BEJ32LC7DUKLCD TV/MONITOR

Please read this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service. LCDTV PLASMA TV OWNER’S MANUAL LCD TV MODELS 32LC7D 37LC7D 42LC7D PLASMA TV MODELS 42PC5D 50PC5D 60PC1D www.lgusa.com / www.lg.ca As an ENERGY STAR Partner LGE U. S. A.,Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. ENERGY STAR is a set of power-saving guidelines issued by the U.S. Environmental Protection Agency(EPA). LG's own special digital image generator, consisting of a full digital image processor, six different main picture quality factors. High-definition television. High-resolution digital television broadcast and playback system composed of roughly a million or more pixels, 16:9 aspect-ratio screens, and AC3 digital audio. A subset of digital television, HDTV formats include 1080i and 720p resolutions. With HDMI CEC support of LG’s audio/video device connected to the HDMI (high-definition multimedia interface), LG TV with this logo works easily with one remote control. Manufactured under license from Dolby Laboratories. “Dolby“and the double-D symbol are trademarks of Dolby Laboratories. is a trademark of SRS Labs, Inc. TruSurround XT technology is incorporated under license from SRS Labs, Inc. It has 2 HDMI ports that connect audio and video devices with one cable and produces the highest quality digital images and sound. 1 WARNING / CAUTION WARNING / CAUTION To prevent fire or shock hazards, do not expose this product to rain or moisture. FCC NOTICE Class B digital device This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized modification could void the user’s authority to operate this product The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the litera- ture accompanying the appliance. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. WARNING/CAUTION TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. NOTE TO CABLE/TV INSTALLER This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as practical. 2 IMPORTANT SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS Important safety instructions shall be provided with each apparatus. This information shall be given in a separate booklet or sheet, or be located before any operating instructions in an instruction for installation for use and supplied with the apparatus. This information shall be given in a language acceptable to the country where the apparatus is intended to be used. The important safety instructions shall be entitled “Important Safety Instructions”. The following safety instructions shall be included where applicable, and, when used, shall be verbatim as follows. Additional safety information may be included by adding statements after the end of the following safety instruction list. At the manufacturer’s option, a picture or drawing that illustrates the intent of a specific safety instruction may be placed immediately adjacent to that safety instruction: Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers)that produce heat. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong, The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. Protect the power cord from being walked on or pinched particularly a…

Text truncated - open the document above for the full version.

LG Electronics Inc. Date: Aug 27, 2007 Compliance Certification Services Certification Division 561F Monterey Road Morgan Hill, CA 95037 To whom it may concern: We, the undersigned, hereby authorize <ESTECH CO.,Ltd.>, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by <ESTECH CO., Ltd.> on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing <ESTECH CO.,Ltd.> as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Sang-Wook Lee/Manager Engineer Tel:82-54-470-4532 REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us.

642 Jinpyoung-dong, Kumi-city, Kyoungsangbuk-do, 730-727,Korea TEL : +82-54-470-5639 FAX : 82-54-470-4534 Federal Communications Commission Authorization and Evaluation Division FCC ID : BEJ32LC7DUK Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram Curcuit Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, Sang-Wook Lee/ Manager Engineer LG Electronics Inc. TEL : +82-54-470-5639 FAX : 82-54-470-4534

1. FRONT 2. REAR 3. PORT

INTERNAL PHOTO 1. MAIN 1.1 Front 1.2 Rear 2. Power 2.1 Front 2.2 Rear 3. LCD 3.1 Front 3.2 Rear 4. LED 4.1 Front 4.2 Rear 5. SWITCH 5.1 Front 5.2 Rear 6. DISPLAY 6.1 Front 6.2 Rear 7. AV 7.1 Front 7.2 Rear 8. TUNER

6.3 Test data Test Date : Lisn (dB) Cable (dB) Limit (dB㎶) Reading (dB㎶) Result (dB㎶) Limit (dB㎶) Reading (dB㎶) Result (dB) 0.160.170.0 H 65.41 51.23 51.44 55.41 47.55 47.76 0.170.160.0 H 64.86 39.58 39.78 54.86 33.99 34.19 0.200.150.0N 63.49 30.30 30.50 53.49 25.50 25.70 0.270.130.0N 61.15 34.37 34.55 51.15 34.14 34.32 0.370.130.1N 58.43 31.66 31.86 48.43 26.43 26.63 0.490.150.1N 56.15 36.61 36.85 46.15 33.76 34.00 0.600.150.1 H 56.00 31.13 31.39 46.00 28.37 28.63 0.620.150.1N 56.00 31.79 32.05 46.00 32.09 32.35 0.690.160.1N 56.00 29.90 30.17 46.00 20.07 20.34 1.030.250.2N 56.00 29.07 29.48 46.00 25.36 25.77 1.360.260.2N 56.00 30.57 31.03 46.00 27.37 27.83 3.370.330.4N 56.00 28.54 29.23 46.00 24.85 25.54 7.560.500.6N 60.00 34.20 35.31 50.00 31.07 32.18 7.880.520.6 H 60.00 32.85 33.99 50.00 25.50 26.64 8.320.540.7N 60.00 35.92 37.11 50.00 32.94 34.13 8.430.550.7 H 60.00 35.75 36.96 50.00 26.96 28.17 9.300.610.7 H 60.00 31.94 33.25 50.00 24.16 25.47 23.820.931.3 H 60.00 36.79 38.99 50.00 35.42 37.62 Remark 27-Aug-07 Frequency (MHz) Correction Factor Line (H/N) Quasi-peak Value H : Hot Line, N : Neutral Line *After connect with ferrite cores to RGB cable,tested conducted emission. Report Number : ESTF150708-020 , Web : www. estech. co. kr Page 12 of 15 Average Value 7. Photographs of test setup 7.1 Setup for Radiated Test : 30 ~ 1000 MHz [ Front ] [ Rear ] Report Number : ESTF150708-020 , Web : www. estech. co. kr Page 13 of 15 7.2 Setup for Conducted Test : 0.15 ~ 30 MHz [ Front ] [ Rear ] Report Number : ESTF150708-020 , Web : www. estech. co. kr Page 14 of 15 8. Photographs of EUT [ Front ] [ Rear ] Report Number : ESTF150708-020 , Web : www. estech. co. kr Page 15 of 15

TEST SETUP PHOTO 1. Conducted Emission setup photo 1.1. Front 1.2. Rear 2. Radiated Emission setup photo 2.1 Front 2.2. Rear
