BCG-B0534solo2 wireless

beatsbydre.com facebook.com/beatsbydre @beatsbydre @beatsbydre +beatsbydre QUICK START GUIDE 780-00024-01-A_HAN_Wireless_QSG_AMER_AR6_071514H-v2.indd 12-108/10/14 11:04 PM 90º R EN Press power button to turn off headphone. FR Appuyez sur le bouton d’alimentation pour éteindre le casque d’écoute. ES Oprima el botón de encendido para apagar el auricular. PT Pressione o botão liga/desliga para desligar o fone de ouvido. FOLD + FIT EN Press power button without cable for wireless mode. FR Appuyez sur le bouton d’alimentation sans le câble pour le mode sans fil. ES Oprima el botón de encendido sin cable para utilizar el modo inalámbrico. PT Pressione o botão liga/desliga sem o cabo para o modo sem fio. WIRELESS MODE EN Expand and collapse to play and store. FR Agrandir et réduire pour jouer et entreposer. ES Expanda y pliegue para reproducir y almacenar. PT Expanda e minimize para reproduzir e guardar. EN Slide earcups up and down and ensure correct earcup orientation for proper fit. FR Glissez les écouteurs vers le haut ou le bas et orientez correctement les oreillettes pour bien les ajuster. ES Deslice los auriculares hacia arriba y hacia abajo y asegúrese de que estén en la orientación para un ajuste adecuado. PT Deslize os fones de ouvido para cima e para baixo e verifique se estão na orientação correta para obter o ajuste adequado. 780-00024-01-A_HAN_Wireless_QSG_AMER_AR6_071514H-v2.indd 2-308/10/14 11:04 PM EN Pair with device when Bluetooth ® indicator light is blinking. FR Couplez l’appareil lorsque l’indicateur Bluetooth ® clignote. ES Acoplar con el dispositivo cuando la luz indicadora de Bluetooth ® esté parpadeando. PT Emparelhe com o dispositivo quando o indicador do Bluetooth ® estiver piscando. x 2 x 3 WIRELESS PAIRINGWIRELESS CONTROLS Play, Lecture, Reproducir, Reproduzir Pause, Pause, Pausa, Pausa Next Track, Prochaine piste, Próxima Pista, Próxima Faixa Previous Track, Piste précédente, Pista Anterior, Faixa Anterior Answer, Répondre, Contestar, Atender End Call, Fin de l’Appel, Finalizar Llamada, Encerrar Chamada Volume Up, Augmenter le volume, Subir Volumen, Aumentar volume Volume Down, Baisser le volume, Bajar Volumen, Diminuir volume Music ControlsPhone Controls EN Press and hold “b” button for 2 seconds for pairing mode. FR Appuyez sur le bouton “b” et maintenez-le enfoncé pendant 2 secondes pour activer le mode de couplage. ES Presione el botón “b” sin soltar durante 2 segundos para utilizar el modo de conexión. PT Pressione e segure o botão “b” durante dois segundos para o modo de emparelhamento. 