BEJ37LG700HUALCD TV/MONITOR

Please r ead this manual carefully before operating your set. Retain it for future reference. Record model number and serial number of the set. See the label attached on the back cover and quote this information to your dealer when you require service. LCD TV OWNER’S MANUAL 32LG700H 37LG700H 42LG700H Inst aller Reference for Commercial Mode MPI/PPV Card Setup see page 19 Commercial Mode Setup see pages 87-104 P/NO : SAC30708043 (0810-REV00) www.lgcommercial.com This product qualifies for ENERGY STAR in the “factory default (Home mode)” setting and this is the setting in which power savings will be achieved. Changing the factory default picture setting or enabling other features will increase power consumption that could exceed the limits necessary to quality for Energy Star rating. 1 WARNING / CAUTION WARNING / CAUTION To prevent fire or shock hazards, do not expose this product to rain or moisture. FCC NOTICE Class B digital device This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CAUTION Do not attempt to modify this product in any way without written authorization from LG Electronics. Unauthorized modification could void the user’s authority to operate this product The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the litera- ture accompanying the appliance. TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER TO QUALIFIED SERVICE PERSONNEL. WARNING/CAUTION TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. NOTE TO CABLE/TV INSTALLER This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of the cable entry as practical. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers)that produce heat. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong, The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. Only use attachments/accessories specified by the manufacturer. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. Unplug this apparatus during lighting storms or when unused for long periods of time. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. 2 IMPORTANT SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS 1 2 3 4 5 7 8 6 9 10 3 Never touch this apparatus or antenna during a thunder or lighting storm. When mounting a TV on the wall, make sure not to install the TV by the hanging power and signal cables on the back of the TV. Do not allow an impact shock or any objects to fall into the product, and do not drop onto the screen with something. CAUTION concerning the Power Cord : It is recommend that appliances be placed upon a dedicated circuit; that is, a single outlet circuit which powers only that appliance and has no additional outlets or branch circuits. Check the specification page of this owner's manual to be certain. Do not connect too many appliances to the same AC power outlet as this could result in fire or elec- tric shock. Do not overload wall outlets. Overloaded wall out- lets, loose or damaged wall outlets, extension c…

Text truncated - open the document above for the full version.

