BCGA1197Apple Bluetooth Mouse

PATTERN DATA Peak Gain-1.55-2.67-1.55-1.43-1.55-4.95 Angle 2402 MHz Vertical xy 2402 MHz Horizontal xy 2402 MHz Vertical xz 2402 MHz Horizontal xz 2402 MHz Vertical yz 2402 MHz Horizontal yz 0-16.98-13.31-16.98-13.72-16.98-18.46 5-16.58-14.84-16.58-9.67-16.58-18.95 10-17.65-15.08-17.65-7.46-17.65-20.70 15-20.38-16.31-20.38-6.75-20.38-21.20 20-24.11-18.48-24.11-6.98-24.11-22.49 25-23.50-19.43-23.50-8.70-23.50-23.49 30-20.90-19.70-20.90-11.23-20.90-25.54 35-18.65-20.23-18.65-16.16-18.65-27.15 40-17.00-19.30-17.00-22.57-17.00-27.17 45-17.00-15.09-17.00-18.94-17.00-26.70 50-17.63-11.61-17.63-13.56-17.63-24.49 55-18.59-9.28-18.59-11.38-18.59-20.49 60-20.52-8.08-20.52-9.89-20.52-17.22 110-12.90-10.31-12.90-6.56-12.90-6.79 115-12.57-11.45-12.57-5.70-12.57-6.80 120-11.89-12.32-11.89-4.43-11.89-7.03 125-10.72-11.01-10.72-3.24-10.72-7.73 130-9.70-8.16-9.70-2.44-9.70-8.84 135-8.15-6.13-8.15-1.77-8.15-9.52 140-6.70-4.26-6.70-1.43-6.70-9.53 145-5.46-3.29-5.46-1.47-5.46-8.69 150-4.17-2.87-4.17-2.12-4.17-7.74 155-3.22-2.80-3.22-3.15-3.22-6.82 160-2.30-2.67-2.30-4.78-2.30-5.98 165-1.83-3.28-1.83-6.87-1.83-5.64 170-1.62-3.80-1.62-9.65-1.62-5.13 175-1.62-4.56-1.62-12.66-1.62-4.95 180-1.87-5.47-1.87-14.37-1.87-4.95 185-1.98-6.25-1.98-14.45-1.98-5.23 190-2.08-6.37-2.08-11.76-2.08-5.58 195-1.97-5.75-1.97-9.08-1.97-6.01 200-1.77-5.16-1.77-6.58-1.77-6.89 205-1.63-4.85-1.63-4.98-1.63-7.36 210-1.55-4.31-1.55-3.86-1.55-8.28 215-1.61-4.26-1.61-3.21-1.61-9.45 220-1.79-4.67-1.79-2.96-1.79-9.88 225-1.96-5.81-1.96-3.10-1.96-10.12 230-2.21-8.08-2.21-3.66-2.21-10.17 235-2.55-11.81-2.55-4.57-2.55-10.32 240-2.77-17.91-2.77-5.71-2.77-10.11 245-3.08-17.01-3.08-7.43-3.08-9.46 250-3.27-11.86-3.27-10.04-3.27-8.90 255-3.37-8.81-3.37-12.69-3.37-8.90 260-3.48-8.40-3.48-16.03-3.48-9.08 265-3.55-9.41-3.55-17.03-3.55-9.20 270-3.82-10.50-3.82-14.79-3.82-9.79 275-4.13-10.43-4.13-11.80-4.13-10.28 280-4.61-8.33-4.61-10.23-4.61-11.03 285-5.25-5.22-5.25-9.38-5.25-11.63 290-6.22-3.60-6.22-9.05-6.22-12.06 295-7.88-2.95-7.88-9.74-7.88-12.47 300-9.78-3.17-9.78-12.41-9.78-13.07 350-19.20-11.25-19.20-10.34-19.20-17.38 355-18.54-12.27-18.54-14.35-18.54-18.27 360-17.21-13.20-17.21-14.13-17.21-18.52 m6 antenna gain -40 -30 -20 -10 0 10 0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 115 120 125 130 135 140 145 150 155 160 165 170 175 180185 190 195 200 205 210 215 220 225 230 235 240 245 250 255 260 265 270 275 280 285 290 295 300 305 310 315 320 325 330 335 340 345 350 355 360 2402 MHz Vertical xy 2402 MHz Horizontal x 2402 MHz Vertical xz 2402 MHz Horizontal x 2402 MHz Vertical yz 2402 MHz Horizontal y

TABLE OF CONTENTS 1 Test Report Summary 3 2 EUT Description 4 3 Test Methodology 5 4 Facilities and Accreditation 5 5 Calibration and Uncertainty 6 6 Setup of Equipment Under Test 8 7 Applicable Limits and Test Results 12 7.1 99% and 20 dB Bandwidth 12 7.2 Hopping Frequency Separation 15 7.3 Number of Hopping Channels 17 7.4 Average Time of Occupancy 18 7.5 Maximum Peak Output Power 20 7.6 Average Power 21 7.7 Peak Power Spectral Density 22 7.8 Conducted Spurious Emissions 25 7.9 Radiated Emissions 29 Apple Bluetooth Mouse Apple File No. 2063r1 EUT: Bluetooth Module FCC ID: BCGA1197 Page 2 of 45 1 Test Report Summary Apple Bluetooth Mouse Apple File No. 2063r1 EUT: Bluetooth Module FCC ID: BCGA1197 Page 3 of 45 SpecificationTest or RequirementResultComment N/A – For reporting purposes only 99% Bandwidth and 20 dB BandwidthN/ASection 7.1 CFR 15.247(a)(1)Hopping Frequency SeparationPassSection 7.2 CFR 15.247(a)(1)(iii)Number of Hopping ChannelsPassSection 7.3 CFR 15.247(b)(1)(iii)Average Time of OccupancyPassSection 7.4 CFR 15.247(b)(1) CFR 15.247(b)(4) Peak Output PowerPassSection 7.5 N/A – For reporting purposes only Average PowerN/ASection 7.6 CFR 15.247(d) CFR 15.247(f) Peak Power Spectral DensityPassSection 7.7 CFR 15.247(c)Conducted Spurious EmissionsN/ASection 7.8 CFR 15.205(a) CFR 15.209(a) Radiated EmissionsPassSection 7.9 CFR 15.207(a)AC Power Line Conducted EmissionsN/AN/A 2 EUT Description The Apple Bluetooth Mouse, model number A1197, operates in the 2.4 GHz unlicensed Industrial, Scientific and Medical band and uses Frequency Hopping Spread Spectrum. This device uses the CSR BC417143B BlueCore4 External which is a