LIVE PREVIEW DRAFT APPLE CONFIDENTIAL - NEED TO KNOW Apple TV User Guide Important safety and handling information WARNING: Read all safety information below and operating instructions before using Apple TV to avoid injury. Failure to follow these safety instructions could result in fire, electric shock, or other injury or damage to Apple TV or other property. Safety To use Apple TV safely, read and keep all instructions and heed all warnings below. Power Apple TV has no on/off switch. To disconnect Apple TV from power, you must disconnect the power cord. Make sure the power cord is always easily accessible. Protect the power cord from being walked on or pinched, particularly at plugs and at the point where they exit from Apple TV. Unplug Apple TV during lightning storms or when unused for long periods of time. When connecting or disconnecting Apple TV, always hold the plug by its sides. Keep fingers away from the metal part of the plug. Location Do not use Apple TV outdoors. Apple TV is an indoor product. Do not install near any heat sources such as radiators, heat registers, stoves, or other devices (including amplifiers) that produce heat. Do not place naked flame sources, such as lighted candles, on or near Apple TV. Do not use Apple TV near water. Do not expose Apple TV to dripping or splashing, and do not place any object filled with liquid, such as a vase, on Apple TV. Do not move Apple TV if another device such as a TV, computer, or other electronic device is connected to it. WARNING: To reduce the risk of fire or electric shock, do not expose Apple TV to rain, liquid, moisture, excessive heat, or naked flame. Cleaning and care To clean Apple TV, unplug and power cord and all cables. Then use a soft, dry, lint-free cloth. Avoid getting moisture in openings. Don’t use window cleaners, household cleaners, aerosol sprays, solvents, alcohol, ammonia, or abrasives to clean Apple TV. Repairing Do not make make repairs yourself. Refer all servicing to qualified service personnel. Servicing is required when Apple TV has been damaged in any way, such as when the power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into Apple TV, or Apple TV has been exposed to rain or moisture, does not operate normally, or has been dropped. You can find more information about getting service at www.apple.com/support/appletv/service/faq. WARNING: Do not attempt to open Apple TV or disassemble it. You run the risk of electric shock and voiding the limited warranty. No user-serviceable parts are inside. Handling Your Apple TV may be damaged by improper storage or handling. Be careful not to drop Apple TV when transporting the device. Operating temperature Apple TV is designed to work best in ambient temperatures between 32° and 95° F (0° and 35° C) and be stored in temperatures between -4° and 113° F (-20° and 45° C). When you’re using Apple TV, it’s normal for the case to get warm. The Apple TV case functions as a cooling surface that transfers heat from inside the unit to the cooler air outside. Medical conditions If you have a medical condition that you believe could be affected by using Apple TV (for example, seizures, blackouts, eyestrain, or headaches), consult with your physician prior to using Apple TV. Accessories Only use attachments/accessories specified by the manufacturer. Device information Information such as model number, serial number, electrical rating, and other classifications is located on the bottom of Apple TV. You can also find the serial number in the Apple TV Settings menu. On Apple TV, choose Settings > General > About. Apple TV Support site Comprehensive support information is available online at www.apple.com/support/appletv. To contact Apple for personalized support (not available in all areas), see www.apple.com/support/contact. Restart Apple TV If Apple TV isn’t responding, try restarting it. VERIFY all below Restart Apple TV Do any of the following: Press and hold Menu and Down on the remote until the Apple TV status light blinks rapidly. Disconnect Apple TV from the power outlet, wait five seconds, then reconnect it. On Apple TV, choose Settings > General > Restart. Restore Apple TV If Apple TV still doesn’t respond after restarting, try restoring it. VERIFY all below Restore Apple TV Do the following: On Apple TV, choose Settings > General > Reset, and then select Restore. Restoring Apple TV can take some time, so be patient. If Apple TV still doesn’t respond, disconnect the power and HDMI cables from Apple TV. Connect one end of a USB-C cable (sold separately) to the back of Apple TV, and the other end to your computer. Open iTunes on your computer, select Apple TV in the Source list, and then click Restore. Update Apple TV software You’ll see a message on Apple TV when a software update is available. You can also check for updates, or set Apple TV to update automatically. Check for updates On Apple TV, choose Settings > General > Software Updates > Check for Update. If an update is available, a message will appear. Click Download and Install to start downloading. During the update process, do not disconnect your Apple TV. The status light may flash slowly during the update and restart process. Set automatic updates On Apple TV, choose Settings > General > Software Updates and choose Update Automatically. FCC compliance statement for Apple TV This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy an…

Text truncated - open the document above for the full version.

