Authorization and Evaluation Division Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we request short-term confidential treatment for the following information until 180 days after the Grant Date of Equipment Authorization in order to ensure sensitive business information remains confidential until the actual marketing of the device: External photos Test Setup photos User’s manual Internal Photos Sincerely yours, ----------------------------------------------- Name: Vanessa Tsai Title: Product Compliance Engineer Tel: +886 932285270 E-mail: [email protected]

Date: 2022-12-12 FCC ID: B94-CEB005R A U T H O R I Z A T I O N L E T T E R To Whom It May Concern: We, the undersigned, hereby authorize Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch (“BV CPS Taoyuan”) of Taiwan to act on our behalf as our agent, related to the FCC application for equipment authorization of our products with the model No.: CEB005 In the following matter: report submittal, related correspondence, the signing of all documents relating to these matters, and any other lawful activity necessary to obtain such certification. Any act carried out by BV Bureau Veritas Consumer Product Services (H.K.) Ltd., Taoyuan branch of Taiwan within the scope of this authorization shall have the same effects as our own. This authorization is valid for six months from the original date. If you have any questions regarding the authorization, please don’t hesitate to contact us. Sincerely yours, ----------------------------------------------- Name: Vanessa Tsai Title: Product Compliance Engineer Tel: +886 932285270 E-mail: [email protected]

HP Inc. 3390 E Harmony Rd Fort Collins, CO 80528 USA Authorization on Behalf of HP Inc. for the US Federal Communications Commission Office of Engineering and Technology and Other FCC Programs and Offices 1. I, Richard P. Tarsio, am on the Worldwide Technical Regulations staff of HP Inc. (“HP”) and Applicant/Grantee Contact of Record for HP Inc. together with its subsidiaries and affiliates worldwide (collectively, “HP”) for HP’s dealings with the United States Federal Communications Commission (“FCC”). I am duly authorized by HP to make this Authorization on HP’s behalf. 2. This Authorization will designate the person named below to act on my behalf and HP’s behalf as an authorized agent and representative, until further notice, with the additional power to designate one or more third party agents for HP with regard to particular matters and applications. All acts carried out and requests made by this named representative relating to any matter before the FCC, including requests for confidentiality, shall have the same effect as mine. Name: Vanessa Tsai Title: Product Compliance Engineer Address: HP Inc. No. 1-5, Lixing 1 st Road, East District Hsinchu City, HSZ Taiwan Telephone: +886 932285270 E-mail: [email protected] 3. Questions about the scope and effect of this Authorization should be addressed as follows: Richard P. Tarsio US/Canada Technical Regulations & Standards Engineer Worldwide Technical Regulations HP Inc. (A) 3390 East Harmony Road, MS 66 Fort Collins, CO 80528 (T) +1 970 898 8713 (E) [email protected] 4. I declare under penalty of perjury that the foregoing is true and correct, and that this Authorization was executed at Fort Collins, Colorado on the date indicated below my signature. Richard P. Tarsio US/Canada Technical Regulations & Standards Engineer HP Inc. Date: 29 June 2021

Reference No.: BDMD-WTW-P22070452-2_EXT 1 of 32 CONSTRUCTION PHOTOS OF EUT Brand: HYPERX / Model: CEB005 Reference No.: BDMD-WTW-P22070452-2_EXT 2 of 32 Right Earbud (Blue) Reference No.: BDMD-WTW-P22070452-2_EXT 3 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 4 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 5 of 32 Left Earbud (Blue) Reference No.: BDMD-WTW-P22070452-2_EXT 6 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 7 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 8 of 32 Charging Case (Blue) (Brand: HYPERX / Model: T910000116850) Reference No.: BDMD-WTW-P22070452-2_EXT 9 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 10 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 11 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 12 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 13 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 14 of 32 Right Earbud (Black) Reference No.: BDMD-WTW-P22070452-2_EXT 15 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 16 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 17 of 32 Left Earbud (Black) Reference No.: BDMD-WTW-P22070452-2_EXT 18 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 19 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 20 of 32 Charging Case (Black) (Brand: HYPERX / Model: T910000116770) Reference No.: BDMD-WTW-P22070452-2_EXT 21 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 22 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 23 of 32 Right Earbud (Tan) Reference No.: BDMD-WTW-P22070452-2_EXT 24 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 25 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 26 of 32 Left Earbud (Tan) Reference No.: BDMD-WTW-P22070452-2_EXT 27 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 28 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 29 of 32 Charging Case (Tan) (Brand: HYPERX / Model: T910000116860) Reference No.: BDMD-WTW-P22070452-2_EXT 30 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 31 of 32 Reference No.: BDMD-WTW-P22070452-2_EXT 32 of 32

