Regulatory, Safety and Environmental Notices USER GUIDE NB_RegGuide_718033-002.book Page 1 Friday, March 15, 2013 3:44 PM About This Guide                            WARNING! Text set off in this manner indicates that failure to follow directions could result in bodily harm or loss of life.  CAUTION: Text set off in this manner indicates that failure to follow directions could result in damage to equipment or loss of information. NB_RegGuide_718033-002.book Page 2 Friday, March 15, 2013 3:44 PM User Guide1 Regulatory notices This document provides country- and region-specific non-wireless and wireless regulatory notices and compliance information for the computer product. Some of these notices may not apply to your product. One or more integrated wireless devices may be installed. In some environments, the use of wireless devices may be restricted. Such restrictions may apply on-board airplanes, in hospitals, near explosives, in hazardous locations, and so on. If you are uncertain of the policy that applies to the use of this product, ask for authorization to use it before you turn it on. To identify a hardware device such as a wireless LAN (WLAN) network device, follow the instructions provided by your operating system. Regulatory markings for your country or region may be located on the bottom of the product, either under the battery, (or some other user-accessible location), or on the wireless or modem module.  Caution: Devices not for sale or use in the United States may not have an FCC ID. Federal Communications Commission notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures. Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by HP may void the user’s authority to operate the equipment. NB_RegGuide_718033-002.book Page 1 Friday, March 15, 2013 3:44 PM 2User Guide Cables To maintain compliance with FCC Rules and Regulations, connections to this device must be made with shielded cables having metallic RFI/EMI connector hoods. Declaration of Conformity for products marked with the FCC logo (United States only) This device complies with Part 15 of the FCC Rules. Operation is subject to the following 2 conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. If you have questions about the product that are not related to this declaration, write to Hewlett-Packard Company P. O. Box 692000, Mail Stop 530113 Houston, TX 77269-2000 For questions regarding this FCC declaration, write to Hewlett-Packard Company P. O. Box 692000, Mail Stop 510101 Houston, TX 77269-2000 or call HP at 281-514-3333. To identify your product, refer to the part, series, or model number located on the product. Products with wireless LAN devices or HP Mobile Broadband Modules This device must not be co-located or operating in conjunction with any other antenna or transmitter. NB_RegGuide_718033-002.book Page 2 Friday, March 15, 2013 3:44 PM User Guide3  WARNING! Exposure to Radio Frequency Radiation: The radiated output power of this device is below the FCC radio frequency exposure limits. Nevertheless, the device should be used in such a manner that the potential for human contact is minimized during normal operation of tablet PCs and notebook computers. During normal operation of tablet PCs and notebook computers with displays equal to or less than 30.5 cm (12 inches): To avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antennas should not be less than 2.5 cm (1 inch). To identify the location of the wireless antennas, refer to the computer user guides included with your computer. During normal operation of notebook computers with displays greater than 30.5 cm (12 inches): To avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity to the antennas should not be less than 20cm (8 inches), including when the computer display is closed. To identify the location of the wireless antennas, refer to the computer user guides included with your computer.  CAUTION: When using IEEE 802.11a wireless LAN, this product is restricted to indoor use, due to its operation in the 5.15- to 5.25-GHz frequency range. The FCC requires this product to be used indoors for the frequency range of 5.15 GHz to 5.25 GHz to reduce the potential for harmful interference to co-channel mobile satellite systems. High-power radar is allocated as the primary user of the 5.25- to 5.35-GHz and 5.65- to 5.85-GHz bands. These radar stations can cause interference with and/or damage to this device. Brazil notice Este equipamento opera em caráter secundário, isto é, não tem d…

Text truncated - open the document above for the full version.