780-00024-01-A_HAN_Wireless_QSG_AMER_AR6_071514H-v2.indd 4-508/10/14 11:04 PM EN Plug in straight cable end for wired mode. FR Branchez l’extrémité du câble droit pour utiliser le mode avec fil. ES Conecte directamente el extremo del cable para usar el modo con cable. PT Conecte a extremidade do cabo reto para o modo com fio. EN Plug L shaped cable end into source device for wired mode. FR Branchez l’extrémité du câble en forme de L dans le dispositif source pour utiliser le mode avec fil. ES Conecte el extremo del cable en forma de L en el dispositivo de la fuente para usar el modo con cable. PT Conecte a extremidade do cabo em forma de L no dispositivo de origem para o modo com fio. WIRED MODE iPod ® , iPhone ® and iPad ® Android ™ , Windows ® and BlackBerry ® Answer, Répondre, Contestar, Atender End Call, Fin de l’Appel, Finalizar Llamada, Encerrar Chamada Voice Command, Commande Vocale, Orden de Voz, Comando de Voz: Volume Control, Contrôle du Volume, Control de Volumen, Controle de Voz *Functionality may vary by device Music ControlsPhone Controls RE MOTETALK ™ CONTROL x 2 x 3 Play, Lecture, Reproducir, Reproduzir Pause, Pause, Pausa, Pausa Next Track, Prochaine piste, Próxima Pista, Próxima Faixa Previous Track, Piste précédente, Pista Anterior, Faixa Anterior 780-00024-01-A_HAN_Wireless_QSG_AMER_AR6_071514H-v2.indd 6-708/10/14 11:04 PM EN Charge using micro USB cable provided. FR Chargez le dispositif en utilisant le câble micro USB fourni. ES Cargue utilizando el cable micro USB que se le brinda. PT Carregue usando o cabo micro USB fornecido. CHARGINGSTORING + TRAVEL EN Collapse both earcups and place in case to store. FR Rabattez les deux oreillettes et rangez dans l’étui. ES Pliegue ambos auriculares y colóquelos en el estuche de almacenamiento. PT Minimize os fones de ouvido e guarde-os no estojo. EN While unplugged from power source, turn on to see power gauge fuel. FR Lorsque le dispositif n’est pas branché sur le secteur, allumez-le pour voir la jauge de charge de la batterie. ES Mientras esté desconectado de la fuente de poder, encienda para ver el indicador de estado de potencia. PT Quando desconectado da fonte de alimentação, ligue para ver o indicador de carga da alimentação. BATTERY POWER EN Visit www.namemybeats.com to personalize your beats. FR Visitez le site www.namemybeats.com pour personnaliser votre beats. ES Visite www.namemybeats.com para personalizar sus beats. PT Acesse www.namemybeats.com para personalizar suas batidas. NAME YOUR BEATS 780-00024-01-A_HAN_Wireless_QSG_AMER_AR6_071514H-v2.indd 8-908/10/14 11:04 PM VISIT BEATSBYDRE.COM/SUPPORT FOR MORE INFORMATION Product Care Entretien du Produit Cuidado del Producto Cuidados com o Produto Product Registration Enregistrement du Produit Registro del Producto Registro do Produto Troubleshooting Dépannage Localización y solución de problemas Resolução de Problemas Software Updates Mises à Niveau des Logiciels Actualizaciones del Software Atualizações do Software 1-800-442-4000 6am to 7pm PST Warranty Garantie Garantía Garantia “iPod”, “iPhone” and “iPad” are trademarks of Apple Inc., registered in the U.S. and other countries. “Android” is a trademark of Google Inc. “Windows” is a registered trademark of Microsoft Corporation in the United States and other countries. Blackberry ® is the property of Research In Motion Limited and is registered and/or used in the U.S. and countries around the world. Us…

