BEJ-ICAS3GPCar Navigation

VWAG Head Unit User Manual Model Name : ICAS3GP (2) Product Specifications ItemCategories Specifications Specification ProductNameICAS3GP ModelICAS3GP DimensionsRefer to image Weight 1.3 kg Power sourceDC12 V Operational temperature range -40 °C ~ 80 °C 1.Overview and Specifications (1) Overview 1) The Infotainment system provides infotainment in a car, using the latest technology. See your dealer to have the system or software updated and upgraded. 2)The radio can be easily used by registering up to 36 AM, FM or DAB with the PRESET button. 3) The Infotainment system can play the USB storage device or iPhone products. 4)The Bluetooth phone connection function allows for the use of wireless hands-free Phone calls, as well as a phone music player. In addition, the WiFifunction is provided. ICAS3GP Main Features Broadcast -Dual Tuner with TMC(RDS), DAB Media -USB Connectivity -Bluetooth ver5.2 EDR, Wifi(IEEE 80.211 a/b/g/n/ac) Car Play, Android Auto Ethernet network -OCU(Telematics) Audio -Internal AMP Navigation -Google Map In-Vehicle Network -CAN System CPUSamsung V7 RAMLPDDR4x 12GB StorageUFS V2.1 128GB OSAndroid 1.0 MICOMNXP SC668108CMJ2 Audio/RadioDSPNXP Mercury InterfaceInterfaceHUD, (Cluster) ICAS3GP (3) Dimension & Rear connector information Size : 188.8 x 195.7 x 57.8 (4) RF specifications ItemFrequency rangeUnit FM87.5 ~ 108.0MHz DAB174.928 ~ 239.200MHz Radio ItemSpecificationUnit Frequency2402 ~ 2480MHz Modulation TypeGFSK, π/4 DQPSK, 8 DPSK BT Power 2 (BT Class 2) dBm Data rate1 ~ 3Mbps Channel spacing1 ~ 2MHz BT versionVer5.2+EDR Bluetooth Wifi ItemSpecificationUnit StandardIEEE 802.11 a/b/g/n/ac Frequency 2.4G2412 ~ 2472MHz 5G 5170 ~ 5250 5735 ~ 5835 MHz Bandwidth20 / 40 / 80MHz Data rate 2.4G 802.11 b 20M1, 2, 5.5, 11Mbps 802.11 g 20M 6, 9, 12, 18, 24, 36, 48, 54Mbps 802.11 n 20M 6.5, 13, 19.5, 26, 39, 52, 58.5, 65Mbps 5G 802.11 a 20M 6, 9, 12, 18, 24, 36, 48, 54Mbps 802.11 n 20M 6.5, 13, 19.5, 26, 39, 52, 58.5, 65Mbps 802.11 n 40M 13.5, 27, 40.5, 54, 81, 108, 121.5, 135Mbps 802.11 ac 20M 6.5, 13, 19.5, 26, 39, 52, 58.5, 65, 78Mbps 802.11 ac 40M 13.5, 27, 40.5, 54, 81, 108, 121.5, 135, 162, 180 Mbps 802.11 ac 80M 29.3, 58.5, 87.8, 117, 175.5, 234, 263.3, 292.5, 351, 390 Mbps Modulation DSSS, CCK, OFDM(16-QAM,64-QAM, 256-QAM) ModeAP, Station ItemMax.RF PowerUnit Power Setting 2.4 GHz14 dBm 5 GHz14 * Only CE Certified Country Altitude during operation (m) ......................... : 5000 m or less m Altitude of test laboratory (m) ........................ : 5000 m or less m Altitude 1) Always operate the vehicle in a safe manner. Do not become distracted by the vehicle while driving and always be fully aware of all driving conditions. Do not change settings or any functions. Pull over in a safe and legal manner before attempting such operations. To promote safety, certain functions are disabled unless the parking brake is on. 2) To reduce the risk of electric shock, do not remove the cover or back of this product. There are no user-serviceable parts inside. Refer servicing to qualified service personnel. 3) To reduce the risk of fire or electric shock, do not expose this product to dripping or splashing water, rain, or moisture. 4) When driving your vehicle, be sure to keep the volume of the unit low enough to allow you to hear sounds coming from the outside. 5) Do not drop it and avoid heavy impacts at anytime. 6) The driver should not watch the monitor while driving. If the driver watches the monitor while driving, it may lead to carelessness and cause an accident. 2.Precautions SIMPLIFIED EU DECLARATION OF CONFORMITY Hereby, [LG Electronic Inc.] declares that IR12PT is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.lg.com/global/support/cedoc/cedoc# The antenna(s) must be installed such that a minimum separation distance of at least 20 cm is maintained between the radiator (antenna) and all persons at all times. This device must not be collocated or operating in conjunction with any other antenna or transmitter. Postal Address: 10, Magokjungang10-ro, Gangseo-gu, Seoul, 07796, Korea The use of the 5150 ~ 5350 MHz band is restricted to indoor use only. This restriction will be applied in all member states. FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is con-nected. • Consult the dealer or an experienced radio/TV technician for help. Caution Modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC Compliance Information : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. IMPORTANT NOTE: FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This eq…