PICTURE CONTROL 51 ADVANCED CONTROL - BLACK (DARKNESS) LEVEL Adjusting the contrast and the brightness of the screen using the black level of the screen. This feature is disable in DTV and RGB-PC mode. Select PPIICCTTUURREE . Select AAddvvaanncceedd CCoonnttrrooll . Select BBllaacckk LLeevveell . 1 MENU 3 2 ENTER ENTER Select LLooww or HHiigghh . 4  LLooww : The reflection of the screen gets darker.  HHiigghh : The reflection of the screen gets brighter.  AAuuttoo : Realizing the black level of the screen and set it to High or Low auto- matically. 5 RETURN Return to the previous menu. MENU Return to TV viewing. Enter Move PICTURE E RG • Contrast50 • Brightness50 • Sharpness50 • Color50 • Tint0 • Advanced Control • Reset Screen (RGB-PC) Enter Move PICTURE EE RG • Contrast50 • Brightness50 • Sharpness50 • Color50 • Tint0 • Advanced Control • Reset Screen (RGB-PC) Color Temperature Medium Fresh Contrast Off Fresh Color Off Noise Reduction Auto Gamma Medium Black Level FF Low GG Eye Care Off Close Film Mode Off PICTURE CONTROL 52 PICTURE CONTROL ADVANCED CONTROL - EYE CARE Dims extremely bright pictures. This feature is disabled in “ PPiiccttuurree MMooddee--VViivviidd , CCiinneemmaa ”. Enter Move PICTURE E RG • Contrast50 • Brightness50 • Sharpness50 • Color50 • Tint0 • Advanced Control • Reset Screen (RGB-PC) Enter Move PICTURE EE RG • Contrast50 • Brightness50 • Sharpness50 • Color50 • Tint0 • Advanced Control • Reset Screen (RGB-PC) Color Temperature Medium Fresh Contrast Off Fresh Color Off Noise Reduction Auto Gamma Medium Black Level Low Eye Care FF Off GG Close Film Mode Off Select PPIICCTTUURREE . Select AAddvvaanncceedd CCoonnttrrooll . Select EEyyee CCaarree . 1 MENU 3 2 ENTER ENTER Select OOnn or OOffff . 4 5 RETURN Return to the previous menu. MENU Return to TV viewing. PICTURE CONTROL 53 ADVANCED CONTROL - FILM MODE Set up the TV for the best picture appearance for viewing movies. When you operate Film Mode (3:2 Pull-Down Mode or Cinema Correction Mode), the TV will adjust 24 fps video from movies to 30 fps video for display. This feature operates only in TV (Analog TV, Digital DTV), AV1, AV2, Component 480i/1080i, and HDMI 480i, 1080i mode. Select PPIICCTTUURREE . Select AAddvvaanncceedd CCoonnttrrooll . Select FFiillmm MMooddee . 1 MENU 3 2 ENTER ENTER Select OOnn or OOffff . 4 5 RETURN Return to the previous menu. MENU Return to TV viewing. Enter Move PICTURE E RG • Contrast50 • Brightness50 • Sharpness50 • Color50 • Tint0 • Advanced Control • Reset Screen (RGB-PC) Enter Move PICTURE EE RG • Contrast50 • Brightness50 • Sharpness50 • Color50 • Tint0 • Advanced Control • Reset Screen (RGB-PC) Color Temperature Medium Fresh Contrast Off Fresh Color Off Noise Reduction Auto Gamma Medium Black Level Low Eye Care Off Close Film Mode FF Off GG PICTURE CONTROL 54 PICTURE CONTROL PICTURE RESET Settings of the selected picture modes return to the default factory settings. Select PPIICCTTUURREE . Select RReesseett . Initialize the adjusted value. 1 MENU 3 2 ENTER ENTER MENU Return to TV viewing. Enter Move PICTURE E RG • Contrast50 • Brightness50 • Sharpness50 • Color50 • Tint0 • Advanced Control • Reset Screen (RGB-PC) Enter Move PICTURE E RG • Contrast50 • Brightness50 • Sharpness50 • Color50 • Tint0 • Advanced Control • Reset Screen (RGB-PC) Resetting video configuration... ii SOUND & LANGUAGE CONTROL 55 SOUND & LANGUAGE CONTROL AUTO VOLUME LEVELER (AUTO VOLUME) Auto Volume makes sure that the volume level remains consistent whether you are watching a commercial or a regular TV program. Select AAUUDDIIOO . Select AAuuttoo VVoolluummee . Select OOnn or OOffff . 1 MENU 3 2 ENTER ENTER 4 RETURN Return to the previous menu. MENU Return to TV viewing. Enter Move AUDIO Auto Volume: Off Clear Voice: On Balance0 Sound Mode: Standard • SRS TruSurround XT:Off • Treble50 • Bass50 • Reset Enter Move AUDIO Auto Volume: Off Clear Voice: On Balance0 Sound Mode: Standard • SRS TruSurround XT:Off • Treble50 • Bass50 • Reset LR LR Off On E E SOUND & LANGUAGE CONTROL 56 SOUND &LANGUAGE CONTROL PRESET SOUND SETTINGS (SOUND MODE) Sound Mode lets you enjoy the best sound without any special adjustment as the TV sets the appropriate sound options based on the program content. SSttaannddaarrdd , MMuussiicc , CCiinneemmaa , SSppoorrtt , and GGaammee are preset for optimum sound quality at the factory and are not adjustable. SOUND &LANGUAGE CONTROL Select AAUUDDIIOO . Select SSoouunndd MMooddee . 1 MENU 2 ENTER Select SSttaannddaarrdd , MMuussiicc , CCiinneemmaa , SSppoorrtt , or GGaammee . 3 ENTER 4 RETURN Return to the previous menu. MENU Return to TV viewing. Enter Move AUDIO Auto Volume: Off Clear Voice: On Balance0 Sound Mode: Standard • SRS TruSurround XT:Off • Treble50 • Bass50 • Reset Enter Move AUDIO Auto Volume: Off Clear Voice: On Balance0 Sound Mode: Standard • SRS TruSurround XT:Off • Treble50 • Bass50 • Reset LR LR E E Standard Music Cinema Sport Game SOUND & LANGUAGE CONTROL 57 SOUND SETTING ADJUSTMENT - USER MODE Adjust the sound to suit your taste and room situations. Select AAUUDDIIOO . Select SSoouunndd MMooddee . Select TTrreebbllee or BBaassss . 1 MENU 4 2 ENTER Select SSttaannddaarrdd , MMuussiicc , CCiinneemmaa , SSppoorrtt , or GGaammee . 3 ENTER ENTER Make appropriate adjustments. 5 ENTER 6 RETURN Return to the previous menu. MENU Return to TV viewing. Enter Move AUDIO Auto Volume: Off Clear Voice: On Balance0 Sound Mode: Standard • SRS TruSurround XT:Off • Treble50 • Bass50 • Reset Enter Move AUDIO Auto Volume: Off Clear Voice: On Balance0 Sound Mode: Standard • SRS TruSurround XT:Off • Treble50 • Bass50 • Reset LR LR Close EE EE Treble50 Bass50 SRS TruSurround XT Off E E SOUND & LANGUAGE CONTROL 58 SOUND &LANGUAGE CONTROL Enter Move AUDIO LR SRS TRUSURROUND XT Select AAUUDDIIOO . Select SSRRSS TTrruuSSuurrrroouunndd XXTT . Select OOnn or OOffff . 1 MENU 3 2 ENTER ENTER 4 RETURN Return to the previous menu. MENU Return to TV viewing. Enter Move AUDIO Auto Volume: Off Clear Voice:…