Label and Label location User manual Packaging

Reference No.: BDMD-WTW-P22070452-2_INT 1 of 20 CONSTRUCTION PHOTOS OF EUT Right Earbud Reference No.: BDMD-WTW-P22070452-2_INT 2 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 3 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 4 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 5 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 6 of 20 BT Antenna Reference No.: BDMD-WTW-P22070452-2_INT 7 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 8 of 20 Left Earbud Reference No.: BDMD-WTW-P22070452-2_INT 9 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 10 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 11 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 12 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 13 of 20 BT Antenna Reference No.: BDMD-WTW-P22070452-2_INT 14 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 15 of 20 Charging Case (Brand: HYPERX / Model: T910000116850) Reference No.: BDMD-WTW-P22070452-2_INT 16 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 17 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 18 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 19 of 20 Reference No.: BDMD-WTW-P22070452-2_INT 20 of 20

Plots of System Verification : 1 of 2 Appendix A. Plots of System Verification The plots for system verification are shown as follows. Report No.: SFBDMD-WTW-P22070452-1 Plots of System Verification : 2 of 2 Test Laboratory: Bureau Veritas ADT SAR/HAC Testing Lab Date: 2022/10/18 S02 System Check_H2450_221018 DUT: Dipole 2450 MHz; Type: D2450V2; SN: 737 Communication System: UID 0, CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: H19T27N1_1018 Medium parameters used: f = 2450 MHz; σ = 1.843 S/m; ε r = 38.189; ρ = 1000 kg/m 3 Ambient Temperature：23.7 °C ; Liquid Temperature：23.4 °C DASY5 Configuration: - Probe: EX3DV4 - SN3650; ConvF(7.82, 7.82, 7.82) @ 2450 MHz; Calibrated: 2022/03/24 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn861; Calibrated: 2022/03/23 - Phantom: SAM Phantom_1985; Type: QD 000 P41 AA; - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) Pin=50mW/Area Scan (81x81x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 4.40 W/kg Pin=50mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 48.45 V/m; Power Drift = 0.02 dB Peak SAR (extrapolated) = 5.52 W/kg SAR(1 g) = 2.59 W/kg; SAR(10 g) = 1.21 W/kg (SAR corrected for target medium) Maximum value of SAR (measured) = 4.45 W/kg Report No.: SFBDMD-WTW-P22070452-1 Plots of Measurement : 1 of 2 Appendix B. Plots of Measurement The SAR plots for highest measured SAR in each exposure configuration, wireless mode and frequency band combination are shown as follows. Report No.: SFBDMD-WTW-P22070452-1 Plots of Measurement : 2 of 2 Test Laboratory: Bureau Veritas ADT SAR/HAC Testing Lab Date: 2022/10/18 P02 BT_BDR_Front Face_0mm_Ch39_Sample R_Ant 1 DUT: BDMP-WTW-P22070452 Communication System: UID 10032 - CAA, IEEE 802.15.1 Bluetooth (GFSK, DH5); Frequency: 2441 MHz;Duty Cycle: 1:1.31 Medium: H19T27N1_1018 Medium parameters used (interpolated): f = 2441 MHz; σ = 1.835 S/m; ε r = 38.207; ρ = 1000 kg/m 3 Am bient Temperature：23.7 °C ; Liquid Temperature：23.4 °C DASY5 Configuration: - Probe: EX3DV4 - SN3650; ConvF(7.82, 7.82, 7.82) @ 2441 MHz; Calibrated: 2022/03/24 - Sensor-Surface: 1.4mm (Mechanical Surface Detection) - Electronics: DAE4 Sn861; Calibrated: 2022/03/23 - Phantom: SAM Phantom_1985; Type: QD 000 P41 AA; - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7483) Area Scan (41x41x1): Interpolated grid: dx=1.200 mm, dy=1.200 mm Maximum value of SAR (interpolated) = 0.759 W/kg Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 19.64 V/m; Power Drift = 0.01 dB Peak SAR (extrapolated) = 1.05 W/kg SAR(1 g) = 0.234 W/kg; SAR(10 g) = 0.080 W/kg (SAR corrected for target medium) Smallest distance from peaks to all points 3 dB below = 5.1 mm Ratio of SAR at M2 to SAR at M1 = 41% Maximum value of SAR (measured) = 0.604 W/kg Report No.: SFBDMD-WTW-P22070452-1 Appendix Z. Calibration Certificate for Probe and Dipole The SPEAG calibration certificates are shown as follows. Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Model：D2450V2S/N：737Measurement Date： 2022/8/25 Frequency (MHz) Type Item Previous Measurement Annual Check Deviation Accepted Tolerance Result Real Impedance 53.98951.387-2.602±5ΩPASS Imaginary Impedance 4.29265.36051.07±5ΩPASS Return Loss -24.989-24.145-3.38%±20%PASS 2450 Free Space 2450 MHz，Free Space Annual Confirmation of SAR Reference Dipole Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1 Report No.: SFBDMD-WTW-P22070452-1