Text truncated - open the document above for the full version.

Letter of Authorization Company : LG Electronics USA Address : 111 Sylvan Avenue, North Building, Englewood Cliffs, New Jersey, 07632, United States Product Name : Car Navigation Model Number : ICAS3GP FCC Identifier : BEJ-ICAS3GP We authorize MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the above named equipment. Any individual within MiCOM Labs is authorized to act on our behalf and take action on the application. We declare that MiCOM Labs Inc, 575 Boulder Court, Pleasanton, California 94566, USA, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Name: Sung Soo Kim Date: January 03, 2023 Title: Director, Regulatory and Environmental Affairs Signature of applicant:

LG Electronics USA Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: January 03, 2023 Subject; Request for Confidentiality FCC ID: BEJ-ICAS3GP To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Software Configuration Control Declaration Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Sung Soo Kim Title: Director, Regulatory and Environmental Affairs

Page 1 of 6 Page 2 of 6 Page 3 of 6 Page 4 of 6 Page 5 of 6 Page 6 of 6

Page 1 of 1 IDENTIFICATION LABEL: PROPOSED LABEL The shall be permanently affixed in the rear side of the equipment

Page 1 of 9 Page 2 of 9 Page 3 of 9 Page 4 of 9 Page 5 of 9 Page 6 of 9 Page 7 of 9 Page 8 of 9 PCB Antenna - Bluetooth - WLAN 5 GHz Antenna 1 Page 9 of 9 Chip Antenna - WLAN 2.4 GHz - WLAN 5 GHz Antenna 0