Text truncated - open the document above for the full version.

ENGLISH IMPORTANT SAFETY INFORMATION Use Responsibly Do not use headphones when it is unsafe to do so: while operating a vehicle, crossing the street, or during any activity or in an environment where your full attention to your surroundings is required. It’s dangerous to drive while wearing headphones, and in many places, illegal because it decreases your chances of hearing life-saving sounds outside of your vehicle, such as another car’s horn and emergency vehicle sirens. Please avoiding wearing our headphones while driving. Use an FM transmitter to listen to your mobile media devices instead. Listen Responsibly To avoid hearing damage, make sure that the volume on your music player is turned down before connecting your headphones. After placing the headphones in/on your ear, gradually turn up the volume until you reach a comfortable listening level. Noise levels are measured in decibels (dB); exposure to any noise at or above 85 dB can cause gradual hearing loss. Monitor your use; hearing loss is a function of loudness versus time. The louder it is, the less time you can be exposed to it. The softer it is, the more time you can listen to it. To prevent possible hearing damage, do not listen at high volume levels for long periods. 774-00015-01-B_Beats_SC_SoloWrls_AMER.indd 110/28/14 12:28 PM ENGLISH SOUNDNOISE LEVEL (dB) EFFECT Whisper30Very quiet 50-60Comfortable hearing levels Vacuum Cleaner, Hair Dryer 70Intrusive; interferes with telephone conversations Food Blender85-90 damage (8 hr) begins Dustbin Lorry, Cement Mixer 100No more than 15 minutes of unprotected exposure recommended Power Saw, Drill/Jackhammer 110 hearing loss Rock Concert (varies)110-140Threshold of pain begins * Chart information from http://www.nidcd.nih.gov/health/education/teachers/pages/common_sounds.aspx This decibel (dB) table compares some common sounds and shows how they rank in potential harm to hearing. IC AND FCC COMPLIANCE STATEMENT This device complies with Industry Canada license-exempt RSS standard(s). This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any in terference received, including interference that may cause undesired operation. ENGLISH 774-00015-01-B_Beats_SC_SoloWrls_AMER.indd 2-310/28/14 12:28 PM CANADIENNE-FRANÇAISE RENSEIGNEMENTS DE SÉCURITÉ IMPORTANTS Utilisation en toute Sécurité N’utilisez pas vos écouteurs si cela pose un risque : par exemple en conduisant un véhicule, en traversant la rue, lors d’une activité ou dans un milieu où une grande attention à ce qui se passe autour de vous est requise. Il est dangereux de conduire en portant des écouteurs et c’est illégal dans de nombreuses régions, puisque cela réduit vos chances d’entendre des sons qui pourraient vous sauver la vie, comme le klaxon d’un autre véhicule ou la sirène de véhicules d’urgence. Veuillez donc éviter de porter vos écouteurs au volant. Utilisez un transmetteur FM pour écouter le contenu de votre lecteur multimédia en voiture. Utilisation Responsable Pour éviter de subir des dommages auditifs, assurez-vous que le volume de votre lecteur multimédia est réduit avant de brancher vos écouteurs. Après avoir placé les écouteurs dans/ sur vos oreilles, augmentez progressivement le son jusqu’au niveau qui vous convient. Les niveaux sonores sont mesurés en décibels (dB) ; l’exposition à des sons de 85 dB ou plus peut conduire à une perte auditive graduelle. Surveillez votre utilisation des écouteurs; la perte auditive dépend du niveau sonore et de la durée de l’écoute. Plus un son est fort, moins vous devez vous y exposer. Plus un son est doux, plus longtemps vous pouvez l’écouter. Pour prévenir des dommages auditifs, n’écoutez pas cet appareil à un niveau de volume élevé pendant une longue période. CAUTION STATEMENT Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. WARNING: WARNING: Do not expose beatssolo™ 2 Wireless to excessive heat, fire, or the like. DECLARATION OF CONFORMITY Beats Electronics, LLC hereby declares that this product complies with the essential requirements and other relevant provisions of the guidelines. The Declaration of Conformity can be found on the website www.beatsbydre.com/compliance. DISPOSAL AND RECYCLING INFORMATION The symbol indicates that this product and/or battery should not be disposed of with household waste. When you decide to dispose of this product and/or its battery, do so in accordance with local environmental laws and guidelines. BEATS AND THE ENVIRONMENT At Beats, we recognize our responsibility to minimize the environmental impacts of our operations and products. For more information, go to www.apple.com/environment/ ENGLISH 774-00015-01-B_Beats_SC_SoloWrls_AMER.indd 4-510/28/14 12:28 PM CANADIENNE-FRANÇAISE SONNIVEAU SONORE (dB) EFFET Murmure30Très calme Bureau calme50-60Le niveau d’écoute confortable se situe en dessous de 60 dB Aspirateur, sèche-cheveux70Dérangeant; perturbe les conversations téléphoniques Mélangeur d’aliments85-9085 dB est le niveau où débute les dommages auditifs (8 heures) Camion poubelle, bétonnière 100Pas plus de 15 minutes d’exposition non protégée sont recommandées pour les sons entre 90 et 100 dB Scie électrique, perceuse/marteau-piqueur 110Une exposition régulièr e à des niveaux supérieurs à 100dB pendant plus d’une minute peut entraîner une perte Concert de rock (variable)110-140Le seuil de la douleuer débute aux environs de de 125 dB *Informations fournies par http://www.nidcd.nih.gov/health/education/teachers/pages/common_sounds.aspx Le tableau de décibels (dB) suivant compare certains sons et classe les dommages potentiels à l’audition. DÉCLARATION DE CONFORMITÉ CFC ET IC Cet appareil est conforme aux normes RSS exempts de licence d’Industrie Canada. Cet équipement est conforme à la partie 15 du règlement de …

Text truncated - open the document above for the full version.