Text truncated - open the document above for the full version.

1000 Sylvan Avenue Englewood Cliffs, NJ 07632 TEL : +847-941-8373 Federal Communications Commission Authorization and Evaluation Division FCC ID : BEJ37LG700HUA Confidentiality Request Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, the Applicant hereby requests confidential treatment of information accompanying this Application as outlined below: Schematics Block Diagram The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457, disclosure of this Application and all accompanying documentation will not be made before the data of the Grant for this application. Sincerely, Mr.Daniel Kim,General Manager LG Electronics USA. TEL : +847-941-8373

LG Electronics USA Date:Dec 3,2008 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Compliance Certification Services Certification Division 47173 Benicia Street Fremont, CA 94538, USA To whom it may concern: I, the undersigned, hereby authorize Jin-Mo Yang,Engineering Manager of ESTECH Co., Ltd. and hereafter referred to as ESTECH, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Jin-Mo Yang,Engineering Manager of ESTECH Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing ESTECH as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Mr.Daniel Kim,General Manager LG Electronics USA. REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

150 kHz30 MHz 1 PK CLRWR 2 AV CLRWR SGL TDF 6DB dBμV dBμV RBW 9 kHz MT 1 s PREAMP OFFAtt 10 dB AUTO PRN 1 MHz10 MHz 0 10 20 30 40 50 60 70 80 90 LIMIT CHECK PASS EN55022A EN55022Q Comment: 37LG700H-UA HOT Date: 28.NOV.2008 10:22:20 150 kHz30 MHz 1 PK CLRWR 2 AV CLRWR SGL TDF 6DB dBμV dBμV RBW 9 kHz MT 1 s PREAMP OFFAtt 10 dB AUTO PRN 1 MHz10 MHz 0 10 20 30 40 50 60 70 80 90 LIMIT CHECK PASS EN55022A EN55022Q Comment: 37LG700H-UA NEUTRAL Date: 28.NOV.2008 10:27:38