Date: March 26, 2014 Declaration We, Hewlett-Packard Company, declare that the device, FCC ID: B94TNQ145, Model Name: TPN-Q145, does not have Ad Hoc on non-US frequencies and/or on DFS frequencies. Also, the client software and associated drivers will not initiate any transmission on DFS frequencies without initiation by a master. This includes restriction on transmissions for beacons and support for ad-hoc peer-to-peer modes. Moreover, for 2.4G part of this device, only channels 1~11, will be used in North America and all non- US frequencies and Country code selection are disabled through proprietary software and is not user changeable. Should you have any question or comment regarding this matter, please do not hesitate to contact me. Sincerely yours, _____________________ Liang Rong Chiao/ Regulatory Program Manager Hewlett-Packard Company Tel: 886-2- 8722-8684 E-mail: [email protected]

Date: March 26, 2014 Federal Communications Commission Authorization and Evaluation Division 7345 Oakland Mills Road Columbia MD 21046 SUBJECT: FCC Application for FCC ID: B94TNQ145 To Whom It May Concern, We, Hewlett-Packard Company, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the class B computer peripheral portion of this composite filing. Sincerely yours, Liang Rong Chiao/ Regulatory Program Manager Hewlett-Packard Company Tel: 886-2- 87228684 E-mail: [email protected]

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (current) 2.0 3.0 Jan-31-2012 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 3.0 April 7, 2014 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Hewlett-Packard Company hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Laptop / TPN-Q145 We affirm that between SIEMIC and Hewlett-Packard Company, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, _____________________ Daniel Lee / Vice President Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch Tel: +886 3 318 3232 #1857

Date: March 26, 2014 Federal Communications Commission 7345 Oakland Mills Road Columbia MD21046 Subject: Request for Confidentiality FCC ID: B94TNQ145 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission’s rules (47CFR§§0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely.  Schematic Diagram  Block Diagram  Parts List  Operational Description Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’ s policy, in order to comply with the marketing regulations in 47 CFT §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days after the Grant Date of Equipment Authorizations.  External Photos  Internal Photos  Test Setup Photos  Users Manual It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards, Liang Rong Chiao/ Regulatory Program Manager Hewlett-Packard Company Tel: 886-2- 877-8684 E-mail: [email protected]

Authorization on Behalf of Hewlett-Packard Company For the US Federal Communications Commission Office of Engineering and Technology and Other FCC Programs and Offices 1. I, David P. Adams, am Canada/USA Technical Regulations Manager for Hewlett-Packard Company (“Hewlett-Packard”) and Applicant/Grantee Contact of Record for Hewlett-Packard together with its subsidiaries and affiliates worldwide (collectively, “HP”) for HP’s dealings with the United States Federal Communications Commission (“FCC”). I am duly authorized by HP to make this Authorization on HP’s behalf. 2. This Authorization replaces that dated September 24, 2012 for the person named below to act on my behalf and HP’s behalf as authorized agent and representative, until further notice, with the additional power to designate one or more third party agents for HP with regard to particular matters and applications. All acts carried out and requests made by this named representative relating to any matter before the FCC, including requests for confidentiality, shall have the same effect as mine. Name: Rong-Chiao Liang Title: Product Regulations Engineer Address: HP Taiwan Ltd 10-F1, No. 66 Jingmao 2 nd Rd NanGang District Taipei, Taiwan 11568 Telephone: 866 2 87228684 E-mail: [email protected] 3. Questions about the scope and effect of this Authorization should be addressed as follows: David P. Adams Canada/USA Region Technical Regulations Manager 1501 Page Mill Road, MS 1419 Palo Alto, CA 94304-1126 650 258 7586 Telephone [email protected] 4. I declare under penalty of perjury that the foregoing is true and correct, and that this Authorization was executed at Palo Alto, California, on the date indicated below my signature. ____________________________ Signature David P. Adams Canada/USA Technical Regulations Manager Hewlett-Packard Company __ April 2, 2014__________ Date

Page 1 of 20 Report No.: 140317C23 CONSTRUCTION PHOTOS OF EUT Page 2 of 20 Report No.: 140317C23 Page 20 of 20 Report No.: 140317C23