 v1.0 Apple Inc. 1 Infinite Loop Cupertino, CA www.apple.com Date: October 30, 2014 Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd. Columbia MD 21046 Attn: Office of Engineering and Technology Ref: FCC ID: BCG-B0534, Model: B0534 To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc., located at 47173 Benicia Street, Fremont, CA 94538, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized;  v1.0 Apple Inc. 1 Infinite Loop Cupertino, CA www.apple.com e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely, ____________________ Tiberiu Muresan Apple Inc. Wireless Certification Manager [email protected]

 Apple Inc. 1 Infinite Loop Cupertino, CA v1.0 www.apple.com Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd. Columbia MD 21046 Subject: Request for Confidentiality FCC ID: BCG-B0534, Model B0534 To whom it may concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), Apple Inc. hereby requests confidential treatment for documents filed with the Commission in connection with the application for equipment authorization referenced above. Permanent Confidentiality Apple Inc. requests that the Commission withholds the following documents from public viewing indefinitely: • Block Diagrams • Electrical Schematic Diagrams • Theory of Operation These documents reveal detailed technical and design information that is protected by Apple Inc. as confidential and proprietary trade secrets. This information has been disclosed to those required to maintain its confidentiality, and is not customarily disclosed to the public even after commercial release of a device. As a result, disclosure of this information by the Commission would harm Apple Inc. by giving competitors an unfair advantage even after commercial release of the device. Short Term Confidentiality In addition to the above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, Apple Inc. requests that the Commission withholds the following documents  Apple Inc. 1 Infinite Loop Cupertino, CA v1.0 www.apple.com from public viewing for one hundred eighty days after the date the grant of equipment authorization is issued: • External Photographs • Internal Photographs • Test Setup Photographs • User Manual These documents reveal technical and design information that has not been publicly disclosed in marketing materials and is protected by Apple Inc. as confidential and proprietary trade secrets. This information has been disclosed to those required to maintain its confidentiality, and is not customarily disclosed publicly prior to the commercial release of the device. As a result, disclosure of this information by the Commission prior to commercial release would harm Apple Inc. by giving competitors an unfair market advantage. Apple Inc. believes the period of confidentiality requested is necessary to protect the information until the commercial release of a device. It is our understanding that measurement test reports and FCC ID label format cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Date: October 30, 2014 ____________________ Tiberiu Muresan Apple Inc. Wireless Certification Manager [email protected]

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: December 13, 2012 Subject: Authorized Individual To Whom It May Concern: Pursuant to the provisions of KDB 852134 D01 Authorized Policy Form 731, I, grantee contact, hereby authorize Tiberiu Muresan to act on behalf of Apple Inc. for all matters relating to equipment authorization, including signing Form 731, attestations, and confidentiality request letters. This authorized individual may also assign another party to act as an authorized agent. This authorization is valid until further written notice from the grantee contact. Marc Douat Apple Inc. 1 Infinite Loop Cupertino, CA 95014

Solo 2 Wireless External Pictures

“Android” is a trademark of Google Inc. “Windows” is a registered trademark of Microsoft Corporation in the United States and other countries. Blackberry ® is the property of Research In Motion Limited and is registered and/or used in the U.S. and countries around the world. Used under license from Research In Motion Limited. “DESIGNED FOR SOUND TUNED FOR EMOTION NOW WIRELESS” and “solo” are trademarks of Beats Electronics, LLC. “Android” est une marque de commerce de Google Inc. “Windows” est une marque déposée de Microsoft Corporation, enregistrée aux États-Unis et dans d'autres pays. Blackberry ® , propriété de Research In Motion Limited, est enregistré et/ou utilisé aux États-Unis et dans d'autres pays à travers le monde. Il est utilisé sous licence de Research in Motion Limited. “DESIGNED FOR SOUND TUNED FOR EMOTION NOW WIRELESS” et “solo” sont des marques de commerce de Beats Electronics, LLC. The packaging is recyclable. Recycling programs for this package may not exist in your area. L’emballage est recyclable. Les programmes de recyclage peuvent ne pas exister dans votre région. Apple Inc. 1 Innite Loop Cupertino, CA 95014 USA 777-00412-01-A Model:B0534 Han Product Label - Plan B Dieline 777-00412-01-A AMER October 10, 2014 = Beats Black 13 = Dieline PCH/Beats - HAN-B Packaging - Preliminary Engineering Drawing Over Ear / Split Box Style - Medium Size / Product Label LMS.05Feb2014 140.0mm 46.5mm 46.5mm 93.0mm C M Y CM MY CY CMY K 777-00412-01-A_HanWrls_Product_Label_Black_RD1.pdf 1 11/10/14 2:46 AM