SAR Test Report Report Format Version 5.0.0 Page No. : 1 of 25 Report No. : SFBDMD-WTW-P22070452-1 Issued Date : Nov. 01, 2022 SAR Test Report Report No. : SFBDMD-WTW-P22070452-1 Applicant : HP Inc. Address : 3390 East Harmony Road, Fort Collins, Colorado United States 80528 Product : HyperX Cirro Buds Pro True Wireless Earbuds FCC ID : B94-CEB005R Brand : HYPERX Model No. : CEB005 FCC Rule Part CFR §2.1093 Standards : IEC/IEEE 62209-1528:2020 KDB 865664 D01 v01r04, KDB 865664 D02 v01r02, KDB 447498 D01 v06 Sample Received Date : Oct. 14, 2022 Date of Testing : Oct. 18, 2022 Lab Address : No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location : No. 19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City, Taiwan CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch–Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Lena Wang / Specialist Approved By : Gordon Lin / Manager FCC Accredited No.: TW0003 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our- business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. SAR Test Report Report Format Version 5.0.0 Page No. : 2 of 25 Report No. : SFBDMD-WTW-P22070452-1 Issued Date : Nov. 01, 2022 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement System ................................................................................................................................................... 6 3.1 Definition of Specific Absorption Rate (SAR) ............................................................................................................... 6 3.2 SPEAG DASY6 System ............................................................................................................................................... 6 3.2.1 Robot ............................................................................................................................................................... 7 3.2.2 Probes ............................................................................................................................................................. 8 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................................. 8 3.2.4 Phantoms ......................................................................................................................................................... 8 3.2.5 Device Holder .................................................................................................................................................. 9 3.2.6 System Validation Dipoles ............................................................................................................................. 10 3.2.7 Power Source ................................................................................................................................................ 10 3.2.8 Tissue Simulating Liquids .............................................................................................................................. 11 3.3 SAR System Verification ............................................................................................................................................ 13 3.4 SAR Measurement Procedure ................................................................................................................................... 14 3.4.1 Area Scan and Zoom…

Text truncated - open the document above for the full version.

Middyantenna Measurement Report CEB005L CEB005R Manufacturingname: Dongguan DongchengTymphanyAcoustic Technology Co., Ltd. Address: 135 ShijieKejiEast Road, Dongguan City, Guangdong Province,China Measurement Setup 2 Free Space Phantom Head Return Loss –Free Space 3 Left SideRight Side Return Loss –Phantom Head 4 3 Views of Antenna 5 2D Radiation –Free space L 6 2D Radiation –Free space R 7 2D Radiation –Phantom Head L 8 2D Radiation –Phantom Head R 9 Antenna Efficiency and Gain 10 Antenna size/photo 11

Report No.: RFBDMD-WTW-P22070452-2 Page No. 1 / 53 Report Format Version: 6.1.1 FCC Test Report Report No.: RFBDMD-WTW-P22070452-2 FCC ID: B94-CEB005R Test Model: CEB005 Received Date: Jul. 15, 2022 Test Date: Jul. 26, 2022 ~ Sep. 30, 2022 Issued Date: Nov. 01, 2022 Applicant: HP Inc. Address: 3390 East Harmony Road, Fort Collins, Colorado United States 80528 Issued By: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Lin Kou Laboratories Lab Address: No. 47-2, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan Test Location (1): No.19, Hwa Ya 2nd Rd., Wen Hwa Vil., Kwei Shan Dist., Taoyuan City 33383, Taiwan Test Location (2): No. 70, Wenming Rd., Guishan Dist., Taoyuan City 333, Taiwan FCC Registration / Designation Number: (1) 788550 / TW0003 (2) 281270 / TW0032 This report is governed by, and incorporates by reference, the Conditions of Testing as posted at the date of issuance of this report at http://www.bureauveritas.com/home/about-us/our-business/cps/about-us/terms-conditions/ and is intended for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. Measurement uncertainty is only provided upon request for accredited tests. Statements of conformity are based on simple acceptance criteria without taking measurement uncertainty into account, unless otherwise requested in writing. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence or if you require measurement uncertainty; provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Report No.: RFBDMD-WTW-P22070452-2 Page No. 2 / 53 Report Format Version: 6.1.1 Table of Contents Release Control Record .................................................................................................................................. 4 1 Certificate of Conformity ........................................................................................................................... 5 2 Summary of Test Results ........................................................................................................................... 6 2.1 Measurement Uncertainty ..................................................................................................................... 7 2.2 Modification Record .............................................................................................................................. 7 3 General Information ................................................................................................................................... 8 3.1 General Description of EUT .................................................................................................................. 8 3.2 Description of Test Modes ..................................................................................................................... 9 3.2.1 Test Mode Applicability and Tested Channel Detail .................................................................. 10 3.3 Duty Cycle of Test Signal ..................................................................................................................... 11 3.4 Description of Support Units ............................................................................................................... 12 3.4.1 Configuration of System under Test ......................................................................................... 12 3.5 General Description of Applied Standards and References ............................................................... 13 4 Test Types and Results ............................................................................................................................ 14 4.1 Radiated Emission and Bandedge Measurement .............................................................................. 14 4.1.1 Limits of Radiated Emission and Bandedge Measurement ..................................................... 14 4.1.2 Test Instruments ....................................................................................................................... 15 4.1.3 Test Procedures ........................................................................................................................ 16 4.1.4 Deviation from Test Standard ................................................................................................... 17 4.1.5 Test Set Up ..............................................................…

Text truncated - open the document above for the full version.