Page 1 of 13 Report No.: OT-22D-RWD-060 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) EMF TEST REPORT Test Report No. : OT-22D-RWD-060 Reception No. : 2204001280 Applicant : LG Electronics USA Address : 111 Sylvan Avenue, North Building, Englewood Cliffs, New Jersey, 07632, United States Manufacturer : LG Electronics Inc. Address : 222 LG-ro, Jinwi-Myeon, Pyeongtaek -Si, Gyeonggi-Do, 451-713, Korea Type of Equipment : Car Navigation FCC ID. : BEJ-ICAS3GP Model Name : ICAS3GP Multiple Model Name : N/A Serial number : N/A Total page of Report : 13 pages (including this page) Date of Incoming : November 28, 2022 Date of issue : December 29, 2022 SUMMARY The equipment complies with the regulation; FCC CFR 47 PART 1.1310 This test report only contains the result of a single test of the sample supplied for the examination. It is not a generally valid assessment of the features of the respective products of the mass-production. This report is not correlated with the "KS Q ISO/IEC 17025 and KOLAS accreditation" of Korean Laboratory Accreditation Scheme. Tested by Su-Min, You / Assistant Manager ONETECH Corp. Reviewed by Tae-Ho, Kim / General Manager ONETECH Corp. Approved by Ki-Hong, Nam / General Manager ONETECH Corp. Page 2 of 13 Report No.: OT-22D-RWD-060 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) CONTENTS Page 1. VERIFICATION OF COMPLIANCE ............................................................................................................................. 4 2. GENERAL INFORMATION ............................................................................................................................................ 5 2.1 Product Description ...................................................................................................................................................... 5 2.2 Alternative type(s)/model(s); also covered by this test report. .................................................................................. 7 3. EUT MODIFICATIONS .................................................................................................................................................... 7 4. MAXIMUM PERMISSIBLE EXPOSURE ...................................................................................................................... 8 4.1 RF Exposure Calculation ............................................................................................................................................. 8 4.2 EUT Description ........................................................................................................................................................... 8 4.3 Calculated MPE Safe Distance for WLAN ................................................................................................................. 9 4.3.1 DATA for Antenna 0 ............................................................................................................................................... 9 4.3.2 DATA for Antenna 1 ............................................................................................................................................. 10 4.3.3 DATA for Multiple Transmit ................................................................................................................................ 11 4.4 Calculated MPE Safe Distance for Bluetooth .......................................................................................................... 12 4.5 DATA for Intermodulation Transmit ....................................................................................................................... 13 Page 3 of 13 Report No.: OT-22D-RWD-060 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) Revision History Rev. No. Issue Report No. Issued Date Revisions Section Affected 0 OT-22D-RWD-060 December 29, 2022 Initial Release All Page 4 of 13 Report No.: OT-22D-RWD-060 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) 1. VERIFICATION OF COMPLIANCE Applicant : LG Electronics USA Address : 111 Sylvan Avenue, North Building, Englewood Cliffs, New Jersey, 07632, United States Contact Person : Sung Soo, Kim / Director, Regulatory and Environmental Affairs Telephone No. : +201-266-2215 FCC ID : BEJ-ICAS3GP Model Name : ICAS3GP Brand Name : LG, Volkswagen, Seat, Skoda, Ford Serial Number : N/A Date : December 29, 2022 EQUIPMENT CLASS DSS – PART 15 SPREAD SPECTRUM TRANSMITTER E.U.T. DESCRIPTION Car Navigation THIS REPORT CONCERNS Original Grant MEASUREMENT PROCEDURES ANSI C63.10: 2013 TYPE OF EQUIPMENT TESTED Pre-Production KIND OF EQUIPMENT AUTHORIZATION REQUESTED Certification EQUIPMENT WILL BE OPERATED UNDER FCC RULES PART(S) FCC PART 15 SUBPART C Section 15.247 KDB 558074 D01 15.247 Meas Guidance v05r02 Modifications on the Equipment to Achieve Compliance None Final Test was Conducted On 3 m, Semi Anechoic Chamber -. The above equipment was tested by ONETECH Corp. for compliance with the requirement set forth in the FCC Rules and Regulations. This said equipment in the configuration described in this report, shows the maximum emission levels emanating from equipment are within the compliance requirements. Page 5 of 13 Report No.: OT-22D-RWD-060 It should not be reproduced except…

Text truncated - open the document above for the full version.

