BEJ-LW9880GCellular Modem

LTE / WCDMA /GSM Wireless Module Cellular modem_LW-9880G Product Manual This document has been submitted under terms of Non-Disclosure Agreement. By accepting deliver of this document, the recipient acknowledges and agrees that: i) the recipient will use this document only for the purpose for which it has been supplied; ii) the recipient will not disclose this information to anyone not covered by our mutual NDA; and iii) all the information contained herein will be treated as strictly confidential material." Revision History RevisionDateAuthorsDescription V1.0 11/30/23 Song Jin Young Initial Version Copyright© LG Electronics Inc Co., Ltd. All Right Reserved Table of Contents Table of Contents.................................................................................................................................... 3 1.Executive Summary ......................................................................................................................... 4 1.1. Device Introduction...................................................................................................................................................4 2.Electrical Specifications ................................................................................................................... 4 2.1. General Specifications ......................................................................................................................................... 4 2.2. HW Specifications ......................................................................................................................................................4 2.3. Environmental Specifications.................................................................................................................................6 3.Mechanical Specifications................................................................................................................ 6 3.1. Mechanical Appearance .......................................................................................................................................... 6 3.1.1. Mechanical Dimensions......................................................................................................... 7 4.Cellular modem_LW-9880G Interface ............................................................................................ 8 4.1 Application Note of Cellular modem_LW-9880G Interface ....................................................... 8 4.1.1 Power Supply.......................................................................................................................... 8 4.1.2 UART Signal ........................................................................................................................... 8 4.1.3 USB Interface ........................................................................................................................ 9 4.1.4 E-SIM Interface ..................................................................................................................... 9 5.Antenna Approved Source............................................................................................................. 10 5.1 Description......................................................................................................................................................................10 5.2 Electrical Properties................................................................................................................................................... 10 5.2.1 Specification ...........................................................................................................................10 5.2.2 Impedance` ............................................................................................................................ 10 5.2.2.1 Nominal Impedance.............................................................................................................. 10 5.2.2.2 Measuring Method ............................................................................................................... 10 5.2.2.3 Directive ness .................................................................................................................... 11 5.2.2.4 Gain( Free Space) ............................................................................................................. 11 5.2.2.5 Radiation Pattern (XY-Plane) ................................................................................................ 12 Copyright© LG Electronics Inc Co., Ltd. All Right Reserved 1. Executive Summary 1.1. Device Introduction Cellular modem_LW-9880G is a telecommunication (PLS63-W) modem module that supports LTE / WCDMA / GSM with up to 10.2Mbps download, and 5.2Mbps upload. 2. Electrical Specifications 2.1. General Specifications Main chipset Cinterion® Memory - Interface Type High-speed USB 2.0 UART serial interface Common Air interface FDD-LTE / TDD-LTE / WCDMA / GSM Frequency band (LTE & WCDMA & GSM) B2, 4, 5, 12, 13, 26, 66 / II, IV, V / 850, 1900 DC input operating voltage Typical Input 5V, DC Converter output 3.8V Maximum current @ +5VDC, Maximum TX Power (23dBm) Under 1 A Dimensions 33.0 x 29.0 x 2.5mm Operating temperature(board temperature) Normal operation: -30°C to +75°C Extended operation: -40°C to +85°C Table 2-1 General Specifications 2.2. HW Specifications ITEMSPECIFICATION LTE Standard 3GPP Release 9 UE Category LTE Cat 1 LTE Support LTE : 2, 4, 5, 12, 13, 26, 66 - FDD Copyright© LG Electronics Inc Co., Ltd. All Right Reserved Duplex Mode HD-FDD / TDD RF Paths 2 x Rx / 1 x Tx Reference Sensitivity 3GPP Spec all meet Maximum Tx Power 22.5dBm +3.2 / -2.2dBm @Antenna Port Transmit Data Rate Downlink : 10.2Mbps, Uplink : 5.2Mbps ITEMSPECIFICATION WCDMA Standard 3GPP Release 7 UE Category WCDMA WCDMA Support Band 2, 4, 5 Duplex Mode HD-FDD RF Paths 2 x Rx / 1 x Tx Reference Sensitivity 3GPP Spec all eet Maximum Tx Power 24dBm…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name LG Electronics USA, Inc. Address 111 Sylvan Ave, North Building, Englewood Cliffs, NJ 07632 United States Grantee Code BEJ FCC ID BEJ-LW9880G Authorized Contact Name David Kim Contact Email David,[email protected] Contact Phone +1-201-470-2696 I, the unders igned, certify that I am an authorized signatory for the Applicant and therefore declare; a)in accordance w ith 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b)in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c)if the Applic ant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d)in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept t hat they are the responsible party and agree to abide by t heir responsibilities as specified under 47 CFR 2.909 and KDB394321. e)in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f)neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g)the Applicant has r ead, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List LG Electronics USA, Inc. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. LG Electronics USA, Inc. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date: Dec 11, 2023 Print Name: David Kim Title: Director, Regulatory and Environmental Affairs *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