Model B0534 Markings MODEL NUMBER FCC & IC ID

NVLAP LAB CODE 200065-0 SAR EVALUATION REPORT FCC 47 CFR § 2.1093 IEEE Std 1528-2013 For solo2 wireless Model: B0534 FCC ID: BCG-B0534 Report Number: 14U18945-S1B Issue Date: 11/4/2014 Prepared for APPLE, INC. 1 INFINITE LOOP CUPERTINO, CA 95014, U.S.A. Prepared by UL VERIFICATION SERVICES INC. 47173 BENICIA STREET FREMONT, CA 94538, U.S.A. TEL: (510) 771-1000 FAX: (510) 661-0888 Report No.: 14U18945-S1B Issue Date: 11/4/2014 Page 2 of 19 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. REVISION HISTORY Rev. Issue Date Revisions Revised By -- 10/31/2014 Initial Issue -- A 11/3/2014 Report revised based on reviewer’s comments: 1. Sec. 6.2, 11.1.: Updated Kenneth Mak B 11/4/2014 Report revised based on reviewer’s comments: 1. Sec. 6.1., 11.: Updated description/statement 2. Appendix A: Updated with statement Kenneth Mak Report No.: 14U18945-S1B Issue Date: 11/4/2014 Page 3 of 19 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. Table of Contents 1. Attestation of Test Results ......................................................................................................... 5 2. Test Specification, Methods and Procedures ............................................................................ 6 3. Facilities and Accreditation ........................................................................................................ 6 4. SAR Measurement System & Test Equipment .......................................................................... 7 4.1. SAR Measurement System ...................................................................................................... 7 4.2. SAR Scan Procedure ............................................................................................................... 8 4.3. Test Equipment ...................................................................................................................... 10 5. Measurement Uncertainty ......................................................................................................... 11 6. Device Under Test (DUT) Information ...................................................................................... 12 6.1. DUT Description ..................................................................................................................... 12 6.2. Wireless Technologies ........................................................................................................... 12 6.3. Maximum Output Power ......................................................................................................... 12 6.4. Simultaneous Transmission Condition ................................................................................... 12 6.5. Antenna Dimensions and Separation Distances ..................................................................... 12 7. RF Exposure Conditions (Test Configurations) ...................................................................... 12 8. Conducted Output Power Measurements ................................................................................ 13 8.1. Bluetooth ................................................................................................................................ 13 9. Dielectric Property Measurements ........................................................................................... 14 9.1. Tissue Dielectric Parameters ................................................................................................. 14 9.2. Dielectric Property Measurements Results ............................................................................. 14 10. System Check ............................................................................................................................ 15 10.1. Reference Target SAR Values ............................................................................................... 15 10.2. System Check Results ........................................................................................................... 15 11. Measured and Reported (Scaled) SAR Results ....................................................................... 16 11.1. Bluetooth ................................................................................................................................ 17 12. SAR Measurement Variability ................................................................................................... 18 12.1. The Highest Measured SAR Configuration in Each Frequency Band ..................................... 18 12.2. Repeated Measurement Results ............................................................................................ 18 13. Simultaneous Transmission SAR Analysis ............................................................................. 18 Appendixes .......................................................................................................................................... 19 Appendix A: SAR Photos .................................................................................................................... 19 Appendix B: SAR System Check Plots ............................................................................................... 19 Report No.: 14U18945-S1B Issue Date: 11/4/2014 Page 4 of 19 UL Verification Services Inc. Doc. No.: 1.0 This report shall not be reproduced without the written approval of UL Verification Services Inc. Appendix C: SAR Highest SAR Test Plots .......................................................................................... 19 Appendix D: SAR Tissue Ingredients .................................................................................................. 19 Appendix E: SAR Probe Cal. Certificates ...............................................................................…

Text truncated - open the document above for the full version.