 Apple Inc. 1 Infinite Loop Cupertino, CA www.apple.com Date: May 07, 2015 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Rd. Columbia MD 21046 Attn: Equipment Authorization Branch Ref: FCC ID: BCGA1625, Model: A1625 To whom it may concern: I, the undersigned, hereby authorize UL Verification Services Inc. to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by UL Verification Services Inc. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing UL Verification Services Inc. as our representative, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized;  Apple Inc. 1 Infinite Loop Cupertino, CA www.apple.com e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely, ____________________ Abhishek Rala Apple Inc. Wireless Certification Manager [email protected]

 Apple Inc. 1 Infinite Loop Cupertino, CA v1.0 www.apple.com Federal Communications Commission Office of Engineering and Technology Laboratory Division 7435 Oakland Mills Rd. Columbia MD 21046 Subject: Request for Confidentiality FCC ID: BCGA1625, Model A1625 To whom it may concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), Apple Inc. hereby requests confidential treatment for documents filed with the Commission in connection with the application for equipment authorization referenced above. Permanent Confidentiality Apple Inc. requests that the Commission withholds the following documents from public viewing indefinitely: • Block Diagrams • Electrical Schematic Diagrams • Technical Description • Antenna Specifications, Antenna Locations • Software Security Description • MLB Layout These documents reveal detailed technical and design information that is protected by Apple Inc. as confidential and proprietary trade secrets. This information has been disclosed to those required to maintain its confidentiality, and is not customarily disclosed to the public even after commercial release of a device. As a result, disclosure of this information by the Commission would harm Apple Inc. by giving competitors an unfair advantage even after commercial release of the device.  Apple Inc. 1 Infinite Loop Cupertino, CA v1.0 www.apple.com Short Term Confidentiality In addition to the above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, Apple Inc. requests that the Commission withholds the following documents from public viewing for one hundred eighty days after the date the grant of equipment authorization is issued: • External Photographs • Internal Photographs • Test Setup Photographs • User Manual These documents reveal technical and design information that has not been publicly disclosed in marketing materials and is protected by Apple Inc. as confidential and proprietary trade secrets. This information has been disclosed to those required to maintain its confidentiality, and is not customarily disclosed publicly prior to the commercial release of the device. As a result, disclosure of this information by the Commission prior to commercial release would harm Apple Inc. by giving competitors an unfair market advantage. Apple Inc. believes the period of confidentiality requested is necessary to protect the information until the commercial release of a device. It is our understanding that measurement test reports and FCC ID label format cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Date: May 07, 2015 ____________________ Abhishek Rala Apple Inc. Wireless Certification Manager [email protected]

Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: February 25, 2015 Subject: Authorized Individual To Whom It May Concern: Pursuant to the provisions of KDB 852134 D01 Authorized Policy Form 731, I, grantee contact, hereby authorize Abhishek Rala to act on behalf of Apple Inc. for all matters relating to equipment authorization, including signing Form 731, attestations, and confidentiality request letters. This authorized individual may also assign another party to act as an authorized agent. This authorization is valid until further written notice from the grantee contact. Marc Douat Apple Inc. 1 Infinite Loop Cupertino, CA 95014

A1625 To p Apple Proprietary and Confidential A1625 Bottom Apple Proprietary and Confidential A1625 Front Apple Proprietary and Confidential A1625 Back - Ethernet, HDMI, Lighting USB, Power Socket Apple Proprietary and Confidential A1625 Left Apple Proprietary and Confidential A1625 Right Apple Proprietary and Confidential

Designed by Apple in California Assembled in China Model A1625 EMC 2907 100-240V~ 50-60Hz 1A CAN ICES-3 (B)/NMB-3(B) FCC ID: BCGA1625 IC: 579C-A1625 Serial PPYWWSSSEEER NOTICE OF PROPRIETARY PROPERTY. THE INFORMATION CONTAINED HEREIN IS THE PROPRIETARY PROPERTY OF APPLE INC. THE POSSESSOR AGREES TO THE FOLLOWING: (i) TO MAINTAIN THIS DOCUMENT IN CONFIDENCE, (ii) NOT TO REPRODUCE OR COPY IT (iii) NOT TO REVEAL OR PUBLISH IT IN WHOLE OR PART. A1625 - Label Location Apple proprietary and confidential

A1625 With bottom cover removed Apple Proprietary and Confidential A1625 PCB covering plate removed Apple Proprietary and Confidential A1625 PCB Back Apple Proprietary and Confidential A1625 PCB Front WiFi / BT Antenna 1 WiFi / BT Antenna 2 WiFi / BT Module Apple Proprietary and Confidential A1625 Power Supply - Front Apple Proprietary and Confidential A1625 Power Supply - Back Apple Proprietary and Confidential