UNITED STATES DESIGNATE D AGENT LETTER Date: 2023-12-11 TO: Federal Communicat ion Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Applicant Company Name: LG Electronics USA, Inc. U.S. designated agent Company Name: LG Electronics USA, Inc. Grantee Code: BEJ FRN: Contact Name: David Kim Contact Name: Address: 111 Sylvan Ave, North Building, Englewood Cliffs, NJ Address: 0023476120 David Kim 111 Sylvan Ave, North Building, Englewood Cliffs, NJ City/Province/Zip: Englewood Cliffs/New Jersey/07632 City/Province/Zip: Englewood Cliffs/New Jersey/07632 Telephone: 201-470-2696 Telephone: 201-470-2696 Fax: Fax: Email: 201-816-2031 [email protected] Email: 201-816-2031 [email protected] Applicable Equipment: FCC ID: < BEJ-LW9880G > ATTN: Director of Certification: We, < LG Electronics USA, Inc. > understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and e-mail of the designated agent listed above. We, < LG Electronics USA, Inc. > acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): David Kim Name (Printed): David Kim Title: Director, Regulatory and Environmental Affairs Title: Director, Regulatory and Environmental Affairs Signature: Signature:

Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 LETTER FOR AUTHORIZATION FCC ID: BEJ-LW9880G To whom it may concern: I, the undersigned, hereby authorize SGS Korea Co., Ltd. and hereafter referred to as SGS Korea, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by SGS Korea Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti‐Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing SGS Korea as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; Dec 11, 2023 LG Electronics USA, Inc. 111 Sylvan Avenue, North Building, Englewood Cliffs, New Jersey, United States, 07632 i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours David Kim Director, Regulatory & Environmental Affairs LG Electronics USA, Inc. LG Electronics USA, Inc. 111 Sylvan Avenue, North Building, Englewood Cliffs, New Jersey, United States, 07632

LG Electronics USA, Inc. 111 Sylvan Avenue, North Building, Englewood Cliffs, New Jersey, United States, 07632 Dec 11, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road, Columbia, MD 21046 REQUEST FOR CONFIDENTIALITY FCC ID: BEJ-LW9880G Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules (CFR 47), and Section 552 (b) (4) of the Freedom of Information Act, LG Electronics USA, Inc. hereby requests co nfidentiality and treatment of certain information accompanying this application. The materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. We are also hereby request Short-Term Confidentiality for 180 days after the grant as o utlined in Public Notice DA 04-1705. This provision will give LG Electronics USA, Inc. temporary confidentiality of commercially sensitive information prior to product release. The requested Permanent and Temporary Confidential exhibits are listed as follows: The Applicant understands that pursuant to Rule 0.457, disclosure of this application and all accompanying documentations, where applicable, will not be made public before the date of the Grant for this application. Sincerely Yours David Kim Dir ector, NA Regulatory & Environmental Affairs LG Electronics USA, Inc. CONFIDENTIAL LIST Short-Term 1 External Photos 2 Internal Photos 3 Test-Setup Photos 4 Operational Description Long-Term 5 Block Diagram 6 Schematics 7 User Manual