Appendix Data 1. MINIMUM 6 DB BANDWIDTH ............................................................................................................. 2 2. MAXIMUM CONDUCTED(AVERAGE) OUTPUT POWER ............................................................. 9 3. 100 KHZ BANDWIDTH OUTSIDE THE FREQUENCY BAND ...................................................... 16 4. PEAK POWER SPECTRAL DENSITY ............................................................................................... 32 5. 99% OCCUPIED BANDWIDTH .......................................................................................................... 39 6. DUTY CYCLE ......................................................................................................................................... 46 Test ItemNo.ModeChannelBandwitdhRU ToneRB indexVerdict 1802.11 b241220 MHz--Pass 2802.11 b243720 MHz--Pass 3802.11 b246220 MHz--Pass 4802.11 g241220 MHz--Pass 5802.11 g243720 MHz--Pass 6802.11 g246220 MHz--Pass 7802.11 n20241220 MHz--Pass 8802.11 n20243720 MHz--Pass 9802.11 n20246220 MHz--Pass 6dB Bandwidth Test BandWLAN_2.4GHz AntennaAnt 0 Test Parameters for Channel Bandwidths 1 2 6dB Bandwidth 6dB Bandwidth 3 6dB Bandwidth 4 5 6dB Bandwidth 6dB Bandwidth 6 6dB Bandwidth 7 8 6dB Bandwidth 6dB Bandwidth 9 6dB Bandwidth Test ItemNo.ModeChannelBandwitdhRU ToneRB indexVerdict 1802.11 b241220 MHz--Pass 2802.11 b243720 MHz--Pass 3802.11 b246220 MHz--Pass 4802.11 g241220 MHz--Pass 5802.11 g243720 MHz--Pass 6802.11 g246220 MHz--Pass 7802.11 n20241220 MHz--Pass 8802.11 n20243720 MHz--Pass 9802.11 n20246220 MHz--Pass Output Power Test BandWLAN_2.4GHz AntennaAnt 0 Test Parameters for Channel Bandwidths 1 2 Output Power Output Power 3 Output Power 4 5 Output Power Output Power 6 Output Power 7 8 Output Power Output Power 9 Output Power Test ItemNo.ModeChannelBandwitdhRU ToneRB indexVerdict 1802.11 b241220 MHz--Pass 2802.11 b243720 MHz--Pass 3802.11 b246220 MHz--Pass 4802.11 g241220 MHz--Pass 5802.11 g243720 MHz--Pass 6802.11 g246220 MHz--Pass 7802.11 n20241220 MHz--Pass 8802.11 n20243720 MHz--Pass 9802.11 n20246220 MHz--Pass 100 kHz Bandwidth Test BandWLAN_2.4GHz AntennaAnt 0 Test Parameters for Channel Bandwidths 1 1.1 100 kHz Bandwidth 100 kHz Bandwidth 1.2 2 100 kHz Bandwidth 100 kHz Bandwidth 2.1 2.2 100 kHz Bandwidth 100 kHz Bandwidth 3 3.1 100 kHz Bandwidth 100 kHz Bandwidth 3.2 100 kHz Bandwidth 4 4.1 100 kHz Bandwidth 100 kHz Bandwidth 4.2 5 100 kHz Bandwidth 100 kHz Bandwidth 5.1 5.2 100 kHz Bandwidth 100 kHz Bandwidth 6 6.1 100 kHz Bandwidth 100 kHz Bandwidth 6.2 100 kHz Bandwidth 7 7.1 100 kHz Bandwidth 100 kHz Bandwidth 7.2 8 100 kHz Bandwidth 100 kHz Bandwidth 8.1 8.2 100 kHz Bandwidth 100 kHz Bandwidth 9 9.1 100 kHz Bandwidth 100 kHz Bandwidth 9.2 100 kHz Bandwidth Test ItemNo.ModeChannelBandwitdhRU ToneRB indexVerdict 1802.11 b241220 MHz--Pass 2802.11 b243720 MHz--Pass 3802.11 b246220 MHz--Pass 4802.11 g241220 MHz--Pass 5802.11 g243720 MHz--Pass 6802.11 g246220 MHz--Pass 7802.11 n20241220 MHz--Pass 8802.11 n20243720 MHz--Pass 9802.11 n20246220 MHz--Pass Power Spectral Density Test BandWLAN_2.4GHz AntennaAnt 0 Test Parameters for Channel Bandwidths 1 2 Power Spectral Density Power Spectral Density 3 Power Spectral Density 4 5 Power Spectral Density Power Spectral Density 6 Power Spectral Density 7 8 Power Spectral Density Power Spectral Density 9 Power Spectral Density Test ItemNo.ModeChannelBandwitdhRU ToneRB indexVerdict 1802.11 b241220 MHz--Pass 2802.11 b243720 MHz--Pass 3802.11 b246220 MHz--Pass 4802.11 g241220 MHz--Pass 5802.11 g243720 MHz--Pass 6802.11 g246220 MHz--Pass 7802.11 n20241220 MHz--Pass 8802.11 n20243720 MHz--Pass 9802.11 n20246220 MHz--Pass 99% Occupied Bandwidth Test BandWLAN_2.4GHz AntennaAnt 0 Test Parameters for Channel Bandwidths 1 2 99% Occupied Bandwidth 99% Occupied Bandwidth 3 99% Occupied Bandwidth 4 5 99% Occupied Bandwidth 99% Occupied Bandwidth 6 99% Occupied Bandwidth 7 8 99% Occupied Bandwidth 99% Occupied Bandwidth 9 99% Occupied Bandwidth Test ItemNo.ModeRateBandwitdhRU ToneRB indexVerdict 1802.11 b120 MHz--Pass 2802.11 b220 MHz--Pass 3802.11 b5.520 MHz--Pass 4802.11 b1120 MHz--Pass 5802.11 g620 MHz--Pass 6802.11 g920 MHz--Pass 7802.11 g1220 MHz--Pass 8802.11 g1820 MHz--Pass 9802.11 g2420 MHz--Pass 10802.11 g3620 MHz--Pass 11802.11 g4820 MHz--Pass 12802.11 g5420 MHz--Pass 13802.11 n20MCS020 MHz--Pass 14802.11 n20MCS120 MHz--Pass 15802.11 n20MCS220 MHz--Pass 16802.11 n20MCS320 MHz--Pass 17802.11 n20MCS420 MHz--Pass 18802.11 n20MCS520 MHz--Pass 19802.11 n20MCS620 MHz--Pass 20802.11 n20MCS720 MHz--Pass Duty Cycle Test BandWLAN_2.4GHz AntennaAnt 0 Test Parameters for Channel Bandwidths 1 2 Duty Cycle Duty Cycle 3 4 Duty Cycle Duty Cycle 5 6 Duty Cycle Duty Cycle 7 8 Duty Cycle Duty Cycle

