BEJ37LG30UDLCD TV/MONITOR

Please read this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service. LCD TV PLASMA TV OWNER’S MANUAL LCD TV MODEL 26LG3037LG50 32LG3042LG50 37LG3047LG50 42LG3052LG50 32LG6032LG70 37LG6042LG70 42LG6047LG70 47LG6052LG70 52LG60 PLASMA TV MODELS 42PG1050PG60F 50PG1060PG60F 42PG2042PG20C 50PG2050PG20C P/NO : SAC30708020 (0711-REV00) www.lgusa.com / www.lg.ca / www.lgcommercial.com As an ENERGY STAR Partner LGE U. S. A.,Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. ENERGY STAR is a set of power-saving guidelines issued by the U.S. Environmental Protection Agency(EPA). 1 WARNING / CAUTION WARNING / CAUTION To prevent fire or shock hazards, do not expose this product to rain or moisture. FCC NOTICE Class B digital device This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized modification could void the user’s authority to operate this product The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the litera- ture accompanying the appliance. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. WARNING/CAUTION TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. NOTE TO CABLE/TV INSTALLER This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as practical. 2 IMPORTANT SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS Important safety instructions shall be provided with each apparatus. This information shall be given in a separate booklet or sheet, or be located before any operating instructions in an instruction for installation for use and supplied with the apparatus. This information shall be given in a language acceptable to the country where the apparatus is intended to be used. The important safety instructions shall be entitled “Important Safety Instructions”. The following safety instructions shall be included where applicable, and, when used, shall be verbatim as follows. Additional safety information may be included by adding statements after the end of the following safety instruction list. At the manufacturer’s option, a picture or drawing that illustrates the intent of a specific safety instruction may be placed immediately adjacent to that safety instruction: Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers)that produce heat. When mounting a TV it on the wall, make sure not to install TV by hanging power and signal cables on the back of the TV. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong, The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. Only use attachments/accessories specified by the manufacturer. Unplug this apparatus when unused for long periods of time. 1 2 3 4 5 6 7 8 9 3 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Never touch this apparatus or antenna during a thunder or lighting storm. Do not allow a impact shock or any objects to fall into the product, and do not drop onto the screen with s…

Text truncated - open the document above for the full version.