FCC ID: B94TNQ145 IC: 466X‐TNQ145 Bottom of EUT Label Location

Page 3 of 20 Report No.: 140317C23 Page 4 of 20 Report No.: 140317C23 Page 5 of 20 Report No.: 140317C23 Page 6 of 20 Report No.: 140317C23 Page 7 of 20 Report No.: 140317C23 WLAN Aux. Antenna WLAN Main Antenna Page 8 of 20 Report No.: 140317C23 Page 9 of 20 Report No.: 140317C23 Page 10 of 20 Report No.: 140317C23 Page 11 of 20 Report No.: 140317C23 Page 12 of 20 Report No.: 140317C23 Page 13 of 20 Report No.: 140317C23 Page 14 of 20 Report No.: 140317C23 Page 15 of 20 Report No.: 140317C23 Page 16 of 20 Report No.: 140317C23 Page 17 of 20 Report No.: 140317C23 Page 18 of 20 Report No.: 140317C23 Page 19 of 20 Report No.: 140317C23

FCC SAR Test Report Report Format Version 5.0.0 Page No. : 1 of 27 Report No. : SA140317C23 Issued Date : Apr. 07, 2014 FCC SAR Test Report Report No. : SA140317C23 Applicant : HEWLETT-PACKARD COMPANY Address : 3000 HANOVER STREET, PALO ALTO, CALIFORNIA 94304, USA Product : Laptop FCC ID : B94TNQ145 Brand : hp; Hewlett-Packard Model No. : TPN-Q145 Standards : FCC 47 CFR Part 2 (2.1093) / IEEE C95.1:1992 / IEEE 1528:2003 IEEE 1528a-2005 / KDB 865664 D01 v01r03 / KDB 248227 D01 v01r02 KDB 447498 D01 v05r02 / KDB 616217 D04 v01r01 Sample Received Date : Mar. 17, 2014 Date of Testing : Mar. 25, 2014 ~ Mar. 26, 2014 CERTIFICATION: The above equipment have been tested by Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch – Lin Kou Laboratories, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s SAR characteristics under the conditions specified in this report. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product certification, approval, or endorsement by TAF or any government agencies. Prepared By : Evonne Liu / Specialist Approved By : Gordon Lin / Assistant Manager This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. FCC SAR Test Report Report Format Version 5.0.0 Page No. : 2 of 27 Report No. : SA140317C23 Issued Date : Apr. 07, 2014 Table of Contents Release Control Record ............................................................................................................................................................... 3 1. Summary of Maximum SAR Value ....................................................................................................................................... 4 2. Description of Equipment Under Test ................................................................................................................................. 5 3. SAR Measurement System ................................................................................................................................................... 6 3.1 Definition of Specific Absorption Rate (SAR) ............................................................................................................... 6 3.2 SPEAG DASY System ................................................................................................................................................. 6 3.2.1 Robot.................................................................................................................................................................. 7 3.2.2 Probes ................................................................................................................................................................ 8 3.2.3 Data Acquisition Electronics (DAE) .................................................................................................................... 8 3.2.4 Phantoms ........................................................................................................................................................... 9 3.2.5 Device Holder ................................................................................................................................................... 10 3.2.6 System Validation Dipoles ................................................................................................................................ 10 3.2.7 Tissue Simulating Liquids ................................................................................................................................. 11 3.3 SAR System Verification ............................................................................................................................................ 14 3.4 SAR Measurement Procedure ................................................................................................................................... 15 3.4.1 Area & Zoom Scan Procedure ......................................................................................................................... 15 3.4.2 Volume Scan Procedure................................................................................................................................... 15 3.4.3 Power Drift Monitoring ...................................................................................................................................... 16 3.4.4 Spatial Peak SAR Evaluation ........................................................................................................................... 16 3.4.5 SAR Averaged Methods ...…

Text truncated - open the document above for the full version.

FCC SAR Test Report Report Format Version 5.0.0 Issued Date : Apr. 07, 2014 Report No. : SA140317C23 Appendix C. Calibration Certificate for Probe and Dipole The SPEAG calibration certificates are shown as follows.