Page 1 of 32 Report No.: OT-22D-RWD-058 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) RADIO PERFORMANCE TEST REPORT Test Report No. : OT-22D-RWD-058 Reception No. : 2204001280 Applicant : LG Electronics USA Address : 111 Sylvan Avenue, North Building, Englewood Cliffs, New Jersey, 07632, United States Manufacturer : LG Electronics Inc. Address : 222 LG-ro, Jinwi-Myeon, Pyeongtaek -Si, Gyeonggi-Do, 451-713, Korea Type of Equipment : Car Navigation FCC ID. : BEJ-ICAS3GP Model Name : ICAS3GP Multiple Model Name : N/A Serial number : N/A Total page of Report : 32 pages (including this page) Date of Incoming : November 28, 2022 Date of issue : December 29, 2022 SUMMARY The equipment complies with the regulation; FCC PART 15 SUBPART C Section 15.247 This test report only contains the result of a single test of the sample supplied for the examination. It is not a generally valid assessment of the features of the respective products of the mass-production. This report is not correlated with the "KS Q ISO/IEC 17025 and KOLAS accreditation" of Korean Laboratory Accreditation Scheme. Tested by Su-Min, You / Assistant Manager ONETECH Corp. Reviewed by Tae-Ho, Kim / General Manager ONETECH Corp. Approved by Ki-Hong, Nam / General Manager ONETECH Corp. Page 2 of 32 Report No.: OT-22D-RWD-058 It should not be reproduced except in full, without the written approval of ONETECH Corp. OTC-TRF-RF-001(0) ONETECH Corp.: 43-14, Jinsaegol-gil, Chowol-eup, Gwangju-si, Gyeonggi-do, 12735, Korea (TEL: 82-31-799-9500, FAX: 82-31-799-9599) CONTENTS PAGE 1. VERIFICATION OF COMPLIANCE ............................................................................................................................. 5 2. TEST SUMMARY .............................................................................................................................................................. 6 2.1 TEST ITEMS AND RESULTS ............................................................................................................................................. 6 2.2 ADDITIONS, DEVIATIONS, EXCLUSIONS FROM STANDARDS ........................................................................................... 6 2.3 RELATED SUBMITTAL(S) / GRANT(S) ............................................................................................................................ 6 2.4 PURPOSE OF THE TEST ................................................................................................................................................... 6 2.5 TEST METHODOLOGY .................................................................................................................................................... 6 2.6 TEST FACILITY ............................................................................................................................................................... 6 3. GENERAL INFORMATION ............................................................................................................................................ 7 3.1 PRODUCT DESCRIPTION ................................................................................................................................................. 7 3.2 ALTERNATIVE TYPE(S)/MODEL(S); ALSO COVERED BY THIS TEST REPORT. ................................................................ 9 4. EUT MODIFICATIONS .................................................................................................................................................... 9 5. SYSTEM TEST CONFIGURATION ............................................................................................................................. 10 5.1 JUSTIFICATION ............................................................................................................................................................. 10 5.2 PERIPHERAL EQUIPMENT ............................................................................................................................................ 10 5.3 MODE OF OPERATION DURING THE TEST .................................................................................................................... 10 5.4 CONFIGURATION OF TEST SYSTEM ............................................................................................................................. 12 5.5 ANTENNA REQUIREMENT ............................................................................................................................................ 12 6. PRELIMINARY TEST .................................................................................................................................................... 12 6.1 AC POWER LINE CONDUCTED EMISSIONS TESTS ....................................................................................................... 12 6.2 GENERAL RADIATED EMISSIONS TESTS ..................................................................................................................... 12 7. MIMIMUM 6 DB BANDWIDTH ................................................................................................................................... 13 7.1 OPERATING ENVIRONMENT ......................................................................................................................................... 13 7.2 TEST SET-UP ................................................................................................................................................................. 13 7.3 TEST DATE ................................................................................................................................................................... 13 7.4 TEST DATA FOR 802.11B WLAN MODE .....................................................................…