WATCHING TV / CHANNEL CONTROL 51 INPUT LIST Only these input signals which are connected to a TV can be activated and selected. Select the desired input source. 1 INPUT ■ You can also select the desired input source in the INPUT menu (Only 32/37/42/47/52LG50/60/70, 50/60PG60F). Input List AntennaCableAV1AV2Component1 HDMI4HDMI3HDMI2HDMI1RGB-PC Component2 AntennaCableAV1AV2Component1 Selected input source is linked. 2 ENTER ■ Antenna : Select it when watching the DTV/TV. ■ Cable : Select it when watching the CADTV/CATV. ■ AV 11-2 : Select it when watching the VCR or external equipment. ■ Component 11-2 : Select it when using the DVD or the Digital set-top box depend on connector. ■ RGB-PC : Select it when using PC depend on connector. ■ HDMI1-4 : Select it when using DVD, PC or Digital set-top box depend on con- nector. Enter Move Antenna Cable AV1 AV2 Component1 Component2 RGB-PC HDMI1 INPUT E Except 26/32/37/42/47/52LG30/50, 42/50PG10/20 WATCHING TV / CHANNEL CONTROL 52 INPUT LABEL WATCHING TV / CHANNEL CONTROL Sets a label to each input source which is not in use. Select OPTION . Select Input LLabel . Select the source. Enter Move OPTION Enter Move OPTION 1 MENU 3 2 ENTER ENTER Language: English Input Label SIMPLINK: On Key Lock: Off Caption: Off ISM Method Power Saving: Level 0 Set ID: 1 Language: English Input Label SIMPLINK: On Key Lock: Off Caption: Off ISM Method Power Saving: Level 0 Set ID: 1 AV1 AV2 Component1 Component2 RGB-PC HDMI1 HDMI2 HDMI3 HDMI4 FG Close Select the label. 4 ENTER EE 5 RETURN Return to the previous menu. MENU Return to TV viewing Only for 32/37/42/47/52LG60/70, 50/60PG60F WATCHING TV / CHANNEL CONTROL 53 AV MODE You can select the optimal images and sounds when connecting AV devices to external input. 1 AV MODE 2 OffCinema GameSport Press the AV MMODE button repeatedly to select the desired source. ENTER 3 RETURN Return to the previous menu. MENU Return to TV viewing ■ If you select Cinema Mode in AV mode, Cinema mode will be selected both for Picture and Sound Mode in PICTURE and AUDIO menu respectively. ■ If you select “Off ” in AV mode, the picture and image which you initially set will be selected. WATCHING TV / CHANNEL CONTROL 54 WATCHING TV / CHANNEL CONTROL This function operates only with devices with the logo. Please check the logo. This allows you to control and play other AV devices connected to the display through HDMI cable without additional cables and settings. If you require the SIMPLINK menu, select “ On ”. SIMPLINK function is not supported by HDMI IN 4 input source. Enter Move OPTION Select OPTION . Select SIMPLINK . Select On or Off . Enter Move OPTION E 1 MENU 3 2 ENTER ENTER Language: English Input Label SIMPLINK: On Key Lock: Off Caption: Off ISM Method Power Saving: Level 0 Set ID: 1 Language: English Input Label SIMPLINK: On Key Lock: Off Caption: Off ISM Method Power Saving: Level 0 Set ID: 1 Off On NOTE ! G Connect the HDMI/DVI IN or HDMI IN terminal of the TV to the rear terminal (HDMI terminal) of the SIM- PLINK device with the HDMI cable. G After connecting the HDMI terminal for the home theater with the SIMPLINK function using the above method, connect the DIGITAL AUDIO OUT terminal on the back of the TV to the DIGITAL AUDIO IN ter- minal on the back of the SIMPLINK device with the OPTICAL cable. G When you switch the Input source with the INPUT button on the remote control, you can stop the opera- tion of device controlled by SIMPLINK. G When you select or operate the media device with home theater function, the speaker automatically switch- es to home theater speaker (HT speaker). G When you execute ‘PHOTO LIST, MUSIC LIST’ function during DVD playback included in home theater sup- ported the SimpLink stops and the applicable function is executed after switching the input to TV. E 4 RETURN Return to the previous menu. MENU Return to TV viewing WATCHING TV / CHANNEL CONTROL 55 ■ Direct PPlay: After connecting AV devices to the TV, you can directly control the devices and play media with- out additional settings. ■ Select AAV ddevice: Enables you to select one of the AV devices connected to TV and play it. ■ Disc pplayback: Control connected AV devices by pressing the , ,,,,,, ENTER buttons and buttons for play, stop, pause, fast reverse, fast forward, chapter skip. ■ Power ooff aall ddevices: When you power off the TV, all connected devices are turned off. ■ Switch aaudio-out: Offers an easy way to switch audio-out. (A device, which is connected to the TV through a HDMI cable but does not support SimpLink, does not provide this function) Note: To operate SIMPLINK, the HDMI cable over 1.2 Version with *CEC function should be used. (*CEC: Consumer Electronics Control). SimpLink Menu TV vviewing : Switch to the previous TV channel regardless of the current mode. DISC pplayback : Select and play discs. When multiple discs are available, the titles of discs are conveniently displayed at the bottom of the screen. VCR pplayback : Control the connected VCR. HDD RRecordings pplayback : Control recordings stored in HDD. Audio OOut tto HHT sspeaker/Audio Out tto TTV : Select HT speaker or TV speaker for Audio Out. SimpLink Functions 1 2 3 4 5 G Selected Device G When no device is connected (displayed in gray) G When a device is connected (displayed in bright color) 1 2 3 4 5 Display SIMPLINK menu. Select the desired device. Control connected AV devices. 1 TV SIMPLINK 3 2 ENTER ENTER ENTRY MODES MEDIA HOST 56 USB When you connect a USB device, this screen is displayed, automatically. In USB device, you can not add a new folder or delete the existing folder. Precautions when using the USB device G Only a USB storage device is recognizable. G If the USB storage device is connected through a USB hub, the device is not recognizable. G A USB storage device using an automatic recogni- tion program may not be recognized. G A USB storage device which uses its own driver may not be recognized. G In case of a card reader, up to four memory cards …

Text truncated - open the document above for the full version.