Plot No. 1 Test Laboratory: UL Verification Services Inc. SAR Lab B Date/Time: 10/20/2014 7:49:27 PM 20141020_SystemPerformanceCheck-D2450V2 SN 748 Frequency: 2450 MHz; Duty Cycle: 1:1; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used: f = 2450 MHz; σ = 1.835 S/m; ε r = 38.764; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE3 Sn500; Calibrated: 5/15/2014 - Probe: EX3DV4 - SN3749; ConvF(6.6, 6.6, 6.6); Calibrated: 1/29/2014; - Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: SAM; Type: QD000PCD; Serial: 1632 Head/Pin=100 mW/Area Scan (8x8x1): Measurement grid: dx=12mm, dy=12mm Maximum value of SAR (measured) = 6.95 W/kg Head/Pin=100 mW/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 59.179 V/m; Power Drift = 0.08 dB Peak SAR (extrapolated) = 10.6 W/kg SAR(1 g) = 5.11 W/kg; SAR(10 g) = 2.35 W/kg Maximum value of SAR (measured) = 7.26 W/kg 0 dB = 7.26 W/kg = 8.61 dBW/kg Plot No. 2 Test Laboratory: UL Verification Services Inc. SAR Lab B Date/Time: 10/20/2014 8:09:40 PM 20141020_SystemPerformanceCheck-D2450V2 SN 748 Frequency: 2450 MHz; Duty Cycle: 1:1 Head/Pin=100 mW/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=5mm Maximum value of SAR (measured) = 6.23 W/kg Plot No. 1 Test Laboratory: UL Verification Services Inc. SAR Lab B Date/Time: 10/21/2014 10:20:53 PM Bluetooth Frequency: 2402 MHz; Duty Cycle: 1:1.29033; Room Ambient Temperature: 24.0C; Liquid Temperature: 23.0C Medium parameters used (interpolated): f = 2402 MHz; σ = 1.786 S/m; ε r = 38.923; ρ = 1000 kg/m 3 DASY5 Configuration: - Area Scan Setting: Find Secondary Maximum Within: 2.0 dB and with a peak SAR value greater than 0.0012W/kg - Electronics: DAE3 Sn500; Calibrated: 5/15/2014 - Probe: EX3DV4 - SN3749; ConvF(6.6, 6.6, 6.6); Calibrated: 1/29/2014; - Sensor-Surface: 2.5mm (Mechanical Surface Detection (Locations From Previous Scan Used)), Sensor-Surface: 2.5mm (Mechanical Surface Detection) - Phantom: SAM; Type: QD000PCD; Serial: 1632 LHS/Touch_(without Foam)_802.15_GFSK_Ch 0/Area Scan (10x10x1): Measurement grid: dx=12mm, dy=12mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.0377 W/kg LHS/Touch_(without Foam)_802.15_GFSK_Ch 0/Zoom Scan (7x7x7)/Cube 0: Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 4.369 V/m; Power Drift = 0.06 dB Peak SAR (extrapolated) = 0.0450 W/kg SAR(1 g) = 0.025 W/kg; SAR(10 g) = 0.011 W/kg Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.0342 W/kg 0 dB = 0.0342 W/kg = -14.66 dBW/kg

Head Tissue Simulating Liquids Head Tissue Parameters according to IEEE Std 1528-2013 / IEC 62209 / FCC KDB 865664 D01 Narrow- Band Solutions (±5% tolerance) Product HSL300V2 HSL450V2 HSL750V2 HSL900V2 HSL1450V2 HSL1750V2 HSL1800V2 HSL1900V2 HSL1950V2 HSL2450V2 Test Frequency (MHz) 300 450 750 835, 900 1450, 1500, 1640 1750 1800, 1900 1900 1950, 2000 2450, 2600 Main Ingredients Water, Sugar Water, Sugar Water, Sugar Water, Sugar Water, DGBE Water, DGBE Water, DGBE Water, DGBE Water, DGBE Water, DGBE Broad- Band Solutions (±5% tolerance) Product HBBL30-250V3 HBBL1350-1850V3 HBBL1550-1950V3 HBBL1900-3800V3 HBBL3500-5800V5 Test Frequency (MHz) 30-250 1400-1800 1750-1900 1950-3000 3500-5800 Main Ingredients Water, Tween Water, Tween Water, Tween Water, Tween Water, Oil Body Tissue Simulating Liquids Body Tissue (Muscle) Parameters according to FCC KDB 865664 D01 Narrow- Band Solutions (±5% tolerance) …