Cover Letter-Modular Approval Gentlemen: There’s a RF module that would like to have your authorization as a modular approval. The specific product as below, RF module with its designed features and specified description, meets special requirements for Single modular approval on FCC KDB996369 by cross- reference list below. Company LG Electronics USA, Inc. Model Name Cellular Modem Model Number LW-9880G FCC ID BEJ-LW9880G Requirement of FCC KDB996369 Comply（Y/N） 1.The modular transmitter must have its own RF shielding. Y The EUT provides the RF shielding. See EUT photo. 2.The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Y The EUT has its buffered modulation. Please see the Schematic Diagram. 3.The modular transmitter must have its own power supply regulation. Y The EUT has its own power supply regulation, please see the Schematic Diagram. 4.The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Y The EUT meets the FCC antenna requirements; unique antenna connector and photo of antenna are shown in External Photo . 5. The modular transmitter must be tested in a stand-alone configuration, i.e., the module must not be inside another device during testing. Y The EUT was tested with a test board, Please see test setup photo FCC ID : BEJ-LW9880G Date : Dec 11, 2023 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also d isplay a label referring to the enclosed module. This exterior label can use wording su ch as the following: “Contains Transmitter Module FCC ID: BEJ- LW9880G” or “Contains FC C ID: BEJ- LW9880G” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, o r, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions mu st be included in the application for equipment authorization. Y Please see exhibition label sample for the FCC ID of this module. And also in the exhibition Users manual, there are instructions give to the OEM on how to label the end product. 7.The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are give in the User Manual. 8.The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Y The EUT complies with RF exposure requirement. Thank you. Sincerely, By: ______________________ David Kim (Signature 1 ) (Print name) Title: Director, Regulatory and Environmental Affairs On behalf of: LG Electronics USA, Inc. (Company Name) Telephone: +1-201-470-2696

Model name: LW-9880G External photos of EUT Model name: LW-9880G Top view of EUT Bottom view of EUT WWAN Module WWAN Antenna Model name: LW-9880G Side view of EUT Model name: LW-9880G

LW-9880G <Bottom of EUT> FCC ID: BEJ-LW9880G Product name : Cellular Modem BRAND : LG Model name : LW-9880G LG P/N : XXXXXXXX Since the device is too small, statement will be placed in the user manual.

Model name: LW-9880G Internal photos of EUT Model name: LW-9880G Internal view of EUT Model name: LW-9880G Top view of Main PCB Bottom view of Main PCB Model name: LW-9880G View of Module View of Antenna WWAN Module WWAN Antenna

SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL004668 Page: 2 of 9 RTT7081-02(2020.10.05)(0) A4(210 mmx297 mm) INDEX Table of Contents Page 1. General Information -------------------------------------------------------------------------------- 3 2. RF Exposure Evaluation -------------------------------------------------------------------------- 6 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL004668 Page: 3 of 9 RTT7081-02(2020.10.05)(0) A4(210 mmx297 mm) 1. General Information 1.1. Testing Laboratory SGS Korea Co., Ltd. (Gunpo Laboratory) - 10-2, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 - Designation number: KR0150 All SGS services are rendered in accordance with the applicable SGS conditions of service available on request and accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx. Telephone : +82 31 688 0901 FAX : +82 31 688 0921 1.2. Details of Applicant Applicant : LG Electronics USA, Inc. Address : 111 Sylvan Avenue, North Building, Englewood Cliffs, New Jersey, United States, 07632 Contact Person : Kim, David Phone No. : +1 201 266 2215 1.3. Details of Manufacturer Company : LG Electronics Inc. Address : 170, Seongsanpaechong-ro, Seongan-gu, Changwon-si, Gyeongsangnam-do, Korea, 51533 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL004668 Page: 4 of 9 RTT7081-02(2020.10.05)(0) A4(210 mmx297 mm) 1.4. Description of EUT Kind of Product Cellular Modem Model Name LW-9880G Serial Number 001 Power Supply DC 5 V Rated Power WCDMA II, IV, V: 24 ㏈m GSM850: 33 ㏈m GSM1900: 30 ㏈m LTE Band 2, 4, 5, 12, 13, 26, 66: 22.5 ㏈m Frequency Range WCDMA II: 1 850 ㎒ ~ 1 910 ㎒ WCDMA IV: 1 710 ㎒ ~ 1 755 ㎒ WCDMA V: 824 ㎒ ~ 849 ㎒ GSM 850: 824 ㎒ ~ 849 ㎒ GSM 1900: 1 850 ㎒ ~ 1 910 ㎒ LTE Band 2: 1 850 ㎒ ~ 1 910 ㎒ LTE Band 4: 1 710 ㎒ ~ 1 755 ㎒ LTE Band 5: 824 ㎒ ~ 849 ㎒ LTE Band 12: 699 ㎒ ~ 716 ㎒ LTE Band 13: 777 ㎒ ~ 787 ㎒ LTE Band 26(Part 90): 814 ㎒ ~ 824 ㎒ LTE Band 26(Part 22): 824 ㎒ ~ 849 ㎒ LTE Band 66: 1 710 ㎒ ~ 1 780 ㎒ Modulation Technique QPSK, 16QAM, GMSK, 8PSK LTE Category Cat 1 Antenna Type Carrier press Type Antenna Gain ※ 699 ㎒ ~ 716 ㎒: 3.08 ㏈i 777 ㎒ ~ 787 ㎒: 1.08 ㏈i 814 ㎒ ~ 824 ㎒: 1.11 ㏈i 824 ㎒ ~ 849 ㎒: 1.11 ㏈i 1 710 ㎒ ~ 1 780 ㎒: 1.57 ㏈i 1 850 ㎒ ~ 1 910 ㎒: 1.97 ㏈i H/W Version Rev.1.0 S/W Version V.1.0 SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL004668 Page: 5 of 9 RTT7081-02(2020.10.05)(0) A4(210 mmx297 mm) 1.5. Summary of Test Results The EUT has been tested according to the following specifications: APPLIED STANDARD: FCC Part 1 Section Test Item(s) Result 1.1307(b)(3) RF Exposure Evaluation Complied 1.6. Test Report Revision Revision Report Number Date of Issue Description 0 F690501-RF-RTL004668 2023.12.07 Initial SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL004668 Page: 6 of 9 RTT7081-02(2020.10.05)(0) A4(210 mmx297 mm) 2. RF Exposure Evaluation Test exemptions apply for devices used in general population/uncontrolled exposure environments, according to the SAR-based, or MPE-based exemption thresholds. 2.1. Blanket 1 ㎽ Blanket Exemption The 1 ㎽ Blanket Exemption of § 1.1307(b)(3)(i)(A) applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power of no more than 1 ㎽, regardless of separation distance. The 1 ㎽ blanket exemption applies at separation distances less than 0.5 ㎝, including where there is no separation. This exemption shall not be used in conjunction with other exemption criteria other than those for multiple RF sources in paragraph § 1.1307(b)(3)(ii)(A). The 1 ㎽ exemption is independent of service type and covers the full range of 100 ㎑ to 100 ㎓, but it shall not be used in conjunction with other exemption criteria or in devices with higher-power transmitters operating in the same time-averaging period. Exposure from such higher-power transmitters would invalidate the underlying assumption that exposure from the lower-power transmitter is the only contributor to SAR in the relevant volume of tissue. SGS Korea Co., Ltd. 4, LS-ro 182beon-gil, Gunpo-si, Gyeonggi-do, Korea, 15807 Tel. +82 31 428 5700 / Fax. +82 31 427 2370 http://www.sgsgroup.kr Report Number: F690501-RF-RTL004668 Page: 7 of 9 RTT7081-02(2020.10.05)(0) A4(210 mmx297 mm) 2.2. MPE-based Exemption General frequency and separation-distance dependent MPE-based effective radiated power (ERP) thresholds are in Table B.1 [Table 1 of § 1.1307(b)(1)(i)(C)] to support an exemption from further evaluation from 300 ㎑ through 100 ㎓. Table 1: THRESHOLDS FOR SINGLE RF SOURCES SUBJECT TO ROUTINE ENVIRONMENTAL EVALUATION RF Source Frequency Minimum Distance Threshold ERP f L (㎒) f H (㎒) λ L / 2π λ H / 2π W 0.3 - 1.34 159 m - 35.6 m 1 920 R2 1.34 - 30 35.6 m - 1.6 m 3 450 R 2 /f 2 30 - 300 1.6 m - 159 mm 3.83 R 2 300 - 1 500 159 mm - 31.8 mm 0.012 8 R 2 f 1 500 - 100 000 31.8 mm - 0.5 mm 19.2 R 2 Subscripts L and H are low and high; λ is wavelength. From § 1.1307(b)(3)(i)(C), modified by adding Minimum Distance columns. The table applies to any RF source (i.e., single fixed, mobile, and portable transmitters) and specifies power and distance criteria for each of the five frequency ranges used for the MPE limits. These criteria apply at separation distances from any part of the radiating structure of at least λ/2π. The thresholds are based on the general population MPE limits with a single perfect re…