LG Electronics USA Date:Mar 10,2008 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Jin-Mo Yang,Engineering Manager of ESTECH Co., Ltd. and hereafter referred to as ESTECH, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Jin-Mo Yang,Engineering Manager of ESTECH Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing ESTECH as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Mr.Daniel Kim,General Manager LG Electronics USA. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

1000 Sylvan Avenue Englewood Cliffs, NJ 07632 TEL : +847-941-8373 Federal Communications Commission Authorization and Evaluation Division FCC ID : BEJ37LG30UD Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, Mr.Daniel Kim,General Manager LG Electronics USA. TEL : +847-941-8373

BEJ37LG30UD

6.3 Test data Test Date : Lisn (dB) Cable (dB) Limit (dB㎶) Reading (dB㎶) Result (dB㎶) Limit (dB㎶) Reading (dB㎶) Result (dB) 0.150.150.8N 65.78 46.97 47.88 55.78 33.53 34.44 0.160.150.8 H 65.67 45.12 46.03 55.67 32.43 33.34 0.210.170.8 H 63.41 44.67 45.64 53.41 44.58 45.55 0.220.180.8 H 62.67 39.21 40.20 52.67 28.83 29.82 0.320.210.9 H 59.71 40.75 41.83 49.71 39.54 40.62 0.420.200.8 H 57.39 38.20 39.22 47.39 36.17 37.19 0.530.200.8 H 56.00 37.88 38.86 46.00 35.70 36.68 0.640.200.8 H 56.00 37.83 38.83 46.00 34.09 35.09 0.650.200.8 H 56.00 36.70 37.70 46.00 26.58 27.58 0.740.200.8 H 56.00 30.87 31.88 46.00 27.25 28.26 2.760.260.9 H 56.00 34.17 35.30 46.00 27.09 28.22 3.030.260.9 H 56.00 33.03 34.18 46.00 24.82 25.97 3.080.270.9N 56.00 36.11 37.26 46.00 26.11 27.26 3.190.270.9 H 56.00 31.82 32.98 46.00 14.66 15.82 Remark H : Hot Line, N : Neutral Line *After connect with ferrite cores to RGB cable,tested conducted emission. Report Number : ESTF150803-002 , Web : www. estech. co. kr Page 12 of 15 Average Value 7-Mar-08 Frequency (MHz) Correction Factor Line (H/N) Quasi-peak Value 7. Photographs of test setup 7.1 Setup for Radiated Test : 30 ~ 1000 MHz [ Front ] [ Rear ] Report Number : ESTF150803-002 , Web : www. estech. co. kr Page 13 of 15 7.2 Setup for Conducted Test : 0.15 ~ 30 MHz [ Front ] [ Rear ] Report Number : ESTF150803-002 , Web : www. estech. co. kr Page 14 of 15 8. Photographs of EUT [ Front ] [ Rear ] Report Number : ESTF150803-002 , Web : www. estech. co. kr Page 15 of 15 Appendix 1. Spectral diagram *HOT 150 kHz30 MHz 1 PK CLRWR 2 AV CLRWR SGL TDF 6DB dBμV dBμV RBW 9 kHz MT 1 s PREAMP OFFAtt 10 dB AUTO PRN 1 MHz10 MHz 0 10 20 30 40 50 60 70 80 90 LIMIT CHECK PASS EN55022A EN55022Q Comment: 37LG30-UD_HOT_ Date: 7.MAR.2008 19:26:06 *NEUTRAL 150 kHz30 MHz 1 PK CLRWR 2 AV CLRWR SGL TDF 6DB dBμV dBμV RBW 9 kHz MT 1 s PREAMP OFFAtt 10 dB AUTO PRN 1 MHz10 MHz 0 10 20 30 40 50 60 70 80 90 LIMIT CHECK PASS EN55022A EN55022Q Comment: 37LG30-UD_NEUTRAL Date: 7.MAR.2008 19:30:49