Text truncated - open the document above for the full version.

Type Chip Antenna Application 2.4GHz / 5GHz Part No. AMAN1003030LG02 Revision 1.0 ICAS3GP Chip Antenna Application Wi-Fi (802.11 b/g/n/ac) Features Revision History Revision Data Description Author 1.0 2022.10.13 First release of document for datasheet Sangkyoo. Song Table of Contents 1. Operation performance 2. Measurement results 2.1 S-parameter 2.2 Gain, Efficiency 2.3 Radiation pattern 1. Operation performance No Item Performance 1 Impedance 50 Ω 2 VSWR @ Operating frequency (2400~2483.5MHz) (5150~5850MHz) Max. 1.68:1 Max. 3.62:1 3 Average Gain [dBi] 2450 MHz -0.16 5500 MHz -2.68 4 Efficiency Average [%] 2450 MHz 96.34 5500 MHz 54.00 5 Peak Gain [dBi] 2400 MHz 4.88 2450 MHz 4.71 2485 MHz 4.13 5150 MHz 3.36 5500 MHz 4.87 5850 MHz 4.53 6 Radiation pattern Omni-directional 2. Measurement results 2.1 S-parameter 2.2 Gain Efficiency Freq.[MHz] Eff.[%] Avg.[dBi] Peak[dBi] 2400 93.17 -0.31 4.88 2450 96.34 -0.16 4.71 2485 87.16 -0.60 4.13 5150 43.2 -3.65 3.36 5500 54.00 -2.68 4.87 5850 42.69 -3.70 4.53 2.3 Radiation pattern

Page 1 of 1 RADIATED EMISSION TEST