Report No.: RF140317C23-3 1 of 109 Report Format Version 5.2.0 FCC TEST REPORT (15.407) REPORT NO.: RF140317C23-3 MODEL NO.: TPN-Q145 FCC ID: B94TNQ145 RECEIVED: Mar. 17, 2014 TESTED: Mar. 27, 2014 ~ Mar. 31, 2014 ISSUED: Apr. 07, 2014 APPLICANT: HEWLETT-PACKARD COMPANY ADDRESS: 3000 HANOVER STREET, PALO ALTO, CALIFORNIA 94304, USA ISSUED BY: Bureau Veritas Consumer Products Services (H.K.) Ltd., Taoyuan Branch LAB ADDRESS: No. 47, 14th Ling, Chia Pau Vil., Lin Kou Dist., New Taipei City, Taiwan ( R.O.C ) TEST LOCATION: No. 19, Hwa Ya 2nd Rd, Wen Hwa Tsuen, Kwei Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C. This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. This report should not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: RF140317C23-3 2 of 109 Report Format Version 5.2.0 TABLE OF CONTENTS RELEASE CONTROL RECORD ..............................................................................................................4 1. CERTIFICATION ..................................................................................................................................5 2. SUMMARY OF TEST RESULTS .........................................................................................................6 2.1 MEASUREMENT UNCERTAINTY...............................................................................................6 3. GENERAL INFORMATION ..................................................................................................................7 3.1 GENERAL DESCRIPTION OF EUT ............................................................................................7 3.2 DESCRIPTION OF TEST MODES ..............................................................................................9 3.2.1 TEST MODE APPLICABILITY AND TESTED CHANNEL DETAIL .............................. 10 3.3 DESCRIPTION OF SUPPORT UNITS ..................................................................................... 13 3.3.1 CONFIGURATION OF SYSTEM UNDER TEST ......................................................... 13 3.4 DUTY CYCLE TEST SIGNAL ................................................................................................... 14 3.5 GENERAL DESCRIPTION OF APPLIED STANDARDS .......................................................... 20 4. TEST TYPES AND RESULTS .......................................................................................................... 21 4.1 RADIATED EMISSION AND BANDEDGE MEASUREMENT .................................................. 21 4.1.1 LIMITS OF RADIATED EMISSION AND BANDEDGE MEASUREMENT ................... 21 4.1.2 LIMITS OF UNWANTED EMISSION OUT OF THE RESTRICTED BANDS .............. 21 4.1.3 TEST INSTRUMENTS ................................................................................................. 22 4.1.4 TEST PROCEDURES ................................................................................................. 23 4.1.5 DEVIATION FROM TEST STANDARD ....................................................................... 23 4.1.6 TEST SETUP ............................................................................................................... 24 4.1.7 EUT OPERATING CONDITIONS ................................................................................ 25 4.1.8 TEST RESULTS........................................................................................................... 26 4.2 CONDUCTED EMISSION MEASUREMENT ........................................................................... 70 4.2.1 LIMITS OF CONDUCTED EMISSION MEASUREMENT ........................................... 70 4.2.2 TEST INSTRUMENTS ................................................................................................. 70 4.2.3 TEST PROCEDURES ................................................................................................. 71 4.2.4 DEVIATION FROM TEST STANDARD ....................................................................... 71 4.2.5 TEST SETUP ............................................................................................................... 72 4.2.6 EUT OPERATING CONDITIONS ................................................................................ 72 4.2.7 TEST RESULTS........................................................................................................... 73 4.3 PEAK TRANSMIT POWER MEASUREMENT ......................................................................... 75 4.3.1 LIMITS OF PEAK TRANSMIT POWER MEASUREMENT ......................................... 75 4.3.2 TEST SETUP ............................................................................................................... 75 4.3.3…

Text truncated - open the document above for the full version.

Report No. : RF140317C23 Page 1 of 5 PHOTOGRAPHS OF THE TEST CONFIGURATION CONDUCTED EMISSION TEST (For Bluetooth) Report No. : RF140317C23 Page 2 of 5 CONDUCTED EMISSION TEST (For WLAN 5GHz) Report No. : RF140317C23 Page 3 of 5 CONDUCTED EMISSION TEST (For WLAN 2.4GHz) Report No. : RF140317C23 Page 4 of 5 CONDUCTED EMISSION TEST (For WLAN 5GHz) Report No. : RF140317C23 Page 5 of 5 RADIATED EMISSION TEST

1 PHOTOGRAPHS OF THE TEST CONFIGURATION Set UUT as Client without radar detection mode (Radar injected into Master) Master UUT Receiver Antenna to S.A.