single chip radio and baseband IC for Bluetooth 2.4 GHz system. Technical Information on the Apple Bluetooth Mouse is provided in the table below. Apple Bluetooth Mouse Antenna Information Apple Bluetooth Mouse Apple File No. 2063r1 EUT: Bluetooth Module FCC ID: BCGA1197 Page 4 of 45 Apple Bluetooth Mouse Information ProductTransceiver Trade NameApple Bluetooth Mouse Model NumberA1197 Power Supply3.0V DC Power Supply Frequency Range2402-2480 MHz Transmit Power1 mWatt Modulation TechniqueFHSS Emission Designator894KF1D Antenna Model NumberMaximum Gain (dBi) m6_antenna-1.21 3 Test Methodology The tests documented in this report were performed in accordance with ANSI C63.4 and FCC CFR 47 Part 2 and Part 15. 4 Facilities and Accreditation 4.1 Facilities and Equipment The ac power line and RF conducted emissions measurements were performed at the Apple Computer, Inc. facility located at 20650 Valley Green Drive, Cupertino, California 95014. The radiated emissions measurements were performed at the Apple Computer, Inc. Evelyn 1, 10 meter semi-anechoic chamber located at 123 East Evelyn Ave., Mountain View, California 94041. Both of these facilities are constructed in conformance with the requirements of ANSI C63.4 and CISPR Publication 22. All Receiving equipment conforms to CISPR Publication 16-1, “Radio Interference Measuring Apparatus and Measurement Methods.” 4.2 Laboratory Accreditation The test facilities at Apple Computer, Inc. used to perform radiated and conducted emissions measurements are accredited by National Voluntary Laboratory Accreditation Program to perform Electromagnetic Interference tests according to FCC Part 15 and CISPR 22. Apple Computer, Inc. NVLAP Lab Code is 200071-0 and is effective through September 30, 2006. No part of this report may be used to claim or endorsement by NVLAP or any agency of the US Government. The Apple Computer, Inc. Evelyn 1 10 meter Semi-anechoic chamber is currently listed with the FCC. The FCC Registration Number is 90450 and is effective through Jan 5, 2007. Apple Bluetooth Mouse Apple File No. 2063r1 EUT: Bluetooth Module FCC ID: BCGA1197 Page 5 of 45 5 Calibration and Uncertainty 5.1 Measurement Instrument Calibration The measurement instruments utilized to perform the tests documented in this report have been calibrated in accordance with the manufacturer’s recommendations and are traceable to national standards. 5.2 Measurement Uncertainty The Apple measurement uncertainty policy, available upon request under Apple File Number EMC20, ensures uncertainty has been calculated using the proper procedure. Apple will use this measurement uncertainty knowledge in determining the pass / fail criteria from the test data. The measurement uncertainty has been determined to be the following: Conducted Emissions = +/- 2.3 dB Radiated Emissions = +/- 4.1 dB Apple Bluetooth Mouse Apple File No. 2063r1 EUT: Bluetooth Module FCC ID: BCGA1197 Page 6 of 45 5.3 Test Equipment The following test equipment was used. DescriptionManufacturerModel No.Identification No. Last Cal Next Cal Spectrum AnalyzerR&S ESIB 26100105Sept 2005Sept 2006 Spectrum AnalyzerAgilentE4446AAOU238719Aug 2005Aug 2006 AntennaSunol JB1A122302-1Sept 2005Sept 2006 AntennaSunol JB1A122302-2Sept 2005Sept 2006 AmplifierSanoma310253927April 2005April 2006 AmplifierSanoma310253928April 2005April 2006 AmplifierHP84493008A00713May 2005May 2006 Horn AntennaEMCO 311734197March 2004March 2009 Horn AntennaEMCO3160-09011269-0041264Sept 2001Sept 2006 Power MeterBoonton4532165201April 2006April 2007 Power Meter SensorBoonton573183890April 2006April 2007 Apple Bluetooth Mouse Apple File No. 2063r1 EUT: Bluetooth Module FCC ID: BCGA1197 Page 7 of 45 6 Setup of Equipment Under Test EUT Support Equipment Peripheral Support Equipment DescriptionManufacturerModelSerial NumberFCC ID Laptop ComputerAppleA1054PT342059DoC EUT I/O Cables None Apple Bluetooth Mouse Apple File No. 2063r1 EUT: Bluetooth Module FCC ID: BCGA1197 Page 8 of 45 EUT Operating Conditions All of the equipment and cables were placed in the worst-case configuration to maximize the emissions during the tests. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. The EUT was activated by using special test software which put the EUT into a continuous transmit mode…
